EN User Manual
Washing Machine
L6FSG841P

CONTENTS
1. SAFETY INFORMATION......................................................................................3
2. SAFETY INSTRUCTIONS.................................................................................... 5
3. PRODUCT DESCRIPTION...................................................................................6
4. TECHNICAL DATA............................................................................................... 7
5. INSTALLATION.....................................................................................................8
6. ACCESSORIES.................................................................................................. 12
7. CONTROL PANEL..............................................................................................12
8. DIAL AND BUTTONS......................................................................................... 14
9. PROGRAMMES .................................................................................................16
10. SETTINGS........................................................................................................ 20
11. BEFORE FIRST USE........................................................................................21
12. DAILY USE....................................................................................................... 21
13. HINTS AND TIPS..............................................................................................26
14. CARE AND CLEANING.................................................................................... 27
15. TROUBLESHOOTING......................................................................................32
16. CONSUMPTION VALUES................................................................................35
17. QUICK GUIDE.................................................................................................. 37
18. ENVIRONMENTAL CONCERNS......................................................................38
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler – features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.
Visit our website to:
Get usage advice, brochures, trouble shooter, service and repair information:
www.aeg.com/support
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
www.aeg.com2

1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible for any injuries or damage that are the result
of incorrect installation or usage. Always keep the
instructions in a safe and accessible location for future
reference.
1.1 Children and vulnerable people safety
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
•Children between 3 and 8 years of age and persons
with very extensive and complex disabilities shall be
kept away from the appliance unless continuously
supervised.
•Children of less than 3 years of age should be kept
away from the appliance unless continuously
supervised.
•Children should be supervised to ensure that they do
not play with the appliance.
•Keep all packaging away from children and dispose of
it appropriately.
•Keep detergents away from children.
•Keep children and pets away from the appliance when
the door is open.
•If the appliance has a child safety device, it should be
activated.
•Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
1.2 General Safety
•Do not change the specification of this appliance.
ENGLISH 3

•This appliance is intended to be used in household
and similar applications such as:
–staff kitchen areas in shops, offices and other
working environments;
–by clients in hotels, motels, bed & breakfast and
other residential type environments;
–areas for communal use in blocks of flats or in
launderettes.
•The appliance maximum load is 8 kg. Do not exceed
the maximum load of each programme (refer to the
“Programmes” chapter).
•The operating water pressure at the water entry point
from the outlet connection must be between 0.5 bar
(0.05 MPa) and 8 bar (0.8 MPa).
•The ventilation opening in the base must not be
covered by a carpet, mat, or any floor covering.
•The appliance must be connected to the water mains
using the new supplied hose sets, or other new hose
sets supplied by the Authorised Service Centre.
•Old hose sets must not be reused.
•If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
•Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the
socket.
•Do not use high pressure water sprays and/or steam
to clean the appliance.
•Clean the appliance with a moist cloth. Use only
neutral detergents. Do not use abrasive products,
abrasive cleaning pads, solvents or metal objects.
•If a tumble dryer is stacked on the top of the washing
machine, make sure to use the correct stacking kit
approved by AEG (see more details in chapter
"Accessories - Stacking kit").
www.aeg.com4

2. SAFETY INSTRUCTIONS
2.1 Installation
The installation must comply
with relevant national
regulations.
• Remove all the packaging and the
transit bolts including rubber bush
with plastic spacer.
• Keep the transit bolts in a safe place.
If the appliance is to be moved in the
future they must be reattached to lock
the drum to prevent an internal
damage.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Follow the installation instructions
supplied with the appliance.
• Do not install or use a damaged
appliance.
• Do not install or use the appliance
where the temperature can be less
than 0°C or where it is exposed to the
weather.
• The floor area on which the appliance
is to be installed must be flat, stable,
heat resistant and clean.
• Make sure that there is air circulation
between the appliance and the floor.
• When the appliance is in its
permanent position, check if it is
levelled correctly with the aid of a
spirit level. If it is not, adjust the feet
accordingly.
• Do not install the appliance directly
above a floor drain.
• Do not spray water on the appliance
and do not expose it to excessive
humidity.
• Do not install the appliance where the
appliance door cannot be fully
opened.
• Do not put a closed container to
collect possible water leakage under
the appliance. Contact the Authorised
Service Centre to ensure which
accessories can be used.
2.2 Electrical connection
WARNING!
Risk of fire and electric
shock.
• The appliance must be earthed.
• Always use a correctly installed
shockproof socket.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need to
be replaced, this must be carried out
by our Authorised Service Centre.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• Do not touch the mains cable or the
mains plug with wet hands.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
2.3 Water connection
• The inlet water shall not exceed
25 °C.
• Do not cause damage to the water
hoses.
• Before connection to new pipes, pipes
not used for a long time, where repair
work has been carried out or new
devices fitted (water meters, etc.), let
the water flow until it is clean and
clear.
• Ensure that there are no visible water
leaks during and after the first use of
the appliance.
• Do not use an extension hose if the
inlet hose is too short. Contact the
Authorised Service Centre for the
replacement of the inlet hose.
• When unpacking the appliance, It is
possible to see water flowing from the
drain hose. This is due to the testing
ENGLISH 5

of the appliance with the use of water
in the factory.
• You can extend the drain hose to
maximum 400 cm. Contact the
Authorised Service Centre for the
other drain hose and the extension.
• Make sure that there is access to the
tap after the installation.
2.4 Use
WARNING!
Risk of injury, electric shock,
fire, burns or damage to the
appliance.
• Follow the safety instructions on the
detergent packaging.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Do not wash fabrics which are heavily
soiled with oil, grease or other greasy
substances. It can damage rubber
parts of the washing machine.
Prewash such fabrics by hand before
loading them into the washing
machine.
• Do not touch the glass door while a
programme operates. The glass can
get hot.
• Make sure that all metal objects are
removed from the laundry.
2.5 Service
• To repair the appliance contact the
Authorised Service Centre. Use
original spare parts only.
• Please note that self-repair or non-
professional repair can have safety
consequences and might void the
guarantee.
• The following spare parts will be
available for 10 years after the model
has been discontinued: motor and
motor brushes, transmission between
motor and drum, pumps, shock
absorbers and springs, washing drum,
drum spider and related ball bearings,
heaters and heating elements,
including heat pumps, piping and
related equipment including hoses,
valves, filters and aquastops, printed
circuit boards, electronic displays,
pressure switches, thermostats and
sensors, software and firmware
including reset software, door, door
hinge and seals, other seals, door
locking assembly, plastic peripherals
such as detergent dispensers. Please
note that some of these spare parts
are only available to professional
repairers, and that not all spare parts
are relevant for all models.
• Concerning the lamp(s) inside this
product and spare part lamps sold
separately: These lamps are intended
to withstand extreme physical
conditions in household appliances,
such as temperature, vibration,
humidity, or are intended to signal
information about the operational
status of the appliance. They are not
intended to be used in other
applications and are not suitable for
household room illumination.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains electrical and water supplies.
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
• Remove the door catch to prevent
children or pets from becoming
trapped in the drum.
• Dispose of the appliance in
accordance with local requirements
for the disposal of Waste Electrical
and Electronic Equipment (WEEE).
3. PRODUCT DESCRIPTION
3.1 Special features
Your new washing machine meets all
modern requirements for an effective
treatment of laundry with low water,
energy and detergent consumption and
proper care of fabric.
• The SensiCare System detects the
laundry load size defining the
programme duration in 30 seconds.
www.aeg.com6

The washing programme is tailored to
the laundry load and the type of fabric
without consuming more time, energy
and water than necessary.
• Thanks to the Soft Plus option, the
fabric softener is uniformly spread out
in the laundry and deeply penetrates
the fabric fibres favouring a perfect
softness.
3.2 Appliance overview
1 2 3 9
5
6
7
4
10
8
11 12
1Worktop
2Detergent dispenser
3Control panel
4Door handle
5Rating plate
6Drain pump filter
7Feet for levelling the appliance
8Drain hose
9Inlet hose connection
10 Mains cable
11 Transit bolts
12 Hose support
00000000
00A
Mod. xxxxxxxxx
000V ~ 00Hz 0000 W
910000000 00
A
B
C
Prod.No.
D
The rating plate reports the model name
(A), product number (B), electrical ratings
(C) and serial number (D).
4. TECHNICAL DATA
Dimension Width/ Height/ Total depth 59,6 cm /84,7 cm /60,2 cm
ENGLISH 7

Electrical connection Voltage
Overall power
Fuse
Frequency
230 V
2200 W
10 A
50 Hz
Level of protection against ingress of solid particles and
moisture ensured by the protective cover, except where
the low voltage equipment has no protection against mois‐
ture
IPX4
Water supply pressure Minimum
Maximum
0.5 bar (0.05 MPa)
8 bar (0.8 MPa)
Water supply 1) Cold water
Maximum Load Cotton 8 kg
Spin Speed Maximum spin speed 1351 rpm
1) Connect the water inlet hose to a water tap with a 3/4'' thread.
5. INSTALLATION
WARNING!
Refer to Safety chapters.
5.1 Unpacking
1. Open the door. Remove all the items
from the drum.
Accessories delivered
with the appliance may
vary depending on the
model.
2. Put the packaging element on the
floor behind the appliance and
carefully put it down onto its rear
side. Remove the polystyrene
protection from the bottom.
1
2
CAUTION!
Do not lay washing machine
on its front.
3. Put the appliance back into an
upright position. Remove the power
supply cable and the drain hose from
the hose holders.
www.aeg.com8

WARNING!
It is possible to see
water flowing from the
drain hose. This is
because the washing
machine has been
tested at the factory.
4. Remove the three bolts by using the
key supplied with the appliance. Pull
out the plastic spacers.
We recommend that you
keep the packaging and
the transit bolts for any
transport of the appliance.
5. Put the plastic caps, that you find in
the user manual bag, in the holes.
5.2 Positioning and levelling
1. Install the appliance on a flat hard
floor.
Make sure that carpets do
not stop the air circulation
below the appliance.
Make sure that the appliance
does not touch the wall or
other units.
2. Loosen or tighten the feet to adjust
the level.
WARNING!
Do not put cardboard, wood
or equivalent materials
below the appliance feet to
adjust the level.
x4
The appliance must be level and stable.
A correct adjustment of the
appliance level prevents the
vibration, noise and the
movement of the appliance
when in operation.
When the appliance is
installed on a plinth or a
tumble dryer is stacked on
the washing machine, use
the accessories described in
chapter 'Accessories'. Read
carefully the instructions
supplied with the appliance
and with the accessory.
5.3 The inlet hose
1. Connect the water inlet hose to the
back of the appliance.
ENGLISH 9

2. Position it toward left or right
depending on the position of the
water tap.
20º20º
45º45º
Make sure that the inlet hose
is not in vertical position.
3. If necessary, loose the ring nut to set
it in the correct position.
4. Connect the water inlet hose to the
cold water tap with 3/4" thread.
WARNING!
The inlet water shall not
exceed 25 °C.
CAUTION!
Make sure that there are no
leaks from the couplings.
Do not use an extension
hose if the inlet hose is too
short. Contact the service
centre for the replacement of
the inlet hose.
5.4 Water drainage
The drain hose should be positioned at a
height of not less than 60 cm and not
more than 100 cm from the floor.
You can extend the drain
hose to maximum 400 cm.
Contact the authorized
service centre for the other
drain hose and the
extension.
It is possible to connect the drain hose in
different ways:
1. Make a U shape with the drain hose
and put it around the plastic hose
guide.
2. On the edge of a sink - Fasten the
guide to the water tap or to the wall.
Make sure that the plastic
guide cannot move when the
appliance drains.
Make sure that the drain
hose end is not immersed in
the water. There may be a
return of dirty water into the
appliance.
3. To a stand pipe with vent-hole -
Insert the drain hose directly into a
drain pipe. Refer to the illustration.
www.aeg.com10

The end of the drain hose
must always be ventilated ,
i.e. the inner diameter of the
drain pipe (min. 38 mm -
min. 1.5") must be larger
than the external diameter of
the drain hose.
4. If the end of the drain hose looks like
this (see the picture), you can push it
directly into the stand pipe.
5. Without the plastic hose guide, to
a sink spigot - Put the drain hose in
the spigot and tighten it with a clamp.
Refer to the illustration.
Make sure that the drain
hose makes a loop to
prevent particles going into
the appliance from the sink.
6. Position the hose directly to a built-
in drain pipe in the room wall and
tighten it with a clamp.
5.5 Electrical connection
At the end of installation you can connect
the mains plug to the mains socket.
The rating plate on the inner edge of the
appliance door and the 'Technical Data'
chapter indicate the necessary electrical
ratings. Make sure that they are
compatible with the mains power supply.
Check that your domestic electrical
installation can take the maximum load
required, also taking into account any
other appliances in use.
Connect the appliance to an earthed
socket.
The power supply cable must be easily
accessible after installing the appliance.
For any electrical work required to install
this appliance, contact our Authorised
Service Centre.
The manufacturer does not accept any
responsibility for damage or injury
through failure to comply with the above
safety precaution.
ENGLISH 11

6. ACCESSORIES
6.1 Available in
www.aeg.com/shop or from
authorised dealer
Read carefully the instructions supplied
with the accessory.
Only appropriate
accessories approved by
AEG ensure the safety
standards of the appliance. If
unapproved parts are used,
any claims will be
invalidated.
6.2 Fixing plate kit
If you install the appliance on a plinth
that is not an accessory supplied by
AEG, secure the appliance in the fixing
plates.
Read carefully the instructions supplied
with the accessory.
6.3 Stacking kit
The tumble dryer can be stacked on the
top of the washing machine only by
using the correct stacking kit.
WARNING!
Do not put the tumble dryer
under the washing machine.
Verify the compatible
stacking kit by checking the
depth of your appliances.
7. CONTROL PANEL
7.1 Control panel description
23
6
12 11 10 8
1
4
5
7
9
www.aeg.com12

1Programme dial
2Display
3Inicio Diferido touch button
4Extra Rápido touch button
5Aclarado/Enxag. skipping touch
button
• Extra Aclarado/Enxag. option
• Aclarado/Enxag. option
6Inicio/Pausa touch button
7Manchas/Pre-Lav. skipping touch
button
• Manchas option
• Pre-Lav. option
8Anti-Alergia touch button
9Soft Plus touch button
10 Centrif. reduction touch button
11 Temp.ºC touch button
12 On/Off push button
7.2 Display
MIX
The indicator flashes during the laundry load estimation.
Maximum laundry indicator. It flashes when the laundry load exceeds
the maximum declared load of the selected programme.
Door locked indicator.
Delay start indicator.
The digital indicator can show:
• Programme duration (e. g. ).
• Delay time (e. g. or ).
• Cycle end ( ).
• Warning code ( ).
Washing phase indicator. It flashes during prewash and wash phase.
Rinsing phase indicator. It flashes during rinse phase.
ENGLISH 13

The Extra Rinse option. The indicator appears above the when
a extra rinse is set .
Spinning and draining phase indicator. It flashes during spin and drain
phase.
Child safety lock indicator.
Temperature indicator. The indicator appears when a cold wash is
set.
Spin speed indicator.
No spin speed indicator. Spin phase is off.
Rinse hold indicator.
Extra silent indicator.
Time saving indicator.
8. DIAL AND BUTTONS
8.1 On/Off
Pressing this button for a few seconds
allows to activate or deactivate the
appliance. Two different tunes sound
while switching the appliance on or off.
As the Stand-by function automatically
deactivates the appliance to decrease
the energy consumption in a few cases,
you may need to activate the appliance
again.
For more details, refer to Stand-by
paragraph in Daily Use chapter.
8.2 Introduction
The options/functions are
not selectable with all
washing programmes.
Check the compatibility
between options/functions
and washing programmes in
the "Programme Chart". An
option/function can exclude
another one, in this case the
appliance doesn't allow you
to set the incompatible
options/functions together.
Make sure the screen and
touch buttons are always
clean and dry.
8.3 Temp.ºC
When you select a washing programme,
the appliance automatically proposes a
default temperature.
Touch this button repeatedly until the
desired temperature value appears on
the display.
When the display shows the indicators
and , the appliance does not heat
the water.
www.aeg.com14

8.4 Centrif.
When you set a programme, the
appliance automatically sets the
maximum spin speed allowed.
Touch repeatedly this button to:
•Decrease the spin speed.
The display shows only
the spin speeds available
for the set programme.
•Activate the Rinse Hold option.
The final spin is not performed. The
water of the last rinse is not drained
out to prevent the fabrics from
creasing. The washing programme
ends with water in the drum.
The display shows the indicator .
The door stays locked and the drum
turns regularly to reduce creasing.
You must drain the water to unlock
the door.
If you touch the Inicio/Pausa button,
the appliance performs the spinning
phase and drains the water.
The appliance empties
the water out
automatically after 18
hours approximately.
•Activate the Extra Silent option.
The intermediate and the final
spinning phases are suppressed and
the programme ends with water in the
drum. This helps to reduce creasing.
The display shows the indicator .
The door stays locked. The drum
turns regularly to reduce creasing.
You must drain the water to unlock
the door.
As the programme is very quiet, it is
suitable for use at night time when
cheaper electricity tariffs are
available. In some programmes the
rinses are performed with more water.
If you touch the Inicio/Pausa button,
the appliance performs the only
draining phase.
The appliance empties
the water out
automatically after 18
hours approximately.
8.5 Manchas/Pre-Lav.
Press this button repeatedly to activate
one of the two options.
The relevant indicator goes on in the
display.
•Manchas
Select this option to add an anti-stain
phase to a programme in order to
treat heavily soiled or stained laundry
with stain remover.
Pour the stain remover into
compartment . The stain remover
will be added in the appropriate phase
of the washing programme.
This option is not
available with a
temperature lower than
40 °C.
•Pre-Lav.
Use this option to add a pre-wash
phase at 30 °C before the washing
phase.
This option is recommended for
heavily soiled laundry, especially if
containing sand, dust , mud and other
solid particles.
The options can increase the
programme duration.
8.6 Aclarado/Enxag.
With this button you can select one of the
following options:
• Extra Aclarado/Enxag. option
This option adds a few rinses
according to the selected washing
programme.
Use this option for persons allergic to
detergent residues and in areas
where the water is soft.
This option increases
slightly the programme
duration.
• Skipping wash phase - Aclarado/
Enxag. option
The appliance performs only the
rinsing phase, the spinning and the
draining phases of the selected
programme.
The corresponding indicator above the
touch button illuminates.
ENGLISH 15

8.7 Anti-Alergia
Set this option with white Algod. items
programme. When the option is selected,
neither the temperature or the cycle time
can be changed. Option Extra Rápido
and Extra silent are not available.
The corresponding indicator above the
touch button illuminates.
This option, thanks to washing phase
combined with steam vapour , removes
more than 99,99% of bacteria and
viruses keeping the temperature above
60°C throughout the washing phase; with
an additional action on the fibers thanks
to a vapour phase, an enhanced rinsing
phase ensures a proper removal of
detergent and micro-organism residues.
This option ensures also a proper
reduction of pollens/allergenic items.
Tested for Staphylococcus
aureus, Enterococcus
faecium, Candida albicans,
Pseudomonas aeruginosa
and MS2 Bacteriophage in
external test performed by
Swissatest Testmaterialien
AG in 2021 (Test Report No.
202120117).
8.8 Extra Rápido
With this option you can decrease the
programme duration.
• If your laundry is normally or lightly
soiled, it may be advisable to shorten
the washing programme. Touch this
button once to decrease the duration.
• In case of smaller load, touch this
button twice to set an extra quick
programme.
The display shows the indicator .
8.9 Soft Plus
Set the Soft Plus option to ensures
perfect distribution of the fabric softener
and improves the fabric softness.
This option increases slightly
the programme duration.
8.10 Inicio Diferido
With this option you can delay the start of
a programme in a more convenient time.
Touch the button repeatedly to set the
required delay. The time increases by
steps of 30 minutes up to 90' and from 2
hours up to 20 h.
After touching the Inicio/Pausa button,
the display shows the indicator and
the selected delay time and the
appliance begins the countdown.
8.11 Inicio/Pausa
Touch the Inicio/Pausa button to start,
pause the appliance or interrupt a
running programme.
9. PROGRAMMES
9.1 Programme Chart
Washing programmes
Programme Programme description
Eco 40-60 White cotton and fast-coloured cotton. Normally soiled
items. The energy consumption decreases and the time of the
washing programme is extended, ensuring good washing re‐
sults.
Algod. White and coloured cotton heavily and normally soiled cotton
items.
www.aeg.com16

Programme Programme description
Sintéticos Synthetic items or mixed fabric items. Normally soiled
items.
Delicados Delicate fabrics such as acrylics, viscose and mixed fab‐
rics requiring gentler washing. Normally and lightly soiled
items.
Lana/Lãs + Seda Machine washable wool, hand washable wool and other
fabrics with «hand washing» care symbol1).
Outdoor Do not use fabric softener and make sure that
there is no softener residue in the detergent
dispenser.
Outdoor clothing, technical, sport fabrics, waterproof and
breathable jackets, shell jackets with a removable fleece
or inner insulation. The recommended laundry load is 2,5 kg.
This programme can also be used as water-repellent restoring
cycle, specifically tailored for treating clothes with a hydropho‐
bic coating. To perform the water-repellent restoring cycle, pro‐
ceed as follows:
• Pour the washing detergent in the compartment .
• Pour a special water-repellent restorer for fabric in the
drawer compartment for fabric softener .
• Reduce the laundry load to 1 kg.
To further improve the water-repellent restor‐
ing action, dry the laundry in a tumble dryer by
setting the Outdoor drying programme (if avail‐
able and if the garment care label permits tum‐
ble drying).
20 min. - 3 kg Cotton and synthetic items lightly soiled or once worn.
Edred. Single synthetic blanket, padded clothes, duvets, down
jackets and similar items.
Fácil Plancha/Engomar Synthetic items requiring a gentle wash. Normally and light‐
ly soiled items.2)
Centrif./Drenar All fabrics, except woollens and delicate fabrics. To spin
the laundry and to drain the water in the drum.
1) During this cycle the drum rotates slowly to ensure a gentle wash. It can seem that the drum doesn't
rotate or doesn't rotate properly, but this is normal for this programme.
2) To reduce creasing, this cycle regulates the water temperature and performs a soft wash and spin
phase. The appliance adds some rinses.
ENGLISH 17

Programme temperature, maximum spin speed and maximum load
Programme
Default tempera‐
ture
Temperature
range
Reference spin
speed
Spin speed range
Maximum load
Eco 40-60 40 °C 1) 1400 rpm
1400 rpm - 400 rpm 8 kg
Algod. 40 °C
95 °C - Cold
1400 rpm
1400 rpm - 400 rpm 8 kg
Sintéticos 40 °C
60 °C - Cold
1200 rpm
1200 rpm - 400 rpm 3 kg
Delicados 30 °C
40 °C - Cold
1200 rpm
1200 rpm - 400 rpm 2 kg
Lana/Lãs + Seda 40 °C
40 °C - Cold
1200 rpm
1200 rpm - 400 rpm 1,5 kg
Outdoor 30 °C
40 °C - Cold
1200 rpm
1200 rpm - 400 rpm
2,5 kg2)
1 kg3)
20 min. - 3 kg 30 °C
40 °C - 30 °C
1200 rpm
1200 rpm - 400 rpm 3 kg
Edred. 40 °C
60 °C - Cold
800 rpm
800 rpm - 400 rpm 3 kg
Fácil Plancha/Engomar 40 °C
60 °C - Cold
800 rpm
800 rpm - 400 rpm 3 kg
Centrif./Drenar 4) -1400 rpm
1400 rpm 8 kg
1) According to Commission Regulation EU 2019/2023, this programme at 40 °C is able to clean normal‐
ly soiled cotton laundry declared to be washable at 40 °C or 60 °C, together in the same cycle.
For the reached temperature in the laundry, the programme duration and other data,
please refer to 'Consumption Values' chapter.
The most efficient programmes in terms of energy consumption are generally those that
perform at lower temperatures and longer duration.
2) Washing programme.
3) Washing programme and waterproofing phase.
4) Set the spin speed. Make sure it is suitable for the type of fabric being washed. If you set the No Spin
option then only the drain phase is available.
www.aeg.com18

Programme options compatibility
OPTIONS
PROGRAMME
Eco 40-60
Algod.
Sintéticos
Delicados
Lana/Lãs + Seda
Outdoor
20 min. - 3 kg
Edred.
Fácil Plancha/Engomar
Centrif./Drenar
Centrif. ■ ■ ■ ■ ■ ■ ■ ■ ■ ■
■
■ ■ ■ ■ ■ ■ ■
■ ■ ■ ■
Manchas 1) ■ ■ ■ ■
Pre-Lav. ■ ■ ■ ■
Extra Aclarado/
Enxag. ■ ■ ■ ■ ■ ■
Aclarado/Enxag. ■ ■ ■ ■ ■ ■ ■ ■ ■
Anti-Alergia ■
Extra Rápido 2) ■ ■ ■ ■ ■
Inicio Diferido ■ ■ ■ ■ ■ ■ ■ ■ ■ ■
Soft Plus ■ ■ ■ ■ ■ ■
1) This option is not available with temperature lower than 40 °C.
2) If you set the shortest duration, we recommend that you decrease the load size. It is possible to fully
load the appliance, however the washing results can be less satisfactory.
Suitable detergents for washing programmes
Programme Universal
powder1)
Liquid Uni‐
versal
Liquid for
coloureds
Delicates
woollens Special
Eco 40-60 ▲ ▲ ▲ -- --
Algod. ▲ ▲ ▲ -- --
Sintéticos ▲ ▲ ▲ -- --
ENGLISH 19

Programme Universal
powder1)
Liquid Uni‐
versal
Liquid for
coloureds
Delicates
woollens Special
Delicados -- -- -- ▲ ▲
Lana/Lãs + Seda -- -- -- ▲ ▲
Outdoor -- -- -- ▲ ▲
20 min. - 3 kg -- ▲ ▲ -- --
Edred. -- -- -- ▲ ▲
Fácil Plancha/
Engomar ▲ ▲ ▲ -- --
1) At temperature higher than 60 °C the use of powder detergent is recommended.
▲ = Recommended -- = Not recommended
9.2 Woolmark Apparel Care - Blue
The wool wash cycle of this machine has
been approved by The Woolmark Company
for the washing of wool garments labelled as
«hand wash» provided that the garments are
washed according to the instructions issued
by the manufacturer of this washing machine.
Follow the garment care label for drying and
other laundry instructions. M1511
The Woolmark symbol is a Certification mark
in many countries.
10. SETTINGS
10.1 Child Lock
With this option you can prevent children
from playing with the control panel.
• To activate/deactivate this option,
touch the Centrif. and the Manchas/
Pre-Lav. buttons simultaneously until
the indicator comes on/goes off
on the display.
You can activate this option:
• After you touch the Inicio/Pausa
button: all the buttons and the
programme dial are deactivated
(except On/Off button ).
• Before you touch the Inicio/Pausa
button: the appliance cannot start.
The appliance keeps the selection of this
option after you switch it off.
10.2 Acoustic signals
To deactivate the acoustic signals when
the programme is completed touch the
Manchas/Pre-Lav. and the Anti-Alergia
buttons simultaneously for about 3
seconds.
The acoustic signals, they
continue operate when the
appliance has a malfunction.
www.aeg.com20
