Advanced Wireless Communications AWR-D6000 User manual

User Manual
AWR-D6000
Digital Portable Radio

Thank you for purchasing this digital / analog two-way radio by Advanced
Wireless Communications. This product is designed and developed according to
FCC/IC/EU and advanced international technologies standards. The radio has an
ergonomic design and a comprehensive set of functions to deliver an advanced
communication solution.
Our products are tested using strict and rigorous test procedures with advanced
test instruments and equipment to internationally recognized standards.
Thank you!
This manual should be read to ensure that the user understands the operation of
the AWR-D6000. Please read the Safety Information Manual before use.
1

Product Safety and RF Exposure for Portable Two-Way Radios Compliance with RF Energy
Exposure Standards
NOTICE: This radio is intended for use in occupational/controlled applications where users have been made
aware of the potential for exposure and can exercise control over their exposure. This radio device is NOT
authorized for general population, consumer or similar use.
BEFORE USING THIS RADIO, READ THE TRAINING MATERIAL BELOW WHICH CONTAINS IMPORTANT
OPERATING INSTRUCTIONS FOR SAFE USAGE AND RF ENERGY AWARENESS AND CONTROL
INFORMATION FOR COMPLIANCE WITH RF ENERGY EXPOSURE LIMITS IN APPLICABLE NATIONAL AND
INTERNATIONAL STANDARDS.
Federal Communication Commission (FCC) Regulations
The FCC has established limits for safe exposure to radio frequency (RF) emissions from portable two-way
radios. The FCC requires manufacturers to demonstrate compliance with RF exposure limits before portable
two-way radios can be marketed in the U.S. When two-way radios are approved for occupational/controlled
environment exposure limits, the FCC requires users to be fully aware of, and exercise control over, their
exposure. Awareness and control of RF exposure can be accomplished by the use of labels, or by education
and training through appropriate means such as information and instructions in user manuals or safety
booklets. Your Advanced Wireless Communications’ two-way radio has an RF exposure information label in the
battery compartment. The training material below includes useful information about RF exposure and helpful
instructions.
1 2

Your Advanced Wireless Communications two-way radio is designed and tested to comply with a number
of national and international standards and guidelines (listed below) regarding human exposure to RF
electromagnetic energy. In terms of measuring RF energy for compliance with FCC exposure guidelines,
your radio radiates measurable RF energy only while it is transmitting (during talking), not when it is receiving
(listening) or in standby mode.
Compliance and Control Guidelines and Operating Instructions for Portable Two-Way Radios To control your
exposure and ensure compliance with the occupational/controlled environment exposure limits, always adhere
to the following procedures:
*Transmit no more than 50% of the time. To transmit (talk), push the Push-To-Talk (PTT) button. To receive calls,
release the PTT button. Transmitting 50% of the time or less is important since the radio generates measurable
RF energy exposure only when transmitting (in terms of measuring standards compliance).
* For body-worn operation, always place the radio in an AWC approved belt-clip or similar accessory that
contains no metallic components and provides a minimum separation distance of 1.3 cm between the back of
the radio and the user’s body. AWC approved accessories, antennas, and device combinations comply with
the occupational/controlled environment RF exposure limits. Using non-AWC approved accessories may result
in exposure levels which exceed the FCC’s occupational/controlled environment RF exposure limits. AWC
approved accessories have been tested and comply with FCC RF exposure requirements.
*If you are not using a body-worn accessory and are not using the radio held in front of the face, ensure the
radio is kept at a minimum of 1.3 cm from the body when transmitting. Keeping the radio
3 4

at a proper distance is important since RF exposure decreases with increasing distance from the antenna.
*Use only FCC-approved, supplied or replacement headsets, batteries, and accessories intended for use with
this radio. Use of non-FCC approved headsets, batteries and accessories may exceed FCC RF exposure
guidelines.
FCC License Information
Your Advanced Wireless Communications radio operates on communications frequencies which are subject to
FCC (Federal Communications Commission) Rules & Regulations. FCC Rules require that all operators using
Private Land Mobile radio frequencies obtain a radio license before operating their equipment. Application for
license must be made on FCC main form 601, and schedules D, E, and H.
FAX: Forms can be obtained by fax from the FCC Fax-On-Demand system. Call 1-202-418-0177 from your fax
machine and request document number 000600 for the form, schedules, and instructions.
MAIL: Forms can be ordered by telephone, and will be sent to you by rst class mail. Call the FCC Forms
Hotline at 1-800-418-FORM (1-800-418-3676).
INTERNET: Form 601 and instructions can be downloaded from the FCC Forms website at:
http://www.fcc.gov/Forms/Form601/601.html
4

Before lling out your Form 601 application Technical Data section, you must decide which frequency (or
frequencies) you will operate on.
QUESTIONS? Call the FCC for license application questions at 1-888-CALL-FCC
(1-888-225-5322).
If you have any questions, call Advanced Wireless Communications at 1-800-475-5852
Notices To The User:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
One or more of the following statements may be applicable:
FCC WARNING
This equipment generates or uses radio frequency energy. Changes or modications to this equipment may
cause harmful interference unless the modications are expressly approved in the instruction manual. The user
could lose the authority to operate this equipment if an unauthorized change or modication is made.
5

INFORMATION TO THE DIGITAL DEVICE USER REQUIRED BY THE FCC
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in residential installations. This equipment generates, uses and can generate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that the interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the
equipment o󰀨 and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit di󰀨erent from that to which the receiver is connected.
• Consult with the dealer for technical assistance.
SAFETY INFORMATION:
Your wireless portable two-way radio has been designed using a low power transmitter. When the PTT switch
is pressed, the radio generates radio frequency (RF) electromagnetic energy (EME). This radio is designed to
comply with the FCC Report and Order FCC 96-326 (August, 1996).
User Safety Information
5 6

PLEASE READ THIS IMPORTANT INFORMATION BEFORE USING YOUR ADVANCED
WIRELESS COMMUNICATIONS PORTABLE TWO-WAY RADIO.
◊ Only qualied technicians are allowed to maintain this product.
◊ To avoid electromagnetic interference, turn o󰀨 your radio in places where posted notices instruct you to do so.
Hospitals or health care facilities may be using equipment that is sensitive to external RF energy. When traveling
on aircraft, turn o󰀨 your radio when the airline crew instructs you to do so.
◊ When in vehicles equipped with an air bag, do not place a portable radio in
the airbag deployment area.
◊ Turn o󰀨 your radio prior to entering any area with a potentially explosive
atmosphere. Do not remove, install, or charge batteries in such areas.
◊ To avoid possible interference with blasting operations, turn o󰀨 your radio
when you are near electrical blasting caps.
◊ Do not expose the radio to direct sunlight for long periods of time. Do not
place the radio in direct contact with any heating source.
7

How to use this user manual
This manual introduces the basic operation of the AWR-D6000 Digital Portable Radio. Your
dealer or system administrator may have already programmed features of this radio based on
your operational requirements. Please consult with your dealer or system administrator about
programming details.
The icons below are used for distinguishing between analog and digital features.
This icon indicates the function is only available in Analog mode.
This icon indicates the function is only available in Digital mode.
8

9
10
11
11
12
12
12
12
12
12
13
13
14
15
15
15
15
16
16
17
18
20
22

9 10

11 12

12

13

14

15

15 16

17

18

19
