AEG B1269 User manual

1
231GR-m GB 949600674
INSTRUCTION BOOK
Ceramic griddle
GB

2
Your New Appliance
Thank you for purchasing an AEG appliance.
To enable you to use your new appliance efficiently and safely, please read
this instruction book carefully before installing or using the appliance, and
retain for future reference. Should the appliance be transferred to a new
owner please ensure this instruction book is left with the appliance in order
that the new owner can get to know the functions of the appliance and the
relevant warnings.
If you require further assistance or advice, please contact our Customer Care
Department either by letter or telephone:
Customer Care Department
AEG Domestic Appliances
55-77 High Street
Slough
SL1 1DZ
Tel: [phone]*
* calls to this number may be recorded for training purposes

3
Contents Page no
For the user
Your new appliance ...................................................................................... 2
Safety information ........................................................................................ 4
Description of the product ......................................................................... 5
Operating instructions ................................................................................ 6
Operating grill ....................................................................................... 6
Hints for using the ceramic glass griddle .............................................. 7
Cleaning and maintenance ......................................................................... 8
Splashguard .......................................................................................... 8
Stainless steel surfaces ......................................................................... 8
The ceramic glass griddle .....................................................................
Something not working ............................................................................. 14
Service & spare parts ............................................................................... 15
Guarantee conditions ................................................................................ 16
For the installer
Installation .................................................................................................. 10
Electrical connection ................................................................................. 12
echnical specifications ............................................................................ 13
Unpacking .................................................................................................. 13
Table of contents
1... 2...Step by step
Safety information
Hint and tips
Environmental information
How to read the operating instructions:

4
Safety information
These warnings are provided in the
interests of your safety. Ensure you
fully understand them before installing
or using the appliance. Your safety is of
paramount importance. If you are
unsure about the meaning of these
warnings contact the Customer Care
Department for assistance.
Installing
Do not install the appliance if the
ceramic glass is damaged or cracked.
This appliance must be installed
according to the instructions supplied.
Any electrical installation work must
be undertaken by a qualified
electrician/ competent person.
Do not alter the specifications or
attempt to modify the appliance in any
way.
During Use
The appliance is intended for domestic
cooking only. It is not designed for
commercial/industrial purposes.
Ensure that all the control knobs are in
the OFF position when not in use.
Do not use the appliance if it is
damaged in any way. If a fault or crack
becomes visible, disconnect the
appliance immediately from the
electricity supply and contact your
local AEG Service Force Centre.
Never use plastic or aluminium dishes
on the appliance.
Child Safety
Young children must not be allowed to
tamper with the appliance or play with
the controls.
The appliance gets hot when it is in
use. Children should be kept away
until the appliance has cooled.
Maintenance and Cleaning
Only clean this appliance in
accordance with the instructions given
in this book.
Service
Repairs carried out by inexperienced
persons may cause injury or serious
malfunction of the appliance. Repairs
must only be carried out by a
qualified/competent person. Contact
your local AEG Service Force Centre.
Disposal
Make the appliance unusable by
cutting off the cable.
Dispose of any packaging material and
old appliances at an authorised
disposal site.

5
Kontrolleuchte für die Kombi-Grill
Pilot light
Control knob
Description of the product
Ceramic glass griddle
Pilot light
Griddle control
knob

6
Operating instructions -
griddle
Griddle control knob
Variable griddle temperature
"1" - low heat
"9" - high heat
"0" - off
Control light
Operating instructions

7
Ceramic glass is insensitive to
temperature shock and very robust,
however it is not unbreakable. Hard
and sharp objects, in particular, can
damage the cooking surface if they fall
on it.
Warning
If visible cracks appear in the surface,
the appliance must be disconnected
from the mains immediately.
Spillages of plastics and other meltable
materials such as sugar and food
containing sugar (also applies to food
with a natural sugar content to which
no extra sugar has been added), such
as marmalade, jam, fruit juice, etc.
must be wiped off the ceramic surface
while still hot.
Failure to do this could cause the
griddle to peel and crack.
Use the enclosed glass scraper and
polish with a ceramic glass cream
cleaner afterwards.
Any cooking utensils which have been
into contact with the above mentioned
materials must be cleaned thoroughly
before being placed on the ceramic
surface.
The warranty does not cover
damage to the glass ceramic griddle
which can be attributed to any of the
above events.
Hints on the ceramic glass griddle

8
Cleaning and maintenance
For reasons of hygiene and
safety, the griddle must be
kept clean.
Grease stains and spilled
food generate smoke when
heated, and can even cause
fire.
Splashguard
The splashguard can be removed to
make it easier to clean the surface.
What to do:
1. Hold the splashguard as shown
in the diagram
2. Lift the splashguard straight up
3. Clean the top surface as
described in “cleaning the steel
surface”
Be aware of the two retaining
pegs, which are sharp.
4. Replace the splashguard in
position ENSURE that it is
fitted the correct way round.
Never use hard or sharp
implements to lift off the
splashguard.
Do not wash the splashguard
in a dishwasher.
The hob must not be used
with the splashguard off.

Stainless steel surfaces
Perform daily cleaning with a slightly
damp cloth. For more severe soiling,
use a liquid scouring cream. Always
clean the steel in the direction of the
steel finish. To ensure that the steel
retains its shine, it is recommended
that you use a polishing agent for
stainless steel on a regular basis.
Always polish in the direction of the
steel finish (cross-wise).
Never use steel wool, metal sponges or
other abrasive cleaning agents.
The ceramic glass griddle
The glass griddle must be cleaned each
time it has been used.
1. Pour water onto the glass griddle,
add a little washing-up liquid, and
scrape off as much as possible using
the scraper. Remove the dirty water
with kitchen roll.
2. Use the rough side of a scouring
sponge to apply more water and
detergent (washing-up liquid or
liquid scouring agent) to the glass
surface. Scour thoroughly.
3. Remove the dirty water with kitchen
roll.
4. Apply more water and washing-up
liquid, using the rough side of a
scouring sponge. Scour thoroughly.
5. Heat the glass griddle until the
water boils, brushing with a stiff
brush as you do so.
6. Switch off the glass griddle when
the water boils. Continue cleaning
with the stiff brush.
7. Allow the glass griddle to cool
(only cool enough so you can
touch it).
8. Remove the dirty water with
kitchen roll.
9. Wipe the surface with a clean, wet
cloth.
10. Wipe the surface with a dry cloth.
11. Apply a thin coat of cooking oil to
the glass griddle and rub in.

10
Installation
Caution: In order to avoid a hazard this
appliance must be installed according to
these instructions for installation
The appliance unit can be mounted in
any type of kitchen with a work top
whose thickness is between 28 mm and
40 mm.
Clearance
The distance between the top side of the
work top and the carpentry underneath
must be at least 47 mm.
Fixing
Screw the fixing brackets out to such an
extent that they can be turned in under
the work top. Tighten the brackets on to
the work top with an ordinary
screwdriver.
Cut-out measurements
One rectangular hole is sawn out for the
appliance combination chosen.
The depth of the cut-out for any unit is:
490 mm
Length of hole = sum of all units`
externally measured length, less 20 mm.
Mounting of Reinforcement
Beams
A reinforcement Beam, with supporting
flanges at each end, is included with
each two-burner unit. For unit
combinations, a reinforcement beam
must be used between each unit.
Min. 47 mm
Minimum distance
to side wall:
150 mm
Minimum distance
to rear wall (non-
flammable material):
150 mm
Reinforcement
beams
