AEG L6FBG51470 User manual

USER
MANUAL
EN User Manual
Washing Machine
L6FBG51470

FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to
give you impeccable performance for many years, with
innovative technologies that help make life simpler – features
you might not find on ordinary appliances. Please spend a few
minutes reading to get the very best from it.
Visit our website to:
Get usage advice, brochures, trouble shooter, service and repair information:
www.aeg.com/support
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that
you have the following data available: Model, PNC, Serial
Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
2/68

CONTENTS
1. SAFETY INFORMATION.......................................................... 6
1.1 Children and vulnerable people safety.............................6
1.2 General Safety................................................................. 6
2. SAFETY INSTRUCTIONS.........................................................9
2.1 Installation........................................................................ 9
2.2 Electrical connection...................................................... 10
2.3 Water connection........................................................... 10
2.4 Use.................................................................................11
2.5 Service........................................................................... 11
2.6 Disposal......................................................................... 12
3. PRODUCT DESCRIPTION......................................................13
3.1 Special features............................................................. 13
3.2 Appliance overview........................................................ 13
3.3 Information for register product...................................... 14
4. TECHNICAL DATA................................................................. 15
5. ELECTRICAL CONNECTION.................................................16
6. ACCESSORIES.......................................................................17
6.1 Available in www.aeg.com/shop or from
authorised dealer............................................................... 17
6.2 Fixing plate kit................................................................ 17
6.3 Stacking kit.....................................................................17
7. BEFORE FIRST USE.............................................................. 18
8. CONTROL PANEL..................................................................19
8.1 Control panel..................................................................19
9. DISPLAY................................................................................. 21
10. KNOB AND BUTTONS......................................................... 22
10.1 Ein /Aus ................................................................... 22
10.2 Introduction.................................................................. 22
10.3 Temp. .......................................................................22
10.4 Schleudern .................................................................. 22
10.5 Option...........................................................................23
3/68

10.6 Zeitvorwahl...................................................................24
10.7 Zeit Sparen...................................................................24
10.8 Start/Pause ...............................................................25
11. PROGRAMMES ................................................................... 26
11.1 Programme Chart.........................................................26
12. SETTINGS.............................................................................33
12.1 Child Lock.................................................................... 33
12.2 Acoustic signals........................................................... 33
12.3 Permanent Extra Rinse ............................................ 33
13. DAILY USE............................................................................34
13.1 Activating the appliance............................................... 34
13.2 Loading the laundry......................................................34
13.3 Filling the detergent and additives............................... 35
13.4 Check the position of the flap.......................................35
13.5 Setting a programme....................................................37
13.6 Starting a programme with the delay start................... 38
13.7 Starting a programme.................................................. 38
13.8 The ProSense load detection ......................................39
13.9 Interrupting a programme and changing the options... 40
13.10 Cancelling a running programme............................... 40
13.11 Opening the door - Adding garments ........................ 40
13.12 End of the programme............................................... 41
13.13 Draining water out after end of cycle..........................42
13.14 Stand-by option.......................................................... 42
14. HINTS AND TIPS.................................................................. 44
14.1 The laundry load.......................................................... 44
14.2 Stubborn stains............................................................ 45
14.3 Detergent type and quantity......................................... 45
14.4 Ecological hints............................................................ 46
14.5 Water hardness............................................................47
15. CARE AND CLEANING........................................................ 48
15.1 Periodic cleaning schedule.......................................... 48
15.2 Removing foreign objects.............................................48
4/68
CONTENTS

15.3 External cleaning..........................................................49
15.4 Descaling..................................................................... 49
15.5 Maintenance wash....................................................... 50
15.6 Door seal......................................................................50
15.7 Cleaning the drum........................................................50
15.8 Cleaning the detergent dispenser................................ 51
15.9 Cleaning the drain pump.............................................. 52
15.10 Cleaning the inlet hose and the valve filter................ 54
15.11 Emergency drain........................................................ 56
15.12 Frost precautions....................................................... 56
16. TROUBLESHOOTING.......................................................... 57
16.1 Alarm Codes and Possible failures.............................. 57
17. CONSUMPTION VALUES.................................................... 63
17.1 Introduction.................................................................. 63
17.2 Legend......................................................................... 63
17.3 According to Commission Regulation Eu 2019/2023...64
17.4 Common programmes................................................. 64
18. ENVIRONMENTAL CONCERNS..........................................66
5/68
CONTENTS

1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible
for any injuries or damage that are the result of incorrect
installation or usage. Always keep the instructions in a safe
and accessible location for future reference.
1.1 Children and vulnerable people safety
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved.
•Children between 3 and 8 years of age and persons with
very extensive and complex disabilities shall be kept away
from the appliance unless continuously supervised.
•Children of less than 3 years of age should be kept away
from the appliance unless continuously supervised.
•Children should be supervised to ensure that they do not
play with the appliance.
•Keep all packaging away from children and dispose of it
appropriately.
•Keep detergents away from children.
•Keep children and pets away from the appliance when the
door is open.
•If the appliance has a child safety device, it should be
activated.
•Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
1.2 General Safety
•Do not change the specification of this appliance.
6/68

•This appliance is intended to be used in household and
similar applications such as:
–staff kitchen areas in shops, offices and other working
environments;
–by clients in hotels, motels, bed & breakfast and other
residential type environments;
–areas for communal use in blocks of flats or in
launderettes.
•The appliance maximum load is 7 kg. Do not exceed the
maximum load of each programme (refer to the
“Programmes” chapter).
•The operating water pressure at the water entry point from
the outlet connection must be between 0.5 bar (0.05 MPa)
and 8 bar (0.8 MPa).
•The ventilation opening in the base must not be covered by
a carpet, mat, or any floor covering.
•The appliance must be connected to the water mains using
the new supplied hose sets, or other new hose sets supplied
by the Authorised Service Centre.
•Old hose sets must not be reused.
•If the mains power supply cable is damaged, it must be
replaced by the manufacturer, its Authorised Service Centre
or similarly qualified persons to avoid an electrical hazard.
•Before any maintenance operation, deactivate the appliance
and disconnect the mains plug from the socket.
•Do not use high pressure water sprays and/or steam to
clean the appliance.
•Clean the appliance with a moist cloth. Use only neutral
detergents. Do not use abrasive products, abrasive cleaning
pads, solvents or metal objects.
7/68
SAFETY INFORMATION

•If a tumble dryer is stacked on the top of the washing
machine, make sure to use the correct stacking kit approved
by AEG (see more details in chapter "Accessories -
Stacking kit").
8/68
SAFETY INFORMATION

2. SAFETY INSTRUCTIONS
2.1 Installation
The installation must comply with relevant national regulations.
• Remove all the packaging and the transit bolts including rubber
bush with plastic spacer.
• Keep the transit bolts in a safe place. If the appliance is to be
moved in the future they must be reattached to lock the drum to
prevent an internal damage.
• Always take care when moving the appliance as it is heavy.
Always use safety gloves and enclosed footwear.
• Follow the installation instructions supplied with the appliance.
• Do not install or use a damaged appliance.
• Do not install or use the appliance where the temperature can be
less than 0°C or where it is exposed to the weather.
• The floor area on which the appliance is to be installed must be
flat, stable, heat resistant and clean.
• Make sure that there is air circulation between the appliance and
the floor.
• When the appliance is in its permanent position, check if it is
levelled correctly with the aid of a spirit level. If it is not, adjust the
feet accordingly.
• Do not install the appliance directly above a floor drain.
• Do not spray water on the appliance and do not expose it to
excessive humidity.
• Do not install the appliance where the appliance door cannot be
fully opened.
• Do not put a closed container to collect possible water leakage
under the appliance. Contact the Authorised Service Centre to
ensure which accessories can be used.
9/68

2.2 Electrical connection
WARNING!
Risk of fire and electric shock.
• WARNING: This appliance is designed to be installed /
connected to a grounding connection in the building.
• Always use a correctly installed shockproof socket.
• Make sure that the parameters on the rating plate are compatible
with the electrical ratings of the mains power supply.
• Do not use multi-plug adapters and extension cables.
• Make sure not to cause damage to the mains plug and to the
mains cable. Should the mains cable need to be replaced, this
must be carried out by our Authorised Service Centre.
• Connect the mains plug to the mains socket only at the end of the
installation. Make sure that there is access to the mains plug after
the installation.
• Do not touch the mains cable or the mains plug with wet hands.
• Do not pull the mains cable to disconnect the appliance. Always
pull the mains plug.
2.3 Water connection
• The inlet water shall not exceed 25 °C.
• Do not cause damage to the water hoses.
• Before connection to new pipes, pipes not used for a long time,
where repair work has been carried out or new devices fitted
(water meters, etc.), let the water flow until it is clean and clear.
• Ensure that there are no visible water leaks during and after the
first use of the appliance.
• Do not use an extension hose if the inlet hose is too short.
Contact the Authorised Service Centre for the replacement of the
inlet hose.
10/68
SAFETY INSTRUCTIONS

• When unpacking the appliance, It is possible to see water flowing
from the drain hose. This is due to the testing of the appliance
with the use of water in the factory.
• You can extend the drain hose to maximum 400 cm. Contact the
Authorised Service Centre for the other drain hose and the
extension.
• Make sure that there is access to the tap after the installation.
2.4 Use
WARNING!
Risk of injury, electric shock, fire, burns or damage to the
appliance.
• Follow the safety instructions on the detergent packaging.
• Do not put flammable products or items that are wet with
flammable products in, near or on the appliance.
• Do not wash fabrics which are heavily soiled with oil, grease or
other greasy substances. It can damage rubber parts of the
washing machine. Prewash such fabrics by hand before loading
them into the washing machine.
• Do not touch the glass door while a programme operates. The
glass can get hot.
• Make sure that all metal objects are removed from the laundry.
2.5 Service
• To repair the appliance contact the Authorised Service Centre.
Use original spare parts only.
• Please note that self-repair or non-professional repair can have
safety consequences and might void the guarantee.
• The following spare parts will be available for 10 years after the
model has been discontinued: motor and motor brushes,
transmission between motor and drum, pumps, shock absorbers
and springs, washing drum, drum spider and related ball
bearings, heaters and heating elements, including heat pumps,
piping and related equipment including hoses, valves, filters and
11/68
SAFETY INSTRUCTIONS

aquastops, printed circuit boards, electronic displays, pressure
switches, thermostats and sensors, software and firmware
including reset software, door, door hinge and seals, other seals,
door locking assembly, plastic peripherals such as detergent
dispensers. Please note that some of these spare parts are only
available to professional repairers, and that not all spare parts
are relevant for all models.
• Concerning the lamp(s) inside this product and spare part lamps
sold separately: These lamps are intended to withstand extreme
physical conditions in household appliances, such as
temperature, vibration, humidity, or are intended to signal
information about the operational status of the appliance. They
are not intended to be used in other applications and are not
suitable for household room illumination.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the mains electrical and water
supplies.
• Cut off the mains electrical cable close to the appliance and
dispose of it.
• Remove the door catch to prevent children or pets from
becoming trapped in the drum.
• Dispose of the appliance in accordance with local requirements
for the disposal of Waste Electrical and Electronic Equipment
(WEEE).
12/68
SAFETY INSTRUCTIONS

3. PRODUCT DESCRIPTION
3.1 Special features
Your new washing machine meets all modern requirements for an
effective treatment of laundry with low water, energy and detergent
consumption and respectful of fabric care.
• The ProSense technology adjusts automatically the programme
duration to the laundry in the drum to achieve perfect washing
results in the minimum possible time.
3.2 Appliance overview
1 2 3 9
5
6
7
4
10
8
11 12
1. Worktop
2. Detergent dispenser
3. Control panel
4. Door handle
5. Rating plate
6. Drain pump filter
7. Feet for levelling the appliance
8. Drain hose
9. Inlet hose connection
10. Mains cable
11. Transit bolts
12. Hose support
13/68

3.3 Information for register product.
The rating plate reports the model name (A) , product number (B),
electrical ratings (C) and serial number (D).
00000000
00A
Mod. xxxxxxxxx
000V ~ 00Hz 0000 W
910000000 00
A
B
C
Prod.No.
D
14/68
PRODUCT DESCRIPTION

4. TECHNICAL DATA
Dimension Width/ Height/ Total
depth
59,6 cm /84,7 cm /
57,7 cm
Electrical connec‐
tion
Voltage
Overall power
Fuse
Frequency
230 V
2200 W
10 A
50 Hz
Level of protection against ingress of solid
particles and moisture ensured by the
protective cover, except where the low
voltage equipment has no protection
against moisture
IPX4
Water supply pres‐
sure
Minimum
Maximum
0.5 bar (0.05 MPa)
8 bar (0.8 MPa)
Water supply 1) Cold water
Maximum Load Cotton 7 kg
Spin Speed Maximum spin
speed
1400 rpm
1) Connect the water inlet hose to a water tap with a 3/4'' thread.
15/68

5. ELECTRICAL CONNECTION
At the end of installation you can connect the mains plug to the
mains socket.
The rating plate on the inner edge of the appliance door and the
'Technical Data' chapter indicate the necessary electrical ratings.
Make sure that they are compatible with the mains power supply.
Check that your domestic electrical installation can take the
maximum load required, also taking into account any other
appliances in use.
Connect the appliance to an earthed socket.
The power supply cable must be easily accessible after installing
the appliance.
For any electrical work required to install this appliance, contact our
Authorised Service Centre.
The manufacturer does not accept any responsibility for damage or
injury through failure to comply with the above safety precaution.
16/68

6. ACCESSORIES
6.1 Available in www.aeg.com/shop or from authorised
dealer
Read carefully the instructions supplied with the accessory.
Only appropriate accessories approved by AEG ensure the
safety standards of the appliance. If unapproved parts are used,
any claims will be invalidated.
6.2 Fixing plate kit
If you install the appliance on a plinth that is not an accessory
supplied by AEG, secure the appliance in the fixing plates.
Read carefully the instructions supplied with the accessory.
6.3 Stacking kit
The tumble dryer can be stacked on the top of the washing
machine only by using the correct stacking kit..
WARNING!
Do not put the tumble dryer under the washing machine. Verify
the compatible stacking kit by checking the depth of your
appliances.
17/68

7. BEFORE FIRST USE
During installation or before first use you may observe some
water in the appliance. This is a residual water left in the
appliance after a full functional test in the factory to ensure the
appliance is delivered to customers in perfect working order and
is no cause for concern.
1. Make sure that all transit bolts have been removed from the
appliance.
2. Make sure that the electrical power is available and the water tap
is open.
3. Pour a small quantity of detergent into the compartment marked
.
4. Set and start a programme for cotton at the highest temperature
without any laundry in the drum.
This removes all possible dirt from the drum and the tub.
18/68

8. CONTROL PANEL
8.1 Control panel
23
9 8 6
1
4
5
7
1Programme dial
For selecting the desired washing programme. Refer to
"Programmes" chapter for more details.
2Display
It provides information about the setting programme. Refer to
'"Display'" paragraph for more details.
3Zeitvorwahl touch button
For delaying the programme start until convenient hour.
4Zeit Sparen touch button
For reducing washing time.
5Start/Pause touch button
For starting or pausing the programme.
6Option touch button
•Flecken option
For pre-treating stubborn stains.
•Vorwäsche option
For adding a pre-wash phase.
•Nur Spülen option
For skipping the washing phase.
7Schleudern touch button
19/68

For changing the default spin speed or selecting one of the
following option:
•Ohne Schleudern option
For deactivating spin phases.
•Spülstopp option
For reducing creases. The final spin is not performed and
programme ends with water in the drum.
8Temp. touch button
For changing the default temperature.
9Ein /Aus push button
For activating/deactivating the appliance.
20/68
CONTROL PANEL
