AEG KD91402M User manual

EN User Manual 02
DE 1gnusiewnashcuarbeG 7
KD91403E
KD91402M
KD91403M
KD91404E
KD91404M
KD92903E
KD92923E
RU Инструкция 30

4
www.aeg.com
CONTENTS
SAFETY INFORMATION...................................................................................5
Safety Instructions .............................................................................................7
Precautions during use......................................................................................7
Appliance Description........................................................................................8
Use.....................................................................................................................9
Load capacity...................................................................................................11
Cleaning and Maintenance..............................................................................12
What should I do if the crockery warmer doesn’t work?..................................13
Environmental concerns..................................................................................13
Installation instructions ....................................................................................14
Installation........................................................................................................47
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you impeccable
performance for many years, with innovative technologies that help make life simpler –
features you might not find on ordinary appliances. Please spend a few minutes
reading to get the very best from it.
Visit our website to:
Get usage advice, brochures, trouble shooter, service information:
www.aeg.com
Register your product for better service:
www.aeg.com/productregistration
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
We recommend the use of original spare parts.
When contacting Service, ensure that you have the following data available.
The information can be found on the rating plate. Model, PNC, Serial Number.
Warning / Caution-Safety information.
General information and tips.
Environmental information.
Subject to change without notice.

5
ENGLISH
1. SAFETY INFORMATION
1.1.
1.2.

www.aeg.com
6

7
ENGLISH
2. SAFETY INSTRUCTIONS
Before connecting the appliance
compare the power data (voltage and
frequency) indicated on the
characteristics plate with those of the
power supply in question. If these data
do not match there may be problems.
In case of doubt, contact an
electrician.
If the electrical wire plug is removed,
the appliance must be installed and
connected by a technician. Contact a
qualified electrician who knows and
respects current safety standards. The
manufacturer cannot be held
responsible for damage resulting from
fitting or connecting errors.
The electrical safety of the appliance
can only be guaranteed if it is earthed.
The manufacturer cannot be held
responsible for damage resulting from
the absence of or defects in the
installation’s protection system (e.g.
electrical shock).
Only use the appliance once it has
been fitted into its built-in position.
Only in this manner can it be
guaranteed that users cannot access
the electrical components.
Never open up the appliance’s frame.
Possible contacts with electrical
conducting parts or changes to
electrical or mechanical components
may represent a danger to users’
safety and prejudice the correct
working of the appliance.
Repairs and maintenance, especially
of parts carrying electrical current,
must only be done by technicians
authorised by the manufacturer. The
manufacturer and retailers do not
accept responsibility for any damaged
caused to people, animals or property
as a result of repairs and maintenance
carried out by non-authorised
personnel.
Repairs undertaken during the
guarantee period must only be done
by technicians authorised by the
manufacturer. If this is not the case
then any damage resulting from the
repair in question is excluded from the
guarantee
The appliance must be disconnected
from the electrical current when
installation and repair work is being
done. To disconnect the appliance
from the current, one of the following
conditions must apply:
The switchboard fuses / circuit
breakers must be disconnected.
The plug should be removed from
the socket. To remove the plug
from the socket do not pull on the
electric cable but rather pull out the
plug itself directly.
3. PRECAUTIONS DURING USE

www.aeg.com
8
When you stop using the appliance at the
end of its working life, disconnect it from the
power supply and render the electrical cable
unusable so that the appliance is not a
danger if, for example, children use it for
playing
4. APPLIANCE DESCRIPTION
4.1. Main Components
Function selector
Handle
On/Off switch
Anti-Slip mat
Control Lamp
Drawer Grid *
6
3
5
2
4
1
KD91403 / KD92903 / KD92923
KD91404
6

9
ENGLISH
4.2. How the crockery warmer works
This appliance is equipped with a
warm air circulation system. A fan
distributes the heat generated by an
electrical heating element throughout
the interior of the appliance.
The thermostat allows the user to
define and control the temperature
wanted for the crockery.
The circulating hot air that is generated
heats up the crockery quickly and
evenly.
A metal grille protects both the heating
element and the fan.
The base of the drawer is fitted with a
non-slip mat to prevent plates and
dishes sliding around when the drawer
is opened and closed.
5. USE
5.1. Before using for the first
time
Before using the appliance for the first
time you should clean the interior and
the exterior, following the cleaning
instructions given in the section
“Cleaning and Maintenance”.
Then heat the crockery warmer for at
least 2 hours. For this, turn the
temperature control to the maximum
position (see section ‘Selecting
temperature”).
Make sure the kitchen is well-
ventilated when you are doing this.
The appliance’s parts are protected by
a special product. For this reason,
during the first heating an odour will be
released. Both the odour and any
smoke that may form will disappear
after a short time and neither signifies
that there is anything wrong with the
connection or the appliance.
5.2. Control Panel
The control panel has a function and
the on/off switch. The control panel is
only visible when the drawer is open.
*Drawer Grid only available with the model KD92903E/KD92923E
6

www.aeg.com
10
5.3. Using the crockery warmer
To use the crockery warmer, proceed
as follows:
Put the crockery in the drawer.
Select the function you want by
turning the thermostat control to the
desired position.
Switch on the appliance by pressing
the switch, which will light up.
Close the drawer.
Be careful not to use too much force
when closing the drawer since it may
open up again. Before taking out the
warm crockery you must switch off the
crockery warmer by pressing the
switch again
5.4. Selecting function
By turning the thermostat control you
can select temperatures between 30
and 80 °C.
Do not force the thermostat control to
the left of the “0” position or to the right
of the maximum position since this
may damage the appliance.
As soon as the temperature selected is
reached, the heating is turned off.
When the temperature drops to a
value below that selected, the heating
is turned back on.
The temperature scale is not marked
with absolute temperatures in ºC but
instead has symbols which correspond
to the optimum temperatures for
groups of crockery:
Symbol
ºC
Function
30ºC
Defrosting
40ºC-
50ºC
Proving dough
Cups / glasses warming
60ºC-
70ºC
Crockery warming
Keep food warm
80ºC
Low temperature cooking
Food Warming
5.5. Heating times
Various factors affect heating times:
Material and thickness of the
crockery;
Load quantity;
How the crockery is arranged;
Temperature setting.
It is therefore not possible to give any
precise heating times.
As you use the crockery warmer more
and more you will learn the best
settings for your crockery.
However, as a guide, the following
times are given for the thermostat
setting and for uniform heating
of the crockery:
Load
Time (min)
Crockery for 6 people
30 –35
Crockery for 12 people
40 –45

11
ENGLISH
Suggestions for the function
Keep Food Warm and Food
Warming:
Preheat the Warming Drawer 15
minutes to ensure the interior space
has the required temperature.
Low temperature cooking 80° C
(only available with the model
KD92903E)
With the low temperature cooking
meat can be gently prepared at low
temperatures over a longer period of
cooking time. The cooking time is
dependent on the piece of meat’s size.
Use dishes made of glass, china or
ceramics.
Preparation:
Preheat the device with the dishes at
80°C for 10 minutes.
Sear the meat in a pan using fat and
place it into the heat drawer on the
preheated dishes. Keep the setting
at 80° C.
Table: Low Temperature Cooking (Reference Values)
Application
Quantity
Roast gently on the cooking
plate
Cooking times
Beef
Completely rare
1kg
on all sides, on each 2min.
1hr
Rare
1kg
on all sides, on each 3min
1.25hrs
Medium
1kg
on all sides, on each 3min
1.75 hrs
Well-done
1kg
on all sides, on each 3min
2.25hrs –2.5hrs.
Roast beef in one
piece
1kg
on all sides, on each 3min
3 hrs rare
4.5 hrs medium
Veal
Filet, whole
1kg
on all sides, on each 2min.
1.75 –2hrs.
Loin, in one piece
1kg
on all 4 sides, on each 3min.
2 –2.5hrs.
Roast, vat
1kg
on all sides, on each 3min.
2 –2.5hrs.
Roast, shoulder
1kg
on all sides, on each 3min.
2.5hrs.
Porc
Filet, whole
500-600 g
on all sides, on each 2min.
1.5hrs
Loin
600 -1000g
all around 10-15min.
2 - 3hrs
Lamb
Gigot with haunch
2kg
on all sides, on each 4min.
3 –4hrs
Gigot steak of the
haunch
2kg
on all sides, on each 2min
0.75-1hr
Filet
400g
on all sides, on each 2min
1 –1.25hrs.
If you wish to keep the cooked meat warm, put the setting back to 60° C. We recommend
not to use the warming function for more than 1hr.
6. LOAD CAPACITY
6.1. Load capacity depends on the size of the crockery items:
KD 91403 / KD 91404
KD 92903 / KD 92923
6 persons servings
12 persons servings
6 x 24cm Dinner Plates
12 x 24cm Dinner Plates
6 x 10cm Soup Bowls
12 x 10cm Soup Bowls
1 x 19cm Serving Dish
1 x 19cm Serving Dish

www.aeg.com
12
KD 91403 / KD 91404
KD 92903 / KD 92923
1 x 17cm Serving Dish
1 x 17cm Serving Dish
1 x 32cm Meat Plates
2 x 32cm Meat Plates
or
or
20 dishes with 28 cm
40 dishes with 28 cm
or
or
80 espresso coffee cups
160 espresso coffee cups
or
or
40 tea cups
80 tea cups
or
or
…
…
7. CLEANING AND MAINTENANCE
7.1. Cleaning is the only
maintenance action that is
required normally.
Warning! Cleaning must be done with
the crockery warmer disconnected
from the electrical power supply.
Remove the plug from the power
socket or disconnect the crockery
warmer power supply circuit.
Do not use aggressive or abrasive
cleaning products, abrasive sponges
or pointed objects since stains or
abrasion marks may appear.
Do not use high pressure or steam jet
cleaning appliances.
Appliance front and control
panel
The crockery warmer can be cleaned
using just a damp cloth. If it is very
dirty, add a few drops of washing-up
liquid to the washing water.
Wipe the surfaces dry using a dry
cloth.
For stainless steel fronted crockery
warmers, special products for
treatment of stainless steel surfaces
can be used. These products prevent
the surfaces becoming dirty again for
some time. Apply a thin layer of such a
product on the surface using a soft
cloth
On aluminium fronted crockery
warmers use a gentle glass cleaning
product and a soft cloth that does not
release fluff. Wipe horizontally without
pressing on the surface since
aluminium is sensitive to scratches
and cuts.
Interior of the crockery warmer
Clean the inside of the crockery
warmer regularly using a damp cloth. If
it is very dirty add a few drops of

13
ENGLISH
washing-up liquid to the washing
water.
Wipe the surfaces dry using a dry
cloth.
Avoid water entering through the air
circulation opening.
Only use the crockery warmer again
when it is completely dry.
Mat with non-slip surface
The non-slip surface mat can be
removed to facilitate cleaning of the
drawer.
The mat can be cleaned by hand using
hot water with a few drops of washing-
up liquid. Dry thoroughly.
The non-slip mat should only be
replaced when it is completely dry.
8. WHAT SHOULD I DO IF THE CROCKERY WARMER
DOESN’T WORK?
WARNING! Any type of repair must
only be done by a specialised
technician. Any repair done by a
person not authorised by the
manufacturer is dangerous.
Before contacting Technical
Assistance, check on the following:
The crockery doesn’t heat up
enough. Check whether:
The appliance has been switched
on.
The appropriate temperature has
been selected.
The air circulation orifices are
covered by the crockery.
The crockery was left to heat up for
sufficient time.
Heating time depends on several
factors, such as, for example:
Crockery material type and
thickness.
Quantity of crockery.
How the crockery is arranged.
The crockery doesn’t heat up at all.
Check whether:
You can hear the noise of a fan. If
the fan is operating then the
heating element is broken; if the
fan is not operating then the fan is
broken.
The switchboard fuses / circuit
breakers have fused / tripped out.
The crockery is heating up too
much:
The temperature selector is
broken.
The on/off switch does not light up:
The switch’s pilot light has blown.
9. ENVIRONMENTAL CONCERNS
Recycle the materials with the
symbol . Put the packaging in
applicable containers to recycle it.
Help protect the environment and
human health and to recycle waste of
electrical and electronic appliances.
Do not dispose appliances marked
with the symbol with the
household waste. Return the product
to your local recycling facility or
contact your municipal office.

www.aeg.com
14
10.INSTALLATION INSTRUCTIONS
10.1. Before installation
Check that the input voltage indicated on
the characteristics plate is the same as the
voltage of the power outlet you are going to
use.
Open the drawer and take out all the
accessories and remove the packing
material.
Attention! The front surface of the
crockery heater may be wrapped in a
protective film. Before using the crockery
warmer for the first time, remove this film
carefully.
Make sure that the crockery warmer is
not damaged in any way. Check that the
drawer opens and closes correctly. If
you find any damage, contact the
Technical Assistance Service.
Attention: the power socket should be
easily accessible after the crockery
warmer has been installed.
The crockery warmer should only be
built-in in combination with those
appliances indicated by the
manufacturer. If it is fitted in combination
with other appliances, the guarantee is
no longer valid since it is impossible to
guarantee that the crockery warmer will
work correctly.
10.2. Installation
To build-in the crockery warmer in
combination with another appliance there
must be a fixed, interim shelf in the housing
unit to support the weight of both
appliances.
The appliance to be combined with the
crockery warmer will be placed directly on
the latter without any need to have a
separating shelf.
To build-in the appliance which is combined
with the crockery warmer, follow the
instructions set out in the respective
instructions and fitting booklet.
The relevant installation dimensions are
indicated in mm in the diagrams shown at
the end of this booklet. Proceed as follows:
1. Place the crockery warmer on the shelf
and slide it towards the interior of the
niche in such a way that it is centred and
completely lined up with the front of the
unit.
2. Check that the crockery warmer’s frame
is properly levelled and is sitting evenly
on the shelf.
3. Open the drawer and fix the crockery
warmer to the sides of the unit using the
provided screws.
10.3. Electrical Connection
Electrical installation must be performed by
an electrician qualified in accordance with
the legislation in force.
Before connecting the crockery warmer to
the electric mains, check that the voltage
and frequency of the mains matches that
which is shown on the rating plate located in
the heating block inside.
The electric connection is made via an
omnipolar switch, which is suitable for the
intensity to be tolerated and which has a
minimum gap of 3mm between its contacts,
which will ensure
disconnection in case of emergency or
when cleaning the crockery warmer.
If a plug is used for the electric connection,
then it must be accessible after installation.

15
ENGLISH
The connection should include correct
earthing, in compliance with current norms.
WARNING: THE CROCKERY
WARMER MUST BE EARTHED.
If the flexible supply cable fitted to the
crockery warmer ever needs to be changed,
it should be replaced by an official After
Sales Service, because it requires special
tools.
The manufacturer and retailers do not
accept responsibility for any damage that
may be caused to people, animals or
property if these installation instructions are
not observed.

www.aeg.com
16

17
DEUTSCH
INHALTSVERZEICHNIS
INFORMATIONEN ZUR SICHERHEIT ...........................................................18
Sicherheitshinweise.........................................................................................20
Vorsichtsmaßnahme während Benutzung.......................................................21
Gerätebeschreibung ........................................................................................22
Bedienung........................................................................................................23
Fassungsvermögen.........................................................................................25
Reinigung und Pflege ......................................................................................26
Was ist im Falle einer Funktionsstörung zu tun?.............................................27
Umwelt- und Gesundheitsschutz.....................................................................27
Installationsanleitung .......................................................................................28
Einbau..............................................................................................................47
FÜR PERFEKTE ERGEBNISSE
Danke, dass Sie sich für dieses AEG Produkt entschieden haben. Wir haben es
geschaffen, damit Sie viele Jahre von seiner ausgezeichneten Leistung und den
innovativen Technologien, die Ihnen das Leben erleichtern, profitieren können. Es ist
mit Funktionen ausgestattet, die in gewöhnlichen Geräten nicht vorhanden sind.
Nehmen Sie sich ein paar Minuten Zeit zum Lesen, um seine Vorzüge kennen zu
lernen.
Besuchen Sie uns auf unserer Website, um:
Anwendungshinweise, Prospekte, Fehlerbehebungs- und Service-
Informationen zu erhalten:
www.aeg.com
Lhr erworbenes Produkt zu registrieren, um den besten Service dafür zu
gewährleisten:
www.aeg.com/productregistration
Zubehör,
Verbrauchsmaterial und Original-Ersatzteile für Ihr Gerät zu erwerben:
www.aeg.com/shop
REPARATUR- UND KUNDENDIENST
Bitte verwenden Sie ausschließlich Original-Ersatzteile für Ihre Produkte.
Halten Sie folgende Angaben bereit, wenn Sie sich an den Kundendienst wenden
(diese Informationen finden Sie auf dem Typenschild): Modell, Produktnummer (PNC),
Seriennummer.
Warnungs-/ Sicherheitshinweise.
Allgemeine Informationen und Empfehlungen.
Informationen zum Umweltschutz.
Änderungen vorbehalten.

18
www.aeg.com
1. INFORMATIONEN ZUR SICHERHEIT
1.1.
1.2.

19
DEUTSCH

20
www.aeg.com
2. SICHERHEITSHINWEISE
Vergleichen Sie vor dem Anschließen
des Gerätes die Anschlussdaten
(Spannung und Frequenz) auf dem
Typenschild mit denen des
Elektronetzes. Diese Daten müssen
unbedingt übereinstimmen, damit
keine Schäden am Gerät auftreten. Im
Zweifelsfall fragen Sie Ihren
Elektroinstallateur.
Wird der Stecker von der
Netzanschlussleitung entfernt, muss
das Gerät von einer Elektrofachkraft
eingebaut und angeschlossen werden.
Beauftragen Sie bitte eine
Elektrofachkraft, die die
landesüblichen Vorschriften und die
Zusatzvorschriften der örtlichen
Elektroversorgungsunternehmen
genau kennt und sorgfältig einhält. Der
Hersteller kann nicht für Schäden
verantwortlich gemacht werden, die
durch Fehler beim Einbau oder
Anschluss verursacht werden.
Die elektrische Sicherheit des Gerätes
ist nur dann gewährleistet, wenn es an
ein vorschriftsmäßig installiertes
Schutzleitersystem angeschlossen
wird. Der Hersteller kann nicht für
Schäden verantwortlich gemacht
werden, die durch eine fehlende oder
unterbrochene Schutzleiterverbindung
verursacht werden (z. B. elektrischer
Schlag).
Benutzen Sie das Gerät nur im
eingebauten Zustand. Nur so ist
sichergestellt, dass Sie nicht mit Strom
führenden Teilen in Berührung
kommen.
Öffnen Sie auf keinen Fall das
Gehäuse des Gerätes. Eventuelles
Berühren spannungsführender Teile
sowie Verändern des elektrischen und
mechanischen Aufbaus gefährden Sie
und führen möglicherweise zu
Funktionsstörungen des Gerätes.
Installations- und Wartungsarbeiten
sowie Reparaturen dürfen nur
qualifizierte Fachleute durchführen.
Durch unsachgemäße Installations-
und Wartungsarbeiten oder
Reparaturen können erhebliche
Gefahren für den Benutzer entstehen,
für die der Hersteller nicht haftet.
Eine Reparatur des Gerätes während
der Garantiezeit darf nur von einem
vom Hersteller autorisierten
Kundendienst vorgenommen werden,
sonst besteht bei nachfolgenden
Schäden kein Garantieanspruch mehr.
Bei Installations- und
Reparaturarbeiten muss das Gerät
vom Netz getrennt sein. Das Gerät ist
nur dann elektrisch vom Netz getrennt,
wenn eine der folgenden Bedingungen
erfüllt ist:
die Netzanschlussleitung vom
Elektronetz getrennt ist. Ziehen Sie
bei Geräten mit Netzstecker nicht an
der Anschlussleitung, sondern am
Stecker, um das Gerät vom Netz zu
trennen.

21
DEUTSCH
3. VORSICHTSMAßNAHME WÄHREND BENUTZUNG
Dieses Gerät entspricht den
vorgeschriebenen Sicherheits-
bestimmungen. Ein unsach-gemäßer
Gebrauch kann jedoch zu Schäden an
Personen und Sachen führen.
Lesen Sie vor dem ersten Benutzen
aufmerksam die Gebrauchsanweisung.
Dadurch schützen Sie sich selbst und
vermeiden Schäden an Ihrem Gerät.
Das Gerät kann im Innenraum je nach
gewählter Temperatur und
Benutzungsdauer bis zu ca. 80 °C heiß
werden. Verwenden Sie zum
Herausnehmen des erwärmten Geschirrs
bei Bedarf Topfhand-schuhe.
Stellen oder setzen Sie sich nicht auf die
geöffnete Geschirr-schublade. Der
Teleskopauszug wird beschädigt. Die
Belastbarkeit der Geschirrschublade
beträgt max. 25kg.
Bewahren Sie keine Kunststoff-behälter
oder brennbare Gegenstände im Gerät
auf. Beim Einschalten können sie
schmelzen oder sich entzünden.
Brandgefahr!
Benutzen Sie das Gerät nicht zum
Beheizen von Räumen. Durch die
Temperaturentwicklung können leicht
entzündbare Gegenstände in der Nähe zu
brennen beginnen.
Verwenden Sie keinesfalls einen
Dampfreiniger. Zum einen kann der Dampf
an spannungsführende Teile gelangen und
einen Kurzschluss auslösen. Zum anderen
kann der Dampfdruck zu dauerhaften
Beschädigungen von Oberflächen und
Bauteilen führen, für die der Hersteller
keinen Schadenersatz leistet
Nicht mehr benutzte Geräte müssen vom
Elektronetz getrennt und alle
wegführenden elektrischen Leitungen
entfernt werden, damit sie z. B. für
spielende Kinder keine Gefahr darstellen.
