ADVANTEST R3264 User manual

MANUAL NUMBER
CPrinted in Japan
ADVANTEST CORPORATION
All rights reserved.
R3267 Series OPT11
3GPP Level Calibration
Operation Manual
FOE-8370635B01
First printing December 25, 2000
Applicable
R3264
R3267
R3273
2000
Cover

No. ESF00
Safety-1
Safety Summary
To ensure thorough understanding of all functions and to ensure efficient use of this instrument, please read the
manual carefully before using. Note that Advantest bears absolutely no responsibility for the result of operations
caused due to incorrect or inappropriate use of this instrument.
If the equipment is used in a manner not specified by Advantest, the protection provided by the equipment may
be impaired.
• Warning Labels
Warning labels are applied to Advantest products in locations where specific dangers exist. Pay
careful attention to these labels during handling. Do not remove or tear these labels. If you have
any questions regarding warning labels, please ask your nearest Advantest dealer. Our address
and phone number are listed at the end of this manual.
Symbols of those warning labels are shown below together with their meaning.
DANGER: Indicates an imminently hazardous situation which will result in death or serious
personal injury.
WARNING: Indicates a potentially hazardous situation which will result in death or serious
personal injury.
CAUTION: Indicates a potentially hazardous situation which will result in personal injury or
a damage to property including the product.
• Basic Precautions
Please observe the following precautions to prevent fire, burn, electric shock, and personal inju-
ry.
• Use a power cable rated for the voltage in question. Be sure however to use a power cable
conforming to safety standards of your nation when using a product overseas.
• When inserting the plug into the electrical outlet, first turn the power switch OFF and then
insert the plug as far as it will go.
• When removing the plug from the electrical outlet, first turn the power switch OFF and then
pull it out by gripping the plug. Do not pull on the power cable itself. Make sure your hands
are dry at this time.
• Before turning on the power, be sure to check that the supply voltage matches the voltage
requirements of the instrument.
• Be sure to plug the power cable into an electrical outlet which has a safety ground terminal.
Grounding will be defeated if you use an extension cord which does not include a safety
ground terminal.
• Be sure to use fuses rated for the voltage in question.
• Do not use this instrument with the case open.
• Do not place objects on top of this product. Also, do not place flower pots or other containers
containing liquid such as chemicals near this product.
Safety Summary

Safety Summary
Safety-2
• When the product has ventilation outlets, do not stick or drop metal or easily flammable ob-
jects into the ventilation outlets.
• When using the product on a cart, fix it with belts to avoid its drop.
• When connecting the product to peripheral equipment, turn the power off.
• Caution Symbols Used Within this Manual
Symbols indicating items requiring caution which are used in this manual are shown below to-
gether with their meaning.
DANGER: Indicates an item where there is a danger of serious personal injury (death or seri-
ous injury).
WARNING: Indicates an item relating to personal safety or health.
CAUTION: Indicates an item relating to possible damage to the product or instrument or relat-
ing to a restriction on operation.
• Safety Marks on the Product
The following safety marks can be found on Advantest products.
: ATTENTION - Refer to manual.
: Protective ground (earth) terminal.
: DANGER - High voltage.
: CAUTION - Risk of electric shock.
• Replacing Parts with Limited Life
The following parts used in the instrument are main parts with limited life.
Replace the parts listed below after their expected lifespan has expired.
Note that the estimated lifespan for the parts listed below may be shortened by factors such as
the environment where the instrument is stored or used, and how often the instrument is used.
The parts inside are not user-replaceable. For a part replacement, please contact the Advantest
sales office for servicing.
There is a possibility that each product uses different parts with limited life. For more informa-
tion, refer to Chapter 1.

Safety Summary
Safety-3
Main Parts with Limited Life
• Hard Disk Mounted Products
The operational warnings are listed below.
• Do not move, shock and vibrate the product while the power is turned on.
Reading or writing data in the hard disk unit is performed with the memory disk turning at a
high speed. It is a very delicate process.
• Store and operate the products under the following environmental conditions.
An area with no sudden temperature changes.
An area away from shock or vibrations.
An area free from moisture, dirt, or dust.
An area away from magnets or an instrument which generates a magnetic field.
• Make back-ups of important data.
The data stored in the disk may become damaged if the product is mishandled. The hard disc
has a limited life span which depends on the operational conditions. Note that there is no
guarantee for any loss of data.
• Precautions when Disposing of this Instrument
When disposing of harmful substances, be sure dispose of them properly with abiding by the
state-provided law.
Harmful substances: (1) PCB (polycarbon biphenyl)
(2) Mercury
(3) Ni-Cd (nickel cadmium)
(4) Other
Items possessing cyan, organic phosphorous and hexadic chromium
and items which may leak cadmium or arsenic (excluding lead in sol
der).
Example: fluorescent tubes, batteries
Part name Life
Unit power supply 5 years
Fan motor 5 years
Electrolytic capacitor 5 years
LCD display 6 years
LCD backlight 2.5 years
Floppy disk drive 5 years

Environmental Conditions
Safety-4
This instrument should be only be used in an area which satisfies the following conditions:
• An area free from corrosive gas
• An area away from direct sunlight
• A dust-free area
• An area free from vibrations
Figure-1 Environmental Conditions
• Operating position
Figure-2 Operating Position
• Storage position
Figure-3 Storage Position
This instrument can be used safely under the following conditions:
• Altitude of up to 2000 m
• Installation Categories II
• Pollution Degree 2

























Vibration
Direct sunlight
Corrosive
gas
Dust
Front
Keep at least 10 centimeters of space
between the rear panel and any other
surface
Front
This instrument should be stored in a horizontal
position.
When placed in a vertical (upright) position for
storage or transportation, ensure the instrument is
stable and secure.
-Ensure the instrument is stable.
-Pay special attention not to fall.

R3267 Series OPT11 3GPP Level Calibration Operation Manual
C-1
TABLE OF CONTENTS
1. INTRODUCTION
....................................................................................... 1-1
1.1 Product Description ........................................................................................... 1-1
1.2 Accessories ........................................................................................................ 1-1
1.3 Precautions in Use ............................................................................................. 1-1
1.4 Calibration ......................................................................................................... 1-2
2. OPERATION
................................................................................................ 2-1
2.1 3GPP Level Calibration Data and the Setting Conditions ................................ 2-1
2.2 Using 3GPP Level Calibration Data ................................................................. 2-2
2.3 Measurement Sample ........................................................................................ 2-3
3. REFERENCE
................................................................................................ 3-1
3.1 Menu Index ....................................................................................................... 3-1
3.2 Menu Map ......................................................................................................... 3-2
3.3 Functional Description ...................................................................................... 3-2
3.3.1 STD Menu .................................................................................................. 3-2
4. REMOTE PROGRAMMING
................................................................... 4-1
4.1 GPIB Command Index ...................................................................................... 4-1
4.2 GPIB Command Codes ..................................................................................... 4-2
5. PERFORMANCE VERIFICATION TEST
.......................................... 5-1
5.1 GENERAL ........................................................................................................ 5-1
5.1.1 Introduction ................................................................................................ 5-1
5.1.2 Test Equipment ........................................................................................... 5-1
5.1.3 Performance Verification Test Record Sheet ............................................. 5-2
5.1.4 Performance Verification Procedure .......................................................... 5-3
5.2 Performance Verification Test Procedure ......................................................... 5-4
5.2.1 Level Calibration ........................................................................................ 5-4
5.3 Performance Verification Test Record Sheet .................................................... 5-8
6. SPECIFICATIONS
...................................................................................... 6-1
APPENDIX................................................................................................................. A-1
A.1 Error Message List............................................................................................. A-1
ALPHABETICAL INDEX..................................................................................... I-1
TABLE OF CONTENTS

F-1
R3267 Series OPT11 3GPP Level Calibration Operation Manual
LIST OF ILLUSTRATIONS
No. Title Page
1-1 Installed Option Labels ..................................................................................................... 1-1
2-1 2 GHz Modulation Signal Measurement Sample
(Using the 3GPP Level Calibration Function) .................................................................. 2-4
5-1 Setup of Level Calibration Test ........................................................................................ 5-5

T-1
R3267 Series OPT11 3GPP Level Calibration Operation Manual
LIST OF TABLES
No. Title Page
2-1 Frequency Range for 3GPP Level Calibration Data and the Frequency .......................... 2-1
2-2 Setting Conditions Used for 3GPP Level Calibrations ..................................................... 2-1
4-1 3GPP Level Calibration (OPT11) ..................................................................................... 4-2
5-1 Equipment List .................................................................................................................. 5-2
5-2 List for SG and PM Correction Data Setting .................................................................... 5-6
5-3 Setting of SG and R3267 Series ....................................................................................... 5-7

R3267 Series OPT11 3GPP Level Calibration Operation Manual
1. INTRODUCTION
1-1
1. INTRODUCTION
This chapter includes a product overview, information on the accessories, and notes on using this option and
the calibration intervals.
1.1 Product Description
This option is designed to improve the Tx power measurement level accuracy in the 2 GHz band (1.8483
GHz to 2.1717 GHz) when the 3GPP level calibration option (OPT 11) is installed in the R3267 Series Spec-
trum Analyzer.
1.2 Accessories
1.3 Precautions in Use
1. Option labels
The number 11 is written on the INSTALLED OPTION NO label attached to the rear panel when the
3GPP calibration option is installed in the R3267 Series.
Figure 1-1 Installed Option Labels
Name of accesories Type of name Quantitiy Remarks
R3267 Series OPT11
Operation manual ER3267/73OPT11 1English
Installed options
are indicated

R3267 Series OPT11 3GPP Level Calibration Operation Manual
1.4 Calibration
1-2
2. Performing a calibration
A calibration must be performed in order to improve the level accuracy of Tx Power measurement using
the 3GPP level calibration function.
CAUTION: The R3267 Series should be warmed up for at least 60 minutes before performing a calibration
for OPT 11.
a. Performing CAL ALL
Performs calibrations for all items according to the specifications for each item.
Be sure to calibrate the instrument using the procedure below before making measurements.
1. Connect the A01036-0150 cable that comes with the R3267 Series to the 30 MHz
CAL OUT connector and the INPUT connector.
2. Press SHIFT, 7(CAL) and Cal All.
Cal All is performed (this takes approx. 9 minutes).
b. Performing Gain Cal
Performs a calibration for the Tx power measurement.
Perform this calibration when an ambient temperature changes.
1. Connect the A01036-0150 cable that comes with the R3267 Series to the 30 MHz
CAL OUT connector and the INPUT connector.
2. Press TRANSIENT, STD and Gain Cal.
Gain Cal is performed (this takes approx. 20 seconds).
1.4 Calibration
When you want to calibrate the analyzer, please contact a sales representative.
Desirable Period 1 year

R3267 Series OPT11 3GPP Level Calibration Operation Manual
2. OPERATION
2-1
2. OPERATION
This chapter describes 3GPP level calibration data and setting conditions, operating methods and provides
measurement examples.
2.1 3GPP Level Calibration Data and the Setting Conditions
Table 2-1 shows the frequency range for 3GPP level calibration data and the frequency interval between cal-
ibrations.
Table 2-2 shows the setting conditions used for 3GPP level calibrations.
Table 2-1 Frequency Range for 3GPP Level Calibration Data and the Frequency
Frequency range Frequency interval between calibrations
1.8483 GHz to 2.1717 GHz 6.6 MHz
Table 2-2 Setting Conditions Used for 3GPP Level Calibrations
Item Setting
Input attenuator 10 dB to 50 dB
Tx Power measurement Root Nyquist OFF
Averaging times: 5
Number of calibrated points 50 points

R3267 Series OPT11 3GPP Level Calibration Operation Manual
2.2 Using 3GPP Level Calibration Data
2-2
2.2 Using 3GPP Level Calibration Data
Select whether or not 3GPP level calibration data is used.
NOTE: The initial setting after the PRESET sets Level Cal Correction to ON.
1. Press TRANSIENT and STD.
The menu that includes STD is displayed.
2. Press Level Cal Correction ON/OFF.
ON: 3GPP level calibration data is used for the measurement.
OFF: 3GPP level calibration data is not used for the measurement.

R3267 Series OPT11 3GPP Level Calibration Operation Manual
2.3 Measurement Sample
2-3
2.3 Measurement Sample
A method of measuring 2-GHz modulation signal Tx power, which uses 3GPP level calibration data, is
explained in this sample.
Resetting the settings
1. Press SHIFT and CONFIG(PRESET).
The initial settings are read.
Setting the measurement condition
2. Press FREQ, 2and GHz.
The center frequency is set to 2 GHz.
Level calibration for the R3267 Series
3. Connect the A01036-0150 cable that comes with the R3267 Series to the 30 MHz
CAL OUT connector and the INPUT connector.
4. Press TRANSIENT, STD and Gain Cal.
Gain Cal is performed (this takes approx. 20 seconds).
The level is automatically calibrated for the R3267 Series.
5. Input a modulation signal to the INPUT connector on the R3267 Series.
6. Press TRANSIENT, Modulation, Power, Tx Power and Auto Level Set.
The reference level is automatically set.

R3267 Series OPT11 3GPP Level Calibration Operation Manual
2.3 Measurement Sample
2-4
7. Press SINGLE.
The modulation signal power is measured.
The level of the modulation signal is displayed on the R3267 Series screen.
Figure 2-1 2 GHz Modulation Signal Measurement Sample (Using the 3GPP
Level Calibration Function)

R3267 Series OPT11 3GPP Level Calibration Operation Manual
3. REFERENCE
3-1
Operation Key Pages
3. REFERENCE
This chapter describes the keys used with the 3GPP level calibration option (OPT 11).
For information on the other keys, refer to Section 3.3, “Functional Description” in R3267 Series Spectrum
Analyzer Operation Manual.
3.1 Menu Index
Level Cal Correction ON/OFF ................ 3-2
STD.......................................................... 3-2
TRANSIENT........................................... 3-2

R3267 Series OPT11 3GPP Level Calibration Operation Manual
3.2 Menu Map
3-2
3.2 Menu Map
3.3 Functional Description
This section describes the keys used with the 3GPP level calibration option (OPT 11).
3.3.1 STD Menu
Press the TRANSIENT and STD keys displays Level Cal Correction ON/OFF is displayed.
Level Cal Correction ON/OFF Toggles the level correction function on or off.
ON: 3GPP level calibration data is used for the measure-
ment.
OFF: 3GPP level calibration data is not used for the measure-
ment.
TRANSIENT
STD Level Cal Correction ON/OFF

R3267 Series OPT11 3GPP Level Calibration Operation Manual
4. REMOTE PROGRAMMING
4-1
GPIB Command Pages
4. REMOTE PROGRAMMING
A list of GPIB codes required for remote control is shown in this section.
4.1 GPIB Command Index
This GPIB command index can be used as the index for this Chapter.
LCALCORR OFF.................................... 4-2
LCALCORR ON ..................................... 4-2

R3267 Series OPT11 3GPP Level Calibration Operation Manual
4.2 GPIB Command Codes
4-2
4.2 GPIB Command Codes
The following table list the GPIB commands by function.
Table 4-1 3GPP Level Calibration (OPT11)
Function Listener Code Talker Request
Code Output Format
Level Cal
Correction Level Cal Correction
ON LCALCORR ON LCALCORR? 0: OFF
OFF LCALCORR OFF 1: ON

R3267 Series OPT11 3GPP Level Calibration Operation Manual
5. PERFORMANCE VERIFICATION TEST
5-1
5. PERFORMANCE VERIFICATION TEST
A list of GPIB codes required for remote control is shown in this section.
5.1 GENERAL
5.1.1 Introduction
This chapter provides R3267 Series OPT11 performance verification test procedures.
5.1.2 Test Equipment
The Table 5-1 lists recommended test equipment.
The equipment needed to perform all of the performance test.
Equipment lists for individual tests are provided in each performance verification test.
CAUTION:
1. The R3267 Series with OPT 11 to be tested should be warm up for at least 60 minutes before starting test.
2. Make sure that the test equipment used meets its own published specifications.
3. Any equipment that meets the critical specifications given in the table can be substituted for recommended
models.

R3267 Series OPT11 3GPP Level Calibration Operation Manual
5.1.3 Performance Verification Test Record Sheet
5-2
5.1.3 Performance Verification Test Record Sheet
The performance verification test record sheet and performance check record sheet is provided at the end
of this chapter.
The test record lists test specification and acceptable limits.
Recommend that make a copy of this table, record the complete test results on the copy, and keep the copy
for calibration test record.
This record could prove invaluable in tracking gradual changes in test result over long period of time.
Table 5-1 Equipment List
No. Description Critical Specifications Recommended
Model Manufacturer Notes
1RFPower
Meter & RF
Power Sensor
Frequency Range: 10 MHz to 3.0 GHz
Power Range: 1 µW to 100 mW
VSWR: ≤1.1
Measurement accuracy: < 0.08 dB
Note: Must be calibrated in advance.
NRVS & NRV-
Z52 Rohde & Schwarz PM/PS
2 Signal Genera-
tor Frequency Range: 10 MHz to 3.0 GHz Output Level: -15 dBm to +10 dBm
Aging Rate: 1 x 10 exp-6/year
SMP03 equipped
Option B11 Rohde & Schwarz SG
3 RF Cable Impedance: 50 Ω
Connector Type: SMA(m)-SMA(m)
Frequency Range: DC to 3.0 GHz
VSWR: ≤1.1
Length: 0.7 m approx.
A01002 Advantest RF_CBL1
4 RF Cable Impedance: 50 Ω
Connector Type: BNC(m)-BNC(m)
Length: 15 cm approx.
A01036-0150 Advantest RF_CBL2
5 RF Cable Impedance: 50 Ω
Connector Type: BNC(m)-BNC(m) A01037-1500 Advantest
6 Adapter Type N(f)-SMA(f) 31 N-SMA-50-1/1 HUBER+
SUHNER Adap_1
7 Adapter Type N(m)-SMA(f) HRM-554S Advantest Adap_2
8 Adapter Type N(m)-BNC(f) JUG-201A-U Advantest Adap_3
