AEG 96901K-MN User manual

96901K-MN
Ceramic glass hob
Table de cuisson vitrocéramique
Glaskeramische kookplaat
Installation and Operating Instructions
Instructions de montage et mode d’emploi
Montage- en gebruiksaanwijzing

2
Dear Customer,
Please read these user instructions carefully and keep them to refer to
later.
Please pass the user instructions on to any future owner of the appli-
ance.
The following symbols are used in the text:
1Safety instructions
Warning! Information that affects your personal safety.
Important! Information that prevents damage to the appliance.
3Useful tips and hints
2Environmental information

3
Contents
Operating Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Safety instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Description of the Appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Cooking surface layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Control panel layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Touch Control sensor fields. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Residual heat indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Operating the appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Switching the appliance on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Setting the heat setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Switching the outside ring on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Switching the STOP+GO function on and off. . . . . . . . . . . . . . . . . . . . . . . . . 9
Locking/unlocking the control panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Using the automatic warm-up function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Using the child safety device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Using the timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Safety cut-out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Power-Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Tips on Cooking and Frying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Cookware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Energy saving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Examples of cooking applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Cleaning and Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
What to do if … . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Guarantee/Customer Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

4
Operating Instructions
1Safety instructions
3Please comply with these instructions. If you do not, any damage re-
sulting is not covered by the warranty.
5This appliance conforms with the following EU Directives:
–73/23/EEC dated 19.02.1973 Low Voltage Directive
–89/336/EEC dated 03.05.1989 EMC Directive inclusive of Amending
Directive 92/31/EEC
–93/68/EEC dated 22.07.1993 CE Marking Directive
Correct use
•This appliance should be used only for normal domestic cooking and
frying of food.
•The appliance must not be used as a work surface or as a storage sur-
face.
•Additions or modifications to the appliance are not permitted.
•Do not place or store flammable liquids, highly inflammable materials
or fusible objects (e.g. plastic film, plastic, aluminium) on or near the
appliance.
Children’s safety
•Small children must be kept away from the appliance.
•Only let bigger children work on the appliance under supervision.
•To avoid small children and pets unintentionally switching the appli-
ance on, we recommend activation of the child safety device.
General safety
•The appliance may only be installed and connected by trained, regis-
tered service engineers.
•Built-in appliances may only be used after they have built in to suita-
ble built-in units and work surfaces that meet standards.
•In the event of faults with the appliance or damage to the glass ce-
ramic (cracks, scratches or splits), the appliance must be switched off
and disconnected from the electrical supply, to prevent the possibility
of an electric shock.
•Repairs to the appliance must only be carried out by trained regis-
tered service engineers.

5
Safety during use
•Overheated fats and oils can ignite quickly. When cooking with fat or
oil (e.g. chips) do not leave the appliance unattended.
•There is the risk of burns from the appliance if used carelessly.
•Remove stickers and film from the glass ceramic.
•Cables from electrical appliances must not touch the hot surface of
the appliance or hot cookware.
•Switch the cooking zones off after each use.
Safety when cleaning
•For cleaning, the appliance must be switched off and cooled down.
•For safety reasons, the cleaning of the appliance with steam jet or
high-pressure cleaning equipment is not permitted.
How to avoid damage to the appliance
•The glass ceramic can be damaged by objects falling onto it.
•The edge of the glass ceramic can be damaged by being knocked by
the cookware.
•Cookware made of cast iron, cast aluminium or with damaged bot-
toms can scratch the glass ceramic if pushed across the surface.
•Objects that melt and things that boil over can burn onto the glass
ceramic and should be removed straightaway.
•To avoid damaging cookware and glass ceramics, do not allow sauce-
pans or frying pans to boil dry.
•Do not use the cooking zones with empty cookware or without cook-
ware.

6
Description of the Appliance
Cooking surface layout
Control panel layout
.................
Single cooking zone
1800W
Multi-purpose zone
1400/2200W
Single cooking zone
1200W
Control panel Single cooking zone
1800W
Triple ring cooking zone
1050/1950/2700W
Triple ring pilot light
Timer display
Cooking zone indicators
Timer function
On/Off
with power indicator Heat setting selection
Lock
Double ring
pilot light
Outside/middle ring
On/Off
Display
STOP+GO Outside
ring
On/Off

7
Touch Control sensor fields
The appliance is operated using Touch Control sensor fields. Functions
are controlled by touching sensor fields and confirmed by displays and
acoustic signals.
Touch the sensor fields from above, without covering other sensor
fields.
Displays
Sensor field Function
On / Off To switch the appliance on and off
Increase settings Increasing heat setting/time
Decrease settings Decreasing heat setting/time
TIMER Timer Timer selection
Lock Locking/unlocking the control panel
Stop+Go To switch the Keep Warm setting on/
off
Triple ring switch To switch outer rings
on and off
Multi-purpose zone
switch To switch the outside ring on and off
Display Description
¾Cooking zone is switched off
uKeep warm setting Keep warm setting/STOP+GO func-
tion is set
¿- ÇHeat settings Heat setting is set
2- 6Heating setting plus
decimal point Intermediate heat setting is set
aAutomatic warm up
function Automatic warm-up function is acti- vated
eFault Malfunction has occurred
hResidual heat Cooking zone is still hot
lChild safety device Lock/child safety device is engaged
_Safety cut-out Safety cut-out has been activated

8
Residual heat indicator
1Warning! Risk of burns from residual heat. After being switched off,
the cooking zones need some time to cool down. Look at the residual
heat indicator h.
3Residual heat can be used for melting and keeping food warm.
Operating the appliance
Switching the appliance on and off
3After switching on, within approx. 10 seconds a heat setting or a func-
tion must be set, otherwise the appliance automatically switches itself
off.
Setting the heat setting
3The keep warm setting ulies between ¾and ¿. It is used to keep
food warm.
Control panel Display Pilot light
Switch on Touch for 2 seconds ¾/ hlights up
Switch off Touch for 1 second h/ none goes out
Control panel Indicator
To increase Touch uto Ç
To decrease Touch Çto ¾
To switch off Touch and at the same time ¾

9
Switching the outside ring on and off
By switching the outside rings on or off, the effective heating surface
can be matched to the size of the cookware.
3Before an outside ring can be switched on, the inside ring must be
switched on.
Switching the STOP+GO function on and off
The STOP+GO function simultaneously switches all cooking zones that
are switched on to the keep warm setting and then back to the heat
setting that was previously set. This function can be used to briefly in-
terrupt and then continue the cooking process e.g. to take a telephone
call.
3Timer functions are not stopped by STOP+GO.
3STOP+GO locks the whole control panel except the sensor field .
Triple cooking zone Sensor panel Power indicator
To switch on middle ring Touch for 1-2 seconds.One power indicator is lit.
To switch on outside ring Touch for 1-2 seconds.Two power indicators are
lit.
To switch off outside ring Touch for 1-2 seconds.Second power indicator
goes out.
To switch off middle ring Touch for 1-2 seconds.First power indicator goes
out.
Roasting zone Sensor panel Power indicator
To switch on outside ring Touch for 1-2 sec-
onds is lit
To switch off outside ring Touch for 1-2 seconds goes out
Control panel Display
To switch
on Touch STOP+GO u
To switch
off Touch STOP+GO heat setting that was previ- ously set (not automatic
warm up function)

10
Locking/unlocking the control panel
The control panel, with the exception of the “On/Off” sensor field, can
be locked at any time in order to prevent the settings being changed
e.g. by wiping over the panel with a cloth.
3When you switch the appliance off, the locking function is automati-
cally switched off.
Using the automatic warm-up function
All cooking zones are equpped with an automatic warm up function
When setting a heat setting using , when starting from ¾, the cook-
ing zone switches to full power for a certain amount of time and then
automatically switches back to the heat setting set.
3If during the automatic warm up aa higher heat setting is selected,
e.g. from Áto Ã, the automatic warm up is adjusted.
3If there is still residual heat on the cooking zone (display h), the auto-
matic warm up is not performed.
Control panel Display
Switch on Touch l(for 5 seconds)
Switch off Touch previously set heat setting
Control
panel possible heat set-
tings
Display
Switch on
(only when starting at
¾)
Touch ¿to Æ a (after 5 sec-
onds)
Switch off Touch Æto ¿/ uÆto u
Not used Touch Çto u Ç to u

11
The length of time that the automatic warm up function operates de-
pends on the heat setting selected.
Heat
setting Length of the automatic warm up
[min:sec]
Intermedi-
ate heat
setting
Length of the
automatic warm up
[min:sec]
v0:30
11:00
21:40 2. 2:40
34:50 3. 5:30
46:30 4. 8:10
510:10 5. 12:20
62:00 6. 2:30
73:30
84:30
9---

12
Using the child safety device
The child safety device prevents unintentional use of the appliance.
Setting the child safety device
Releasing the child safety device
Overriding the child safety device
The child safety device can be released in this way for a single cooking
session; it remains activated afterwards.
Step Control panel Display/Signal
1. Switch on the appliance
(Do not set a heat setting)
¾
2. Touch until the signal sounds Acoustic signal
3. Touch l
Appliance switches off. The child safety device is engaged.
Step Control panel Display/Signal
1. Switch on the appliance l
2. Touch until the signal sounds Acoustic signal
3. Touch
Appliance switches off. The child safety device is released.
Step Control panel Display/Signal
1. Switch on the appliance l
2. Touch and at the same time ¾/ acoustic signal
Until the appliance is next switched off, it can used as normal.

13
Using the timer
All cooking zones can use each use one of the two timer functions at
the same time.
3If a cooking zone is switched off, the timer function set is also switched
off.
3If a heat setting is set on this cooking zone in addition to a countdown
timer, the cooking zone is switched off after the time set has elapsed.
Selecting a cooking zone
Function Condition Outcome after the
time has elapsed
Automatic cut-out a heat setting is set acoustic signal
00 flashes
Cooking zone
switches off
Countdown timer cooking zones not in use acoustic signal
00 flashes
Step Control panel Indicator
1. Touch TIMER 1x Pilot light for the first
cooking zone flashes
2. Touch TIMER 1x Pilot light for the sec-
ond cooking zone flash-
es
3. Touch TIMER 1x Pilot light for the third
cooking zone flashes
4. Touch TIMER 1x Pilot light for the
fourth cooking zone
flashes
5. Touch TIMER 1x Pilot light for the fifth
cooking zone flashes

14
3The heat setting indicator of the selected cooking zone goes out, until
the timer time is set.
3If the power indicator is flashing more slowly, the heat setting indicator
appears again and the heat setting can be re-set or modified.
3If other timer functions are set, after a few seconds the shortest re-
maining time of all the timer functions is displayed and the corre-
sponding pilot light flashes.
Setting the time
Switching off the timer function
Step Control panel field Display
1. TIMER Select cook-
ing zone Pilot light of the cooking zone select- ed flashes
2. Touch or for
the cooking zone se-
lected
00 to 99 minutes
After a few seconds the pilot light flashes more slowly.
The time is set.
The time counts down.
Step Control panel field Display
1. TIMER Select cook-
ing zone Pilot light of the cooking zone select- ed flashes faster
The time remaining is displayed
2. Touch for the
cooking zone select-
ed
The time remaining counts down to
00.
The pilot light goes out.
The timer function for the selected cooking zone is switched off.

15
Changing the time
Displaying the time remaining for a cooking zone
Switching off the acoustic signal
Step Control panel field Display
1. TIMER Select cook-
ing zone Pilot light of the cooking zone select- ed flashes faster
The time remaining is displayed
2. Touch or for
the cooking zone se-
lected
01 to 99 minutes
After a few seconds the pilot light flashes more slowly.
The time is set.
The time counts down.
Step Control panel field Display
1. TIMER Select cooking
zone Pilot light of the cooking zone select- ed flashes faster
The time remaining is displayed
After a few seconds the pilot light flashes more slowly.
Step Control panel field Acoustic signal
1. Touch TIMER Acoustic signal to acknowledge.
Acoustic signal stops.

16
Safety cut-out
Cooking surface
•If after switching on the cooking surface, a heat setting is not set for
a cooking zone within approx. 10 seconds, the cooking surface auto-
matically switches itself off.
•If one or more sensor fields are covered for longer than approx. 10
seconds, e.g. by a pan placed upon it, a signal sounds and the cooking
surface switches off automatically.
•If all cooking zones are switched off, the cooking surface automati-
cally switches itself off after approx. 10 seconds.
Control panel
•When the appliance is switched off, if one or more of the sensor
fields on the control panel are covered for more that 10 seconds, an
acoustic signal sounds. The acoustic signal switches itself off auto-
matically when the sensor fields are no longer covered.
Cooking zones
•If one of the cooking zones is not switched off after a certain time, or
if the heat setting is not modified, the relevant cooking zone switches
off automatically.
Heat setting Switches off after
V, 1 - 26 hours
3- 45 hours
54 hours
6- 91.5 hours

17
Power-Management
The three cooking zones front left,
front right and back right together
have a maximum possible power
available to them.
If it looks like the maximum power
of all three cooking zones is going
to be exceeded, for example by
turning on an additional cooking
zone or by turning up a heat setting, the Power Management automat-
ically reduces the power of another cooking zone. The power of the
cooking zone that has been switched on for the longest time is re-
duced. For two minutes the indicator for this cooking zone changes be-
tween the previously set heat setting and the maximum possible heat
setting at this time. After two minutes the actual heat setting is dis-
played.
The following table shows the distribution of the maximum possible
heat settings when all three cooking zones are on at the same time.
1st cooking zone 2nd cooking zone
1 - 6 8 9
7 7 9
8 8 8

18
Tips on Cooking and Frying
3Information on acrylamides
According to the latest scientific knowledge, intensive browning of
food, especially in products containing starch, can constitute a health
risk due to acrylamides. Therefore we recommend cooking at the lowest
possible temperatures and not browning foods too much.
Cookware
•You can recognise good cookware from the bottoms of the pans. The
bottom should be as thick and flat as possible.
•Cookware made of enamelled steel or with aluminium or copper bot-
toms can leave discolorations on the glass ceramic surface which are
difficult or impossible to remove.
Energy saving
2Always place cookware on the cook-
ing zone before it is switched on.
2If possible, always place lids on the
pans.
2Switch cooking zones off before the
end of the cooking time, to take ad-
vantage of residual heat.
2Bottom of pans and cooking zones
should be the same size.

19
Examples of cooking applications
The information given in the following table is for guidance only.
Heat
set-
ting
Cooking-
process suitable for Cooking time Tips/Hints
0Off position
V
Keeping
food
warm
Keeping cooked foods
warm as required Cover
1-2
Melting Hollandaise sauce,
melting butter, chocolate,
gelatine 5-25 mins. Stir occasionally
Solidi-
fying Fluffy omelettes, baked eggs 10-40 mins. Cook with lid on
2-3 Simmer-
ing on
low heat
Simmering rice and milk-
based dishes
Heating up ready-cooked
meals
25-50 mins.
Add at least twice as
much liquid as rice, stir
milk dishes part way
through cooking
3-4 Steaming
Braising Steaming vegetables, fish braising meat 20-45 mins. With vegetables add
only a little liquid (a
few tablespoons)
4-5 Boiling
Steaming potatoes 20-60 mins. Use only a little liquid,
e. g.: max. ¼l water
for 750 g potatoes
Cooking larger quantities
of food, stews and soups 60-150 mins. Up to 3 l liquid plus in- gredients
6-7 Gentle
Frying
Frying escalopes, veal
cordon bleu, cutlets, ris-
soles, sausages, liver, roux,
eggs, pancakes, dough-
nuts
Steady
frying Turn halfway through cooking
7-8 Heavy
Frying
Hash browns, loin steaks,
steaks, Flädle (pancakes
for garnishing soup)
5-15 mins.
per pan Turn halfway through cooking
9
Boiling
Searing
Deep
frying
Boiling large quantities of water, cooking pasta, searing meat
(goulash, pot roast), deep frying chips

20
Cleaning and Care
1Take care! Risk of burns from residual heat.
1Warning! Sharp objects and abrasive cleaning materials will damage
the appliance. Clean with water and washing up liquid.
1Warning! Residues from cleaning agents will damage the appliance.
Remove residues with water and washing up liquid.
Cleaning the appliance after each use
1.Wipe the appliance with a damp cloth and a little washing up liquid.
2.Rub the appliance dry using a clean cloth.
Removing deposits
1.Place a scraper on the glass ceramic surface at an angle.
2.Remove residues by sliding the blade over the surface.
3.Wipe the appliance with a damp cloth and a little washing up liquid.
4.Rub the appliance dry using a clean cloth.
*Scrapers and cleaners for glass ceramic and stainless steel can be purchased in specialist shops
3Remove stubborn residues with a cleaner for glass ceramic or stainless
steel.
3Scratches or dark stains on the glass ceramic that cannot be removed
do not however affect the functioning of the appliance.
Remove
Type of dirt imme-
diately when the appliance has cooled down using
sugar, food containing sugar yes --- a scraper*
plastics, tin foil yes ---
limescale and water rings --- yes cleaner for glass ce-
ramic or stainless
steel*
fat splashes --- yes
shiny metallic discolorations --- yes
