Advantech MARS-3100-CRADLE Installation and operation manual

MARS-3100-CRADLE Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
Cradle for MARS-3100 x1
VESA Mount screw x4
VESA Mount copper stub x4
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note: The adapter is not contained in this packing list.
please use the adapter with the MARS-3100 unit.
1.
2.
3.
MARS-3100-CRADLE
Startup Manual
Dimensions: (H x W x D): 245mm (9.6”) x 300mm(11.8”)
x 55mm (2.2”)
VESA mount: 75 mm x 75 mm standard VESA mount
USB 2.0 x 1 on the front and USB 2.0 x 2 on the back
VGA x1
Audio out x1
DC in x1 for 19Vdc only
Note: The VGA output signal will switch from system
side to cradle side automatically when MARS-
3100 is docking on the cradle.
Start to Use
Before you start to use this cradle, please remove the
power adapter on MARS-3100 unit.
Caution: The cradle and MARS-3100 unit may damage if
the power adapters are both plug in MARS-3100
unit and cradle.
Figure1: Remove the adapter from MARS-3100 unit
1.
2.
3.
4.
5.
6.
1.
Specications
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/epc
For technical support and service, please visit our
support website at:
http://service.advantech.com.tw/eservice/
This manual is for the MARS-3100-CRADLE.
Part No. 2006310020 1st Edition,
Sep 2008

2 MARS-3100-CRADLE Startup Manual
Plug the power adapter with 19Vdc to the cradle DC-in
jack.
Note: The cradle will supply power to the MARS-3100
unit and the 3x USB port on the cradle.
Note: The battery will also be charged if the MARS-
3100 unit is put on the cradle.
Figure2: Plug the adapter on the cradle.
Note: The 19Vdc power adapter is not contained in this
packing list. Please use the adapter which use
on MARS-3100 unit.
Close the DC-in jack door on the MARS-3100 unit.
Figure3: Close the DC-in jack door on the MARS-3100 unit
Figure 4: Close the door to prevent mis-operation
2.
3.
Note: If the door is not close well, the mechanical
interference will happen.
Figure 5: Correct. The door is closed and no interference.
Lift the hook before insert the MARS-3100 unit.
Figure 6: Lift up the hook.
Put the MARS-3100 unit on the cradle.
Figure 7: The MARS-3100 unit is sit on the cradle
4.
5.

MARS-3100-CRADLE Startup Manual 3
Installing VESA Mounting
The MARS-3100-CRADLE also provides standard VESA
mounting to help system integrators conveniently integrate
into their systems.
To prevent the unstable mounting of MARS-3100-CRADLE,
never use mounting brackets other than those provided by
Advantech. VESA mount installation should be done by a
professional technician; please contact the service techni-
cian or your retail vendor if you need this service.
Step1
Step2
Step3
Warning! Be sure to secure the screws of the mounting
bracket tightly. A loose joint between the MARS-
3100-CRADLE and the mounting bracket could
cause risk of injury!
Push back the hook and the hook will be locked until
you hear “CLICK”.
Figure 8. The cradle is already locked the MARS-3100 unit.
Caution: The hook may loosen if it is not locked. And it
may damage the MARS-3100 unit.
Release the hook. Press the button on the back of the
hook and lift up the hook. Then you can release the
MARS-3100 unit.
Figure 9: Press the button and release the MARS-3100 unit
FCC
This device complies with the requirements in Part 15 of
the FCC rules. Operation is subject to the following two
conditions.
This device may not cause harmful interference.
This device must accept any interference received,
including interference that may cause undesired opera-
tion.
6.
7.
1.
2.
Press
Release
