AEG Electrolux Lavatherm 57800 Operation manual

LAVATHERM 57800
Condenser dryer
User information

2
Dear Customer,
Please read this user information carefully and keep it to refer to later.
Please pass the user information on to any future owner of the appli-
ance.
The following symbols are used in the text:
1Safety instructions
Warning! Information that affects your personal safety.
Important! Information that prevents damage to the appliance.
3Useful tips and hints
2Environmental information

3
Contents
Operating Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Environmental tips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Description of machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Operating screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Before the first drying cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Sorting and preparing laundry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Overview of programmes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Drying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Switching machine on / switching light on . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Opening loading door / filling laundry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Selecting the programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Selecting additional functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
INTENSITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
SPECIAL CARE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
AUDIBLE SIGNAL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
SENSITIVE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Setting time delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Starting the programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Changing programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Removing laundry or loading laundry when necessary. . . . . . . . . . . . . . . . . 15
Drying cycle complete / removing laundry . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Cleaning and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Cleaning lint filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Cleaning the door seal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Emptying the water reservoir . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Cleaning heat exchanger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Cleaning the drum. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Clean operating screen and housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
What to do if … . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Troubleshooting by yourself . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Changing bulb for interior light. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Programming options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

4
Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Consumption values. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Installation and connection instructions. . . . . . . . . . . . . . . . . 25
Installation safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Removing transport safety packaging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Electrical connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Door reversal instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Special accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Warranty conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Service and Spare Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

5
Operating Instructions
1Safety
Prior to initial start up
•Note the ”Installation and connection instructions”
•Before first starting up, check the machine for any damage incurred
during transport. Never connect a damaged machine. If parts are
damaged, contact your supplier.
Intended use
•The dryer is intended for drying standard laundry in domestic envi-
ronments.
•Conversions or modifications to the dryer are not permitted.
•The laundry must not contain flammable solvents (benzene,
alcohol, stain remover, etc.) . Risk of fire and/or explosion! Laundry
which has come into contact with such substances must be rinsed
thoroughly by hand before drying.
•When using dry-cleaning sets: Only use those products which are de-
clared as suitable for the dryer by the manufacturer.
•Do not place items of laundry in the dryer which contain foam rubber
or materials similar to rubber. Risk of fire!
•Do not place heavily worn laundry items in the dryer. Risk of fire!
•Do not place laundry items with loose fillings (e.g. cushions) in the
dryer. Risk of fire!
•Parts with rigid components (e.g. door mats) may cover the air slots.
Risk of fire! Do not place such items in the dryer.
•Do not overfill the dryer. Risk of fire! Observe max. loading volume of
6 kg.
•Ensure that explosive objects (e.g. cigarette lighters, spray cans, etc.)
do not enter the dryer with the laundry. Risk of fire and/or explo-
sion!
•Clean the micro-fine filter and fine strainer after each drying cycle.
•Do not use the machine if there are no lint filters or if these are dam-
aged. Risk of fire!
•Clean the heat exchanger regularly.
•With stacked washer and dryer: Do not place objects on the dryer.
These may fall off during operation.
•The lampcover for the interior light must be screwed down tightly.

6
Child safety
•Keep packaging away from children. Risk of suffocation!
•Children can often not see the dangers associated with electrical ap-
pliances. Never leave unsupervised children near the dryer.
•Ensure that children and small animals cannot climb into the dryer’s
drum. Risk of death! Keep the dryer door shut whenever it is not be-
ing used.
General safety
•Only our qualified engineers may undertake repairs on the dryer.
•Never start up the dryer if the mains cable is damaged or if the oper-
ating screen, operating plate or base area are damaged so that the in-
side of the machine is open and accessible.
•Switch off the dryer before all cleaning, care or maintenance work.
Also disconnect the mains plug from the socket or – with permanent
connections – switch off the LS switch in the fuse box and/or remove
the fuse.
•Disconnect the machine from the power supply when it is not in use.
•When removing from the socket, never pull the mains plug by the ca-
ble, instead take a hold of the plug.
•Adapter plugs, couplings and extension cables must not be used. Risk
of fire from overheating!
•Do not spray down the dryer with jets of water. Risk of electric shock!
•Do not lean on the open door. The machine may tip over.
•Once the drying cycle has been interrupted, the laundry and drum
may be hot. Risk of burns! Take care when removing the laundry.

7
Disposal
2Packaging material
The packaging materials are environmentally friendly and can be recy-
cled. The plastic components are identified by markings, e.g. >PE<,
>PS<, etc. Please dispose of the packaging materials in the appropriate
container at your local waste disposal facilities.
2Old appliance
Please dispose of your old appliance in line with the guidelines for dis-
posal in your area.
1Warning! When your appliance has finished it's working life, remove
the plug from the mains socket. Cut off the cable and plug and dispose
of them.
Destroy the door lock. This prevents children from trapping themselves
inside and endangering their lives.
2Environmental tips
•Your dryer will function most economically if you:
–always keep the ventilation slots on the base of the dryer unob-
structed;
–use the loading volumes specified in the programme overview;
–ensure you have good ventilation in the installation room;
–clean the micro-fine filter and fine strainer after each drying cycle;
–spin the laundry well before drying. Example: Consumption data –
depending on spinning speed – for 6kg of laundry, dried using the
COTTONS STORAGE DRY programme.
Pre-draining Drying cycle
Revolutions per
minute
Residual dampness Energy
in kWh
in litres as a %
800 4.2 70 4.3
1200 3.2 53 3.3
1400 3.0 50 3.1
1800 2.5 42 2.6

8
Description of machine
Operating screen
Water reservoir
Screwed feet
(with height ad-
justment)
Loading door
(reversible)
Display panel
Large mesh filter
(lint filter)
Air slots
Lamp for interior
lamp
Rating plate
Base door up-
stream of heat ex-
changer
Micro-fine filter
(
lint filter)
Fine strainer
(lint filter)
Display showing
level of dryness
Programme progress display
Programme selector
Maintenance displays
–HEAT EXCHANGER (clean!)
–EMPTY WATER(empty!)
–CLEAN FILTER (clean lint filter!)
Block of buttons and displays
Multi-display
DELAY TIMER
button
INTENSITY button

9
Before the first drying cycle
In order to remove any residue which may have been produced during
production, wipe the dryer drum with a damp cloth or undertake a
brief drying cycle (30 MIN) with damp cloths.
Sorting and preparing laundry
Sorting laundry
•Sort by fabric type:
–Cotton/linen for programmes in COTTONS programme group.
–Mixtures and synthetics for programmes in EASY CARES pro-
gramme group.
•Sorting by care label. The care labels mean:
•Do not dry new, coloured textiles together with light-coloured laun-
dry items. Textile colours may bleed.
•Do not dry tricot or knitted items with the EXTRA DRY programme.
Items may become stuck!
•Do not dry wool in the dryer. May become entangled! After air-dry-
ing, wool may be dried with the WOOL CARE programme.
Preparing laundry
•To avoid laundry becoming tangled: Close zips, button up coverings
and tie loose bands or ribbons (e.g. of aprons).
•Empty pockets. Remove metallic items (paperclips, safety pins etc).
•Turn items with double-layered fabrics inside out (e.g. with cotton-
lined anoraks, the cotton layer should be outermost). These fabrics
will then dry better.
n m l k
Basic drying in tumble
dryer possible
Drying at
normal
temperature
Drying at
reduced temperature
(press SPECIAL CARE
button!)
Drying in tumble
dryer not
possible

10
Overview of programmes
Programme
max. loading volume (weight when dry)
Additional
functions
Application/properties Care
symbols
SPECIAL CARE1)
1) SPECIAL CARE and SENSITIVE cannot both be selected at the same time.
AUDIBLE SIGNAL SENSITIVE 1) INTENSITY
COTTONS
EXTRA DRY 6kg • • • • Drying thick or multi-layered tex-
tiles, e.g. terry towelling items
mn
INTENSIVE
DRY 6kg • • • • Drying thick textiles, e.g. terry towelling items, towels.
mn
STORAGE
DRY 6kg • • • •
Drying textiles of even thickness-
es, e.g. terry towelling items, knit-
ted items, towels.
mn
DAMP 6kg • • • •
For thin textiles which are still to
be ironed, e.g. knitted items, cot-
ton shirts.
mn
HAND
IRON 6kg • • • •
For normal thickness cotton or
linen laundry, e.g. bedding, table
linen.
mn
MACHINE
DRY 6kg • • • •
For cotton or linen laundry which
are still to be put through a ma-
chine, e.g. bedding, table linen.
mn
EASY CARES
EXTRA DRY 3kg • • • •
Drying thick or multi-layered tex-
tiles, e.g. pullovers, bedding, table
linen.
ml2)
n
2) Press the SPECIAL CARE button!
STORAGE
DRY 3kg • • • •
For thin textiles which are not
ironed, e.g. easy care shirts, table
linen, baby’s clothes, socks, under-
wear.
ml2)
n
DAMP 3kg • • • •
For thin textiles which are still to
be ironed, e.g. knitted items, cot-
ton shirts.
ml2)
n

11
Programme
max. loading volume (weight when dry)
Additional
functions
Application/properties Care
symbols
SPECIAL CARE1)
1) SPECIAL CARE and SENSITIVE cannot both be selected at the same time.
AUDIBLE SIGNAL SENSITIVE 1) INTENSITY
30 MIN 1kg • • - - For drying individual items of laundry
or for small volumes of less than 1kg.
ml2)
n
2) Press the SPECIAL CARE button!
LEISURE 6kg • • • •
Special programme for leisure cloth-
ing, such as jeans, sweat-shirts, etc.,
of different material thicknesses (e.g.
at the cuffs and seams).
mn
EASY IRON 1kg • • - -
Special programme with anti-crease
feature for easy care textiles such
shirts and blouses; for minimum iron-
ing effort. The result depends on the
type and quality of textiles. (The load-
ing volume corresponds to approx. 5
to 7 shirts.)
Recommendation: Place textiles in the
dryer straight after spinning. Once
dried, immediately remove textiles
and place on clothes hanger.
ml2)
n
WOOL CARE 1kg • • - -
Special programme for briefly treating
woollens with warm air after they
have been dried naturally, worn or
stored for long periods. Wool fibres
are aligned and the wool becomes
soft and snugly.
Recommendation: Remove textiles
immediately after drying.
REFRESH 1kg • • - -
Special programme, lasting around 35
minutes, for refreshing or gently
cleaning textiles with commercially
available dry cleaning sets.
(Only use those products which are
declared as suitable for the drier by
the manufacturer; please observe the
manufacturer’s instructions for use.)

12
Drying
Switching machine on / switching light on
Turn the programme selector to any programme or turn it to LIGHT. The
machine has been switched on. When the door is opened, the drum is
illuminated.
Opening loading door / filling laundry
1. Open loading door:
–Either press against the loading door push point
–or if the machine is switched on: Press the DOOR button.
2. Load your laundry (do not force it in/over load the machine).
1Caution! Be careful not to trap laundry in between the loading door
and rubber seal.
3. Close loading door securely. Lock must audibly lock.
Selecting the programme
Use the programme selector to set
the programme you require.
The probable programme run time
is displayed (in minutes) on the
multi-display.

13
Selecting additional functions
INTENSITY
Precise setting of humidity content
of laundry. Laundry becomes dryer
from + to +++.
1. Press the INTENSITY button as
many times as necessary until the
small light at the level of residual
dampness required is illuminated.
If required, press the SPECIAL
CARE, AUDIBLE SIGNAL or SENSI-
TIVE buttons.
SPECIAL CARE
For especially gentle drying of sensitive fabrics with the lcare label
and for temperature-sensitive textiles (e.g. acrylic, viscose). Programme
is executed with reduced heat.
SPECIAL CARE is only suitable for use with loads of up to 3kg!
AUDIBLE SIGNAL
When the drying cycle has finished, an intermittent audible signal will
sound.
SENSITIVE
For gentle drying of frequently-worn textiles. Programme starts on full
heat setting, which is then reduced towards the end of the programme
to ensure gentle care of laundry.
3SPECIAL CARE and SENSITIVE cannot be selected together.

14
Setting time delay
3With the DELAY TIMER button, you can delay the start of a programme
by between 30 minutes (30' and a maximum of 23 hours (23h).
1. Select the programme
2. Press the DELAY TIMER button as many times as necessary until the re-
quired start delay appears on the multi display, e.g. 12h if the pro-
gramme is to be started in 12 hours. The DELAY TIMER display is
illuminated.
3If 23h is displayed and you press the button again, the time delay will
be cancelled. The display will show 0' and then the duration of the se-
lected programme.
3. To activate the delay timer, press the START/PAUSE button. The amount
of time remaining until the programme is set to start is continuously
displayed (e.g. 12h, 11h, 10h, … 30'etc).
Starting the programme
Press the START/PAUSE button. The programme is started.
The programme progress display and the display showing the level of
dryness show drying progress.
Changing programme
To change a programme which has been selected by mistake once the
programme has started, first turn the programme selector to OFF and
then reset the programme.
3The programme can no longer be changed directly once the programme
has started. If nevertheless there is an attempt to change the pro-
gramme on the programme knob, the programme progress display and
the maintenance indicators flash. If an option button (excluding the
AUDIBLE SIGNAL button) is pressed, Err appears in the multidisplay.
The drying programme is not however affected by this (laundry protec-
tion).

15
Removing laundry or loading laundry when necessary
1. Open loading door
1Warning! Laundry and drum can become hot. Risk of burns!
2. Load or remove laundry items.
3. Close the door securely. Lock must audibly lock.
4. Press the START/PAUSE button to continue the drying cycle.
Drying cycle complete / removing laundry
Once the drying cycle is complete, the END and CREASE GUARD dis-
plays light up. If the AUDIBLE SIGNAL button has been pressed, an au-
dible signal sounds intermittently.
3The drying cycle is automatically followed by a crease guard phase
which lasts around 30 minutes. The drum rotates in intervals during
this phase. The laundry thereby remains relaxed and free of creases. The
laundry can be removed at any time during the crease guard phase.
(The laundry should be taken out towards the end of the crease guard
phase at the latest to prevent creases from forming.)
1. Open loading door
2. Before removing the laundry, remove lint from the micro-fine filter. It is
best to use a damp hand for this purpose (refer to “Cleaning and main-
tenance” section).
3. Remove laundry.
4. Turn the programme selector to OFF.
Important! After each drying cycle
–clean the micro-fine filter and fine strainer,
–drain the condensate tank
(refer to the “Cleaning and maintenance” section).
5. Close loading door.

16
Cleaning and maintenance
Cleaning lint filter
To ensure that the dryer works efficiently, the lint filters (micro-fine fil-
ter and fine strainer) must be cleaned after every drying cycle.
1Caution! Never operate the dryer without fluff filters or with damaged
or blocked fluff filters.
1. Open door
2. Use a damp hand to clean the mi-
cro-fine filter, which is built into
the lower part of the loading aper-
ture.
3. Push down unlock button on large
mesh filter.
Large mesh filter elevates.
4. Take out fine strainer.
5. Remove fluff from fine strainer. It
is best to use a damp hand for this
purpose.

17
Clean the entire filter area
3The strainer area does not have to be cleaned after every drying cycle,
but should be checked regularly and cleaned of fluff if necessary.
6. To do this, grip the top of the large
mesh filter and pull it forwards un-
til it comes loose from the two
brackets.
7. Remove fluff from the entire filter
area. It is best to use a vacuum
cleaner for this purpose.
8. Press both lugs of the large mesh
filter into the brackets on the load-
ing door until they snap into place.
9. Re-insert fine strainer.
10. Press against the large mesh filter
until it locks into the interlock.
3If the fine strainer is not fitted, the
large mesh filter will not snap into
place and the door cannot be
closed.
Cleaning the door seal
1. Wipe the door seal with a damp cloth immediately after the drying cy-
cle has finished.

18
Emptying the water reservoir
Empty water reservoir after every drying cycle.
If the water reservoir is full, an active programme will be interrupted
automatically and the EMPTY WATER display will light up. In order to
continue the programme, the water reservoir must be emptied.
1Warning! The condensed water is not suitable for drinking or for pre-
paring foodstuffs.
1. Take out drawer containing water
reservoir completely (1) and pull up
the water reservoir’s drainage pipe
as far as it will go (2).
2. Pour condensed water out into a
sink or other suitable container.
3. Slide outlet connections in and re-
fit water reservoir.
If the programme has been inter-
rupted as a result of the water res-
ervoir being full:
Press the START/PAUSE button to
continue the drying cycle.
3The water reservoir has a volume of approx. 4 litres. This is sufficient for
around 6kg of laundry which has previously been spun at 800 revolu-
tions/minute.
3The condensed water can be used as distilled water, e.g. for steam iron-
ing. However first filter it (e.g. with a coffee filter) to remove any resi-
due and small pieces of fluff.

19
Cleaning heat exchanger
If the HEAT EXCHANGER display is illuminated, the heat exchanger
needs to be cleaned.
1Caution! Operating when the heat exchanger is clogged with lint can
damage the dryer. This also increases energy consumption.
1. Open loading door
2. Open base door. To do this, press
the release button located beneath
the loading aperture and open the
base door to the left.
3. Remove lint from the inside of the
door and the heat exchange cham-
ber. Wipe the door seal with a
damp cloth.
4. Turn both lock washers inwards.
5. Use the handle to pull the heat ex-
changer out of the base and carry
it horizontally to prevent any re-
maining water from spilling.
6. To empty the heat exchanger, hold
vertically over a washing-up bowl.
1Caution! Do not use sharp objects
to clean the heat exchanger. You
could damage it an cause leaks.
7. Clean heat exchanger.
It is best to use a brush or to rinse thoroughly with a shower head.
8. Replace heat exchanger and lock into place (turn both lock washers
outwards until they snap into place).
9. Close base door.
3The dryer will not operate if the base door is not closed.
1Caution! Never operate the dryer without the heat exchanger.

20
Cleaning the drum
1Caution! Do not use abrasives or steel wool to clean the drum.
3Lime in the water or cleaning agents may form a barely visible lining on
the inside of the drum. The degree to which the laundry has been dried
is then no longer detected reliably. The laundry is damper than expect-
ed when removed from the dryer.
Use a damp cloth, which has been soaked in water and a little vinegar,
to wipe the inside of the drum and drum ribs.
Clean operating screen and housing
1Caution! Do not use furniture cleaners or aggressive cleaning agents to
clean the machine.
Use a damp cloth to wipe down the operating screen and housing.
What to do if …
Troubleshooting by yourself
If, during operation, the error code (Eplus number or letter) appears on
the multi-display: Switch the machine off and on again. Reset pro-
gramme. Press the START/PAUSE button
If the error is still displayed, please inform your local Service Force Cen-
tre and quote the error code.
Problem Possible cause Remedy
Dryer does not work.
Mains plug is not plugged in
or fuse is not working cor-
rectly.
Plug in at mains socket. Check
fuse in fuse box (domestic in-
stallation).
Loading door is open. Close loading door.
Base door is open. Close base door.
Have you pressed the START/
PAUSE button?
Press the START/PAUSE button
again.
