PixLite E16-S Mk3 Quick Start Guide
1 - Physical Connections
In order to connect to the PixLite E16-S Mk3, there must be a working power supply
between 5 – 24Vdc connected to the power input, which is the small screw terminal
marked “+” & “-”. The screws should be loosened for wire insertion and then tightened
again, providing a highly robust and secure connection. Polarity for the connector is
clearly marked on the lid.
Figure 1: Connection Points

- 2 -
www.advateklights.com PixLite E16-S Mk3 Quick Start Guide V20220722
2 - Startup & Network Connection
2.1 - Startup
Upon startup for the first time, the PixLite will be using DHCP/AutoIP and the status LED
will flash green, indicating normal operation. If you have a router, then DHCPwill
automatically assign an IPaddress to both the PixLite and your computer.
No Router? No Problem. Simply connect the PixLite directly to your computer, and
open Advatek Assistant 3.
2.2 - Advatek Assistant 3
The easiest method for connecting to the PixLite E16-S Mk3 is by launching Advatek
Assistant 3 to discover the device. Advatek Assistant 3 can be downloaded and
installed, using the URLbelow:
www.advateklights.com/advatek-assistant-3
Any active PixLite devices on the network will automatically be discovered and
displayed. Double click to open its Management Interface, and begin configuring your
new PixLite E16-S Mk3.
Figure 2: Advatek Assistant 3

- 3 -
www.advateklights.com PixLite E16-S Mk3 Quick Start Guide V20220722
3 - Further Information
For a more in-depth understanding of the device, including physical installation,
electrical connections, network connections, operation, and specifications, you
should consult the PixLite E16-S Mk3 User Manual:
www.advateklights.com/downloads/user-manuals/pixlite-e16-s-mk3
To learn how the Management Interface can be used for management, configuration,
and monitoring the device's performance, see the PixLite Mk3 Management Guide:
www.advateklights.com/downloads/user-manuals/pixlite-mk3-management-guide
4 - Advatek SHOWTime
Advatek SHOWTime™ unleashes the potential of Advatek PixLite® Mk3 devices to
independently drive light shows without a computer or any source of live data.
SHOWTime™ allows users to record and play back pixel shows from the PixLite E16-S
Mk3 using the inbuilt microSD slot. Design your own breathtaking pixel shows, record
them directly onto the microSD card and play them back as many times as you wish.
SHOWTime™ also unlocks the ability to create up to 25 powerful triggers and use
advanced intensity controls to enable true standalone behavior and enhance live
environments.
For more information, download the PixLite Mk3 Management Guide here:
www.advateklights.com/downloads/user-manuals/pixlite-mk3-management-guide
5 - Warranty Registration
For your complete peace of mind, this PixLite E16-S Mk3 comes with an industry
leading extended warranty period of 5 years, subject to registration.
Please register your Advatek PixLite® Mk3 product using the link below.
www.advateklights.com/warranty-registration
All products need to be used and installed in accordance with their designed purpose
and operating environment. See our Store Policy below for full terms and conditions
on returns, faults and warranty claims.
www.advateklights.com/store-policy
