AED MULTI12 User manual

12“ TWO-WAY FULL RANGE
ACTIVE SPEAKER / WEDGE MONITOR
MULTI12
INSPIRED BY PROFESSIONALS CREATED BY EXPERIENCE UNMATCHED BY PERFORMANCE
USER
MANUAL
This manual is subject to change without further notice. No rights can be derived from this manual.
AED Audio® is a registered trademark of AED Distribution NV.
©2022 - AED Audio® - www.AEDaudio.com – [e-mail]

AED Audio - MULTI12 - User manual 1
TABLE OF CONTENTS
Introduction ............................................................................................................................................................................................... 2
Disclaimers .................................................................................................................................................................................................. 2
Intended use .............................................................................................................................................................................................. 2
General safety information and instructions .................................................................................................................................... 3
Warnings .................................................................................................................................................................................................... 3
Safety features & devices of the product ......................................................................................................................................... 3
Modification ............................................................................................................................................................................................. 3
System components ................................................................................................................................................................................. 4
General characteristics and technical specifications .................................................................................................................... 4
Technical data ........................................................................................................................................................................................ 4
Dimensions drawing ............................................................................................................................................................................ 4
Connectivity ............................................................................................................................................................................................... 5
Panel identifiers ....................................................................................................................................................................................... 5
Connection layout .................................................................................................................................................................................. 6
Transportation, handling and commissioning .................................................................................................................................. 7
Transportation ......................................................................................................................................................................................... 7
Remove the shipping assembly .......................................................................................................................................................... 7
Installation .................................................................................................................................................................................................. 7
Attention ................................................................................................................................................................................................... 7
Maintenance ............................................................................................................................................................................................... 8
Troubleshooting and repair ................................................................................................................................................................... 8
Fault list ..................................................................................................................................................................................................... 8
Repair ........................................................................................................................................................................................................... 8
Contact details certified repair center .............................................................................................................................................. 8
Notes ............................................................................................................................................................................................................ 9

AED Audio - MULTI12 - User manual 2
INTRODUCTION
DISCLAIMERS
INTENDED USE
The MULTI12 is a multipurpose 12“ two-way self-powered speaker with built-in DSP. The cabinet is made of robust
engineering Polymers which results in a lower weight, and a high power. The MULTI12 has an improved sound quality
due to its high quality European branded speaker components. You can use the MULTI12 as live PA speaker, for DJ
sets, with or without sub, but also as a wedge monitor, DJ monitor and for sound reinforcement in pub’s, clubs, small
theaters, churches and many more. This highly versatile product can be used in many ways.
With a 12” low-frequency woofer and a 1” high-frequency compression driver with a titanium diaphragm, the MUL-
TI12 is a 2-way full-range active speaker that can be deployed in multiple applications. Its characteristics include big
dynamic, high sensitivity, clear MF and HF with a powerful LF.
The MULTI12 design takes care of combining the horn with the cabinet. Due to its rigging points and mounting holes,
the rigging possibilities are endless. Pair your Bluetooth device by only pressing a button and play your favourite
music in an instant. Connect your instrument or microphone by using a jack or XLR input on the back panel of the
speaker. The 2-way XLR/TRS input mode ensures ease of use.
With the all-weather tote that also can used as rain cover, no weather condition is too rough to fulfil the job that has
to be done. The MULTI12 is an all-round 12 inch loudspeaker that stand its ground and will make sure you will get
your job done.
AED Audio, AED DISTRIBUTION SA, with registered office at Bedrijvenpark De Veert 13/4, 2830 Willebroek (Belgium),
or any of its affiliates, does not accept any liability for material damage, including damage to the Product, or personal
injury caused by non-observance by the user of the safety instructions in the Manual or the applicable laws. As such
AED Audio shall among others not be liable for any damage or injury if the Product is used contrary to or for purpos-
es other than its intended use, is installed, used, maintained or repaired negligently or contrary to the instructions
mentioned in the Manual or on the Product, when the Product is modified and when the safety devices and features
of the Product are disregarded or overridden.
This system is intended for use by trained personnel for professional applications. The Product is not intended to be
used by minors. Any use, regardless whether or not under the supervision of an adult, is at own risk.

AED Audio - MULTI12 - User manual 3
GENERAL SAFETY INFORMATION AND INSTRUCTIONS
WARNINGS
SAFETY FEATURES & DEVICES OF THE PRODUCT
MODIFICATION
For your own safety, please read this instruction manual carefully before turning on the product for the first time.
For your own safety, please read the safety instructions included with the product.
Always take note of any information marked with the CAUTION or WARNING symbol.
The pictograms, warnings and instructions attached to the Product are part of its safety features. They must not be
covered or removed and must be present and legible during the entire use of the Product. Immediately replace or
repair missing, damaged or illegible pictograms, warnings and instructions.
Under no circumstances any modification of the Product may be done by any person other than AED Audio person-
nel.
CAUTION: The signal word WARNING points out the potential risk of serious injury.
WARNING: The signal word CAUTION points out the potential risk of slight injury. The CAUTION symbol is used to
draw attention to circumstances which could cause the machine to become damaged.
The device can only run with 240V voltage, 50/60 Hz power, don’t connect to any other wrong power source.
Safety I class device, need to be earth connected.
Keep this device away from children and unauthorized users, the manufacturer will not take responsibility for the
damage due to any disregard of the information provided in this manual and wrong operation.
Don’t put or install the device on a surface that subject to vibration or bumps.

AED Audio - MULTI12 - User manual 4
SYSTEM COMPONENTS
GENERAL CHARACTERISTICS AND TECHNICAL SPECIFICATIONS
TECHNICAL DATA
DIMENSIONS DRAWING
Frequency response (-3dB) 47 Hz to 18 kHz
Max SPL @1m 117 dB / 123 dB peak
HF Dispersion 90° x 60°
Compression driver 1x 1”HF
Woofer 1x 12” LF
Input signal 100 Hz HP with sub, Mixer in/out, Stereo/Mono, 3.5mm AUX in, Bluetooth streaming
Input connectors 2x XLR, 2x 1/4”, 1/8”, Bluetooth and Main in (XLR)
Total power 500W program - 1.000W peak
Power connector TrueCon
Cooling Speed controlled fan
Voltage range 110V/230V AC, 50Hz/60Hz
Cabinet/Case material Polypropylene cabinet, ABS bae, metal grille
Handles 2x Plastic handles (1x side + 1x back)
Grille Powder coated steel with grille cloth
Color Black
Dimensions (HxWxD) 595 x 345 x 365 mm - 23.4 x 13.6 x 14.4 in
Package dimensions (HxWxD) 655 x 436 x 420 mm - 25.8 x 17.2 x 16.5 in
Net weight 15,6 kg - 34.4 lb
Gross weight 17,6 kg - 38.8 lb
3 performance modes Concert - Club - Monitor
Certication CE – UKCA – cETL
161mm
345mm
365mm
595mm

AED Audio - MULTI12 - User manual 5
1
3
5
2
17
6
910
13
14
4
15
16
8
12
7
11
1 Gain adjust
2 Master volume
3Line / Instrument input - Mono 1/4 TRS -
4 Line / Instrument input - Mono 1/4 TRS
5 Stereo / Aux In - Stereo 3.5mm
6 Main In - Mono XLR
7Mic In - Mono XLR -
8 Mic In - Mono XLR
9 Bluetooth® pairing
CONNECTIVITY
PANEL IDENTIFIERS
10 Stereo / Mono switcher
11 Mode selector (concert / club / monitor)
12 Sub / No sub -
13 Mixer enable
14 Link Thru - Mono XLR
15 Scan QR code for more information
16 AC Input PowerCon
17 Power switch

AED Audio - MULTI12 - User manual 6
CONNECTION CHART
MIC
LINE
MODE
LINK
MAIN IN
MASTER
Activity
Concert
Club
Monitor
SUB MIXER ENABLE
OUT IN
AUX IN
STEREO
INSTRUMENT
CLIP 1 CLIP 2 CLIP 3
MIC 90 Hz
90 Hz
100 Hz
Pairing:
Hold for 4s
then release
IN
MONO
OUT
STEREO
M
i
n
M
a
x
61 23
7
4
11Keyboard or other instrument input (Line level) Mono TRS
22Microphone input XLR
33Keyboard / guitar amplier or other instrument input (Line level) Mono TRS
44Microphone or instrument via DI-box) input XLR
55Smartphone or other device auxiliary input Stereo 3.5 mm
66Main input XLR
77Wireless connection Bluetooth®
88Balanced mono output XLR
5
8
4

AED Audio - MULTI12 - User manual 7
TRANSPORTATION, HANDLING AND COMMISSIONING
INSTALLATION
TRANSPORTATION
REMOVE THE SHIPPING ASSEMBLY
ATTENTION
Keep the product dry and the temperature between 0°C and 30°C to avoid damage to the speaker. Please always
handle with care.
Before unpacking the fixture, please make sure that the packaging is in good condition and that following items will
be found in the box:
Installation overhead needs a high level of experience. This includes (but is not just limited to) calculation and defini-
tion of load capacity, used installation material and regular safety inspections of used material and the fixture itself.
Never try to do the installation by yourself if you are not qualified, instead you have to instruct a skilled installer.
Inappropriate installations can cause injuries and/or damage of property.
Remove the tape from the box and open the box. Take the unit out and remove the plastic foil around the unit. Make
a visual inspection of the unit. Please check condition of units while unpacking, if any damages occur, the unit must
be repaired/replaced before it can be used. Please contact your local distributor for service. If units are damaged and
still used, AED Audio cannot be held liable for any risk/danger or occurrence given by these damaged units.
There are specific regulations like BGV C1 (old VBG 70) or country related regulations which need to attend during the
installation. The installation has to be handled by skilled persons only!
Suspension device has to be built and calculated in order to handle up to 10 times its specific load limit over a time of
one hour without permanent or harmful deformation.
Installation has to be done with a separate, independent suspension device like a safety chain.
Trespassing the danger zone below the installation during the assembling is prohibited.
Installer has to take care of all safety and machinery installations are approved by authorized persons before first
operation or after changes before restarting.
Installer has to take care of all safety and machinery installations are approved by skilled persons at least once a year.
Installer has to take care of all safety and machinery installations are approved by authorized persons every four years
during the acceptance inspection. Spotlight should ideally installed outside peoples lounge area.
1x MULTI12
1x Safety instructions
CAUTION: Mounting place must be sucient stable and be able to support a weight of 10 times of the unit’s
weight.
CAUTION: Assure the specied safety distances to ammable material.

AED Audio - MULTI12 - User manual 8
MAINTENANCE
TROUBLESHOOTING AND REPAIR
REPAIR
Operation only allowed to qualified person, damages due to unprofessional operation or remove of any parts inside
will not be considered in warranty service. There are no serviceable parts inside the device or package, service only
leaves to authorized dealers.
If the Product is damaged or malfunctions, contact the AED Audio Service Department or a AED Audio authorized
distributor. Repairs by parties other than AED Audio or a AED Audio authorized distributor may not involve the use
of AED Audio genuine parts and may affect the safety and functionality of the Product. For repair options or specific
inquiries, please contact the AED Audio Service Department.
AED Repair
Bedrijvenpark De Veert 11, 2830 Willebroek – Belgium
[e-mail]
aedgroup.com/en/services/aed-repair
CONTACT DETAILS CERTIFIED REPAIR CENTER
FAULT LIST
PROBLEM SOLUTION
Bluetooth® doens’t connect Check if your telephone Bluetooth® function is active
The unit will not turn on Try a dierent power socket or check the power on switch (more info: on page 5). If
this doesn’t work, contact your repair center.
There is no bass in my music Check button number 12 (Sub / No Sub) (more info: page 5)
The unit sounds distorted Check the gain adjust settings (more info: page 5)
My microphone is connected but I have
no sound Check the Mixer enable button (more info: page 5)
I have connected with Bluetooth® but I
don’t hear anything Check if your music on your mobile device is playing

AED Audio - MULTI12 - User manual 9
NOTES
All rights reserved. No part of this manual may be copied or published by means of printing, photocopying, micro-
film or otherwise without the prior written consent of the manufacturer. This restriction also applies to the corre-
sponding drawings.
The information given in this manual has been collected for the general convenience of our customers. It has been
based on general data pertaining to construction material properties and working methods known to us at the
time of issue of the manual and is therefore subject at any time to change or amendment, and the right to change
or amend is hereby expressly reserved. The instructions in this manual only serve as a guideline for installation, use,
maintenance and repair of the product mentioned on the cover page of this document. This manual is to be used
for the standard model of the product of the type given on the cover page. Thus the manufacturer cannot be held
responsible for any damage resulting from the application of this manual to any other product.
This manual has been written with great care. However, the manufacturer cannot be held responsible, either for any
errors occurring in this manual or their consequences.

WWW.AEDAUDIO.COM
AED Distribution NV, Bedrijvenpark de Veert 13/004, 2830 Willebroek, Belgium
AEDaudio aed_audio
