1. Introduction
advan VD1 Network Camera is a vandal proof dome provides a
broad overview with high efficient codec (H.265) support. The
camera’s sensor give a 115° angle of view with smooth capture of
movements at up to 30 fps in 4K resolution. The varifocal lens
provide the flexibility of focus distance and view angle. The camera
is effectively installed indoors or outdoors with a wide operating
temperature range powered by standard PoE is delivered with a
repaintable weather shield that protects against sun, rain, or snow.
The camera is equipped with video motion detection, active
tampering alarm, and *face recognition. It also support both
Android SDK/NDK and AVC SDK in order to develop Android
application and pluggableAI (Artificial Intelligence) module running
on camera devices.
The advan VD1 designed with IK10 vandal resistance and IP67
ingress protection. The camera is equipped with an automatic
IR-cut filter and IR LEDs for day and night surveillance. With the
low lux CMOS image sensor, the camera is capable of providing a
color live view in a low light environment. Adjustable in 3 axis (pan,
tilt and rotate), it offers an entry-level surveillance solution with all
the essential features and excellent image quality.

6
2. Packing List
advan VD-1 Vandal Proof IP
Dome
Torx Wrench
Screw x 4
Screw Anchor x 4
RJ-45 Connector
Audio Wires x 2
Installation sticker
1
1
1
Ceiling mount template
1
Water proof rubber sets
(for RJ-45 Cat.5 and 12V DC /
for RJ-45 Cat.6)
Conduit Converter
Small Concave hexagon
Wrench
Big Concave hexagon
Wrench
Sticker (for Silica Gel Bag)
Silica Gel Bag
Ruler
Warranty Card

7
3. Features
Android L (5.1.1)
4K video streaming at 30 fps under H.264/H.265 Video
Codec
Megapixel Varifocal lens (40~115°)
ONVIF Profile S conformant
Outdoor-ready with wide operating temperature range
Triple streams from H.264 and H.265
Up to 30 fps at 3840x2160
Vandal resistance (IK10)
Ingress protection (IP67)
P-iris lens for auto iris control
Intelligent IR
IR distance up to 40 m (131 ft)
Day and Night function (with removable IR-cut filter)
3-axis mechanism (pan / tilt / rotate)
PoE (IEEE 802.3at)
Wide Dynamic Range
Defog
Motion detection
Tampering alarm
Text overlay
Privacy mask
Supports iPhone, iPad, Android
14 languages on Web interface

8
4. Camera Overview

9
No.
Name
Description
1
LED Indicators
The power LED (top) turns on (green) when
the power is on and turns off when there is
no power supply. The status LED (bottom)
turns on (green) when the system operates
normally and turns off when system error
occurs.
2
Audio Out
Connects to a speaker for audio output.
3
Audio In
Connects to a microphone for audio input.
4
LAN / PoE
Connects to a 10/100 Ethernet or PoE.
5
Digital I/O
One Digital Input and One digital Output
6
Default Button
Resets the camera to factory default. For
details, see 3.6 Loading Factory Default.
7
Rotational Screw
Loosens to rotate the camera.
8
Cable Gland
Waterproofs the Ethernet cable.
9
Tilt Screw
Loosens the screw to tilt the camera.
10
Mic in
Microphone slot
11
Silica Gel Bag
Absorbs moisture in the camera body.
12
Zoom Screw
Adjusts the zoom of the camera.
13
Focus Screw
Adjusts the focus of the camera.
14
Conduit Connector
Waterproofs the audio wires.

10
5. Installation
The advan VD-1 Vandal Proof IP Dome is designed for outdoors. With the standard
package, you can install the camera on the ceiling. Note: You can also install the
camera to ceilings, wall corners (concave or convex), and poles using optional
mounting kits.
