INTREPID120TM –Assembly Instructions

INTREPID120
UK Office Phone [phone]  Fax [phone]
US Office Phone [phone]  Fax [phone]
Canada Office Phone [phone]  Fax [phone]
E-mail [e-mail]
Website www.AdvantechAMT.com
Page 2 of 14
Ref: PM-INT120-002-11023
The INTREPID120 Antenna System
The ‘INTREPID’ class of antenna systems are renowned for their compact size,
light weight and powerful performance having been designed to excel in today’s
ever demanding satellite communications industry.
The user friendly modular design allows for simple, fast and accurate satellite
acquisition either as a manually controlled mount or as a fully auto-acquisition
motorised mount.
The clever design of the tri-pod mount also means that other 3rd party
antennas can be fitted allowing existing equipment to be cost effectively
upgraded.
The main reflector is manufactured from high quality carbon fibre and is
supplied in six easily assembled petals that employ a revolutionary spherical
dowel locking mechanism.
The revolutionary design of the complete fly-away system allows for the
INTREPID class antenna to be transported in easily manageable carry cases
weighing less than 32kg that can be checked onto any commercial aircraft
making the INTREPID class antenna a totally flexible fly-away system.

INTREPID120
UK Office Phone [phone]  Fax [phone]
US Office Phone [phone]  Fax [phone]
Canada Office Phone [phone]  Fax [phone]
E-mail [e-mail]
Website www.AdvantechAMT.com
Page 3 of 14
Ref: PM-INT120-002-11023
Contents
1.0 Case Contents
2.0 Assembly Instructions

INTREPID120
UK Office Phone [phone]  Fax [phone]
US Office Phone [phone]  Fax [phone]
Canada Office Phone [phone]  Fax [phone]
E-mail [e-mail]
Website www.AdvantechAMT.com
Page 4 of 14
Ref: PM-INT120-002-11023
1.0 Case Contents
1.1 Case 1 - Tripod Case
Tripod Base
Extension Legs
1.2 Case 2 –Elevation & Feed arm Case
Elevation head
Extension arm
OMT Assembly

INTREPID120
UK Office Phone [phone]  Fax [phone]
US Office Phone [phone]  Fax [phone]
Canada Office Phone [phone]  Fax [phone]
E-mail [e-mail]
Website www.AdvantechAMT.com
Page 5 of 14
Ref: PM-INT120-002-11023
The Tripod is transported in its custom built transit case. The components are
secured in place by the lid of the case and are supported as shown.
1.3 Case 3 - Antenna Case
Antenna Stays
Antenna Bag
Remove the Antenna stays & lift out the antenna bag containing the carbon
antenna.

INTREPID120
UK Office Phone [phone]  Fax [phone]
US Office Phone [phone]  Fax [phone]
Canada Office Phone [phone]  Fax [phone]
E-mail [e-mail]
Website www.AdvantechAMT.com
Page 6 of 14
Ref: PM-INT120-002-11023
2.0 Assembly Instructions
2.1 Tripod Assembly
Remove the tripod base from the packing case.

INTREPID120
UK Office Phone [phone]  Fax [phone]
US Office Phone [phone]  Fax [phone]
Canada Office Phone [phone]  Fax [phone]
E-mail [e-mail]
Website www.AdvantechAMT.com
Page 7 of 14
Ref: PM-INT120-002-11023
Invert and Place Tri-pod base securely. Splay the Tri-pod legs and force the
centre lock into the stow position.
Remove the tripod extension legs and locate into tripod head. Tighten and lock
leg cams.

INTREPID120
UK Office Phone [phone]  Fax [phone]
US Office Phone [phone]  Fax [phone]
Canada Office Phone [phone]  Fax [phone]
E-mail [e-mail]
Website www.AdvantechAMT.com
Page 8 of 14
Ref: PM-INT120-002-11023
Stand tripod on legs and level using adjustable levelling feet and bubble level
mounted on the tripod base.
Remove the elevation head from the packing case.

INTREPID120
UK Office Phone [phone]  Fax [phone]
US Office Phone [phone]  Fax [phone]
Canada Office Phone [phone]  Fax [phone]
E-mail [e-mail]
Website www.AdvantechAMT.com
Page 9 of 14
Ref: PM-INT120-002-11023
Assemble elevation head onto the rear locations on the tripod base
and lock with Vee-Lock handle by pushing in an upward motion.
RF Location points
Antenna Clamp
Inclinometer
RF Location points
Elevation Adjustment
Azimuth Adjustment
Azimuth Brake
The tripod is ready to accept the
antenna.

INTREPID120
UK Office Phone [phone]  Fax [phone]
US Office Phone [phone]  Fax [phone]
Canada Office Phone [phone]  Fax [phone]
E-mail [e-mail]
Website www.AdvantechAMT.com
Page 10 of 14
Ref: PM-INT120-002-11023
2.2 Antenna Assembly
Remove antenna base petal, antenna carry case and stays.
Locate and lock antenna base petal onto tripod head.

INTREPID120
UK Office Phone [phone]  Fax [phone]
US Office Phone [phone]  Fax [phone]
Canada Office Phone [phone]  Fax [phone]
E-mail [e-mail]
Website www.AdvantechAMT.com
Page 11 of 14
Ref: PM-INT120-002-11023
Secure and lock bottom petal into position on tripod base petal using over
centre locking clips.

INTREPID120
UK Office Phone [phone]  Fax [phone]
US Office Phone [phone]  Fax [phone]
Canada Office Phone [phone]  Fax [phone]
E-mail [e-mail]
Website www.AdvantechAMT.com
Page 12 of 14
Ref: PM-INT120-002-11023
Tripod with 1st and 2nd petal attached.
Assemble left and right sides of the antenna.

INTREPID120
UK Office Phone [phone]  Fax [phone]
US Office Phone [phone]  Fax [phone]
Canada Office Phone [phone]  Fax [phone]
E-mail [e-mail]
Website www.AdvantechAMT.com
Page 13 of 14
Ref: PM-INT120-002-11023
Lock right and left sides of the antenna to the tripod antenna assembly.
2.3 Feed Arm Assembly
Remove OMT assembly and extension arm. Remove Quick-Connect™dust
caps

INTREPID120
UK Office Phone [phone]  Fax [phone]
US Office Phone [phone]  Fax [phone]
Canada Office Phone [phone]  Fax [phone]
E-mail [e-mail]
Website www.AdvantechAMT.com
Page 14 of 14
Ref: PM-INT120-002-11023
Lock both parts of the feed arm together with feed arm cam. Make the Quick-
Connect™connections.
Lock the feed arm into tripod assembly using the secure cam lock.
Attach feed arm stays into position, one on each side.
Attach flexible waveguide from feed arm to elevation head & from elevation
head to HPA.
