AEG 34942G User manual

AUS ERFAHRUNG GUT
34942G/35940G/35941G/35944G
Gas hob
Table de cuisson
Gaskookplaat
Piano di cottura
Operating and Installation Instructions GB
Notice dutilisation et dencastrement FR
Gebruiksaanwij ing
en Installatievoorschrift
Istru ioni per luso e linstalla ione IT
NL
All manuals and user guides at all-guides.com
all-guides.com

2
Important Safety Information
You MUST read these warnings carefully before installing or using the
hob. If you need assistance, contact our Customer Care Department on
87 5 35 35
Installation
lThis hob must be installed by qualified personnel, according to the
manufacturers instructions and to the relevant British Standards.
lAny gas installation must be carried out by a registered C RGI installer.
lRemove all packaging before using the hob.
lEnsure that the gas and electrical supply complies with the type stated on
the rating plate, located near the gas supply pipe.
lDo not attempt to modify the hob in any way.
Child Safety
lThis hob is designed to be operated by adults. Do not allow children to
play near or with the hob.
lThe hob gets hot when it is in use. Children should be kept away until it has
cooled.
lChildren can also injure themselves by pulling pans or pots off the hob.
During Use
lThis hob is intended for domestic cooking only. It is not designed for
commercial or industrial purposes.
lWhen in use a gas cooking hob will produce heat and moisture in the
ENGLISH GB
All manuals and user guides at all-guides.com

3
room in which it has been installed. Ensure there is a continuous air supply,
keeping air vents in good condition or installing a cooker hood with a venting
hose.
lWhen using the hob for a long period of time, the ventilation should be
improved, by opening a window or increasing the extractor speed.
lDo not use this hob if it is in contact with water. Do not operate the hob with
wet hands.
lEnsure the control knobs are in the  FF position when not in use.
lWhen using other electrical appliances, ensure the cable does not come
into contact with the hot surfaces of the cooking appliance.
lUnstable or misshapen pans should not be used on the hob as unstable
pans can cause an accident by tipping or spillage.
lNever leave the hob unattended when cooking with oil and fats.
lNever use plastic or aluminium foil dishes on the hob.
lPerishable food, plastic items and areosols may be affected by heat and
should not be stored above or below the hob unit.
Service
lThis hob should only be repaired or serviced by an authorised Service
Engineer and only genuine approved spare parts should be used.
Environmental Information
lAfter installation, please dispose of the packaging with due regard to safety
and the environment.
lWhen disposing of an old appliance, make it unusable, by cutting off the
cable.
Keep this instruction book for future reference and ensure
it is passed on to any new owner.
These instructions are only valid for countries whose identification
symbols are shown on the inside cover of this instruction booklet and on
the appliance itself.
All manuals and user guides at all-guides.com

4
Contents
Important Safety Information ...................................................... 2
Instructions for the User .............................................................. 6
Description of the Hob .................................................................. 6
Operation .................................................................................... 7
Maintenance and Cleaning ............................................................ 8
The Hob Top ........................................................................ 8
Pan Supports ....................................................................... 8
The Burners ......................................................................... 8
So ething Not Working? .............................................................. 9
Service and Spare Parts ............................................................... 10
Guarantee Conditions ..................................................................11
Instructions for the Installer ...................................................... 12
Engineers technical data ............................................................. 12
I portant safety require ents ..................................................... 14
Location .................................................................................... 14
Installation ................................................................................ 15
Gas Connection ................................................................. 16
Cut Out Size ...................................................................... 17
Building In ........................................................................ 17
Building over a cupboard or drawer ................................. 17
Building over a kitchen unit with door ............................. 18
Fitting the hob to the worktop ........................................ 19
Electrical connections ................................................................. 20
Per anent Connection ....................................................... 21
Wiring diagra .................................................................. 21
Fault Finding .............................................................................. 22
Preli inary Electrical Syste s Check .................................... 22
Ignition Syste / Gas Ignition ............................................. 24
Co issioning ........................................................................... 25
Pressure Testing ................................................................. 25
Servicing ................................................................................... 26
Conversion fro Natural Gas to LPG ............................................. 27
All manuals and user guides at all-guides.com

5
This appliance is manufactured according to
the following EEC directives:
73/23 EEC - 90/683 EEC - 93/68 EEC -
89/336 EEC - 90/396 EEC,
current edition.
Guide to Use the instructions
The following symbols will be found in the text to guide you throughout the
Instructions:
Safety Instructions
Step by step instructions for an
operation
Hints and Tips
F
All manuals and user guides at all-guides.com

6
1. Hob Top
2. Rapid Burner
3. Semi-rapid Burners
4. Double-crown Burner
5. Auxiliary Burner
6. Control knob for back left burner (semi-rapid)
7. Control knob for back right burner (semi-rapid)
8. Control knob for front right burner (auxiliary)
9. Control knob for central burner (double-crown)
10. Control knob for front right burner (rapid)
Description of the Hob (Mod. 34942 G)
I STALLATIO
Any gas installation must be carried out by a registered CORGI
installer, and in accordance with existing rules and regulations.
The relevant instructions are to be found in the second section of this
manual.
Please, ensure that, once the hob is installed, it is easily accessible for
the engineer in the event of a breakdown.
WHE THE HOB IS FIRST I STALLED
nce the hob has been installed, it is important to remove any
protective materials, which were put on in the factory.
7
8
9
10
123
5
3
4
6
All manuals and user guides at all-guides.com
all-guides.com

7
HOB BUR ERS
To light a burner, turn the relevant control knob anticlockwise to
the maximum position ( ), then push it down to ignite the
burner. Upon, ignition, adjust the flame as required.
If the burner does not ignite, turn the control knob to zero, and
try again.
When switching on the mains, after installation or a power cut, it
is quite normal for the spark generator to be activated
automatically.
To ensure maximum burner efficiency, you should only use pots
and pans with a flat bottom fitting the size of the burner used
(see table).
Burner minimum maximum
diameter diameter
Double-crown 180 mm. 260 mm.
Large (rapid) 180 mm. 260 mm.
Medium (semi-rapid) 120 mm. 220 mm.
Small (Auxiliary) 80 mm. 160 mm.
Operation
As soon as a liquid starts boiling, turn down the flame so that it will
barely keep the liquid simmering.
If you use a saucepan which is smaller than the recommended size,
the flame will spread beyond the bottom of the essel, causing the
handle to o erheat.
Take care when frying food in hot oil or fat, as the o erheated
splashes could easily ignite
If the control knobs become difficult to turn, please contact your local
AEG Ser ice Force Centre.
All manuals and user guides at all-guides.com

8
Before any maintenance or cleaning can be carried out, you must
DISCONNECT the hob from the electricity supply.
The hob is best cleaned whilst it is still warm, as spillage can be
removed more easily than if it is left to cool.
The Hob Top
Regularly wipe over the hob top using a soft cloth well wrung out in
warm water to which a little washing up liquid has been added. Avoid
the use of the following:
- household detergent and bleaches;
- impregnated pads unsuitable for non-stick saucepans;
- steel wool pads;
- bath/sink stain removers.
Should the hob top become heavily soiled, it is recommended that a
cleaning product such as Hob Brite or Bar Keepers Friend is used.
Pan Supports
When washing the pan supports by hand, take care when drying them
as the enamelling process occasionally leaves rough edges. If necessary,
remove stubborn stains using a paste cleaner.
The Burners
The burner caps and crowns can be removed for cleaning.
Wash the burner caps and crowns using hot soapy water, and remove
marks with a mild paste cleaner. A well moistened soap impregnated
steel wool pad can be used with caution, if the marks are particularly
difficult to remove.
After cleaning, be sure to wipe dry with a soft cloth.
Maintenance and Cleaning
All manuals and user guides at all-guides.com

9
Something Not Working?
If the hob is not working correctly, please carry out the following checks
before contacting your local AEG Service Force Centre.
SYMPT M
nThere is no spark when lighting
the gas
nThe gas ring burns unevenly
S LUTI N
uCheck that the unit is plugged in
and the electrical supply is
switched on
uCheck that the RCCB has not
tripped (if fitted)
uCheck the mains fuse has not
blown
uCheck the burner cap and crown
have been replaced correctly, e.g.
after cleaning.
uCheck the main jet is not blocked
and the burner crown is clear of
food particles.
uCheck the burner cap and crown
have been replaced correctly, e.g.
after cleaning.
If after all these checks, your hob still does not operate correctly, contact
your local AEG Service Force Centre.
Please note that it will be necessary to provide proof of purchase for any in-
guarantee service calls.
In-guarantee customers should ensure that the above checks have been
made as the engineer will make a charge if the fault is not a mechanical or
electrical breakdown.
All manuals and user guides at all-guides.com

10
Service and Spare Parts
When you contact the Service Centre, they will need the following
information:
1. Your name, address and post code.
2. Your telephone number
3. Clear and concise details of the fault
4. The model and the serial number (see rating label on the back of this
instruction booklet)
5. Date of purchase
If you require spare parts or an engineer contact your local Service
Force Centre by telephoning:
0870 5 929 929
Your call will be routed to your local Service Force Centre.
For the address of your local Service Force Centre and further
information about Service Force, please visit the website at
www.serviceforce.co.uk
CUSTOMER CARE
For general enquiries concerning your AEG appliance and for further
information on AEG products, contact our Customer Care Department
by letter or telephone at the address below or visit our website at
www.aeg.co.uk
Customer Care Department
AEG Domestic Appliances
55 - 77 High Street
Slough
Berkshire
SL1 1DZ
Tel : [phone]*
* calls to this number may be recorded for training purposes.
All manuals and user guides at all-guides.com

11
Guarantee Conditions
Standard guarantee conditions
We, AEG, undertake that if within 12 months of the date of the purchase this AEG appliance or
any part thereof is proved to be defective by reason only of faulty workmanship or materials, we
will, at our discretion repair or replace the same FREE F CHARGE for labour, materials or
carriage on condition that:
·The appliance has been correctly installed and used only on the electricity or gas supply
stated on the rating plate.
·The appliance has been used for normal domestic purposes only, and in accordance with
the manufacturers operating and maintenance instructions.
·· The appliance has not been serviced, maintained, repaired, taken apart or tampered with
by any person not authorised by us.
·All service work under this guarantee must be undertaken by a Service Force Centre. Any
appliance or defective part replaced shall become the Companys property.
·This guarantee is in addition to your statutory and other legal rights.
·Home visits are made between 8.30am and 5.30pm Monday to Friday. Visits may be available
outside these hours in which case a premium will be charged.
Exclusions
This guarantee does not cover:
·Damage or calls resulting from transportation, improper use or neglect, the replacement of
any light bulbs or removable parts of glass or plastic.
·Costs incurred for calls to put right an appliance which is improperly installed or calls to
appliances outside the United Kingdom.
·Appliances found to be in use within a commercial environment, plus those which are subject
to rental agreements.
·Products of AEG manufacture which are not marketed by AEG.
European Guarantee
If you should move to another country within Europe then your guarantee moves with you to your
new home subject to the following qualifications:
·The guarantee starts from the date you first purchased your product.
·The guarantee is for the same period and to the same extent for labour and parts as exists in
the new
country of use for this brand or range of products.
·This guarantee relates to you and cannot be transferred to another user.
·Your new home is within the European Community (EC) or European Free Trade Area.
·The product is installed and used in accordance with our instructions and is only used
domestically, i.e. a normal household.
·The product is installed taking into account regulations in your new country.
Before you move, please contact your nearest Customer Care centre, listed below, to give them
details of your new home. They will then ensure that the local Service rganisation is aware of
your move and able to look after you and your appliances.
France Senlis [phone]
Germany Nürnberg [phone]
Italy Pordenone [phone]
Sweden Stockholm [phone]
UK Slough [phone]
All manuals and user guides at all-guides.com
all-guides.com

12
OVERALL DIMENSIONS Width: 860 mm.
Depth: 500 mm.
Height: 88 mm.
Weight: 16 Kg.
CUT OUT DIMENSIONS Width: 830 mm.
Depth: 470 mm.
Thickness: 30 mm.
SUPPLY CONNECTIONS Gas:
RC 1/2 inch (1/2 inch male) Rear right hand corner
Electric:
230-240V 50Hz supply, 3 core flexible cable with
non rewireable plug fitted with a 3 amp cartridge fuse.
IGNITION HT SPARK Spark Generator
Ispra Control's BF 50066 - 230-240V 0.6 YA T120
Spark Gap : Fixed
HEAT INPUT
Rear Left Burner (semi rapid) 2.0 kW (6824 BTU/HR)
Front Left Burner (rapid) 3.0 kW Natural Gas (10236 BTU/HR)
2.8 kW L.P.G. (9554 BTU/HR)
Central Burner (double-crown) 3,5 kW (11942 BTU/HR)
Rear Right Burner (semi rapid) 2.0 kW (6824 BTU/HR)
Front Right Burner
(auxiliary) 1.0 kW (3412 BTU/HR)
APPLIANCE CLASS 3
APPLIANCE CATEGORY II2H3+
GAS SUPPLY Natural gas G20 / 20mbar
Instructions for the Installer
Engineers technical data
All manuals and user guides at all-guides.com

13
Burner Dia. Tap By-pass
1/100 mm
Auxiliary 28
Semi-rapid 32
Rapid 40
ouble-Crown 56
Aeration adjustment none
BURNER RAP D SEM -RAP D AUX L ARY DOUBLE
(large) (medium) (small) CROWN
POS T ON MAX M N MAX M N MAX M N MAX M N
N MINAL THERMAL
P WER kW 3.0 0.65 2.0 0.45 1.0 0.33 3.5 1.2
N MINAL FL W
RATE m
3
/h 0.286 0.057 0.190 0.038 0.095 0.028 0.333 0.114
N ZZLE REFERENCE 119 Adjust. 96 Adjust. 70 Adjust. 136 Adjust.
1/100 mm
N MINAL THERMAL
P WER kW 2.8 0.65 2.0 0.45 1.0 0.33 3.5 1.2
N MINAL FL W
RATE g/h 202 43.5 144 29 72 21,5 252 86
N ZZLE REFERENCE 86 40 71 32 50 28 93 56
1/100 mm
NATURAL GAS
20 mbar
VALUE =
37.78 MJ/m
3
Ws - 50.7 MJ/ m
3
TYPE OF GAS
LPG GAS
28-30/37 mbar
VALUE =
49.92 MJ/Kg
Instructions for the Installer
All manuals and user guides at all-guides.com

14
Important safet requirements
This hob must be installed in accordance with the Gas Safety
(Installation and Use) Regulations (Current Edition) and the IEE Wiring
Regulations (Current Edition).
Detailed recommendations are contained in the following British
Standards Codes f Practice: B.S. 6172/ B.S. 5440, Par. 2 and B.S. 6891
Current Editions.
The hob should not be installed in a bed sitting room with a volume of
less than 20 m3. If it is installed in a room of volume less than 5 m3 an
air vent of effective area of 110 cm2 is required. If it is installed in a
room of volume between 5 m3 and 10 m3 an air vent of effective area
of 50 cm2 is required, while if the volume exceeds 11 m3 no air vent is
required.
However, if the room has a door which opens directly to the outside
no air vent is required even if the volume is between 5 m3 and 11 m3.
If there are other fuel burning appliances in the same room, B.S. 5440
Part 2 Current Edition, should be consulted to determine the requisite
air vent requirements.
Location
The hob may be located in a kitchen, a kitchen/diner or bed sitting
room, but not in a bathroom or shower room.
Before making the cut out in the worktop ensure that there is a
minimum distance of 55 mm. between the rear edge of the hob and
the wall.
A minimum distance of 100 mm. must be left between the side edges
of the hob and any adjacent cabinets or walls.
The minimum distance combustible material can be fitted above the
hob in line with the edges of the hob is 400 mm. If it is fitted below
400 mm. a space of 50 mm. must be allowed from the edges of the
hob.
The minimum distance combustible material can be fitted directly
above the hob is 700 mm.
All manuals and user guides at all-guides.com

15
CLEARANCES REQUIRED
WHEN FITTING THE GAS HOB
WITHOUT A COOKER HOOD ABOVE
CLEARANCES REQUIRED
WHEN FITTING THE GAS HOB
WITH A COOKER HOOD ABOVE
Installation
IMP RTANT
This hob must be installed by qualified personnel to the relevant
British Standards.
Any gas installation must be carried out by a CORGI registered
installer.
The manufacturer will not acce t liability, should the above
instructions or any of the other safety instructions incor orated
in this book be ignored.
700 mm
420 mm
100 mm
420 mm
50 mm
50 mm
55 mm
650 mm
420 mm
420 mm
100 mm
50 mm
50 mm
55 mm
FO 2027* FO 2028*
700 mm
Installation
All manuals and user guides at all-guides.com

16
A) End of shaft with nut
B) Washer
C) Elbow
FO 0814
FO 0264
n the end of the shaft, which includes the G 1/2" threaded elbow,
adjustment is fixed so that the washer is fitted between the components
as shown in the diagram. Screw the parts together without using
excessive force.
It is im ortant to install the elbow correctly, with the shoulder on
the end of the thread, fitted to the hob connecting i e.
Failure to ensure the correct assembly will cause leakage of gas.
Gas Connection
Connection to the gas supply should be with either rigid or semi-rigid
pipe, i.e. steel or copper.
The connection should be suitable for connecting to RC 1/2 (1/2 BSP
male thread).
When the final connection has been made, it is essential that a thorough
leak test is carried out on the hob and installation.
Ensure that the main connection pipe does not exert any strain on the
hob.
Installation
All manuals and user guides at all-guides.com
all-guides.com

17
830
470
55 min.
860
500
FO 2407
Cut Out Size
The dimensions of the cut-out are given in the diagram.
Building In
Building over a cupboard or drawer
If the hob is to be installed above a cupboard or drawer it will be
necessary to fit a heat resistant board below the base of the hob on
the underside of the work surface.
It is also recommended to carry out the electrical connection to the
hob as shown in diagrams 1 and 2 (see next page).
Building in
All manuals and user guides at all-guides.com

18
ON/OFF SWITCH
FLEX
OUTLET
ON/OFF SWITCH
FLEX
OUTLET
FO 0763 FO 0764
12
Building over a kitchen unit with door
Proper arrangements must be
taken in designing the furniture
unit, in order to avoid any contact
with the bottom of the hob which
can be heated when it is operated.
The recommended solution is
shown in diagram 3.
The panel fitted under the hob
("a") should be easily removable
to allow easy access if technical
assistance is needed. The space
behind the kitchen unit ("b") can
be used for connections.
30
20 min
60 a
b
FO 1013
3
Dimensions are given in mm.
Building in
All manuals and user guides at all-guides.com

19
Building in
Fitting the hob to the worktop
Before fitting the hob into the
cut out, a sealing gasket
supplied with the hob must be
fitted to the edge of the cut
out. It is essential that no gaps
are left in this seal in order to
prevent spillage near the hob
seeping into the cabinet below.
1) Place the sealing
gasket all around the
edge of the cut out.
2) Place the hob into
the cut out and
secure it by means of
the relevant fixing
clamps and screws, as
shown in the diagram.
3) Remove the excess seal
The edge of the hob forms a double seal which prevents the ingress of
liquids.
FO 0199
a
Seal
F
All manuals and user guides at all-guides.com

20
Electrical connections
Any electrical work required to install this hob should be carried out
by a qualified electrician or competent person, in accordance with the
current regulations.
THIS H B MUST BE EARTHED.
The manufacturer declines any liability should these safety measures not be
observed.
This hob is designed to be connected to a 230-240V 50Hz AC electrical
supply.
Before switching on, make sure the electricity supply voltage is the same as
that indicated on the hob rating plate. The rating plate is located on the
bottom of the hob. A copy is attached on the back cover of this book.
The hob is supplied with a 3 core flexible supply cord incorporating a 3amp
plug fitted. In the event of having to change the fuse, a 3amp ASTA
approved (BS 1362) fuse must be used.
Should the plug need to be replaced for
any reason, the wires in the mains lead
are coloured in accordance with the
following code:
Green and Yellow - Earth
Blue - Neutral
Brown - Live
1) Connect the green and yellow
(earth) wire to the terminal in the plug which is marked with the
letter 'E' or the earth symbol or coloured green and yellow.
2) Connect the blue (neutral) wire to the terminal in the plug which is
marked with the letter 'N' or coloured black.
3) Connect the brown (live) wire to the terminal in the plug which is
marked with the letter 'L' or coloured red.
Upon completion there must be no cut, or stray strands of wire present and
the cord clamp must be secure over the outer sheath.
In the event of having to change the fuse, a 3amp ASTA approved (BS 1362)
fuse must be used.
A cut off plug inserted into a 13 amp socket is a serious safety
(shock) hazard. Ensure that the cut off plug is disposed of safely.
FO 0390
F
All manuals and user guides at all-guides.com
