NCR 1668-2000 User manual

INSTALLATION GUIDE
NCR 1668-2000 iPad Stand (7641)
Release 1.0
B005-0000-2323
Issue A

The product described in this document is a licensed product of NCR Corporation.
NCR is a registered trademark of NCR Corporation. NCR RealPOS is a trademark of NCR Corporation in the United States
and/or other countries. Other product names mentioned in this publication may be trademarks or registered trademarks of their
respective companies and are hereby acknowledged.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks
of HDMI Licensing LLC in the United States and other countries.
Where creation of derivative works, modifications or copies of this NCR copyrighted documentation is permitted under the terms
and conditions of an agreement you have with NCR, NCR's copyright notice must be included.
It is the policy of NCR Corporation (NCR) to improve products as new technology, components, software, and firmware become
available. NCR, therefore, reserves the right to change specifications without prior notice.
All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances,
photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR
office for information that is applicable and current.
To maintain the quality of our publications, we need your comments on the accuracy, clarity, organization, and value of this book.
Please use the link below to send your comments.
EMail: [e-mail]
Copyright © 2013
By NCR Corporation
Duluth, GA U.S.A.
All Rights Reserved
Revision Record
Issue Date Remarks
AOct 2013 First Issue

NCR 1668-2000 iPad Stand
Introduction
The NCR 1668-2000 iPad Stand provides mounting hardware remote mount an Apple
iPad. An Allen wretch is included for display angle adjustment.

2 NCR 1668-2000 iPad Stand
Display Viewing Adjustments
The Display Bracket can be rotated to display the iPad horizontally or vertically.
The Display Bracket can also be tilted 180 degrees from front to rear for customer
viewing/input.

NCR 1668-2000 iPad Stand 3
Installing the iPad
The iPad Bracket is spring loaded.
1. Loosen the thumbscrew on the iPad Bracket.

4 NCR 1668-2000 iPad Stand
2. Insert the edge of the iPad onto the bottom half of the bracket and press down to
spread the bracket apart sufficiently to accept the iPad.
3. Insert the top edge of the iPad into the top of the bracket and then allow the spring
tension of the bracket to grasp the iPad.
4. Secure the bracket by tightening the thumbscrew.

NCR 1668-2000 iPad Stand 5
NCR Mobile Gateway Controller Integration
The stand can be used to integrate the iPAD on the NCR Mobile Gateway Controller.
The stand is secured with two screws into the top of the MGC (includedwith the MGC).
Note: There are two sets of screw holes in the top of the MGC, which facilitates
mounting the display to face the front or rear of the MGC.
