Adria RICO User manual

RICO DINING CHAIR
Assembly Instructions
Page 1 of 5

DESCRIPTION
ID QTY
ASSEMBLY INSTRUCTIONS
Please kindly read these instructions carefully and keep for future
reference. Refer to parts inventory for guidance, and
ensure you have all pieces before starting.
When assembling, place all parts on a soft, clean, and flat
surface such as a carpet to prevent scratches.
If you’re having difficulty, our friendly Customer Care
team is always here to help. Call us at (310)-873-3380
during business hours, email [email protected] or chat
live at www.adriaworkshop.com
M6x70mm
RICO DINING CHAIR
M6x45mm
M4x50mm
Allen Key
Ø10mm
Ø16mm
8pcs+ ext 1pc
2pcs+ ext 1pc
4pcs+ ext 1pc
10pcs+ ext 2pcs
10pcs+ ext 2pcs
1pc
1pc
1pc
2pcs
1pc
Screw
(A)
(B)
(C)
(L)
(R)
(H5)
(H4)
(H3)
(H2)
(H1)
(K)
Flat Washer
Spring Washer
Bolts
Bolts
PARTS LIST
1pc
HARDWARE LIST
Seat
Back Frame
Side Rail
Front Leg
Front Leg
Note: Make sure you have all the parts and hardware with quantity listed above before
assemblying the product . A screwdriver is also required (not included)
Page 2 of 5

STEP 1
80%
x4
80%
x4
STEP 2
(A)
(B)
(C)
(L)
(R)
(H3)
(H3)
(H2)
(H1)
(H2)
(H1)
(K)
(K)
Page 3 of 5
RICO DINING CHAIR

x4
80%
x2
OR
(C)
(A)
(B)
(H5)
(H4)
(H2)
(H1)
(K)
100%
100%
(K)
Page 4 of 5
STEP 3
STEP 4
RICO DINING CHAIR

RICO DINING CHAIR
Page 5 of 5
STEP 5
Finished
