ADJ ON-X User manual

8/15
User Instructions
ON-X
©2015 ADJ Products, LLC all rights reserved. Information,
specications, diagrams, images, and instructions herein are
subject to change without notice. ADJ Products, LLC logo and
identifying product names and numbers herein are trademarks
of ADJ Products, LLC. Copyright protection claimed includes all
forms and matters of copyrightable materials and information
now allowed by statutory or judicial law or hereinafter granted.
Product names used in this document may be trademarks or
registered trademarks of their respective companies and are
hereby acknowledged. All non-ADJ Products, LLC brands and
product names are trademarks or registered trademarks of their
respective companies.
ADJ Products, LLC and all aliated companies hereby dis-
claim any and all liabilities for property, equipment, building,
and electrical damages, injuries to any persons, and direct or
indirect economic loss associated with the use or reliance of
any information contained within this document, and/or as a
result of the improper, unsafe, unsucient and negligent as-
sembly, installation, rigging, and operation of this product.
Europe Energy Saving Notice
Energy Saving Matters (EuP 2009/125/EC)
Saving electric energy is a key to help protecting the enviroment.
Please turn o all electrical products when they are not in use. To
avoid power consumption in idle mode, disconnect all electrical
equipment from power when not in use. Thank you!

ADJ Products, LLC - www.adj.com - ON-X User Manual Page 3
• Multi-Colors
• 3 Operating Modes - Sound Active, Show Mode, and DMX Control
• 6 DMX Channel Modes (2 Channel Mode, 9 Channel Mode,
11 Channel Mode, 12 Channel Mode, 16 Channel Mode, & 18
Channel Mode)
• Stand Alone or Master-Slave Setup
• Internal Microphone
• Digital Display for Address and Function Setting
• Power Cord Daisy Chain (See page 20)
• UC IR Compatible (Not Included)
ON-X Features
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures
warranty. In the unlikely event your unit may require service please
contact ADJ Products, LLC.
ADJ Products, LLC will not accept any liability for any resulting dam-
ages caused by the non-observance of this manual or any unauthor-
ized modication to this unit.
ON-X Handling Precautions
ON-X Warranty Registration
The ON-X carries a 2 year (730 days) limited warranty. Please fill out
the enclosed warranty card to validate your purchase and warranty.
You may also register your product online at www. americandj.com.
All returned service items whether under warranty or not, must be
freight pre-paid and accompany a return authorization (R.A.) number.
If the unit is under warranty you must provide a copy of your proof of
purchase invoice. Please contact ADJ Products, LLC customer sup-
port for a R.A. number.
To optimize the performance of this product, please read these
operating instructions carefully to familiarize yourself with the basic
operations of this unit. These instructions contain important safety
information regarding the use and maintenance of this unit. Please
keep this manual with the unit, for future reference.
ON-X General Instructions
ADJ Products, LLC - www.adj.com - ON-X User Manual Page 2
ON-X General Information
Unpacking: Thank you for purchasing the ON-X by ADJ Products,
LLC. Every ON-X has been thoroughly tested and has been shipped
in perfect operating condition. Carefully check the shipping carton for
damage that may have occurred during shipping. If the carton appears
to be damaged, carefully inspect your xture for any damage and be
sure all equipment necessary to operate the unit has arrived intact. In
the event damage has been found or parts are missing, please contact
our toll free customer support number for further instructions. Please
do not return this unit to your dealer without contacting customer sup-
port rst.
Introduction: The ADJ ON-X creates exciting lighting effects with
it’s 8 quick sweeping beams and it’s dual 4-zone LEDs. The ON-X can
operate as a stand alone fixture or in a Master/Slave configuration. The
ON-X has three operating modes; sound active mode, show mode,
and DMX control. This fixture is suitable for theaters, studios, retail
stores, and other similar locations. For best results use fog or special
effects smoke to enhance the beams projections.
Customer Support: ADJ Products, LLC provides a toll free cus-
tomer support line, to provide help and to answer any question should
you encounter problems during your set up or initial operation. You
may also visit us on the web at www.adj.com for any comments or
suggestions. Service Hours are Monday through Friday 8:00 a.m. to
4:30 p.m. Pacic Standard Time.
Voice: [phone]
Fax: [phone]
E-mail: [e-mail]
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Warning! This may cause severe eye damage. Avoid looking directly
into the light source at all times!

For Your Own Personal Safety, Please Read and Understand This
Manual Completely Before You Attempt To Install Or Operate
This Unit!
• To reduce the risk of electrical shock or re, do not expose this unit
rain or moisture
• Do not spill water or other liquids into or on to your unit.
• Be sure that the local power outlet match that of the required volt-
age for your unit.
• Do not attempt to operate this unit if the power cord has been
frayed or broken.
• Do not attempt to remove or break o the ground prong from
the electrical cord. This prong is used to reduce the risk of electrical
shock and re in case of an internal short.
• Disconnect from main power before making any type of connection.
• Do not remove the cover under any conditions. There are no user
serviceable parts inside.
• Never operate this unit when it’s cover is removed.
• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.
• Do not attempt to operate this unit, if it becomes damaged.
• This unit is intended for indoor use only, use of this product out-
doors voids all warranties.
• Always mount this unit in safe and stable matter.
• Power-supply cords should be routed so that they are not likely to
be walked on or pinched by items placed upon or against them,
paying particular attention to cords at plugs, convenience recep-
tacles, and the point where they exit from the appliance.
• Cleaning -The fixture should be cleaned only as recommended by
the manufacturer. See page 28 for cleaning details.
• Heat -This fixture should be situated away from heat sources such
as radiators, heat registers, stoves, or other appliances (including
amplifiers) that produce heat.
• The fixture should be serviced by qualified service personnel when:
A. Objects have fallen, or liquid has been spilled into the appliance.
B. The appliance has been exposed to rain or water.
C. The appliance does not appear to operate normally or exhibits a
marked change in performance.
ON-X Safety Precautions
ADJ Products, LLC - www.adj.com - ON-X User Manual Page 4 ADJ Products, LLC - www.adj.com - ON-X User Manual Page 5
Power Supply: The ADJ ON-X contains a automatic voltage switch,
which will auto sense the voltage when it is plugged into the power
source. With this switch there is no need to worry about the correct
power voltage, this unit can be plugged in anywhere.
DMX-512: DMX is short for Digital Multiplex. This is a universal pro-
tocol used by most lighting and controller manufactures as a form of
communication between intelligent fixtures and controllers. A DMX
controller sends DMX data instructions from the controller to the fix-
ture. DMX data is sent as serial data that travels from fixture to fixture
via the DATA “IN” and DATA “OUT” XLR terminals located on all DMX
fixtures (most controllers only have a DATA “OUT” terminal).
DMX Linking: DMX is a language allowing all makes and models
of dierent manufactures to be linked together and operate from a
single controller, as long as all xtures and the controller are DMX
compliant. To ensure proper DMX data transmission, when using
several DMX fixtures try to use the shortest cable path possible. The
order in which fixtures are connected in a DMX line does not influence
the DMX addressing. For example; a fixture assigned a DMX address
of 1 may be placed anywhere in a DMX line, at the beginning, at the
end, or anywhere in the middle. Therefore, the first fixture controlled
by the controller could be the last fixture in the chain. When a fixture
is assigned a DMX address of 1, the DMX controller knows to send
DATA assigned to address 1 to that unit, no matter where it is located
in the DMX chain.
Data Cable (DMX Cable) Requirements (For DMX and Master/Slave
Operation): The ON-X can be controlled via DMX-512 protocol. The
ON-X has 5 DMX Channel Modes. The DMX address is set electroni-
cally using the controls on the front panel of the
unit. Your unit and your DMX controller require a
approved DMX-512 110 Ohm Data cable for data
input and data output (Figure 1). We recommend
Accu-Cable DMX cables. If you are making your
own cables, be sure to use standard 110-120 Ohm
shielded cable (This cable may be purchased at
almost all professional sound and lighting stores).
Your cables should be made with a male and
ON-X Set Up
Figure 1

ADJ Products, LLC - www.adj.com - ON-X User Manual Page 7
female XLR connector on either end of the cable. Also remember that
DMX cable must be daisy chained and cannot be split.
ON-X Set Up
Notice: Be sure to follow gures two and three when making your own
cables. Do not use the ground lug on the XLR connector. Do not con-
nect the cable’s shield conductor to the ground lug or allow the shield
conductor to come in contact with the XLR’s outer casing. Grounding
the shield could cause a short circuit and erratic behavior.
DMX512 IN
3-PIN XLR
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
DMX512
DMX+,DMX-,COMMON
1
2
3
Termination reduces signal errors and
avoids signal transmission problems
and interference. It is always advisable
to connect a DMX terminal, (Resistance
120 Ohm 1/4 W) between PIN 2 (DMX-)
and PIN 3 (DMX +) of the last fixture.
1
2
3
1
2
3
DMX +
DMX -
COMMON
DMX512 OT
3-PIN XLR
Figure 2
Figure 3
1 Ground 1 Ground
XLR Male Socket XLR Pin Conguration
3 Hot
2 Cold 2 Cold
3 Hot
XLR Female Socket
Pin 3 = Data True (positive)
Pin 2 = Data Compliment (negative)
Pin 1 = Ground
Special Note: Line Termination. When longer runs of cable are
used, you may need to use a terminator on the last unit to avoid erratic
behavior. A terminator is a 110-120 ohm 1/4 watt resistor which is con-
nected between pins 2 and 3 of a male XLR connector (DATA + and
DATA -). This unit is inserted in the female XLR connector of the last
unit in your daisy chain to terminate the line. Using a cable terminator
(ADJ part number Z-DMX/T) will decrease the possibilities of erratic
behavior.
DMX512 IN
3-PIN XLR
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
SOUND
REMOTE
CONTROL
INPUT
POWER
INPUT OUTPUT
DMX512
DMX+,DMX-,COMMON
1
2
3
Termination reduces signal errors and
avoids signal transmission problems
and interference. It is always advisable
to connect a DMX terminal, (Resistance
120 Ohm 1/4 W) between PIN 2 (DMX-)
and PIN 3 (DMX +) of the last fixture.
1
2
3
1
2
3
DMX +
DMX -
COMMON
DMX512 OT
3-PIN XLR
Figure 4
ADJ Products, LLC - www.adj.com - ON-X User Manual Page 6
5-Pin XLR DMX Connectors. Some manufactures use 5-pin DMX-
512 data cables for DATA transmission in place of 3-pin. 5-pin DMX
xtures may be implemented in a 3-pin DMX line. When inserting stan-
dard 5-pin data cables in to a 3-pin line a cable adaptor must be used,
these adaptors are readily available at most electric stores. The chart
below details a proper cable conversion.
Conductor 5-Pin XLR Male (In)3-Pin XLR Female (Out)
Pin 1
Pin 5 - Do Not Use
Pin 4 - Do Not Use
Pin 3
Pin 2
Pin 1
Pin 3
Pin 2
Not Used
Not Used
Data True (+ signal)
Data Compliment (- signal)
Ground/Shield
3-Pin XLR to 5-Pin XLR Conversion
ON-X Set Up

ADJ Products, LLC - www.adj.com - ON-X User Manual Page 9
ADJ Products, LLC - www.adj.com - ON-X User Manual Page 8
ON-X System Menu ON-X System Menu
System Menu: When making adjustments press ENTER to
conrm your setup then press and hold the MENU button
for at least 3 seconds. To exit without making any adjust-
ments press the MENU button. The display will lock after 30
seconds, press the MENU button for 3 seconds to unlock.
ADDR - DMX Address Setting.
1. Press the either the MENU, UP, or DOWN buttons until “ADDR” is
displayed, press ENTER.
2. The current address will now be displayed and ashing. Press the
UP or DOWN buttons to nd your desired address. Press ENTER to
set your desired DMX address.
CHND - This will let select your desired DMX channel
mode.
1. Press the MENU button until “CHND” is displayed, press ENTER.
The current DMX channel mode will be displayed
2. Press the UP or DOWN buttons to nd your desired DMX channel
mode and press ENTER to conm and exit.
SLND - This will let you set unit as a master or slave in a
master/slave conguration.
1. Press the MENU button until “SLND” is displayed, press ENTER.
Either “MAST”, “SL 1”, or “SL 2” will be displayed.
2. Press the UP or DOWN buttons until your desired setting is dis-
played, press ENTER to conm.
NOTE: In a Master/Slave conguration you can set one xture to
Master and then set the next xture to “SL 2”, the xtures will now
have contrast movement to each other.
SHND - Show modes 0-2 (Factory programs). Show
mode can run with or without sound active mode active.

ADJ Products, LLC - www.adj.com - ON-X User Manual Page 11
1. Press the MENU button until “SHND” is displayed, press ENTER.
2. “Sh X” will now be displayed, “X” representing a number between
0-2. Shows 1-2 are factory programs, while show “0” is random mode.
Use the UP or DOWN buttons to nd your desired show.
3. When you have found your desired show press ENTER, then press
and hold the MENU button for at least 3 seconds to activate. After
you have set your desired show, it can be changed at any time using
the UP or DOWN buttons.
SOUN - Sound Active mode.
1. Press the MENU button until “SOUN” is displayed, press ENTER.
2. The display will show either “ON” or “OFF”. Press the UP or
DOWN buttons to select “ON” to activate sound active mode, or
“OFF” to deactivate sound active mode.
3. Press ENTER to conrm.
SENS - In this mode you can adjust the sound sensitiv-
ity.
1. Press the MENU button until “SENS” is displayed, press ENTER.
2. A number between 0-100 will be displayed. Press the UP or DOWN
buttons to adjust the sound sensitivity. 0 being the least sensitive,
and 100 being the most sensitive.
3. When you have found your desired setting press ENTER to conrm.
DNST - This mode can be used as a precaution mode,
that in case the DMX signal is lost, interrupted, or power is
lost, the operating mode chosen in the setup is the running
mode the xture will go into when the DMX signal is lost. You
can also set this as the operating mode you would like the
unit to return to when power is applied.
1. Press the MENU button until “DNST” is displayed, and either
“MASL”, “BLND”, or “LAST” will be displayed beneath.
ON-X System Menu
ADJ Products, LLC - www.adj.com - ON-X User Manual Page 10
2. Press ENTER and the bottom choice will begin to ash. Use the UP
or DOWN buttons to choose an operating mode you would like the unit
to start up in when power is applied or the DMX signal is lost.
• LAST - If the DMX signal is lost the xture will stay in the last DMX
setting. If power is applied and this mode is set, the unit will automati-
cally go into the last DMX set up.
• MASL (Master Slave) - If the DMX signal is lost or power is applied,
the unit will automatically go into Master Slave mode and run a built-in
show.
• BLND (Blackout) - If the DMX signal is lost or interrupted, the unit will
automatically go into stand by mode.
3. Press ENTER to conrm your desired set up.
DIND - This will let select your desired dimmer curve.
1. Press the either the MENU button until “DIND” is displayed, press
ENTER. 1 of 5 dimmer curves will be displayed. “STDA” (standard),
“STGE” (stage), “TV” (TV), “ARAL” (theatrical), or “THAL” (Architec-
tural).
2. Press the UP or DOWN buttons to nd your desired dimmer curve
and press ENTER to conm and exit.
TILT - Tilt Inversion
1. Press the MENU button until “TILT” is displayed, press
ENTER. Either “Yes” or “No” will be displayed.
2. To activate the tilt inversion press the UP or DOWN buttons
until “Yes” is displayed, press ENTER to conm. To deactivate
tilt inversion, select “No” and press Enter.
LED - With this function you can have the LED display
turn off after 10 seconds.
1. Press the MENU button until “LED” is displayed, press ENTER.
2. The display will show either “ON” or “OFF”. Press the UP or
ON-X System Menu

ADJ Products, LLC - www.adj.com - ON-X User Manual Page 12 ADJ Products, LLC - www.adj.com - ON-X User Manual Page 13
DOWN buttons to select “ON” to keep the LED display on at all
times, or “OFF” to switch to have the LED display switch o after 10
seconds.
DISP - This function will reverse the display 180º.
1. Press the MENU button until “DISP” is displayed, press ENTER.
2. Press ENTER to “ip” the display. Press ENTER to “ip” it again.
Press ENTER when you have made your desired setup.
3. Press ENTER to conrm. To make you LED display reappear again
press any button.
TEST - This function will run a self test program.
1. Press the MENU button until “TEST” is displayed, press ENTER.
2. The xture will now run a self test.
FHRS - With this function you can display the running
time of the unit.
1. Press the MENU button until “FHRS” is displayed, press ENTER.
2. The running time of the xture will now be displayed. Press MENU
to exit.
VER - Use this function to display the Software version of
the unit.
1. Press the either the MENU button until “VER” is displayed, press
ENTER.
2. The display will show the software version.
RSET - This function will reset the unit.
1. Press the MENU button until “RSET” is displayed. Press the
ENTER button and the unit will reset itself.
ON-X System Menu ON-X Offset Submenu
To enter the Oset Menu, press the ENTER button for at least 3 sec-
onds. In this submenu you are able to adjust the home positions of
the tilt motor positions.
Tilt Offset - Adjustment of the tilt home position for
any of the 2 bars.
1. Press the ENTER button for at least 3 seconds, then press the UP
or DOWN buttons so that either “Til 1” or “Til 2” is displayed, and
press ENTER.
2. Use the UP and DOWN buttons to make your adjustments, and
then press ENTER to conrm. Press the MENU button for one second
to exit.

ADJ Products, LLC - www.adj.com - ON-X User Manual Page 15ADJ Products, LLC - www.adj.com - ON-X User Manual Page 14
Operating Modes: The ON-X can operate in three different modes.
In each mode you can run the fixture as a stand alone fixture or in a
master/slave confiugration. This next section will detail the differences
in the operating modes.
Universal DMX Control: This function allows you to use a univer-
sal DMX-512 controller to control the chases and patterns, dimmer
and strobe. A DMX controller allows you to create unique programs
tailored to your individual needs.
1. The ON-X has 6 DMX Channel modes; 2 Channels, 9 Channels,
11 Channels, 12 Channels 16 Channels, & 18 Channels. See
pages 17-26 for detailed description of the DMX values and traits.
2. To control your fixture in DMX mode, follow the set-up procedures
on pages 5-7 as well as the set-up specifications that are includ-
ed with your DMX controller.
3. Use the controller’s faders to control the various DMX fixture traits.
4. This will allow you to create your own programs.
5. Follow the instructions on page 9 to select your desired DMX
channel mode and to set the DMX address.
6. For longer cable runs (more than a 100 feet) use a terminator on
the last fixture.
7. For help operating in DMX mode consult the manual included
with your DMX controller.
Sound Active Mode: This mode allows either single unit or several
units linked together, to run to the beat of the music.
1. Press the MENU button until “SOUN” is displayed, and press
ENTER.
2. Press the UP or DOWN button so that “ON” is displayed. The unit
will now run to the beat of the music.
3. The sound sensitivity can be adjusted by pressing the MENU
button until “SENS” is displayed, and then press ENTER. Use the
UP or DOWN buttons to adjust the sound sensitivity, 1 being the
least sensitive, and 100 being the most sensitive.
Show Mode: In this mode you can choose 1 of 3 show modes to run.
1. Press the MENU button until “SHND” is displayed, and press
ENTER.
2. Press the UP or DOWN buttons until you nd your desired show,
ON-X Operation ON-X Operation
and press ENTER then press and hold MENU for 3 seconds to
con rm.
With this feature you can connect the xtures to one another
using the IEC input and output sockets. The quantity that can
be connected is 15 xtures maximum for 120V and 28 xtures
maximum for 240V. After the maximum xtures has been reached
you will need to use a new power outlet. They must be the same
xtures. DO NOT mix xtures.
ON-X Power Cord Daisy Chain
Master-Slave Operation This function will allow you to link up to
16 units together and operate without a controller. In a Master-Slave
set up one unit will act as the controlling unit and the others will react
to the controlling units programs. Any unit can act as a Master or as a
Slave.
1. Using approved DMX data cables, daisy chain your units togeth-
er via the XLR connector on the rear of the units. Remember the
Male XLR connector is the input and the Female XLR connector
is the output. The rst unit in the chain (master) will use the female
XLR connector only - The last unit in the chain will use the male
XLR connector only. For longer cable runs we suggest a termina-
tor at the last fixture.
2. For the Master unit press the MENU button until “SLND” is
displayed, and press ENTER. Set the unit to “MAST” and press
ENTER.
3. Next set the Master to your desired operating mode.
4. For the slave units press the MENU button until “SLND” is dis-
played, and Press ENTER. Set the slave units to either “SL 1” or
“SL 2”.
5. The slave units will now follow the Master unit.
ON-X Master-Slave Configuration

ADJ Products, LLC - www.adj.com - ON-X User Manual Page 17ADJ Products, LLC - www.adj.com - ON-X User Manual Page 16
ON-X UC IR Control
The UC IR infrared remote gives you control of various functions.
To control the fixture you must aim the remote at the front of the fix-
ture and be no more then 30 feet away.
STAND BY - Pressing this button will blackout the fixture.
FULL ON -Hold this button down to fully light up the unit. When you
let the button go, the unit will return to its previous state.
FADE/GOBO - This button is invalid for this fixture.
“DIMMER +” and “DIMMER -” - These buttons are used to adjust
the output intensity.
STROBE - Press and hold this button for random strobing. Press the
button to activate sound active strobing.
COLOR - Press this button and use buttons 1-4 to select either of
the RGBW colors.
1-9 - When in color or show mode these buttons will allow you to se-
lect your desired color or show. See Color or Show for more info.
SOUND ON & OFF - These buttons activate and deactivate the
sound active mode.
SHOW 0 - This activates the show mode. Press the Show 0 button
to activate random show mode, or use buttons 1-2 to select a preset
show.
ON-X 2 Channel Mode
Channel Value Function
1 SHOWS
0 - 7 OFF
8 - 15 SHOW 0
16 - 23 SHOW 1
24 - 31 SHOW 2
32 - 39 SOUND ACTIVE
40 - 255 NO FUNCTION
2 SHOW SPEED/SOUND SENSITIVITY
0 - 255 SHOW SPEED SLOW - FAST
0 - 255 LEAST SENSITIVE - MOST SENSITIVE
When Channel 1 is between the values of 8-31, Channel 2 will control
show speed.
When Channel 1 is between the values of 32-39, Channel 2 will con-
trol sound sensitivity.

ADJ Products, LLC - www.adj.com - ON-X User Manual Page 19ADJ Products, LLC - www.adj.com - ON-X User Manual Page 18
ON-X 11 Channel Mode
Channel Value Function
1 HEAD 1
0 - 255 TILT LEFT - RIGHT MOVEMENT
2 HEAD 2
0 - 255 TILT LEFT - RIGHT MOVEMENT
3 0 - 255 RED 0% - 100%
4 0 - 255 GREEN 0% - 100%
5 0 - 255 BLUE 0% - 100%
6 0 - 255 WHITE 0% - 100%
7 SHOWS
0 - 7 OFF
8 - 15 SHOW 0
16 - 23 SHOW 1
24 - 31 SHOW 2
32 - 39 SOUND ACTIVE
40 - 255 NO FUNCTION
8 SHOW SPEED/SOUND SENSITIVITY
0 - 255 SHOW SPEED SLOW - FAST
0 - 255 LEAST SENSITIVE - MOST SENSITIVE
9 STROBE
0 - 7 BLACKOUT
8 - 15 OPEN
16 - 131 STROBING SLOW - FAST
132 - 139 OPEN
140 - 181 SLOW OPEN - FAST CLOSE
182 - 189 OPEN
190 - 231 FAST OPEN - SLOW CLOSE
232 - 239 OPEN
240 - 247 SOUND ACTIVE STROBE
248 - 255 OPEN
10 0 - 255 MASTER DIMMER 0% - 100%
11 SPECIAL FUNCTIONS
0 - 69 NOTHING
70 - 79 BLACKOUT WITH TILT MOVEMENT
80 - 89 NOTHING
ON-X 9 Channel Mode
Channel Value Function
1 HEAD 1
0 - 255 TILT LEFT - RIGHT MOVEMENT
2 HEAD 2
0 - 255 TILT LEFT - RIGHT MOVEMENT
3 0 - 255 RED 0% - 100%
4 0 - 255 GREEN 0% - 100%
5 0 - 255 BLUE 0% - 100%
6 0 - 255 WHITE 0% - 100%
7 STROBE
0 - 7 BLACKOUT
8 - 15 OPEN
16 - 131 STROBING SLOW - FAST
132 - 139 OPEN
140 - 181 SLOW OPEN - FAST CLOSE
182 - 189 OPEN
190 - 231 FAST OPEN - SLOW CLOSE
232 - 239 OPEN
240 - 247 SOUND ACTIVE STROBE
248 - 255 OPEN
8 0 - 255 MASTER DIMMER 0% - 100%
9 SPECIAL FUNCTIONS
0 - 69 NOTHING
70 - 79 BLACKOUT WITH TILT MOVEMENT
80 - 89 NOTHING
90 - 99 BLACKOUT WITH RGBW VALUE
CHANGE
100 - 199 NOTHING
200 - 209 RESET ALL
210 - 255 NOTHING

ADJ Products, LLC - www.adj.com - ON-X User Manual Page 20 ADJ Products, LLC - www.adj.com - ON-X User Manual Page 21
ON-X 11 Channel Mode
Channel Value Function
11 SPECIAL FUNCTIONS
90 - 99 BLACKOUT WITH RGBW VALUE
CHANGE
100 - 199 NOTHING
200 - 209 RESET ALL
210 - 255 NOTHING
When Channel 7 is between the values of 8-31, Channel 8 will control
show speed.
When Channel 7 is between the values of 32-39, Channel 8 will con-
trol sound sensitivity.
ON-X 12 Channel Mode
Channel Value Function
1 HEAD 1
0 - 255 TILT LEFT - RIGHT MOVEMENT
2 HEAD 2
0 - 255 TILT LEFT - RIGHT MOVEMENT
3 0 - 255 RED 0% - 100%
4 0 - 255 GREEN 0% - 100%
5 0 - 255 BLUE 0% - 100%
6 0 - 255 WHITE 0% - 100%
7 SHOWS
0 - 7 OFF
8 - 15 SHOW 0
16 - 23 SHOW 1
24 - 31 SHOW 2
32 - 39 SOUND ACTIVE
40 - 255 NO FUNCTION
8 SHOW SPEED/SOUND SENSITIVITY
0 - 255 SHOW SPEED SLOW - FAST
0 - 255 LEAST SENSITIVE - MOST SENSITIVE
9 STROBE
0 - 7 BLACKOUT
8 - 15 OPEN
16 - 131 STROBING SLOW - FAST
132 - 139 OPEN
140 - 181 SLOW OPEN - FAST CLOSE
182 - 189 OPEN
190 - 231 FAST OPEN - SLOW CLOSE
232 - 239 OPEN
240 - 247 SOUND ACTIVE STROBE
248 - 255 OPEN
10 0 - 255 MASTER DIMMER 0% - 100%
11 DIMMER MODE
0 - 20 STANDARD
21 - 40 STAGE
41 - 60 TV

ADJ Products, LLC - www.adj.com - ON-X User Manual Page 23ADJ Products, LLC - www.adj.com - ON-X User Manual Page 22
ON-X 12 Channel Mode
Channel Value Function
11 DIMMER MODE
61 - 80 ARCHITECTURAL
81 - 100 THEATRE
101 - 255 DEFAULT DIMMER SETTING
12 SPECIAL FUNCTIONS
0 - 69 NOTHING
70 - 79 BLACKOUT WITH TILT MOVEMENT
80 - 89 NOTHING
90 - 99 BLACKOUT WITH RGBW VALUE
CHANGE
100 - 199 NOTHING
200 - 209 RESET ALL
210 - 255 NOTHING
When Channel 7 is between the values of 8-31, Channel 8 will control
show speed.
When Channel 7 is between the values of 32-39, Channel 8 will con-
trol sound sensitivity.
ON-X 16 Channel Mode
Channel Value Function
1 HEAD 1
0 - 255 TILT LEFT - RIGHT MOVEMENT
2 HEAD 2
0 - 255 TILT LEFT - RIGHT MOVEMENT
3 0 - 255 RED LED 1 0% - 100%
4 0 - 255 GREEN LED 1 0% - 100%
5 0 - 255 BLUE LED 1 0% - 100%
6 0 - 255 WHITE LED 1 0% - 100%
7 0 - 255 RED LED 2 0% - 100%
8 0 - 255 GREEN LED 2 0% - 100%
9 0 - 255 BLUE LED 2 0% - 100%
10 0 - 255 WHITE LED 1 0% - 100%
11 SHOWS
0 - 7 OFF
8 - 15 SHOW 0
16 - 23 SHOW 1
24 - 31 SHOW 2
32 - 39 SOUND ACTIVE
40 - 255 NO FUNCTION
12 SHOW SPEED/SOUND SENSITIVITY
0 - 255 SHOW SPEED SLOW - FAST
0 - 255 LEAST SENSITIVE - MOST SENSITIVE
13 STROBE
0 - 7 BLACKOUT
8 - 15 OPEN
16 - 131 STROBING SLOW - FAST
132 - 139 OPEN
140 - 181 SLOW OPEN - FAST CLOSE
182 - 189 OPEN
190 - 231 FAST OPEN - SLOW CLOSE
232 - 239 OPEN
240 - 247 SOUND ACTIVE STROBE
248 - 255 OPEN
14 0 - 255 MASTER DIMMER 0% - 100%

ADJ Products, LLC - www.adj.com - ON-X User Manual Page 24 ADJ Products, LLC - www.adj.com - ON-X User Manual Page 25
ON-X 16 Channel Mode
Channel Value Function
15 DIMMER MODE
0 - 20 STANDARD
21 - 40 STAGE
41 - 60 TV
61 - 80 ARCHITECTURAL
81 - 100 THEATRE
101 - 255 DEFAULT DIMMER SETTING
16 SPECIAL FUNCTIONS
0 - 69 NOTHING
70 - 79 BLACKOUT WITH TILT MOVEMENT
80 - 89 NOTHING
90 - 99 BLACKOUT WITH RGBW VALUE
CHANGE
100 - 199 NOTHING
200 - 209 RESET ALL
210 - 255 NOTHING
When Channel 11 is between the values of 8-31, Channel 12 will
control show speed.
When Channel 11 is between the values of 32-39, Channel 12 will
control sound sensitivity.
ON-X 18 Channel Mode
Channel Value Function
1 HEAD 1
0 - 255 TILT LEFT - RIGHT MOVEMENT
2 HEAD 1
0 - 255 FINE TILT MOVEMENT
3 HEAD 2
0 - 255 TILT LEFT - RIGHT MOVEMENT
4 HEAD 2
0 - 255 FINE TILT MOVEMENT
5 0 - 255 RED LED 1 0% - 100%
6 0 - 255 GREEN LED 1 0% - 100%
7 0 - 255 BLUE LED 1 0% - 100%
8 0 - 255 WHITE LED 1 0% - 100%
9 0 - 255 RED LED 2 0% - 100%
10 0 - 255 GREEN LED 2 0% - 100%
11 0 - 255 BLUE LED 2 0% - 100%
12 0 - 255 WHITE LED 1 0% - 100%
13 SHOWS
0 - 7 OFF
8 - 15 SHOW 0
16 - 23 SHOW 1
24 - 31 SHOW 2
32 - 39 SOUND ACTIVE
40 - 255 NO FUNCTION
14 SHOW SPEED/SOUND SENSITIVITY
0 - 255 SHOW SPEED SLOW - FAST
0 - 255 LEAST SENSITIVE - MOST SENSITIVE
15 STROBE
0 - 7 BLACKOUT
8 - 15 OPEN
16 - 131 STROBING SLOW - FAST
132 - 139 OPEN
140 - 181 SLOW OPEN - FAST CLOSE
182 - 189 OPEN
190 - 231 FAST OPEN - SLOW CLOSE

ADJ Products, LLC - www.adj.com - ON-X User Manual Page 26 ADJ Products, LLC - www.adj.com - ON-X User Manual Page 27
ON-X 18 Channel Mode
Channel Value Function
15 STROBE
232 - 239 OPEN
240 - 247 SOUND ACTIVE STROBE
248 - 255 OPEN
16 0 - 255 MASTER DIMMER 0% - 100%
17 DIMMER MODE
0 - 20 STANDARD
21 - 40 STAGE
41 - 60 TV
61 - 80 ARCHITECTURAL
81 - 100 THEATRE
101 - 255 DEFAULT DIMMER SETTING
18 SPECIAL FUNCTIONS
0 - 69 NOTHING
70 - 79 BLACKOUT WITH TILT MOVEMENT
80 - 89 NOTHING
90 - 99 BLACKOUT WITH RGBW VALUE
CHANGE
100 - 199 NOTHING
200 - 209 RESET ALL
210 - 255 NOTHING
When Channel 13 is between the values of 8-31, Channel 14 will
control show speed.
When Channel 13 is between the values of 32-39, Channel 14 will
control sound sensitivity.
ON-X Dimmer Curve Chart
(Fade Time) (Fade Time)
Ramp Effect
Standard
Stage
TV
Architectural
Theatre
ON-X Photometric Chart

ADJ Products, LLC - www.adj.com - ON-X User Manual Page 28 ADJ Products, LLC - www.adj.com - ON-X User Manual Page 29
ON-X Cleaning
ON-X Trouble Shooting
Trouble Shooting: Listed below are a few common problems that
you may encounter, with solutions.
No light output from the unit;
1. Be sure the external fuse has not blown. The fuse is located on
the rear panel of the unit.
2. Be sure the fuse holder is completely and properly seated.
Unit does not respond to sound;
1. Low frequencies (bass) should cause the unit to react to sound.
Tapping on the microphone, quiet or high pitched sounds may
not activate the unit.
Fixture Cleaning: Due to fog residue, smoke, and dust cleaning
the internal and external optical lenses and mirror should be carried
out periodically to optimize light output. Cleaning frequency depends
on the environment in which the fixture operates (I.e. smoke, fog
residue, dust, dew). In heavy club use we recommend cleaning on a
monthly basis. Periodic cleaning will ensure longevity, and crisp out-
put.
1. Use normal glass cleaner and a soft cloth to wipe down the out-
side casing.
2. Use a brush to wipe down the cooling vents and fan grill.
3. Clean the external optics and mirror with glass cleaner and a soft
cloth every 20 days.
4. Clean the internal optics with glass cleaner and a soft cloth every
30-60 days.
5. Always be sure to dry all parts completely before plugging the unit
back in.
ON-X Fuse Replacement
Disconnect the unit from its power source. Remove the power cord
from the unit. Once the cord has been removed, you will find that
the fuse holder is located inside the power socket. Insert a flat-head
screw driver into the power socket and gently pry out the fuse holder.
Remove the bad fuse and replace with a new one. The fuse holder also
has a holder for a spare fuse.
ON-X Warranty
MANUFACTURER’S LIMITED WARRANTY
A. ADJ Products, LLC hereby warrants, to the original purchaser, ADJ Products, LLC products
to be free of manufacturing defects in material and workmanship for a prescribed period from
the date of purchase (see specific warranty period on reverse). This warranty shall be valid only if the
product is purchased within the United States of America, including possessions and
territories. It is the owner’s responsibility to establish the date and place of purchase by acceptable
evidence, at the time service is sought.
B. For warranty service you must obtain a Return Authorization number (RA#)
before sending back the product–please contact ADJ Products, LLC Service Department
at 800-322-6337. Send the product only to the ADJ Products, LLC factory. All
shipping charges must be pre-paid. If the requested repairs or service (including
parts replacement) are within the terms of this warranty, ADJ Products, LLC will pay return
shipping charges only to a designated point within the United States. If the entire instrument is
sent, it must be shipped in it’s original package. No accessories should be shipped with the product. If
any accessories are shipped with the product, ADJ Products, LLC shall have no liability whatsoever for
loss of or damage to any such accessories, nor for the safe return thereof.
C. This warranty is void if the serial number has been altered or removed; if the product is modified in any
manner which ADJ Products, LLC concludes, after inspection, affects the reliability of the product; if the
product has been repaired or serviced by anyone other than the ADJ Products, LLC factory unless prior
written authorization was issued to purchaser by ADJ Products, LLC; if the product is damaged because
not properly maintained as set forth in the instruction manual.
D. This is not a service contract, and this warranty does not include maintnance, cleaning or periodic check
up. During the period specified above, ADJ Products, LLC will replace defective parts at its expense
with new or refurbished parts, and will absorb all expenses for warranty service and repair labor by
reason of defects in material or workmanship. The sole responsibility of ADJ Products, LLC under this
warranty shall be limited to the repair of the product, or replacement thereof, including parts, at the sole
discretion of ADJ Products, LLC. All products covered by this warranty were manufactured after August
15, 2012, and bear indentifying marks to that effect.
E. ADJ Products, LLC reserves the right to make changes in design and/or improvements upon its products
without any obligation to include these changes in any products theretofore manufactured.
No warranty, whether expressed or implied, is given or made with respect to any accessory supplied with
products described above. Except to the extent prohibited by applicable law, all implied warranties made
by ADJ Products, LLC in connection with this product, including warranties of merchantability or fitness,
are limited in duration to the warranty period set forth above. And no warranties, whether expressed or
implied, including warranties of merchantability or fitness, shall apply to this product after said period
has expired. The consumer’s and/or Dealer’s sole remedy shall be such repair or replacement as is
expressly provided above; and under no circumstances shall ADJ Products, LLC be liable for any loss or
damage, direct or consequential, arising out of the use of, or inability to use, this product.
This warranty is the only written warranty applicable to ADJ Products, LLC Products and
supersedes all prior warranties and written descriptions of warranty terms and conditions heretofore
published.
MANUFACTURER’S LIMITED WARRANTY PERIODS:
 •LightingProducts=1-year(365days)LimitedWarranty(Such as: Special Effect Lighting, Intelligent
Lighting, UV lighting, Strobes, Fog Machines, Bubble Machines, Mirror Balls, Par Cans, Trussing,
Lighting Stands etc. excluding LED and lamps)
 •LaserProducts=1Year(365Days)LimitedWarranty(excluding laser diodes which have a 6 month
limited warranty)
 •L.E.D.Products=2-year(730days)LimitedWarranty(excluding motors, PCB boards, and power
supplies, which have a 1-year (365 day Limited Warranty) batteries which have a 180 day limited war-
ranty). Only the L.E.D.s carry a 2-year warranty (excludingStarTecSerieswhichacarriesa1Year
LimitedWarranty)Note:2YearWarrantyonlyappliestopurchaseswithintheUnitedStates.
•ADJDMXControllers=2Year(730Days)LimitedWarranty(excluding faders and tact switches)

ADJ Products, LLC - www.adj.com - ON-X User Manual Page 30
Please Note: Specications and improvements in the design
of this unit and this manual are subject to change without any
prior written notice.
ON-X Specifications
Model: ON-X
Voltage: 100V ~ 240V/50~60Hz
LEDs: 8 x 3W RGBW LEDs (2 x Red, 2 x
Green, 2 x Blue, & 2 x White)
Power Consumption: 46W
Power Cord Daisy Chain: 15 Fixtures Max. (120V)
28 Fixtures Max. (230V)
Beam Angle: 4 Degrees
Dimensions: 11.25”(L) x 6”(W) x 4.25”(H)
283 x 151 x 110mm (W/O Bracket)
11.25”(L) x 6”(W) x 5.75”(H)
283 x 151 x 147mm (With Bracket)
Colors: RGBW
Weight: 5.5 Lbs. / 2.5 kgs.
Fuse: 2A
Duty Cycle: None
DMX Modes: 6 DMX Channel Modes: 2 Channel
Mode, 9 Channel Mode, 11 Channnel
Mode, 12 Channel Mode, 16 Channnel
Mode & 18 DMX Channels
Working Position: Any Safe, Secure Position
Warranty: 2 Year (730 days)
Auto Sensing Voltage: This xture contains a automatic volt-
age switch, which will auto sense the voltage when it is plugged
into the power source.
ADJ Products, LLC
6122 S. Eastern Ave. Los Angeles, CA 90040 USA
Tel: [phone] / Fax: [phone]
Web: www.adj.com / E-mail: [email protected]
A.D.J. Supply Europe B.V.
Junostraat 2
6468 EW Kerkrade
The Netherlands
[email protected] / www.adj.eu
Tel: [phone] / Fax: [phone]
