Frigidaire FPWD2785K F User manual

frigidaire.com
27" Electric
Warmer Drawer
FPWD2785K F
Signature Features
More Easy-To-Use Features
SpaceWise™ Half-Rack
4-Hour Auto Power-O
Bread Proofing Setting
Fully Extendable Drawer
Power Indicator Light
A.D.A. Compliant*
Capacities
1.3 Cu. Ft. Drawer Capacity
Overall Exterior Dimensions
Height 11-1/4"
Width 27"
Depth 23-3/8"
Available in:
* When properly installed, meets the appliance standards
in the American with Disabilities Act and the Architectural
Barriers Act Accessibility Guidelines as published by the
United States Access Board on June 23, 2004.
Stainless
(F)
Real Stainless Steel
Real stainless steel with a protective
coating that reduces fingerprints and
smudges so it's easy to clean.
Pro-Select™ Controls
With a temperature range from 80° F
to 190° F, you can proof bread or keep
your entire meal warm.
Adjustable Humidity Control
The humidity level can be adjusted
to keep food from drying out before
serving.
Large Capacity
This large 1.3 cubic foot capacity
drawer, along with the half-rack that
creates more space, makes keeping
your meal warm easy.

Warmer Drawer
FPWD2785K F 27" Electric
FRIGIDAIRE®
USA
•
250 Bobby Jones Expressway
•
Martinez, GA 30907
•
1-800-FRIGIDAIRE •frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FPWD2785K 05/09 © 2009 Electrolux Home Products, Inc. Printed in the U.S.A.
Specifications
subject to change.
Warmer Drawer / Wall Oven Combination Specifications
•To support Wall Oven when using in combination with Warmer
Drawer, two 3"-wide x 3/4"-thick planks must be installed as a base,
capable of supporting 200 Lbs. Do NOT use full base, since planks
are necessary to allow for proper air displacement.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at frigidaire.com for detailed instructions.
Warmer Drawer Specifications
•Product Shipping Weight (approx.) – 55 Lbs.
•Voltage Rating – 120V / 450W / 60 Hz / 15 Amps
•Connected Load (kW Rating) @ 120 Volts = 0.5 kW
(For use on adequately wired 120V, dedicated circuit having 2-wire
service with a separate ground wire. Appliance must be grounded
for safe operation.)
•Amps @ 120V = 3.8 Amps
•Recommended Circuit Breaker – 15 Amps
•Always consult local and national electric codes.
•Full plywood base required, capable of supporting 100 Lbs.
•Base must be level and cabinet front must be square.
•Warmer Drawer can be used alone, or is approved to be used in
combination with any Frigidaire® Wall Oven. (Refer to Combination
Installation Specifications and drawing on this page.)
•Warmer Drawer is approved to be used in combination with any
Frigidaire® Built-In Microwave and /or Electric Single Wall Oven.
Warmer Drawer Stand-Alone Installation
27" Warmer Drawer/27" Single
Wall Oven Combination Installation
Warmer Drawer Stand-Alone Installation
27" Warmer Drawer/27" Single
Wall Oven Combination Installation

Specifications
subject to change.
FRIGIDAIRE®
USA
•
250 Bobby Jones Expressway
•
Martinez, GA 30907
•
1-800-FRIGIDAIRE •frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
MOSS_EW_WD 27INST FR 04/09 © 2009 Electrolux Home Products, Inc. Printed in the U.S.A.
Frigidaire 27" Combination Installation –
24" Built-In Microwave (with 27" Trim Kit)
Electric Single Wall Oven
Warmer Drawer
27" Combination Installation
Built-In Microwave / Single Wall Oven / Warmer Drawer
27" Combination Installation Specifications
•Always consult local and national electric codes.
(Refer to product-specific electrical specifications on this page.)
•Minimum23-5/8"deepcutoutdimensioniscriticalforproper
combination installation, to ensure that each built-in product’s
faceplate will fit flush against cabinet front.
•Bases must be level and cabinet front must be square.
•Minimum 4-1/2" required distance from bottom of Warmer Drawer
cutout to floor.
•Respectcriticaldimensionsasnotedforproperinstallationof
built-In products.
•Minimum 21" clearance needed for Wall Oven door depth when open.
27" Built-In Microwave Specifications
•For built-in installation, microwave MUST be installed with optional
27"TrimKitwhichincludesBottomDuctAssembly–shippedin
separate box, ordered by individual part number.
•VoltageRating–120V / 60Hz / 15or20Amps
•ConnectedLoad(kWRating)@120Volts=1.7kW
(Foruseonadequatelywired120V,dedicatedcircuithaving2-wire
service with a separate ground wire. Appliance must be grounded
forsafeoperation.)
•Amps@120Volts=14.3Amps
•Full base of solid plywood or similar material required, capable of
supporting 100 Lbs.
•Minimum2-7/8"clearancerequiredfrombottomofBuilt-InMicrowave
cutout to top edge of Wall Oven’s faceplate, leaving a 2" visible gap
between both product faceplates.
27" Electric Single Wall Oven Specifications
•Single phase 3- or 4-wire cable, 120 / 240 or 120 / 208 Volt, 60 Hertz
AC only electrical supply with ground required on separate circuit
fused on both sides of line.
•For detailed electrical requirements, refer to model-specific product
page and installation guide on web.
•To support Wall Oven when using in combination with Warmer
Drawer, two 3"-wide x 3/4"-thick planks must be installed as a base,
capable of supporting 200 Lbs. Do NOT use full base, since planks
are necessary to allow for proper air displacement.
27" Warmer Drawer Specifications
•VoltageRating–120V / 450W / 60Hz / 15Amps
•ConnectedLoad(kWRating)@120Volts=0.5kW
(Foruseonadequatelywired120V,dedicatedcircuithaving2-wire
service with a separate ground wire. Appliance must be grounded
forsafeoperation.)
•Amps@120V=3.8Amps
•Fullbaseofsolidplywoodorsimilarmaterialrequired,capableof
supporting 100 Lbs.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at frigidaire.com for detailed instructions.
