AEE AT102 User manual

U s e r ' s M a n u a l
2.4GHz Color Wireless Camera Kit
MODEL: At102 & ZT 735
A E E T E C H N O L O G Y
C O . , L T D .
Please read this manual carefully and thoroughly before any
attempt to install and operate this product and retain it for your
future reference.
English
R

T R O U B L E S H O O T I N G
When you experience the operation problems, please check and try
the following yourself before claiming that it is the defective product or
consulting the experienced technician.
Abnormal Phenomena Possible Reasons/Solutions
No
No sound
Check whether the camera/receiver
is connected to power supply and
powered on.
1. Check if the channel of receiver is
Snowflake
s
on
Noisy
the same as that of camera;
2. Check the distance & blocks.
Blurimag
e
Normalsound
Adjust the lens of camera.
Ghost
image Normal sound
1. Interfered with other devices;
2. Check the distance & blocks.
No color
Normal sound
Mismatching the TV system of PAL
or NTSC.
Normal
image Noisy
Interfered with other devices nearby;
Remove or turn off such devices.
15
E U E n v i r o n e n t a l P r o t e c t i o n
Waste electrical products should not be disposed of with
household waste. Please recycle where facilities exist.
Check with your Local Authority or retailer fo
r recycling
advice.

S P E C I F I C A T I O N S
It e s Va lu e
Transmission Frequency ISM 2,400MHz~ 2,483MHz
Antenna Type Omni
Transmission Distance 100m (Without Block)
Operating Temperature
o
o
o
o
F F
Storage Temperature
o
o
o
o
20C~+60C /
4~+140
Storage Humidity ~85% RH
Imaging Sensor 1/3 inch CMOS
CMOS Total Pixels 628 582 (PAL)/ 510 492 (NTSC)
S/N Ratio 40dB (AGC OFF)
Horizontal Resolution 380 TV Lines
Minimum Illumination 5 Lux/F1.2
Transmission Power 10mW (CE)/2mW (FCC)
Power Supply DC 7.5V 300mA
Consumption Current 80 mA (Max.)
Dimensions (WxDxH) 23mmx31mmx23mm (Main Body)
Weight Approx.20g (Main Body)
Receiving Sensitivity 85dBm
Power Supply DC 8.0V 200mA
ConsumptionCurrent 150mA(Max.)
Video Output Level 1
V
p p Ω @75
Audio Output Level 1
V
p p Ω @10k
Dimensions (WxDxH) 100mmx70mmx18mm (Main Body)
Weight Approx. 99g (Main Body)
* Specifications are subject to minor change without prior notice.
T A B L E O F C O N T E N T S
SP EC I FI C ATIO NS 14
TR OU BLE SHO OTING 15
14
1~4
1
1~2
3
3
4
4
IN TR ODU CTI ON
Notice
Approval Information (FCC/CE )
Warranty
Copyright
Restrictions
Maintenance
5~7
5
6
7
PR ODU CT
Package Contents
Feature Locations
Adapter & Battery Clip
INST ALLATION & USAGE
Installation
FixtheCamera
Locate the Receiver
Camera Channel Setup
Receiver Mode Setup
8~ 13
8~10
11~12
12
12
13

1. mode: Slide switch off to enter mode. In this mode,
Man u al Man u al
L
the receiver channel won't change until you press the C h anne l Sel e ct
“SEL" button;
2. mode: Slide L switch on to enter channel scan mode.
Cha n nel S can
In this mode, all the available channels will display one by one
looping in turn per 5s. So you can watch the situations from up to 4
different cameras via one receiver.
13

Locate the Receiver
The receiver can be placed horizontally or vertically. When it is placed
vertically, the supplied holder is required.
Horizontal Vertical
Ca era Channel Setup
This camera has 4 selectable channels to avoid possible interference
from other nearby wireless devices. Please open the channel switch
cover and set the Channel Switch as the following diagram.
I N T R O D U C T I O N
Thank you for your interest and support in our product and purchasing
this wireless camera kit. This product works at ISM 2.4GHz frequency
band, which could be legally used worldwide without permission.
We f eel confident that you will be pleased with the quality and features of
this product.
The camera features one CMOS image sensor and a transmitting
module to capture the image and transmit them wirelessly.
The receiver features a receiving module to receive and outputAV
signals.
Notice
Notice: This product may cause interferences with other wireless
equipment that operates at 2.4GHz ISM band. Please turn off one of
the equipments to eliminate the interference.
Product Assurance: This camera will emit electromagnetic wave, just
like other wireless products. But its transmitting power is lesser than
other wireless products such as mobile phones. The 2.4GHz wireless
camera meets wireless frequency security standards and
recommended indexes while working. These standards and indexes
are certificated by academic organization and represent the cogitative
research of the scientific workers who continuously explore and
annotate the involved fields. So we believe that our products are safe
.
for customers
Approval Infor ation
All our products meet the requirements of approval FCC or CE, and
are granted the FCC or CE certification. They are authorized to bear
FCC or CE mark.
C h a n n e l F r e q u e n c y
CH 1=2,414 MHz;
CH2=2,432MHz;
CH3=2,450MHz;
CH4=2,468MHz
12
1

FCC
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which and be determined by turning
the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the
receiver.
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for
help.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions (1) This device may not cause
harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation
Changes and modification not expressly approved by the manufacturer
or registrant of this equipment can void your authority to pperate this
equipment under Fedral Communications Commissions rules.
F i x t h e C a e r a
Please follow the steps below if you want to fix the camera to wall or
ceiling.
1. Fix to Wal l
1.1 Drill one hole on the mounting surface, insert the anchor into the
hole, then align the mounting plate with the hole you just drilled
and drive the screw through the plate into the anchor;
1.2 Hang the camera on the hooks of mounting plate;
1.3 Push downwards the camera firmly.
2. Fix to Ceiling
2.1 Detach the universal bracket from the camera and then install it to
the camera top for avoiding reverse picture;
2.2 Secure the mounting plate to ceiling with screw;
2.3 Hang the camera on the hooks of mounting plate;
2.4 Push the camera firmly as the shown direction.
2 11

7. If the picture is blur, you could adjust the lens focus with lens W a r r a n t y
adjuster to make the picture clear.
N o t e s :
You can paste the foam base on the bottom of the Universal Bracket to fix the
camera.
When you fix the camera with the mounting plate the foam base can not be
pasted on the bottom of the Universal Bracket.
Please refer to Fi x t h e C ame r a section on page 11 more details to fix the for
camera with the mounting plate.
9. Adjust the brightness, contrast and color setting of the monitor/TV
to get the best display effect.
This manual is furnished under license and may be used or copied only
in accordance with the terms of such license. Except as permitted by
such license, no part of this publication may be reproduced, stored in a
retrieval system, or transmitted, in any form or any means, electronic,
mechanical, recording, or otherwise, including translation to another
language or format, without the prior written permission of AEE
Technology.
The content of this manual is furnished for informational use only, is
subject to change without notice, and should not be construed as a
commitment byAEE Technology.
AEE Technology assumes no responsibility or liability for any errors or
inaccuracies that may appear in this booklet. All other product names,
trademarks and registered trademarks in this document are the
properties of their respective holders.
3
Lens Adjuster
AEE Technology warrants that this product will be free from defects in
materials and workmanship for period of time specified. This limited
warranty shall commence from the date of purchase. AEE
Technology
product's warranty is not transferable and is limited to the original
purchaser. If the product is found to be defective then, as your sole
remedy and as the manufacturer's only obligation, AEE Technology
will repair or replace the product. This warranty shall no
t apply to
products that have been subjected to abuse, misuse, abnormal
electrical or environmental conditions, normal wear and tear or any
condition other than what can be considered normal use. Should you
have problems, please consult the local dealer.
C o p y r i g h t
8. Mount the camera to a desired location.
10

R e s t r i c t i o n s
1. DO NOT use this product to violate one's privacy. Monitoring one's
activities without consent is illegal and this product is not designed
and manufactured for such purpose;
2. DO NOT put this product near any medical equipment. Radio
waves might potentially cause breakdown of electrical medical
equipment. So this product should be placed at least 1 feet away
from any heart pacemaker. Radio waves might potentially
influence heart pacemaker and lead to respiratory disturbance;
3. DO NOT use this product for any illegal activities. AEE Technology
shall not be responsible for any consequences of illegal acts
committed by the user.
M a i n t e n a n c e
1. Ensure the sufficient ventilation space is available;
2. Do not shake or strike the product;
3. Keep it dry and dustless and avoid exposing it to direct sunlight;
4. Do not place product near any magnetic objects;
5. Avoid putting the product in places where the constantly changed
temperature or humidity occurs;
6. Keep product away from heat sources such as electric heater;
7. Do not use the camera near aggressive chemicals;
8. Do not use this camera near water, for example, near a bath tub,
wash bowl, kitchen sink or laundry tub, in a wet basement or near
a swimming pool and the like;
9. Do not use the camera in the places which are enclosed by metal.
The surrounding metal like lifter, cabin, may shield the
electromagnetic wave, and result in failure of signal reception;
10. Please obey the local government's environment protection policy;
11. Please turn off the power when left unused;
12. Do not disassemble or repair the camera or receiver, doing so
might cause damages to the product.
4
4. Connect the power jack of adapter (DC 8.0V 200mA) to receiver.
Note: Please refer to Receiver Mode Setup section
on page 13 for more details.
5. Open the channel switch cover and set the camera to one desired
channel.
Notes:
Please refer to Camera Channel Setup section on page 13 for more details.
Please recover the channel switch after finished setting.
6. Press the channel select button on the receiver until the
"S EL EC T"
channel indicator matches to the channel on the corresponding
camera, and the monitor/TV will display pictures.
9

I N S T A L L A T I O N & U S A G E
I n s t a l l a t i o n
1. Connect the powerjack of adapter (DC 7.5V 300mA) or battery
with battery clip to camera.
a . C o n n e c t w i t h a d a p t e r
2. Connect the antenna to the receiver.
3. Connect the receiver to the monitor/TV with AV cable. (Red socket
for audio; yellow socket for video). Turn on the monitor/TV and
selectAV mode.
P R O D U C T
P a c k a g e C o n t e n t s
This package comes with the following items. Please check whether
they are all included in the packaging box, if one or some is missing,
contact the retailer for
replacement.
1 Wireless camera 1
2 Wireless receiver 1
3 Antenna for receiver 1
4 Holder for receiver 1
5 Mounting plate for camera 1
6 DC 7.5V power adapter for
camera 1
7 DC 8.0V power adapter for
receiver 1
8 AV cable 1
9 Lens adjuster 1
10 Channel pick for camera 1
11 Mounting screw 1
12 Foam base for camera 1
13 User's manual 1
14 Battery clip 1
Note:
1. This product can be either black or silver.
2. The pictures may vary from the actual
objects.
8
5

Adapter
This product always conforms to the authenticated AC adapter. The
adapter should be marked one of the following:
UL Mark
American power
supply authentication
CE Mark
European Union power
supply authentication
GS Mark
German power supply
authentication
SAA Mark
Australia power
supply authentication
PSE Mark
Japan power
supply authentication
CCC Mark
China power
supply authentication
2 . R e c e i v e r
N o t e :
When using the power adapter make sure the rating voltage on it is compatible
with that of the device to avoid potential damages resulting from incorrect usage
of power supply.
Battery Clip
With the supplied battery clip, the camera could be powered by
battery of the same voltage for temporary use.
7
Feature Locations
1 . C a e r a
6
