ADX FIREBASE CC23 User manual

FIREBASE CC23
Cockpit Racing Chair
INSTRUCTION MANUAL
ADXCPCH23

2
Safety Warnings
Read all the instructions carefully before using the unit and keep them for future reference.
Retain the manual. If you pass the unit onto a third party, make sure to include this safety and the
instructions manual.
Caution!
• After unpacking, make sure the product is complete and undamaged.
• Keep all packaging material (plastic bags, polystyrene foam) out of reach of children.
• Use the product on a at surface.
• Do not use the product in case of obvious damage.
Warnings!
• Only use this product when fully assembled.
• Do not overload your chair.
• Do not tilt the chair or lean over the sides – always ensure all casters are rmly placed on a
level surface.
• Children should not play with the chair.
• Do not sit on the armrests.
• Do not lean over the armrests. This could cause the product to become unbalanced and result
in injury.
• Always use the chair on a at, stable surface to prevent injury.
• Do not use on slippery oor.
• Do not stand on the chair.
• If the damaged product is irreparable please dispose of the product. Using a damaged product
may lead to personal injury.
• This product is intended for indoor household use.
• Do not put your ngers into the gaps of revolving parts.
• Fastening parts and wearing parts should regularly be checked for tightness and abrasion.
• To clean the unit, wipe the surface with a slightly moist, lint-free cloth.
• Do not use any cleaning uids containing alcohol, ammonia or abrasives.
• Keep the original packaging for any future transporting requirements.
• Instruction manual needs to be kept for further inquires and references.
• Do not leave your child unsupervised.
• Fully extend the expandable poles after placing the chair on the oor.
• After folding the unit, make sure that it is securely bound with the holding strap.
• While unlocking the steering wheel stand, make sure that the steering wheel support is
securely locked.
• Secure the locks after making any adjustments.
• Make sure that user is out of the unit while adjusting the seat position.

3
CUSTOMER HELPLINE (UK Customers Only)
0344 561 1234
110 kg
1035 mm ±20mm
550 mm
550 m - 856 mm
280 mm
550 mm - 925 mm ±20mm
1260 mm - 1635 mm ±20mm

4
Elastic band
(for binding the foot pedals)
Hook-and-loop fastener × 3
(for binding the cables of
other gaming devices)
Gaming Chair Instruction Manual
Instruction
Manual
Thank you for purchasing your new product.
We recommend that you spend some time reading this instruction
manual in order that you fully understand all the operational features
it oers. You will also nd some hints and tips to help you resolve any
issues.
Read all the safety instructions carefully before use and keep this
instruction manual for future reference.
Unpacking
Remove all items from the packaging. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:

5
Unfold the Gaming Chair
Fold back the Gaming Chair
After folding, make sure that it is securely bound with the holding strap.

6
Seat Adjustments
1
1
1
2
2
2
Fully extend the expandable
poles after placing the chair
on the oor.
Make sure that user is out of the unit
while adjusting the seat position.

7
Steering Wheel (not included) Adjustment
1
2
Hold the steering wheel
while adjusting its angle.
* Steering wheel and foot pedals are not included.

8
180°
Unlock the Steering Wheel Stand
2
1
2
1
After unlocking, insert the
stopper to x the position
of the metal bar of the
steering wheel support.

9
1
Fold the Gaming Chair with Steering Wheel
(not included) installed
2
3
1
2
1
2
3
Lay down the unit on the oor for
the above folding step.

10
For saving space, slide the steering wheel back before folding the unit.
Unfold the Gaming Chair with Steering Wheel
(not included) installed
2
1
1
2
3
4
Lay down the unit on the oor before unfolding the unit.
1
Storage Tips

11
2
1
2
3
4
2
1
3
Fix the foot pedals (not included)
onto the unit with the provided
elastic band.
Make sure that the steering
wheel support is securely locked
after adjustment.
