RiverRidge Prescott 06-163 User manual

ASSEMBLY INSTRUCTIONS
INSTRUCCIONES DE ENSAMBLAJE
INSTRUCTIONS D’ASSEMBLAGE
MONTAGEANLEITUNGEN
RiverRidge® Prescott Tall Cabinet
RiverRidge® Gabinete alto Prescott
RiverRidge® Armoire haute Prescott
RiverRidge® Hochschrank Prescott
06-163 - White, Blanco, Blanc, Weiß
RiverRidge® is a registered trademark of Sourcing Solutions, Inc., Hudson, WI 54016, USA
RiverRidge® es una marca comercial registrada de Sourcing Solutions, Inc., Hudson, WI 54016, USA
RiverRidge® est une marque déposée de Sourcing Solutions, Inc., Hudson, WI 54016, USA
RiverRidge® ist ein eingetragenes Warenzeichen der Sourcing Solutions, Inc. mit Sitz in Hudson, WI 54016, USA

WARNING
ADULT ASSEMBLY REQUIRED:
This product requires assembly by an adult because of small parts. Care should be taken in
unpacking and assembling this item to keep small parts away from children. During assembly
children should be kept away from the product due to possible risk of injury.
SERIOUS OR FATAL INJURIES CAN OCCUR FROM FURNITURE TIP-OVER.
IN ORDER TO PREVENT OVERTURNING, THIS PRODUCT MUST BE USED WITH
THE TIP-OVER RESTRAINTS OR WALL MOUNTING HARDWARE PROVIDED.
PLEASE READ WARNINGS BELOW.
•Product must be assembled exactly per these instructions. Failure to follow assembly
instructions may result in possible risk of injury.
•Young children can be seriously injured or killed if furniture tips over. Install tip-over
restraint provided. Use of tip-over restraints may only reduce, but not eliminate, the risk
of tip-over.
•To help prevent furniture from tip-over or fall, this product must be secured to the wall
using enclosed tip-over restraints or wall mounting hardware.
•Tip-over restraints and wall mounting hardware are provided with this product, however,
you may need to source suitable hardware for your wall type. If in doubt, please consult
a qualified tradesperson.
•Always check the suitability of the wall to ensure the tip-over restraints or wall mounting
hardware will resist the forces applied to it.
•Always ensure any wall used for tip-over restraints or wall mounting hardware is free
from hidden electrical wires, water, or gas pipes.
•Do not use this item for a TV stand or place heavy objects on top of item.
•Place heaviest items in the lowest drawers or shelves.
•Never allow children to climb or hang on to the drawers, doors, or shelves.
•Never open more than one drawer at a time or defeat/remove any drawer interlock
system.
Weight Capacity: This product will hold up to 5 pounds (2.3kgs) per shelf and 5 pounds (2.3kgs)
per drawer for a total weight of 35 pounds (15.9kgs). Please do not overload product for risk of
damage and/or serious injury or death.

ADVERTENCIA
REQUIERE QUE UN ADULTO REALICE EL ENSAMBLAJE:
Este producto requiere que un adulto lleve a cabo el ensamblaje debido a las piezas
pequeñas. Debe tener cuidado al desempacar y ensamblar este artículo para mantener
las piezas pequeñas alejadas de los niños. Los niños deben mantenerse alejados
del producto durante el ensamblaje debido al posible riesgo de lesiones.
LA CAÍDA DE LOS MUEBLES PUEDE OCASIONAR LESIONES GRAVES O FATALES.
A FIN DE EVITAR ESTA SITUACIÓN, ESTE PRODUCTO DEBE SER UTILIZADO CON
LAS SUJECIONES ANTIVUELCO O LOS HERRAJES DE PARED SUMINISTRADOS.
LEA LAS SIGUIENTES ADVERTENCIAS.
•Ensamble el producto exactamente como se indica en estas instrucciones. Si no se siguen
estas instrucciones, existen riesgos de lesiones.
•Si los muebles se caen, los niños pequeños pueden sufrir lesiones graves o la muerte.
Instale el sistema antivuelco provisto. El uso del sistema antivuelco solo puede reducir,
pero no eliminar, el riesgo de caída.
•Para evitar que los muebles se caigan o se volteen, fije este producto a la pared con el
sistema antivuelco incluido o con los herrajes de ensamblaje a la pared.
•Este producto cuenta con sistemas antivuelco y herrajes de ensamblaje a la pared; sin
embargo, es posible que tenga que buscar los accesorios adecuados para su tipo de
pared. Si tiene alguna inquietud al respecto, consulte a un comerciante calificado.
•Compruebe siempre la capacidad de la pared para asegurarse de que el sistema
antivuelco o los herrajes de ensamblaje a la pared resistan las fuerzas aplicadas a ella.
•Asegúrese siempre de que cualquier pared utilizada para los sistemas antivuelco o los
herrajes de ensamblaje a la pared esté libre de cables eléctricos ocultos, tuberías de agua
o gas.
•No utilice este objeto como soporte para el televisor ni coloque objetos pesados sobre él.
•Coloque los artículos más pesados en los cajones o repisas más bajas.
•No permita que los niños se suban o se aferren a los cajones, puertas o repisas.
•No abra nunca más de un cajón a la vez o anule/elimine cualquier sistema de interbloqueo
de cajones.
Capacidad de peso: Este producto soporta un total de 5 libras (2,3 kg) por repisa y 5 libras
(2,3 kg) por cajón, lo que suma un total de 35 libras (15,9 kg). No sobrecargue el producto para
evitar el riesgo de daños o lesiones graves o la muerte.

AVERTISSEMENT
L’ASSEMBLAGE DOIT ÊTRE EFFECTUÉ PAR UN ADULTE :
Ce produit doit être assemblé par un adulte à cause de la présence de petites pièces.
Lorsque vous déballez et assemblez cet article, veillez à tenir les petites pièces hors
de portée des enfants. Les enfants doivent être tenus à l’écart du produit en raison
du risque de blessure pendant l’assemblage.
LE BASCULEMENT D’UN MEUBLE PEUT CAUSER DES BLESSURES GRAVES
VOIRE MORTELLES. CE PRODUIT DOIT ÊTRE UTILISÉ AVEC LES DISPOSITIFS
DE RETENUE ANTI-BASCULEMENT OU LE MATÉRIEL DE FIXATION MURALE
FOURNI AFIN D’ÉVITER TOUT BASCULEMENT.
VEUILLEZ LIRE LES AVERTISSEMENTS CI-DESSOUS.
•Le produit doit être assemblé exactement selon ces instructions. Le non-respect des
instructions de montage peut entraîner un risque de blessure.
•Les enfants en bas âge peuvent être gravement blessés ou tués par le basculement d’un
meuble. Installez les dispositifs de retenue anti-basculement fournis. L’utilisation de
dispositifs de retenue anti-basculement peut uniquement réduire le risque de basculement ;
il n’élimine pas ce risque.
•Ce produit doit être fixé au mur à l’aide de dispositifs de retenue anti-basculement ou de
matériel de fixation murale pour éviter que le meuble ne bascule et ne tombe.
•Les dispositifs de retenue anti-basculement et le matériel de fixation murale sont fournis
avec ce produit. Toutefois, vous devrez peut-être vous procurer du matériel convenant à
votre type de mur. Veuillez consulter un professionnel qualifié en cas de doute.
•Vérifiez toujours la résistance du mur pour s’assurer que les dispositifs de retenue anti-
basculement ou les accessoires de fixation murale résistent aux forces qui lui sont
appliquées.
•Assurez-vous toujours que les murs utilisés pour les dispositifs de retenue anti-
basculement ou le matériel de montage mural soient exempts de fils électriques, de
conduites d’eau ou de gaz cachés.
•N’utilisez pas cet objet comme support de téléviseur et évitez de placer des objets lourds
au-dessus de celui-ci.
•Placez les objets les plus lourds dans les tiroirs ou sur les étagères inférieures.
•Ne laissez jamais les enfants monter ou s’accrocher aux tiroirs, portes ou étagères.
•N’ouvrez jamais plusieurs tiroirs en même temps, et ne démontez et ne retirez jamais le
système de verrouillage du tiroir.
Capacité de poids : Ce produit peut contenir jusqu’à 5 livres (2,3 kg) par étagère et 5 livres
(2,3 kg) par tiroir, pour un poids total de 35 livres (15,9 kg). Veuillez ne pas surcharger le produit
pour éviter tout risque de dommage et de blessure grave ou mortelle.

WARNUNG
MONTAGE DURCH ERWACHSENE ERFORDERLICH:
Dieses Produkt muss wegen der kleinen Teile von einem Erwachsenen zusammengebaut werden.
Beim Auspacken und Zusammenbau dieses Artikels ist darauf zu achten, dass Kleinteile von
Kindern ferngehalten werden. Während der Montage sollten Kinder wegen möglicher
Verletzungsgefahr vom Produkt ferngehalten werden.
BEIM UMKIPPEN VON MÖBELN KANN ES ZU SCHWEREN ODER TÖDLICHEN
VERLETZUNGEN KOMMEN. UM EIN UMKIPPEN ZU VERHINDERN, MUSS DIESES PRODUKT
MIT DEN MITGELIEFERTEN KIPPSICHERUNGEN ODER WANDBEFESTIGUNGSTEILEN
VERWENDET WERDEN.
BITTE LESEN SIE DIE FOLGENDEN WARNHINWEISE.
•Das Produkt muss genau nach diesen Anweisungen zusammengebaut werden. Die
Nichtbeachtung der Montageanweisungen kann zu einer möglichen Verletzungsgefahr
führen.
•Kleine Kinder können schwer verletzt oder getötet werden, wenn Möbel umkippen.
Installieren Sie die mitgelieferte Kippsicherung. Die Verwendung von Kippsicherungen kann
das Risiko des Umkippens nur verringern, aber nicht ausschließen.
•Um zu verhindern, dass Möbelstücke umkippen oder herunterfallen, muss dieses Produkt
mit beiliegenden Kippsicherungen oder einer Wandhalterung an der Wand befestigt
werden.
•Kippsicherungen und Wandhalterungen werden mit diesem Produkt mitgeliefert, Sie
müssen jedoch möglicherweise geeignetes Zubehör für Ihren Wandtyp beschaffen. Im
Zweifelsfall wenden Sie sich bitte an einen qualifizierten Händler.
•Prüfen Sie immer die Eignung der Wand, um sicherzustellen, dass die Kippsicherungen
oder Wandhalterung den auf sie einwirkenden Kräften standhalten.
•Stellen Sie immer sicher, dass alle Wände, die für Kippsicherungen oder Wandhalterungen
verwendet werden, frei von versteckten elektrischen Leitungen, Wasser- oder Gasrohren
sind.
•Verwenden Sie diesen Gegenstand nicht als TV-Ständer und stellen Sie keine schweren
Gegenstände darauf.
•Legen Sie die schwersten Gegenstände in die untersten Schubladen oder Regalfächer.
•Lassen Sie Kinder niemals auf Schubladen, Türen oder Regalböden klettern oder sich
daran hängen.
•Niemals mehr als eine Schublade gleichzeitig öffnen oder ein Schubladenverriegelungs-
system außer Kraft setzen/entfernen.
Gewichtskapazität: Dieses Produkt fasst bis zu 2,3 kg (5 Pfund) pro Regalboden und 2,3 kg
(5 Pfund) pro Schublade bis zu einem Gesamtgewicht von 15,9 kg (35 Pfund). Bitte überlasten Sie
das Produkt nicht, da die Gefahr von Schäden und/oder schweren Verletzungen oder Tod besteht.

PARTS LIST
1
2
3
7
7
48
6
9
10
11
11
18
19
5
13
15
14 16
17
12

PARTS LIST
NO QTY DESCRIPTION
1 1PC
2 1PC
3 1PC
4 1PC
5 1PC
6 1PC
7 2PCS
8 1PC
9
10
11
12
13
14
15
16
17
18
19
1PC
1PC
Top Board
Upper Left Side Board
Upper Right Side Board
Bottom Board
Upper Cross Bar
Lower Cross Bar
Door
Middle Connection Board
Adjustable Shelf
Lower Left Side Board
Lower Right Side Board
2PCS
1PC
1PC
1PC
1PC
1PC
1PC
1PC
1PC
Fixed Shelf
Drawer Front Board
Drawer Back Board
Drawer Left Side Panel
Drawer Right Side Panel
Drawer Bottom Board
Upper Back Board
Lower Back Board

TOOLS NEEDED FOR ASSEMBLY: FLAT & PHILLIPS SCREWDRIVER (NOT INCLUDED)
THE USE OF A POWER SCREWDRIVER IS NOT RECOMMENDED FOR ASSEMBLY
DO NOT USE ITEM IF ANY PARTS ARE MISSING OR DAMAGED
PARTS LIST
NO QTYPARTS DESCRIPTION
A28PCS
12PCS
Wood Dowel
B26PCS Cam Bolt
Cam Lock
D
E
F
Knob
Shelf Holder
G
H
1PC
J
K
L
M
N
P
R
S
T
U
26PCS
4PCS
2PCS
2PCS
2PCS
24PCS
8PCS
1PC
1PC
1PC
2PCS
2PCS
9PCS
Screw (3x10mm)
Hinge
Machine Screw (4x16mm)
Screw (3.5x14mm)
Screw (2.5x10mm)
Screw (4x12mm)
Machine Screw (4x10mm)
Screw (4x30mm)
Drawer Slider
To order replacement parts at no cost to you, email [email protected], call
1-(844)-223-5201 or order parts online at www.riverridgehome.com. Only valid in the United States.
If purchased outside of the United States, please contact retailer where purchased.
Adjustable Anchor Bracket
Plastic Anchor
Screw (4x40mm)

110 13
2
98
3
B
B
B
B
B
B
B B
B
B
B
B
B
B
B
B
BB
B
B
B
B
B
B
B
B
1. Screw 4 cam bolts (B) into cam bolt holes on upper right side board (3).
2. Screw 4 cam bolts (B) into cam bolt holes on upper left side board (2).
3. Screw 3 cam bolts (B) into cam bolt holes on lower right side board (9).
4. Screw 3 cam bolts (B) into cam bolt holes on lower left side board (8).
5. Screw 4 cam bolts (B) into cam bolt holes on top board (1).
6. Screw 4 cam bolts (B) into cam bolt holes on middle connection board (10).
7. Screw 4 cam bolts (B) into cam bolt holes on drawer front board (13).
STEP 1

1
6
K
R
F
F
F
F
G
G
STEP 3
1. Attach adjustable anchor bracket (R) to top board (1) by inserting 1 screw (K) through hole
on adjustable anchor bracket (R), then tighten to top board (1).
2. Attach 2 hinges (G) to door (6) by inserting 4 screws (F) through holes on hinges (G),
then tighten to door (6).
1. Attach drawer slider (M) to lower right side board (9) by inserting 2 screws (E) through
holes on drawer slider (M), then tighten to lower right side board (9). Make sure screws
tighten to correct holes per drawing details.
2. Repeat above step to attach drawer slider (M) to lower left side board (8).
STEP 2

STEP 4
STEP 5
D
D
D
D
D
D
D
D
A
A
A
A
A
A
A
A
A
A
2
3
2
5
5
11
11
11
11
1. Insert 5 wood dowels (A) into wood dowel holes on upper left side board (2).
2. Attach 2 fixed shelves (11) and upper cross bar (5) to upper left side board (2) by inserting
cam bolts into cam lock holes and inserting wood dowels into wood dowel holes on fixed
shelves (11) and upper cross bar (5).
3. Insert 4 cam locks (D) into cam lock holes on fixed shelves (11), then rotate clockwise to
secure cam bolts (B) in place.
1. Insert 5 wood dowels (A) into wood dowel holes on fixed shelves (11) and upper cross
bar (5).
2. Attach upper right side board (3) to fixed shelves (11) and upper cross bar (5) by inserting
cam bolts into cam lock holes on fixed shelves (11) and inserting wood dowels into wood
dowel holes on upper right side board (3).
3. Insert 4 cam locks (D) into fixed shelves (11), then rotate clockwise to secure cam bolts (B)
in place.

STEP 6
STEP 7
DD
D
D
A
A
A
A
2
3
1
L
A
L
A
A
A
L
L
L
L
3
2
5
10
1. Insert 4 wood dowels (A) into wood dowel holes
on upper left side board (2) and upper right side
board (3).
2. Attach top board (1) to upper left side board (2)
and upper right side board (3) by inserting cam
bolts into cam lock holes on upper left side
board (2) and upper right side board (3) and
inserting wood dowels into wood dowel holes on
top board (1).
3. Insert 4 cam locks (D) into upper left side
board (2) and upper right side board (3), then rotate
clockwise to secure cam bolts (B) in place.
1. Insert 1 screw (L) through hole on upper
cross bar (5), then tighten to top board (1).
2. Insert 4 wood dowels (A) into wood dowel holes
on upper left side board (2) and upper right side
board (3).
3. Attach middle connection board (10) to upper left
side board (2) and upper right side board (3) by
inserting wood dowels (A) into wood dowel holes
on middle connection board (10).
4. Insert 4 screws (L) through holes on middle
connection board (10), then tighten to upper left
side board (2) and upper right side board (3).

STEP 8
STEP 9
A
A
A
A
A
A
D
D
D
D
D
D
8
4
4
8
9
12
1. Insert 3 wood dowels (A) into lower left side board (8).
2. Attach bottom board (4) and lower cross bar (12) to lower left side board (8) by inserting
cam bolts into cam lock holes and inserting wood dowels into wood dowel holes on bottom
board (4) and lower cross bar (12).
3. Insert 3 cam locks (D) into cam lock holes on bottom board (4) and lower cross bar (12),
then rotate clockwise to secure cam bolts (B) in place.
1. Insert 3 wood dowels (A) into lower right side board (9).
2. Attach lower right side board (9) to bottom board (4) and lower cross bar (12) by inserting
cam bolts into cam lock holes and inserting wood dowels into wood dowel holes on bottom
board (4) and lower cross bar (12).
3. Insert 3 cam locks (D) into bottom board (4) and lower cross bar (12), then rotate
clockwise to secure cam bolts (B) in place.

STEP 10
STEP 11
A
A
A
D
DD
D
210
8
9
J
J
J
J
J
J
J
J
J
J
J
J
J
J
J
J
J
J
J
J
JJ
J
J
3
9
18
19
1. Insert 4 wood dowels (A) into
lower left side board (8) and lower
right side board (9).
2. Attach upper assembled unit to lower left
side board (8) and lower right side board (9)
by inserting wood dowels into wood dowel
holes on middle connection board (10) and
inserting cam bolts into cam lock holes on
lower left side board (8) and lower right side
board (9).
3. Insert 4 cam locks (D) into lower left side
board (8) and lower right side board (9), then
rotate clockwise to secure cam bolts (B) in place.
1. Attach upper back board (18) and
lower back board (19) to back of cabinet
by inserting 24 screws (J) through holes
on upper back board (18) and lower back
board (19), then tighten to back of cabinet.

STEP 12
F
F
FF
F
F
FF
UUH
H
6
9
1. Attach door (6) to lower right side board (9) by inserting 8 screws (F) through holes on
hinges (G), then tighten to lower right side board (9).
2. Attach knob (U) to door (6) by inserting 1 screw (H) through hole on door (6), then tighten
to knob (U).

D
D
D
D
L
L
L
L
15
16
17 14
13
13
13
U
H
13
1. Attach drawer left side panel (15) and drawer
right side panel (16) to drawer front board (13)
by inserting 4 cam bolts (B) into cam bolt holes
on drawer left side panel (15) and drawer right
side panel (16).
2. Insert 4 cam locks (D) into cam lock holes
on drawer left side panel (15) and drawer right
side panel(16), then rotate clockwise to secure
cam bolts (B) in place.
3. Slide drawer bottom board (17) into
grooves on drawer left side panel (15),
drawer right side panel (16) and drawer
front board (13).
4. Attach drawer back board (14) to drawer
left side panel (15) and drawer right side
panel (16) by inserting 4 screws (L)
through holes on drawer left side
panel (15) and drawer right side
panel (16), then tighten to drawer back
board (14). Make sure bottom board (17)
slides into the groove on the drawer
back board (14).
5. Attach knob (U) to drawer front board (13)
by inserting 1 screw (H) through hole on
drawer front board (13), then tighten to
knob (U).
STEP 13

8
STEP 14 STEP 15
N
N
PP
PP
P
P
P
P
7
7
1. Insert 8 shelf holders (P) into holes on
lower left side board (8) and lower right
side board (9), make sure each 4 shelf
holders (P) are at same level.
2. Place adjustable shelves (7) onto shelf
holders (P).
1. Slide drawer into cabinet by sliding drawer
slider (M) into grooves on drawer left side
panel (15) and drawer right side panel (16).
Pull drawer out and adjust drawer sliders (M)
to be fully extended against drawer front
board (13). Insert 2 machine screws (N)
through holes on drawer left side panel (15)
and drawer right side panel (16), then tighten
to drawer sliders (M).

S
T
Option #1: Securing to Drywall
1. Position cabinet against wall in desired
location. Using a pencil, make 1 small
mark on wall through hole on adjustable
anchor bracket (R). Move cabinet away
from wall and screw 1 plastic anchor (S)
into wall on pencil mark.
2. Place cabinet against wall, insert 1
screw (T) through hole on adjustable
anchor bracket (R), then tighten to plastic
anchor (S).
Option #2: Securing to Drywall
and Wood Stud
1. Place cabinet against wall in desired location.
Insert 1 screw (T) through hole on adjustable
anchor bracket (R), then tighten through drywall
and into wood stud .
*Tip: Anchor bracket (R) can be adjusted to correct distance from wall to cabinet as needed.
Once adjusted, be sure to re-tighten bracket inside cabinet for stability
STEP 16
DRYWALL
WALL ANCHOR
WITH SCREW
OPTION #1
T
SCREW
ONLY
DRYWALL
OPTION #2
WOOD
STUD
T
R
T
S

ATTENTION ADULTS: Cabinet should be checked periodically for damage or
loose screws/parts. Take appropriate action necessary to correct hazards such as
tightening of screws and taking any damaged parts away from children.
WARNING Please make sure your item is
secured to the wall, per assembly instructions.
CARE INSTRUCTIONS:
Wipe clean with a water dampened cloth. Wipe dry with clean cloth.
IMPORTANT:
Keep assembly instructions for future reference.

LISTA DE PIEZAS
N.°
DESCRIPCIÓN
CANT.
1
Tablero superior
1
2
Tablero lateral superior izquierdo
1
3
Tablero lateral superior derecho
1
4
Tablero inferior
1
5
Barra transversal superior
1
6
Puerta
1
7
Repisa ajustable
2
8
Tablero lateral inferior izquierdo
1
9
Tablero lateral inferior derecho
1
10
Tablero de conexión media
1
11
Repisa fija
2
12
Barra transversal inferior
1
13
Tablero delantero del cajón
1
14
Tablero trasero del cajón
1
15
Panel izquierdo del cajón
1
16
Panel derecho del cajón
1
17
Tablero inferior del cajón
1
18
Tablero trasero superior
1
19
Tablero trasero inferior
1
A
Pasador de madera
28
B
Perno de anclaje
26
D
Pestillo de leva
26
E
Tornillo (3x10mm)
4
F
Tornillo (3,5x14mm)
12
G
Bisagra
2
H
Tornillo para metales (4x16mm)
2
J
Tornillo (2,5x10mm)
24
K
Tornillo (4x12mm)
1
L
Tornillo (4x30mm)
9
M
Guía para el cajón
2
N
Tornillo para metales (4x10mm)
2
P
Soporte del estante
8
