AEG LAVAMAT 61470 WDBI User manual

LAVAMAT 61470 WDBI EN User manual

CONTENTS
1. SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2. SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3. TECHNICAL INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4. PRODUCT DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
5. CONTROL PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
6. WASHING PROGRAMMES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
7. CONSUMPTION VALUES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
8. FIRST USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
9. DAILY USE - WASHING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
10. DAILY USE - DRYING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
11. HELPFUL HINTS AND TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
13. CARE AND CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
14. TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
15. INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
16. BUILDING IN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you impeccable
performance for many years, with innovative technologies that help make life simpler –
features you might not find on ordinary appliances. Please spend a few minutes reading to get
the very best from it.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.aeg.com
Register your product for better service:
www.aeg.com/productregistration
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
We recommend the use of original spare parts.
When contacting Service, ensure that you have the following data available.
The information can be found on the rating plate. Model, PNC, Serial Number.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
2www.aeg.com

1. SAFETY INFORMATION
Before the installation and use of the appliance, careful-
ly read the supplied instructions. The manufacturer is
not responsible if an incorrect installation and use cau-
ses injuries and damages. Always keep the instructions
with the appliance for future reference.
1.1 Children and vulnerable people safety
WARNING!
Risk of suffocation, injury or permanent disability.
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
• Do not let children play with the appliance.
• Keep all packaging away from children.
• Keep all detergents away from children.
• Keep children and pets away from the appliance door
when it is open.
• If the appliance has a child safety device, we recom-
mend you activate it.
• Cleaning and user maintenance shall not be made by
children without supervision.
1.2 General Safety
• Before maintenance, deactivate the appliance and
disconnect the mains plug from the mains socket.
• Do not change the specification of this appliance.
• Obey the maximum load volume of 7 kg (refer to the
“Programme chart” chapter).
ENGLISH 3

• If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly quali-
fied persons in order to avoid a hazard.
• The operating water pressure (minimum and maxi-
mum) must be between 0,5 bar (0,05 MPa) and 8 bar
(0,8 MPa)
• The ventilation openings in the base (if applicable)
must not be obstructed by a carpet.
• The appliance is to be connected to the water mains
using the new supplied hose-sets. Old hose sets must
not be reused.
2. SAFETY INSTRUCTIONS
2.1 Installation
• Remove all the packaging and the
transit bolts.
• Keep the transit bolts. When you
move the appliance again you must
block the drum.
• Do not install or use a damaged appli-
ance.
• Do not install or use the appliance
where the temperature is less than 0
°C or where it is exposed to the
weather.
• Obey the installation instruction sup-
plied with the appliance.
• Make sure that the floor where you in-
stall the appliance is flat, stable, heat
resistant and clean.
• Do not install the appliance where the
appliance door can not be fully
opened.
• Always be careful when you move the
appliance because it is heavy. Always
wear safety gloves.
• Make sure that there is air circulation
between the appliance and the floor.
• Adjust the feet to have the necessary
space between the appliance and the
carpet.
Electrical connection
WARNING!
Risk of fire and electrical shock.
• The appliance must be earthed.
• Make sure that the electrical informa-
tion on the rating plate agrees with
the power supply. If not, contact an
electrician.
• Always use a correctly installed shock-
proof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug and to the mains cable.
Should the appliance power supply
cable need to be replaced, this must
be carried out by our Service Centre.
• Connect the mains plug to the mains
socket only at the end of the installa-
tion. Make sure that there is access to
the mains plug after the installation.
• Do not pull the mains cable to discon-
nect the appliance. Always pull the
mains plug.
• Do not touch the mains cable or the
mains plug with wet hands.
• This appliance complies with the
E.E.C. Directives.
4www.aeg.com

Water connection
• Make sure not to cause damage to the
water hoses.
• The appliance is to be connected to
the water mains using the new sup-
plied hose-sets. Old hose sets must
not be reused.
• Before you connect the appliance to
new pipes or pipes not used for a long
time, let the water flow until it is clean.
• The first time you use the appliance,
make sure that there is no leakage.
2.2 Use
WARNING!
Risk of injury, electrical shock,
fire, burns or damage to the ap-
pliance.
• Use this appliance in a household on-
ly.
• Do not change the specification of this
appliance.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Do not touch the glass of the door
while a programme operates. The
glass can be hot.
• Make sure that you remove all metal
objects from the laundry.
• The final part of the drying cycle oc-
curs without heat (cool down cycle) to
ensure that the items will not be dam-
aged.
If you stop the appliance before the
end of the drying cycle, immediately
remove and spread out all items, so
that the heat can dissipate.
• If you use detergent, fabric softener or
similar products, obey the instructions
on the packaging.
• Wipe away lint that has accumulated
around the appliance.
• Do not dry the damaged items which
contain padding or fillings .
• Do not dry items such as foam rubber
(latex foam), shower caps, waterproof
textiles and rubber backed articles.
• Before drying items that have been in
contact with substances such as cook-
ing oil, acetone, alcohol , petrol, kero-
sene, spot removers, turpentine, wax-
es and wax removers, wash them in
hot water with an extra amount of de-
tergent.
• Do not dry items if industrial chemicals
have been used for cleaning.
• Make sure that no gas lighters or
matches have been left in the pockets
of the clothing.
• Only dry fabrics which are applicable
to dry in the tumble dryer. Follow the
instructions on the fabric label.
• Do not dry not washed items in the
appliance.
• If you have washed your laundry with a
stain remover start an extra rinse cycle
before you start the appliance.
• Plastic items are not heat resistant.
– If you use a detergent ball, remove
it before you set the drying pro-
gramme.
– Do not use a detergent ball when
you set a non-stop programme.
WARNING!
Risk of injury or damage to the
appliance.
• Do not sit or stand on the open door.
• Obey the maximum load volume.
• Do not dry dripping wet clothes in the
appliance.
2.3 Care and Cleaning
WARNING!
Risk of injury or damage to the
appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• Do not use water spray and steam to
clean the appliance.
• Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
not use abrasive products, abrasive
cleaning pads, solvents or metal ob-
jects.
2.4 Disposal
WARNING!
Risk of injury or suffocation.
ENGLISH 5

• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent
children and pets to get closed in the
appliance.
3. TECHNICAL INFORMATION
Dimensions Width / Height / Depth 600 / 820 / 630 mm
Total depth 640 mm
Electrical connection: Voltage
Overall power
Fuse
Frequency
230-240 V
2050 W
13 A
50 Hz
Level of protection against ingress of solid particles
and moisture ensured by the protective cover, ex-
cept where the low voltage equipment has no pro-
tection against moisture
IPX4
Water supply pressure Minimum 0,5 bar (0,05 MPa)
Maximum 8 bar (0,8 MPa)
Water supply
1)
Cold water
Maximum wash load Cotton 7 kg
Maximum dry load Cotton 3 kg
Cotton big capacity 4 kg
Synthetics 2 kg
Spin speed Maximum 1400 rpm
1) Connect the water inlet hose to a water tap with a 3/4'' thread.
6www.aeg.com

4. PRODUCT DESCRIPTION
7 8 9
10
1 2
3
4
5
6
1Detergent dispenser
2Control panel
3Door handle
4Rating plate
5Drain pump
6Feet for the appliance level
7Water drain hose
8Mains cable
9Water inlet hose
10 Feet for the appliance level
4.1 Child safety device
• When you activate this device, you
cannot close the door. This prevents
children or pets to be closed in the
drum. To activate the device, turn it
clockwise, until the groove is horizon-
tal. To deactivate the device, turn it
counterclockwise, until the groove is
vertical.
4.2 Accessories
1 2
34
1Spanner
To remove the transit bolts.
2Plastic caps
To close the holes on the rear side
of the cabinet after the removal of
the transit bolts.
3Anti-flood inlet hose
To prevent possible leakage
4Plastic hose guide
To connect the drain hose on the
edge of a sink.
ENGLISH 7

5. CONTROL PANEL
1 2 3 4 5 6 7 98 10
A
B
C
1Programme selector dial
2SPIN button
•Rinse hold position
3STAIN button
4TIME SAVE button
5EXTRA RINSE button
6DRYING TIME button
7Display
8START/PAUSE button
9DELAY START button
10 Indicator pilot lights:
•A–Washingphase
•B–Dryingphase
• C – Door locked
5.1 Display
The display shows the following informa-
tion:
Duration of the set programme
When you set a programme, the display shows the duration in
hours and minutes (for example 2.05).
The duration is calculated automatically on the maximum load
for each type of fabric.
After the programme has started, the time remaining is updated
every minute.
Set drying time
when you set a drying programme, the display shows the drying
time in minutes and/or hours (see paragraph «Drying»).
After the programme has started, the appliance updates the re-
maining time every minute.
8www.aeg.com

Alarm codes
In the event of operating problems, some alarm codes can be
displayed, for example (see chapter «Troubleshooting»).
End of programme
When the programme has finished, the display shows a blinking
zero .
The DOOR light C, the WASHING light A(or the DRYING light B)
and the light of button 8go out.
The door can be opened.
Incorrect option selection
If you set an option which is not compatible with the wash pro-
gramme, the display shows the message Err for some seconds.
The yellow pilot light of button 8light starts blinking.
Delay Start
When you press the relevant button to set the delay (20 hours
max), it appears for some seconds, then the display shows the
duration of the set programme.
The delay time value decreases by one unit every hour. When
only 1 hour remains, the time decreases every minute.
Delay Start symbol
This symbol comes on when you set the delay time.
Child safety lock
This symbol comes on when you activate the child lock function.
5.2 Indicator pilot lights
A
B
C
After you have pressed the button 8, the
WASHING light (A) comes on.
The machine is operating.
When you set a drying programme, the
DRYING light (B) illuminate and stays on
during the drying phase.
The DOOR light (C) indicates when the
door can be opened:
• light on: the door cannot be opened
• light blinking: the door is opening in
some minutes
• light off: the door can be opened
5.3 Acoustic signals
The machine is provided with an acous-
tic device, which sounds in the following
cases:
• at the end of the cycle
• in the event of operating problems.
By pressing the 3and 4buttons simulta-
neously for some seconds, the acoustic
signal is deactivated (except for the
events of operating problems). By press-
ing these two buttons again, the acous-
tic signal is reactivated.
5.4 Child safety lock
This device permits you to leave the ap-
pliance unsupervised and not to worry
that children might be injured by or
cause damage to the appliance.
This function remains able also when the
washing machine is not working.
There are two different ways to set this
option:
• Before pressing button 8: it will be im-
possible to start the machine.
ENGLISH 9

• after pressing button 8: it will be im-
possible to change any other pro-
gramme or option.
To enable or disable this option press si-
multaneously for about 6 seconds but-
tons 4and 5until the symbol comes
on or disappears from the display.
6. WASHING PROGRAMMES
Programme
Maximum and Minimum Temperature
Type of Laundry
Maximum Load
Cycle De-
scription Options
Cottons
95° - 30°
Max. load 7 kg - Reduced load 3 kg
White and coloured cotton
Normally soiled items.
Main wash
Rinses
Long spin
at maxi-
mum speed
SPIN REDUCTION
RINSE HOLD
STAIN
1)
TIME SAVE
2)
EXTRA RINSE
Cotton Economy
40°
Max. load 7 kg
White and fast coloured cotton
Slightly or normally soiled cotton items.
The appliance decreases the temperature
and extends the washing time to obtain a
good washing efficiency so saving energy.
Main wash
Rinses
Long spin
at maxi-
mum speed
SPIN REDUCTION
RINSE HOLD
STAIN
EXTRA RINSE
Cottons + Prewash
3)
95° - 40°
Max. load 7 kg - Reduced load 3 kg
White and coloured cotton
(Very soiled items).
Prewash
Main wash
Rinses
Long spin
at maxi-
mum speed
SPIN REDUCTION
RINSE HOLD
STAIN
TIME SAVE
2)
EXTRA RINSE
Synthetics
60° - 30°
Max. load 3 kg - Reduced load 2 kg
Synthetic or mixed fabrics: underwear,
coloured garments, non-shrink shirts, blou-
ses.
Main wash
Rinses
Short spin
at 1200 rpm
SPIN REDUCTION
RINSE HOLD
STAIN
1)
TIME SAVE
2)
EXTRA RINSE
Easy Iron
40°
Max. load 1 kg
Synthetic fabrics to be gentle washed
and spun.
The laundry is gently washed and spun to
avoid any creasing. Furthermore the ma-
chine will perform additional rinses.
Main wash
Rinses
Short spin
Spin at 1200
rpm
SPIN REDUCTION
RINSE HOLD
EXTRA RINSE
10 www.aeg.com

Programme
Maximum and Minimum Temperature
Type of Laundry
Maximum Load
Cycle De-
scription Options
Delicates
40° - 30°
Max. load kg 3 - Reduced load kg 2
Delicate fabrics: acrylics, viscose, polyest-
er.
Main wash
Rinses
Short spin
at 1200 rpm
SPIN REDUCTION
RINSE HOLD
STAIN
1)
TIME SAVE
2)
EXTRA RINSE
Wool/Silk
30° - Cold
Max. load 2 kg
Machine washable wool as well as for hand
washable woollens and delicate fabrics.
Note: A single or bulky item may cause im-
balance. If the appliance doesn’t perform
the final spin phase, add more items, redis-
tribute the load manually and then select
the spinning programme.
Main wash
Rinses
Short spin
at 1200 rpm
SPIN REDUCTION
RINSE HOLD
Delicate Rinses
Max. load 7 kg
Programme for rinsing and spinning items
which have been washed by hand. The ma-
chine performs some rinses, followed by a
final spin. The spin speed can be reduced.
Rinses
Long spin
Spin at 1200
rpm
SPIN REDUCTION
RINSE HOLD
EXTRA RINSE
Drain
Max. load 7 kg
For emptying out the water of the last rinse
in programmes with the Rinse hold option
set.
Draining of
water
Spin
Max. load 7 kg
Separate spin for hand washed cotton gar-
ments and after programmes with the Rinse
Hold option set.
Turn the programme dial to before
setting this programme.
Reduce the spin speed if needed.
Drain
Long spin
Spin at the
maximum
speed
SPIN REDUCTION
Drying — Syntetics
Drying synthetic programme.
DRYING TIME se-
lection.
Drying — Cottons
Drying cotton programme.
DRYING TIME se-
lection.
Refresh
30°
Max. load 3 kg
Quick wash for sport items, or cotton and
synthetic items lightly soiled or worn once.
Main wash
Rinses
Short spin
Spin at 1200
rpm
SPIN REDUCTION
ENGLISH 11

Programme
Maximum and Minimum Temperature
Type of Laundry
Maximum Load
Cycle De-
scription Options
Cotton Economy
60°
Max. load 7 kg
White and fast coloured cotton.
Slightly or normally soiled cotton items.
The appliance decreases the temperature
and extends the washing time to obtain a
good washing efficiency so saving energy.
Main wash
Rinses
Long spin
Spin at the
maximum
speed
SPIN REDUCTION
RINSE HOLD
STAIN
EXTRA RINSE
For cancelling the running programme or to switch the machine off .
1) Stain option can be selected only at the temperature of 40°C or higher.
2) If you select the Super Quick option by pressing button 4, we recommend that you
reduce the maximum load as indicated. Full loading is possible however with somewhat
reduced cleaning results.
3) If using liquid detergents, a programme without PREWASH must be selected.
12 www.aeg.com

6.1 Drying programmes
Timed programmes
Degree of Drying Type of Fabric Drying
Load
Spin
Speed
Sugges-
ted
drying
time
Minutes
EXTRA DRY
Ideal for towelling mate-
rials
Cotton and linen
(bathrobes, bath
towels, etc)
4 kg 1400 160 -
180
3 kg 1400 110 -
120
1.5 kg 1400 75 - 85
CUPBOARD DRY
1)
Suitable for items to put
away without ironing
Suitable for items to put
away without ironing
Cotton and linen
(bathrobes, bath
towels, etc)
4 kg 1400 150 -
170
3 kg 1400 100 -
110
1.5 kg 1400 65 - 75
Synthetics and
mixed fabrics
(jumpers, blouses,
underwear, house-
hold linen)
2 kg 1200 90 - 100
1 kg 1200 55 - 65
IRON DRY
Suitable for ironing
Cotton and linen
(sheets, table-
cloths, shirts, etc.)
4 kg 1400 120 -
140
3 kg 1400 80 - 90
1.5 kg 1400 50 - 60
1) In compliance with EC directive EN 50229 the cotton reference programme for the
data entered in the Energy Label must be tested dividing the maximum washing load by
two equal parts and drying with DRYING TIME each of them.
ENGLISH 13

7. CONSUMPTION VALUES
Programme Energy con-
sumption
(KWh)
Water con-
sumption
(litres)
Programme
duration
(minutes)
Cottons 60° 1.35 67 For the du-
ration of the
pro-
grammes,
please refer
to the dis-
play on the
control pan-
el.
Cotton Energy Saving Pro-
gramme 60°
1)
1.05 49
Cottons 40° 0.85 67
Synthetics 40° 0.55 42
Delicates 40° 0.55 63
Wool/ Handwash 30° 0.25 55
1) «Cotton Energy Saving programme » at 60°C with a load of 7 kg is the reference
programme for the data entered in the energy label, in compliance with EEC 92/75
standards.
The consumption data shown on
this chart is to be considered
purely indicative, as it may vary
depending on the quantity and
type of laundry, on the inlet wa-
ter temperature and on the am-
bient temperature.
8. FIRST USE
1. To activate the drain system, put 2 li-
tre of water in the main wash com-
partment of the detergent dispens-
er.
2. Put a small quantity of detergent in
the main wash compartment of the
detergent dispenser. Set and start a
programme for cotton at the highest
temperature without laundry. This
removes all possible dirt from the
drum and the tub.
9. DAILY USE - WASHING
9.1 Loading the laundry
1. Open the appliance door.
2. Put the laundry in the drum, one
item at a time. Shake the items be-
fore you put them in the appliance.
Make sure not to put too much laun-
dry in the drum.
3. Close the door.
14 www.aeg.com

Make sure that no laundry stays between
the seal and the door. There is a risk of
water leakage or damage to the laundry.
9.2 Filling the detergent and additives
MAX
The detergent compartment for the prewash phase, the soak
programme and for the stain function.
Add the detergent for prewash, soak and stain remover before
the start of the programme.
The detergent compartment for the washing phase.
If you use a liquid detergent, put it immediately before you start
the programme.
Liquid additives compartment (fabric conditioner, starch).
Put the product in the compartment before you start the pro-
gramme.
This is the maximum level for the quantity of liquid additives.
Always obey the instructions that you find on the packaging of the de-
tergent products.
9.3 Setting the programme
(knob 1 )
Turn the programme selector dial to the
required programme.
The programme dial determines the
type of washing cycle (e.g. water level,
drum movement, number of rinses) and
the washing temperature according to
the type of laundry.
The pilot light of button 8starts blinking.
The programme dial can be turned ei-
ther clockwise or anticlockwise.
= Reset programme / switching
OFF of the machine
ENGLISH 15

If you turn the programme dial to
another programme when the
appliance is working, the yellow
pilot light of button 8blinks 3
times. The display shows the
message Err to indicate a wrong
selection. The machine will not
perform the new set programme.
9.4 Setting the SPIN speed
(button 2)
When you set the programme, the appli-
ance automatically proposes the maxi-
mum spin speed allowed by that pro-
gramme.
Press this button repeatedly to change
the spin speed. The relevant light will
light up.
RINSE HOLD : the water of the last rinse
is not emptied out to prevent the fabrics
from creasing. When the programme
has finished the display shows a blinking
.
The DOOR pilot light goes on.
The pilot light of button 8is off. The
door is blocked to indicate that the wa-
ter must be emptied out.
To empty the water out please read
chapter «At the end of the pro-
gramme».
9.5 Setting the STAIN option
(button 3)
Set this option to treat heavily soiled or
stained laundry with stain remover
The appliance extends the main wash
phase and intensifies the stain action
phase. The relevant light illuminates.
This option is not available with
a temperature lower than 40°C.
If you wish to perform a programme with
the stain option, pour stain remover into
compartment .
9.6 Setting the TIME SAVING
option (button 4)
This option allows you to modify the
washing time, automatically proposed
by the appliance.
Press button 4
once
DAILY The relative pilot light
comes on.
The washing duration will
be reduced to wash daily
soiled laundry.
Press button 4twice
SUPER
QUICK
The relative pilot light re-
mains lit.
The washing duration will
be reduced to wash lightly
soiled laundry or items
used or worn for a short
time.
The display shows the decreased wash-
ing time.
9.7 Setting the EXTRA RINSE
option (button 5)
This appliance is designed for saving wa-
ter.
However, for people with a very delicate
skin (allergic to detergents) it may be
necessary to rinse the laundry using an
extra quantity of water (extra rinse).
The appliance will perform some addi-
tional rinses.
9.8 Starting the programme
(button 8)
Press the button 8to start the pro-
gramme. The corresponding red pilot
light stops blinking.
The pilot light Ais on to indicate that
the appliance starts operating.
The pilot light Cis on to indicate the
door is locked.
Press the button 8to interrupt a pro-
gramme which is running. The corre-
sponding red pilot light starts blinking.
Press the button 8again to restart the
programme from the point at which it
was interrupted
If you have chosen a delayed start with
button 9, the machine will begin the
countdown.
If you set an incorrect option, the yellow
pilot light of the button 8blinks for 3
times. The display shows the message
Err for some seconds.
16 www.aeg.com

9.9 Setting the DELAY START
(button 9)
Press this button again an again to set
the required delay.
The display shows the set delay time val-
ue (up to 20 hours) for some seconds,
then it shows the duration of the pro-
gramme again.
Set the delay before you press the but-
ton 8.
You can delay the wash programme can
be delayed from 30 min - 60 min - 90
min, 2 hours and then by 1 hour up to a
maximum of 20 hours.
Adding items after you have set the
delay (throughout the delay time the
door will be locked):
• Press the button 8to put the machine
in pause
• Add the laundry, close the door .
• Press the button 8again.
Setting the delayed start:
• Set the programme and the required
options.
• Set the delay start.
• Press the button 8: the appliance
starts its hourly countdown.
The programme will start after the se-
lected delay has expired.
Cancelling the delayed start:
• Press the button 8to set the washing
machine to PAUSE;
• Press the button 9once until the dis-
play shows the symbol ’;
• Press the button 8again to start the
programme.
You can change the set delay on-
ly after you set the washing pro-
gramme again.
The Delay Start can not be selected with
DRAIN programme.
9.10 Altering an option or a
running programme
It is possible to change some options
before the programme carries it out. Be-
fore you make any change, you must
press the button 8to pause the appli-
ance.
Changing a running programme is possi-
ble only by resetting it.
Turn the programme dial to and
then to the new programme position.
Press the 8button again to start the new
programme. The washing water in the
tub will not emptied out.
9.11 Interrupting a
programme
Press the button 8to interrupt a pro-
gramme which is running, the corre-
sponding light starts blinking. Press the
button again to restart the programme.
9.12 Cancelling a programme
Turn the selector dial to to cancel a
programme which is running. Now you
can select a new programme.
9.13 Opening the door
When the machine is working and
through the delay time, the door is
locked.
If, for any reason, it is necessary to open
it, firstly press the button 8to set the
machine to pause
If the light Cafter a few minutes goes
off, the door can be opened.
If the light Cstays on and the door re-
mains locked, this means that the ma-
chine is already heating or that the water
level is too high. In this case the door
can not be opened.
If you cannot open the door but you
need to open it, turn the programme di-
al to to switch the machine off. After
a few minutes the door can be opened
(pay attention to the water level and
temperature !) .
After closing the door, it is necessary to
set the programme and the options
again. Press button 8to start the pro-
gramme again.
9.14 At the end of the
programme
The machine stops automatically. The pi-
lot light of button 8, the pilot lights A
and Cgo off. A blinking will appear on
the display.
If you have set a programme or an op-
tion that ends with water in the tub, the
light Cremains lit. The door is locked.
ENGLISH 17

The water must be emptied out before
opening the door. During this time the
drum continues to turn at regular inter-
vals until water drain.
Follow the below instructions to empty
out the water:
• Turn the programme selector dial to
• Set the DRAIN or SPIN programme
• Reduce the spin speed, if needed
• Press the button 8
• When the programme has finished the
display shows a blinking . The pilot
light Cgoes off. The door can be
opened.
Turn the programme selector dial to
to switch the machine off.
Remove the laundry from the drum and
carefully check that the drum is empty. If
you do not intend to carry out another
wash, close the water tap. Leave the
door open to prevent the formation of
mildew and unpleasant smells.
Stand by : once the programme has fin-
ished after a few minutes the energy sav-
ing system will be enabled. The bright-
ness of the display is reduced. By press-
ing any button the appliance will come
out of the energy saving status.
10. DAILY USE - DRYING
10.1 Drying only
The recommended load size is 3 kg for
cottons and linen, and 2 kg for synthetic
items.
It is also possible to dry up to 4
kg of cotton items (see the «Dry-
ing Programme » table).
The water tap must be open and the
drain hose must be positioned in the
sink or connected to the drain pipe.
1. Load the laundry.
2. Select a spin cycle at the maximum
spin speed allowed for the type of
laundry in order to obtain the best
drying performances.
3. Set the drying programme for Cot-
tons or Synthetic in the Drying sec-
tor of the programme dial.
4. Press button 6to set the drying
time. Press this button again and
again until the time you want ap-
pears on the display.
For Cottons you can set a drying
time from 10 minutes to 250 minutes
(hours 4.10).
For Synthetic you can select a drying
time from 10 minutes to 130 minutes
(hours 2.10).
Every time you press this button the
drying time increases by 5 minutes.
Note! The programme time will au-
tomatically increase by a few mi-
nutes.
5. Press button 8to start the pro-
gramme.
After the programme has started,
the time remaining is updated every
minute.
If you set only 10 minutes of dry-
ing phase with the timed drying
button, the appliance performs
only a cooling phase.
6. At the end of the drying pro-
gramme, some acoustic signals
sound. A blinking appears on the
display.
The pilot light B, and Cand the light
of the button 8go off.
At this point, begins an anti-crease
phase, which lasts for about 10 mi-
nutes. During this time the light Cis
on. The door cannot be opened.
If you need to open the door be-
fore or during the anti-crease
phase or to interrupt it, press any
button or turn the programme
dial to any programme position
(except O.
The door can be opened after
some minutes. (In any case do
not try to open the door if it is
locked!) .
18 www.aeg.com

7. Turn the selector dial to the Oposi-
tion to switch the machine off.
8. Remove the laundry.
Note!
The different type of cottons (towelling,
sheets, shirts, and so on) or any laundry
items rolling up during the spinning
phase may result in partial dryness.
In the exceptional case that at the end of
the cycle the laundry remains slightly
wet, we suggest that you unfold the rol-
led up items, redistribute them evenly in
the drum and select an additional drying
cycle of 20-30 minutes.
10.2 NON-STOP programme:
Washing and Timed drying
The recommended load size is 3 kg for
cotton and 2 kg for synthetic.
It is also possible to dry up to 4
kg of cotton items (see the «Dry-
ing Programme » table).
CAUTION!
Do not use a dosing device/ball
when carrying out a washing
and drying programme.
1. Load the laundry.
2. Add detergent and fabric softener.
3. Switch the machine on: turn the se-
lector dial to the required washing
programme/fabric.
4. Press the relevant buttons to set the
required options.
If possible, do not set a spin
speed lower than that proposed
by the appliance to avoid too
long a drying time therefore sav-
ing energy. In any case the low-
est values you can select are 900
r.p.m. for cottons and synthetics
and 700 r.p.m. for delicate fab-
rics. The reduction of the spin
speed is only possible after se-
lecting drying.
5. Press the button 6to set the drying
time. When selecting a «non-stop
programme» the pilot lights Aand B
illuminate.
The DRYING TIME value appears on
the display for some seconds, then
the entire duration of the washing
and drying cycle appears.
If you set a washing programme
and only 10 minutes of drying cy-
cle by pressing the button 6, the
total duration of the cycles dis-
played includes also the unroll-
ing and the cooling phase.
6. Press the button 8to start the pro-
gramme. After the programme has
started, the time remaining is upda-
ted every minute.
7. At the end of the programme, follow
the indications given in the previous
chapter. Then, turn the selector to
the Oposition to switch the machine
off.
8. Remove the laundry.
10.3 Fluff in the garments
During the WASHING AND/OR DRYING
PHASE, certain types of fabric, as
sponge-cloth, wool, sweatshirt, could re-
lease fluff.
The released fluff could stick to the fab-
rics during the next cycle.
This drawback increases with technical
fabrics.
To prevent the lint in your clothes, it is
recommended:
• To do not wash dark fabrics after you
washed and dried light colored fabrics
(new sponge, wool, sweatshirt espe-
cially) and vice versa.
• To air-dry this type of fabrics when
they are washed the first time.
• To clean the filter.
• Perform one or more rinse cycles to
wash the drum between the washing
and drying of fabrics with different col-
ors.
• After the drying phase, thoroughly
clean the empty drum, the gasket and
the door with a wet rag.
ENGLISH 19

11. HELPFUL HINTS AND TIPS
11.1 The laundry load
• Divide the laundry in: white, coloured,
synthetics, delicates and wool.
• Obey the washing instructions that are
on the laundry care labels.
• Do not wash together white and col-
oured items.
• Some coloured items can discolour
with the first wash. We recommend
that you wash them separately for the
first times.
• Button up pillowcases, close zippers,
hooks and poppers. Tie up belts.
• Empty the pockets and unfold the
items.
• Turn inside out multilayered fabrics,
wool and items with painted illustra-
tions.
• Remove hard stains.
• Wash with a special detergent heavy
soil stains.
• Be careful with the curtains. Remove
the hooks or put the curtains in a
washing bag or pillowcase.
• Do not wash in the appliance :
– Laundry without hems or with cuts
– Underwired bras.
– Use a washing bag to wash small
items.
• A very small load can cause balance
problems with the spin phase. If this
occurs, adjust manually the items in
the tub and start the spin phase again.
11.2 Stubborn stains
For some stains, water and detergent is
not sufficient.
We recommend that you remove these
stains before you put the items in the
appliance.
Special stain removers are available. Use
the special stain remover that is applica-
ble to the type of stain and fabric.
11.3 Detergents and additives
• Only use detergents and additives
specially made for washing machines.
• Do not mix different types of deter-
gents.
• To help the environment, do not use
more than the correct quantity of de-
tergent.
• Obey the instructions that you find on
the on packaging of these products.
• Use the correct products for the type
and colour of the fabric, the pro-
gramme temperature and the level of
soil.
• If you use liquid detergents, do not set
the prewash phase.
• If your appliance has not the deter-
gent dispenser with the flap device,
add the liquid detergents with a dos-
ing ball.
11.4 Water hardness
If the water hardness in your area is high
or moderate, we recommend that you
use a water softener for washing ma-
chines. In areas where the water hard-
ness is soft it is not necessary to use a
water softener.
To know the water hardness in your area,
contact your local water authority.
Obey the instructions that you find on
the packaging of the products.
Equivalent scales measure the water
hardness:
• German degrees (°dH).
• French degrees (°TH).
• mmol/l (millimol for each litre - inter-
national unit for the hardness of wa-
ter).
• Clarke degrees.
20 www.aeg.com
