Advantech ASR-3100PP-R11A1E User manual

User Manual
ASR-3100 Series
1U Rackmount dual Xeon E5-
2600 v3 NVMe Storage Server,
supporting SFF-8639 2.5" NVMe
SSD and 2 x PCIe Gen III x8 slot

ASR-3100 Series User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2014
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgements
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandize
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.
Part No. 2001310000 Edition 1
March 2016

iii ASR-3100 Series User Manual
A Message to the Customer
Advantech Customer Services
Each and every Advantech product is built to the most exacting specifications to
ensure reliable performance in the harsh and demanding conditions typical of indus-
trial environments. Whether your new Advantech equipment is destined for the labo-
ratory or the factory floor, you can be assured that your product will provide the
reliability and ease of operation for which the name Advantech has come to be
known.
Your satisfaction is our primary concern. Here is a guide to Advantech’s customer
services. To ensure you get the full benefit of our services, please follow the instruc-
tions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions,
you can easily find answers in your product documentation. These answers are nor-
mally a lot more detailed than the ones we can give over the phone.
So please consult this manual first. If you still cannot find the answer, gather all the
information or questions that apply to your problem, and with the product close at
hand, call your dealer. Our dealers are well trained and ready to give you the support
you need to get the most from your Advantech products. In fact, most problems
reported are minor and are easily solved over the phone.
In addition, free technical support is available from Advantech engineers every busi-
ness day. We are always ready to give advice on application requirements or specific
information on the installation and operation of any of our products.
Declaration of Conformity
FCC Class A
Note: This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Opera-
tion of this equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his own expense.

ASR-3100 Series User Manual iv
Safety Information
Retain and follow all product safety and operating instructions provided with your
equipment. In the event of a conflict between the instructions in this guide and the
instructions in equipment documentation, follow the guidelines in the equipment doc-
umentation.
Observe all warnings on the product and in the operating instructions. To reduce the
risk of bodily injury, electric shock, fire and damage to the equipment, observe all pre-
cautions included in this guide.
You must become familiar with the safety information in this guide before you install,
operate, or service Advantech products.
Machine Room Environment
Make sure that the area in which you install the system is properly ventilated
and climate-controlled.
Ensure that the voltage and frequency of your power source match the voltage
and frequency inscribed on the electrical rating label of the equipment.
Do not install the system in or near a plenum, air duct, radiator, or heat register.
Never use the product in a wet location.
Equipment Chassis
Do not block or cover the openings to the system.
Never push objects of any kind through openings in the equipment.
Dangerous voltages might be present.
Conductive foreign objects can produce a short circuit and cause fire, electric
shock, or damage to your equipment.
Lift equipment using both hands and with your knees bent.
Rack Mount Instructions
The following or similar rack-mount instructions are included with the installation
instructions:
Elevated Operating Ambient - If installed in a closed or multi-unit rack assembly,
the operating ambient temperature of the rack environment may be greater than
room ambient. Therefore, consideration should be given to installing the equip-
ment in an environment compatible with the maximum ambient temperature
(Tma) specified by the manufacturer.
Reduced Air Flow - Installation of the equipment in a rack should be such that
the amount of air flow required for safe operation of the equipment is not com-
promised.
Mechanical Loading - Mounting of the equipment in the rack should be such that
a hazardous condition is not achieved due to uneven mechanical loading.
Circuit Overloading - Consideration should be given to the connection of the
equipment to the supply circuit and the effect that overloading of the circuits
might have on overcurrent protection and supply wiring.
Appropriate consideration of equipment nameplate ratings should be used when
addressing this concern.
Reliable Earthing - Reliable earthing of rackmounted equipment should be
maintained. Particular attention should be given to supply connections other
than direct connections to the branch circuit (e.g. use of power strips).

v ASR-3100 Series User Manual
Make sure only one component is extended at a time. A rack might become
unstable if more than one component is extended.
Equipment Batteries*
The system battery contains lithium manganese dioxide. If the battery pack is
not handled properly, there is risk of fire and burns.
Do not disassemble, crush, puncture, short external contacts, or dispose of the
battery in fire or water.
Do not expose the battery to temperatures higher than 60°C (140°F).
The system battery is not replaceable. If the battery is replaced by an incorrect
type, there is danger of explosion. Replace the battery only with a spare desig-
nated for your product.
Do not attempt to recharge the battery.
Dispose of used batteries according to the instructions of the manufacturer.
Do not dispose of batteries with the general household waste. To forward them
to recycling or proper disposal, use the public collection system or return them
to Advantech, your authorized Advantech partner, or their agents.
Equipment Modifications
Do not make mechanical modifications to the system. Advantech is not respon-
sible for the regulatory compliance of Advantech equipment that has been mod-
ified.
Equipment Repairs and Servicing
The installation of internal options and routine maintenance and service of this
product should be performed by individuals who are knowledgeable about the
procedures, precautions, and hazards associated with equipment containing
hazardous energy levels.
Do not exceed the level of repair specified in the procedures in the product doc-
umentation. Improper repairs can create a safety hazard.
Allow the product to cool before removing covers and touching internal compo-
nents.
Remove all watches, rings, or loose jewelry when working before removing cov-
ers and touching internal components.
Do not use conductive tools that could bridge live parts.
Use gloves when you remove or replace system components; they can become
hot to the touch.
–If the product sustains damage requiring service, disconnect the product from
the AC electrical outlet and refer servicing to an authorized service provider.
Examples of damage requiring service include:
–The power cord, extension cord, or plug has been damaged.
–Liquid has been spilled on the product or an object has fallen into the product.
–The product has been exposed to rain or water.
–The product has been dropped or damaged.
–The product does not operate normally when you follow the operating instruc-
tions.

ASR-3100 Series User Manual vi
Peripheral Compatibility
Note! Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the
manufacture. Discard used batteries according to the manufacture's
instructions.
Danger d'explosion si la batterie est remplacée de façon incorrecte.
Remplacez-la uniquement avec le même type ou équivalent recom-
mandé par la fabrication. Jetez les piles usagées selon les instructions
du fabricant.
Category Advantech PN Vendor Part Description Remarks
CPU
96MPXE-2.2-30M20T Intel Xeon E5-2658 v3/2.2GHz/12cores 95W
96MPXE-2.4-15M20T Intel Xeon E5-2620 v3/2.4GHz/6cores 95W
96MPXE-1.9-15M20T Intel Xeon E5-2609 v3/1.9GHz/6cores 80W
96MPXE-2.6-20M20T Intel Xeon E5-2640 v3/2.6GHz/8cores 95W
96MPXE-2.5-30M20T Intel Xeon E5-2680 v3/2.5GHz/12cores 115W
TBD Intel Xeon E5-2698 v3/2.3GHz/16cores 135W
TBD Intel Xeon E5-2695 v3/2.3GHz/14cores 120W
TBD Intel Xeon E5-2690 v3/2.6GHz/12cores 135W
TBD Intel Xeon E5-2683 v3/2.0GHz/14cores 120W
TBD Intel Xeon E5-2680 v3/2.5GHz/12cores 120W
TBD Intel Xeon E5-2670 v3/2.3GHz/12cores 120W
TBD Intel Xeon E5-2667 v3/3.2GHz/8cores 135W
TBD Intel Xeon E5-2660 v3/2.6GHz/10cores 105W
TBD Intel Xeon E5-2658A v3/2.2GHz/12cores 105W
TBD Intel Xeon E5-2658 v3/2.2GHz/12cores 105W
TBD Intel Xeon E5-2650L v3/1.8GHz/12cores 65W
TBD Intel Xeon E5-2650 v3/2.3GHz/10cores 105W
TBD Intel Xeon E5-2648L v3/1.8GHz/12cores 75W
TBD Intel Xeon E5-2643 v3/3.4GHz/6cores 135W
TBD Intel Xeon E5-2640 v3/2.6GHz/8cores 90W
TBD Intel Xeon E5-2637 v3/3.5GHz/4cores 135W
TBD Intel Xeon E5-2630L v3/1.8GHz/8cores 55W
TBD Intel Xeon E5-2630 v3/2.4GHz/8cores 85W
TBD Intel Xeon E5-2628L v3/2.0GHz/10cores 75W
TBD Intel Xeon E5-2623 v3/3.0GHz/4cores 105W
TBD Intel Xeon E5-2620 v3/2.4GHz/6cores 85W
TBD Intel Xeon E5-2618L v3/2.3GHz/8cores 75W
TBD Intel Xeon E5-2609 v3/1.9GHz/6cores 85W
TBD Intel Xeon E5-2608L v3/2.0GHz/6cores 52W
TBD Intel Xeon E5-2603 v3/1.6GHz/6cores 85W
Memory TBD TBD DDR4 288PIN ECC-REG DIMM,
capacity up to 32GB per module -

vii ASR-3100 Series User Manual
Initial Inspection
Before powering up the system, please make sure that the following materials have
been shipped:
1 x ASR-3100 system
1 x ASR-3100 Startup Manual
1 x Driver CD (User Manual is included)
2 x CPU heatsink
1 x Slide rail kit
1 x CMA (Cable Management Arm)
2 x Mounting ears with handle
If any of these items are missing or damaged, contact distributor or sales representa-
tive immediately. We have carefully inspected the ASR-3100 mechanically and elec-
trically before shipment. It should be free of marks and scratches and in perfect
working order upon receipt. When unpacking the ASR-3100, check it for signs of
shipping damage. (For example, damaged box, scratches, dents, etc.) If it is dam-
aged or it fails to meet the specifications, notify our service department or local sales
representative immediately. Also notify the carrier. Retain the shipping carton and
packing material for inspection by the carrier. After inspection, we will make arrange-
ments to repair or replace the unit.
Order Information
Note! ASR-3100 system MUST use the SSD or enterprise level SATA HDD or
SAS HDD.
Part number 2.5” Front HDD 2nd Row 2.5” HDD PCIe Slot Chassis
Depth
ASR-3100PP-R11A1E x8 NVMe
(SAS is optional) x8 NVMe + SATA 2 806 mm
ASR-3100PT-R11A1E x8 NVMe
(SAS is optional) x8 SATA 2 806 mm
ASR-3100SS-R11A1E x8 SAS+SATA
(x2 NVMe is optional) x8 SAS+SATA 2 806 mm

ASR-3100 Series User Manual viii

ix ASR-3100 Series User Manual
Contents
Chapter 1 Overview...............................................1
1.1 Introduction ............................................................................................... 2
1.2 Features .................................................................................................... 2
1.3 System Specifications ............................................................................... 3
1.4 System Layout, LED, Jumpers and Connectors ....................................... 5
1.4.1 LED Definitions ............................................................................. 6
1.4.2 Jumpers ........................................................................................ 7
1.4.3 Connectors.................................................................................... 7
1.5 Block Diagram........................................................................................... 8
1.6 System Memory ........................................................................................ 8
1.7 Memory Installation Procedures................................................................ 9
Chapter 2 Setting up ...........................................11
2.1 Before you Begin..................................................................................... 12
2.1.1 Work Area ................................................................................... 12
2.1.2 Tools ........................................................................................... 12
2.1.3 Precautions ................................................................................. 12
2.2 Installing Motherboard Components ....................................................... 13
2.2.1 Removing the Chassis Cover ..................................................... 13
2.2.2 Installing the CPU and Heatsink ................................................. 13
2.2.3 Installing the Memory.................................................................. 17
2.2.4 Installing Hard Drives.................................................................. 18
2.2.5 Installing PCIe x8 Expansion Card ............................................. 20
2.3 Rack Mounting ........................................................................................ 22
2.3.1 Installing the Server in a Rack .................................................... 22
Chapter 3 AMI BIOS ............................................27
3.1 Introduction ............................................................................................. 28
3.2 BIOS Setup ............................................................................................. 29
3.2.1 Main Menu .................................................................................. 29
3.2.2 Advanced BIOS Features Setup................................................. 30
3.2.3 Intel RC Setup............................................................................. 40
3.2.4 Server Management ................................................................... 56
3.2.5 Security ....................................................................................... 60
3.2.6 Boot............................................................................................. 60
3.2.7 Save & Exit ................................................................................. 61
Chapter 4 Chipset Software Installation Utility 63
4.1 Before You Begin .................................................................................... 64
4.2 Introduction ............................................................................................. 64
4.2.1 Main Menu .................................................................................. 64
4.3 Windows OS Driver Setup ...................................................................... 65
Chapter 5 VGA Setup..........................................67
5.1 Introduction ............................................................................................. 68
5.2 Windows Series Driver Setup ................................................................. 68

ASR-3100 Series User Manual x
Chapter 6 LAN Configuration / SATA RAID &
AHCI / USB 3.0 Setup69
6.1 LAN Configuration................................................................................... 70
6.1.1 Introduction ................................................................................. 70
6.1.2 Features...................................................................................... 70
6.1.3 Installation................................................................................... 70
6.1.4 Windows Series Driver Setup (LAN)........................................... 70
6.2 AHCI & SATA RAID ................................................................................ 71
6.3 USB3.0.................................................................................................... 72
Appendix A Programming the Watchdog Timer .73
A.1 Watchdog Timer Overview...................................................................... 74
A.2 Programming the Watchdog Timer ......................................................... 74

Chapter 1
1Overview

ASR-3100 Series User Manual 2
1.1 Introduction
ASR-3100, the world’s first 1U rackmount dual Intel® Xeon® E5-2600 16 x NVMe
SSD Storage Server. ASR-3100 is a 1U rackmount dual Intel® Xeon® E5-2600 v3
storage server, equipped with DDR4-2133 RDIMM up to 512GB and maximum 16 x
2.5” hot-plug NVMe SSD, delivering uncompromised high computing performance.
The incredible high IOPS (Input/Output Operations Per Second) performance of 16
NVMe SSD can achieve up to 6 million IOPS read speeds, which is at least 30% bet-
ter than existing products on the market. ASR-3100 is designed to fulfill markets like
cache/hot data, VDI (Virtual Desktop Infrastructure), advanced data mining, OLTP
(Online Transaction Processing)/ OLAP (Online Analytical Processing) for finance
and eCommerce, 3D rendering, video broadcasting and massive media editing/ post
production.
1.2 Features
1U rackmount with dual Intel® Xeon® E5-2600 v3 processor, DDR4-2133
RDIMM up to 512 GB
Up to 6 million IOPS read speeds with 16 x 2.5” hot-plug NVMe SSD, which is
30% better than existing products on the market
SFF-8639 designed for enterprise use – supports 2.5” PCIe, SAS, SATA
Optimized system power, performance and cooling efficiency with a 1100W 1+1
redundant power supply of 80 PLUS Platinum level
Expandable with 2 *PCIe x8 Gen 3 cards (One is FHHL and the other is HHHL)
and embedded M.2 SATA 6G for OS mirror
Easy management with IPMI LSI Raid management, multiple system LED indi-
cator, and front and rear I/O
Note! Please refer to the release note of each Linux OS for Intel's C612 chip-
set SATA RAID function support.

3 ASR-3100 Series User Manual
Chapter 1 Overview
1.3 System Specifications
Processor
CPU
Dual Intel LGA2011-R3 Xeon processor sockets
Supports Intel Xeon E5-2600 v3 series processor
Supports the processor TDP up to 135 W.
System Memory
Memory Capacity
Intel Xeon processor supports DDR4 memory bus
Total 16 288-pin memory slots provided
Supports total capacity up to 512 GB
4 channels per processor, 2 memory slot per channel
Memory Type Supports DDR4 1600/1866/2133 MHz ECC Registered Modules
Memory Sizes Each memory slot supports 4GB, 8GB, 16GB and 32GB memory
modules
Memory Voltage 1.2 V
Error Detection Corrects single-bit errors
Detects double-bit errors (using ECC memory)
On-board Devices
Chipsets Intel C612 PCH provide 8 PCIe x1 Gen2 lanes
Network Controllers
2 x Intel I210 Gigabit Ethernet Controller connected to C612
through PCIe Gen2 Lane
Above network Supports 10BASE-T, 100BASE-T, and
1000BASE-T, with RJ-45 output
VGA ASPEED AST2400 controller with 64 MB VGA memory provides
basic 2D VGA function.
Super I/O Nuvoton NCT6776D chip provide motherboard,
RS-232 and hardware monitor functions.
BMC Sharing with the RJ45 port of LAN2.
Input / Output
Storage
Up to 16 x 2.5" HDD bays to support NVMe/SAS 12G/SATA 6G
by different SKUs
RAID 0, 1, 5, 10 support (Windows only for Native SATA and
NVMe Drives).
LAN 1 x RJ-45 LAN ports (10/100/1000 Base-T LAN).
USB 4 x USB 3.0 ports at rear window.
2 x USB 2.0 ports at front window.
VGA 1 x D-Sub port
Serial Port 1 connector in rear
Power Supply
Power
80 PLUS Platinum 1+1 redundant power supply
900 W @ 100 ~ 120 V
1100 W @ 200 ~ 240 V
Expansion Slots
PCI-express
2 x PCI-E x8 slot (Gen3 x8 link)
–PCIEX8_SLOT2 on the upper from CPU0 and supports
FHHL card with full height bracket
–PCIEX8_SLOT1 on the bottom from CPU1 and support
HHHL card with full height bracket
System BIOS

ASR-3100 Series User Manual 4
BIOS type 128 Mb SPI Flash EEPROM with AMI BIOS
PC Health Monitoring
Voltage Monitors for CPU Cores, +3.3 V, +5 V, +12 V, +5 V Standby, VBAT
Fan Seven 4-pin 40x56 fan for CPU cooling.
All fans with tachometer status monitoring
Temperature Monitoring for CPU0 & CPU1 (PECI)
Monitoring for System (HWM)
Other Features
(Case Open)
Chassis intrusion detection
Chassis Intrusion header
Operating Environment / Compliance
RoHS RoHS Compliant 6/6 Pb Free
Environmental Spec.
Operating Temperature: 0 to 40° C
Non-operating Temperature: -20 to 60° C
Operating Relative Humidity: 10% to 85% @ 40° C (non-con-
densing)
Non-operating Relative Humidity: 10% to 95% (non-condensing)

5 ASR-3100 Series User Manual
Chapter 1 Overview
1.4 System Layout, LED, Jumpers and Connectors
Connectors on the ASR-3100 are linked to external devices such as 10/100/1000
Ethernet, VGA monitor, and Com port. In addition, ASR-3100 has jumpers that are
used to clean CMOS for BIOS.
The tables below list the functions of each jumper and connector. Later sections in
this chapter give instructions for setting jumpers. Chapter 2 gives instructions for con-
necting external devices to ASR-3100.

ASR-3100 Series User Manual 6
1.4.1 LED Definitions
Front l/O LED
HDD LED
Rear I/O LED (1)
Rear I/O LED(2)
LED State Color Description
Power LED
On Green System is turned on
Blinking Green System is under S1 or S4 state
Off Off Power off
LAN1/LAN2 LED
Blinking Green LAN active
On Green LAN linked
Off Off LAN unlinked
Error LED On Red Fan fail; Over-voltage
Off Off No failure
Location LED On Blue System identified
Off Off System unidentified
HDD status Status LED
Color: Amber
Activity LED
Color: Green
No driver present or power disconnected Off Off
Driver present No activity Off On
Access activity Off Blinking
H D D f a i l O n Off (only work under the
RAID mode)
Identify (locate the HDD) 4HZ Off (only work under the
RAID mode)
SATA/SAS RAID building 1 HZ Off (only work under the
RAID mode)
LED Left LED Right LED Description
LAN1 ~ LAN2 LED
Off Green 10 Mbps linked
Off Blinking Green 10 Mbps Active
Amber Green 100 Mbps linked
Amber Blinking Green 100 Mbps Active
Green Green 1000 Mbps linked
Green Blinking Green 1000 Mbps Active
Off Off No Link
Error LED On Red Fan fail; Over voltage
Off Off No failure
Location LED On Blue System identified
Off Off System unidentified

7 ASR-3100 Series User Manual
Chapter 1 Overview
1.4.2 Jumpers
1.4.3 Connectors
Power module LED
Blinking Red No AC power to this module
Blinking Blue AC present standby output on
On Red Power supply failure
On Blue Power supply DC output ON and OK
Off Off No AC power to power module
Label Function Default
JCMOS1 CMOS clear 1-2
JME1 ME update 1-2
1
1
Keep CMOS data / Disable ME update Clear CMOS data / Enable ME update
CPU0 Intel LGA2011-R3 CPU0 socket
CPU1 Intel LGA2011-R3 CPU1 socket
SYSFAN1 ~ SYSFAN3/
SYSFAN5 ~ SYSFAN8 System fan connector (4-pin)
DIMMA1 Channel A DIMM1 of CPU0
DIMMA2 Channel A DIMM2 of CPU0
DIMMB1 Channel B DIMM1 of CPU0
DIMMB2 Channel B DIMM2 of CPU0
DIMMC1 Channel C DIMM1 of CPU0
DIMMC2 Channel C DIMM2 of CPU0
DIMMD1 Channel D DIMM1 of CPU0
DIMMD2 Channel D DIMM2 of CPU0
DIMME1 Channel E DIMM1 of CPU0
DIMME2 Channel E DIMM2 of CPU0
DIMMF1 Channel F DIMM1 of CPU0
DIMMF2 Channel F DIMM2 of CPU0
DIMMG1 Channel G DIMM1 of CPU0
DIMMG2 Channel G DIMM2 of CPU0
DIMMH1 Channel H DIMM1 of CPU0
DIMMH2 Channel H DIMM2 of CPU0
BMC1 IPMI module connector
SSD0-1 NVMe SSD 0 and SSD 1 connector
SSD2-3 NVMe SSD 2 and SSD 3 connector
SSD4-5 NVMe SSD 4 and SSD 5 connector
SSD6-7 NVMe SSD 6 and SSD 7 connector
SSD8-9 NVMe SSD 8 and SSD 9 connector
SSD10-11 NVMe SSD 10 and SSD 11 connector

ASR-3100 Series User Manual 8
1.5 Block Diagram
1.6 System Memory
ASR-3100 has 288-pin memory slots x16 for DDR4 1600/1866/2133 MHz memory
modules with maximum capacity of 512 GB (Maximum 32 GB for each DIMM). ASR-
3100 supports registered DIMMs ONLY.
SSD12-13 NVMe SSD 12 and SSD 13 connector
SSD14-15 NVMe SSD 14 and SSD 15 connector
SATA_CON1 8 ports SATA Drive connector
SATA4 M.2 2242 SATA Drive connector
SATA5 M.2 2242 SATA Drive connector
PCIEX16_SLOT1 PCIe x16 slot for two x8 riser card (Gen3 x 8 link from both CPU0
and CPU1)
LPC1 LPC port for debug
VGA1/COM1 VGA and Com port connector
SMBUS1 SMbus from PCH
USB 4_1 Front Panel one USB 2.0 port
LAN1 10/100/1000 Mbps LAN
LAN2 10/100/1000 Mbps LAN/BMC LAN port
USB0_1 Rear two USB 3.0 port
USB2_3 Rear two USB 3.0 port

9 ASR-3100 Series User Manual
Chapter 1 Overview
1.7 Memory Installation Procedures
Single processor installed
(CPU0)
Dual processor installed
(CPU0 & CPU1)
12345678 12345678
DIMMA1VVVVVVVV VVVVVVVV
DIMMA2 VVVVVVV VVVVVVV
DIMMB1 VVVVVV VVVVVV
DIMMB2
VVVVV VVVVV
DIMMC1 V V V V V V V V
DIMMC2
VVV VVV
DIMMD1
VV VV
DIMMD2
VV
DIMME1 VVVVVVVV
DIMME2 VVVVVVV
DIMMF1
VVVVVV
DIMMF2 VVVVV
DIMMG1 V V V V
DIMMG2 VVV
DIMMH1
VV
DIMMH2 V
