Lightolier Lytespan 9179 User manual

Lightolier a Genlyte company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2006 Genlyte Group LLC • B0706
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lytespan®Track Lighting 9179
Page 1 of 2 MiniForms™ Apollo MR16
Features
1. Lamp Bracket: Stamped steel with insulated end knob made of high
temperature silicone rubber which allows for aiming adjustments while
fixture is on.
2. Socket: Bi-pin base ceramic socket wired with No. 18 stranded Teflon
leads with fiberglass outer sleeve.
3. Transformer: Electronic low voltage transformer with integral radio
frequency interference filter and anti-crossover circuit for increased
reliability; housed in extruded aluminum.
4. Track Attachment Fitting: Molded polycarbonate, rotates into track and
locks on with push tab; integral polarity key guard.
5. Push Tab: Locks and detaches unit from track.
6. Brass Contact: Extends up for connection to second circuit when used
with Advent®Lytespan track.
7. Tension Pivot Mounts: Steel. Allows for 180° horizontal rotation and
180° vertical rotation.
8. Lamp Guard: Tempered glass; can be substituted with 2" filter.
9. Spring: Steel springs hold lamp in place.
10.Housing: Aluminum with vent holes.
Electrical/Dimming
Dimming controls: Use only dimmers specifically designed for use with elec-
tronic transformers, like Lightolier Sunrise™ and Neptune Momentum QE™
series. Low voltage fixtures may produce audible sound when used with dim-
mers, which may be objectionable in acoustically critical areas.
Labels
UL
Ordering Information
Catalog No. Finishes Track Mountings Lamps
9179WH Matte White All Lytespan MR16
9179BK Matte Black Track Systems 50W Max.
9179AL Matte Aluminum
10
1
2
3
4
5
6
7
9
8
51/2
2
1
/
4
3
3
/
4
2
7
/ 8

Lightolier a Genlyte company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2006 Genlyte Group LLC • B0706
Job Information Type:
Lytespan®Track Lighting 9179
Page 2 of 2 MiniForms™ Apollo MR16
FC
D
LC
A
W
L
W
FC
D
 

 
 

 
 

 
 

 
 

 
   
   
   
   
 

 
 

 
 

 






 




   
   
   
   
                  






    
    
    
    
    
    
    
    
    
    
    
    
   
   
   
   
    
    
    
    
    
    
    
    
    
    
    
    
    
    
    
    
    
    
    
    
    
    
    
    
    
    
    
    
    
    
    
    
    
    
    
    
   
   
   
   
    
    
    
    
   
   
   
   
    
    
    
    
    
    
    
    
    
    
    
    
    
    
    
    
    
    
    
    
FC L
C
D
A
   
   
   
   
   
   
   
   
    
    
    
    
    
    
    
    
    
    
    
    
    
   
 

 
   
   
   
   
    
    
    
    
    
    
    
    
    
    
    
    
 

 
   
   
   
   
    
    
    
    
    
    
    
    
    
    
    
    
 

 
 

 
   
   
   
   
    
    
    
    
    
    
    
    
    
    
    
    
   
   
   
   
    
    
    
    
    
    
    
    
    
    
    
    
   
   
   
   
    
    
    
    
    
    
    
    
    
    
    
    
