AEG LR7BREMEN User manual

USER
MANUAL
EN User Manual
Washing Machine
LR7BREMEN

CONTENTS
1. SAFETY INFORMATION......................................................................................3
2. SAFETY INSTRUCTIONS.................................................................................... 5
3. PRODUCT DESCRIPTION...................................................................................7
4. TECHNICAL DATA............................................................................................... 8
5. INSTALLATION.....................................................................................................8
6. ACCESSORIES.................................................................................................. 12
7. CONTROL PANEL..............................................................................................13
8. DIAL AND BUTTONS......................................................................................... 15
9. PROGRAMMES .................................................................................................17
10. SETTINGS........................................................................................................ 21
11. BEFORE FIRST USE........................................................................................22
12. DAILY USE....................................................................................................... 22
13. HINTS AND TIPS..............................................................................................28
14. CARE AND CLEANING.................................................................................... 29
15. TROUBLESHOOTING......................................................................................34
16. CONSUMPTION VALUES................................................................................37
17. QUICK GUIDE.................................................................................................. 39
18. ENVIRONMENTAL CONCERNS......................................................................40
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler – features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.
Visit our website to:
Get usage advice, brochures, trouble shooter, service and repair information:
www.aeg.com/support
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
www.aeg.com2

1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible for any injuries or damage that are the result
of incorrect installation or usage. Always keep the
instructions in a safe and accessible location for future
reference.
1.1 Children and vulnerable people safety
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
•Children between 3 and 8 years of age and persons
with very extensive and complex disabilities shall be
kept away from the appliance unless continuously
supervised.
•Children of less than 3 years of age should be kept
away from the appliance unless continuously
supervised.
•Children should be supervised to ensure that they do
not play with the appliance.
•Keep all packaging away from children and dispose of
it appropriately.
•Keep detergents away from children.
•Keep children and pets away from the appliance when
the door is open.
•If the appliance has a child safety device, it should be
activated.
•Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
1.2 General Safety
•This appliance is for washing domestic-type, machine-
washable laundry only.
ENGLISH 3

•This appliance is designed for single household
domestic use in an indoor environment.
•This appliance may be used in, offices, hotel guest
rooms, bed & breakfast guest rooms, farm guest
houses and other similar accommodation where such
use does not exceed (average) domestic usage levels.
•Do not change the specification of this appliance.
•The appliance maximum load is 8 kg. Do not exceed
the maximum load of each programme (refer to the
“Programmes” chapter).
•The operating water pressure at the water entry point
from the outlet connection must be between 0.5 bar
(0.05 MPa) and 10 bar (1.0 MPa).
•The ventilation opening in the base must not be
covered by a carpet, mat, or any floor covering.
•The appliance must be connected to the water mains
using the new supplied hose sets, or other new hose
sets supplied by the Authorised Service Centre.
•Old hose sets must not be reused.
•If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
•Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the
socket.
•Do not use high pressure water sprays and/or steam
to clean the appliance.
•Clean the appliance with a moist cloth. Use only
neutral detergents. Do not use abrasive products,
abrasive cleaning pads, solvents or metal objects.
•If a tumble dryer is stacked on the top of the washing
machine, make sure to use the correct stacking kit
approved by AEG (see more details in chapter
"Accessories - Stacking kit").
www.aeg.com4

2. SAFETY INSTRUCTIONS
2.1 Installation
The installation must comply
with relevant national
regulations.
• Remove all the packaging and the
transit bolts including rubber bush
with plastic spacer.
• Keep the transit bolts in a safe place.
If the appliance is to be moved in the
future they must be reattached to lock
the drum to prevent an internal
damage.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Follow the installation instructions
supplied with the appliance.
• Do not install or use a damaged
appliance.
• Do not install or use the appliance
where the temperature can be less
than 0°C or where it is exposed to the
weather.
• The floor area on which the appliance
is to be installed must be flat, stable,
heat resistant and clean.
• Make sure that there is air circulation
between the appliance and the floor.
• When the appliance is in its
permanent position, check if it is
levelled correctly with the aid of a
spirit level. If it is not, adjust the feet
accordingly.
• Do not install the appliance directly
above a floor drain.
• Do not spray water on the appliance
and do not expose it to excessive
humidity.
• Do not install the appliance where the
appliance door cannot be fully
opened.
• Do not put a closed container to
collect possible water leakage under
the appliance. Contact the Authorised
Service Centre to ensure which
accessories can be used.
2.2 Electrical connection
WARNING!
Risk of fire and electric
shock.
• WARNING: This appliance is
designed to be installed / connected
to a grounding connection in the
building.
• Always use a correctly installed
shockproof socket.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need to
be replaced, this must be carried out
by our Authorised Service Centre.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• Do not touch the mains cable or the
mains plug with wet hands.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
2.3 Water connection
• The inlet water shall not exceed
25 °C.
• Do not cause damage to the water
hoses.
• Before connection to new pipes, pipes
not used for a long time, where repair
work has been carried out or new
devices fitted (water meters, etc.), let
the water flow until it is clean and
clear.
• Ensure that there are no visible water
leaks during and after the first use of
the appliance.
• Do not use an extension hose if the
inlet hose is too short. Contact the
Authorised Service Centre for the
replacement of the inlet hose.
ENGLISH 5

• When unpacking the appliance, It is
possible to see water flowing from the
drain hose. This is due to the testing
of the appliance with the use of water
in the factory.
• You can extend the drain hose to
maximum 400 cm. Contact the
Authorised Service Centre for the
other drain hose and the extension.
• Make sure that there is access to the
tap after the installation.
2.4 Use
WARNING!
Risk of injury, electric shock,
fire, burns or damage to the
appliance.
• Follow the safety instructions on the
detergent packaging.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Do not wash fabrics which are heavily
soiled with oil, grease or other greasy
substances. It can damage rubber
parts of the washing machine.
Prewash such fabrics by hand before
loading them into the washing
machine.
• Do not touch the glass door while a
programme operates. The glass can
get hot.
• Make sure that all metal objects are
removed from the laundry.
2.5 Service
• To repair the appliance contact the
Authorised Service Centre. Use
original spare parts only.
• Please note that self-repair or non-
professional repair can have safety
consequences and might void the
guarantee.
• The following spare parts will be
available for 10 years after the model
has been discontinued: motor and
motor brushes, transmission between
motor and drum, pumps, shock
absorbers and springs, washing drum,
drum spider and related ball bearings,
heaters and heating elements,
including heat pumps, piping and
related equipment including hoses,
valves, filters and aquastops, printed
circuit boards, electronic displays,
pressure switches, thermostats and
sensors, software and firmware
including reset software, door, door
hinge and seals, other seals, door
locking assembly, plastic peripherals
such as detergent dispensers. Please
note that some of these spare parts
are only available to professional
repairers, and that not all spare parts
are relevant for all models.
• Concerning the lamp(s) inside this
product and spare part lamps sold
separately: These lamps are intended
to withstand extreme physical
conditions in household appliances,
such as temperature, vibration,
humidity, or are intended to signal
information about the operational
status of the appliance. They are not
intended to be used in other
applications and are not suitable for
household room illumination.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains electrical and water supplies.
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
• Remove the door catch to prevent
children or pets from becoming
trapped in the drum.
• Dispose of the appliance in
accordance with local requirements
for the disposal of Waste Electrical
and Electronic Equipment (WEEE).
www.aeg.com6

3. PRODUCT DESCRIPTION
3.1 Special features
Your new washing machine meets all
modern requirements for an effective
treatment of laundry with low water,
energy and detergent consumption and
proper care of fabric.
• The ProSense technology detects
the laundry load size defining the
programme duration in 30 seconds.
The washing programme is tailored to
the laundry load and the type of fabric
without consuming more time, energy
and water than necessary.
• The steam has a quick and easy way
to refresh the clothes. The gentle
steam programmes remove odours
and reduce creases in dry fabrics so
they need little ironing.
The Plus Steam option, finishes
every cycle with gentle steam that
relaxes the fibres and reduces fabric
creasing. Ironing will be easier!
• The AEG Steam Fragrance, thanks
to the steam programmes offers the
perfect solution for refreshing even
the most delicate garments without
washing. Use the delicate fragrance
exclusively developed by AEG to add
a pleasant feeling of "just-washed"
garment to the removing odours and
wrinkles action.
3.2 Fixing plate kit
If you install the appliance on a plinth
that is not an accessory supplied by
AEG, secure the appliance in the fixing
plates.
Read carefully the instructions supplied
with the accessory.
3.3 Appliance overview
1
1 2 3 9
5
6
7
4
10
8
11 12
1Worktop
2Detergent dispenser
3Control panel
4Door handle
5Rating plate
6Drain pump filter
7Feet for levelling the appliance
8Drain hose
9Inlet hose connection
10 Mains cable
11 Transit bolts
12 Hose support
ENGLISH 7

00000000
00A
Mod. xxxxxxxxx
000V ~ 00Hz 0000 W
910000000 00
A
B
C
Prod.No.
D
The rating plate reports the model name
(A), product number (B), electrical ratings
(C) and serial number (D).
4. TECHNICAL DATA
Dimension Width/ Height/ Total depth 59,6 cm /84,7 cm /60,2 cm
Electrical connection Voltage
Overall power
Fuse
Frequency
230 V
2000 W
10 A
50 Hz
Level of protection against ingress of solid particles and
moisture ensured by the protective cover, except where
the low voltage equipment has no protection against mois‐
ture
IPX4
Water supply pressure Minimum
Maximum
0.5 bar (0.05 MPa)
10 bar (1.0 MPa)
Water supply 1) Cold water
Maximum Load Cotton 8 kg
Spin Speed Maximum spin speed 1600 rpm
1) Connect the water inlet hose to a water tap with a 3/4'' thread.
5. INSTALLATION
WARNING!
Refer to Safety chapters.
5.1 Unpacking
1. Open the door. Remove all the items
from the drum.
Accessories delivered
with the appliance may
vary depending on the
model.
2. Put the packaging element on the
floor behind the appliance and
carefully put it down onto its rear
side. Remove the polystyrene
protection from the bottom.
1
2
www.aeg.com8

CAUTION!
Do not lay washing machine
on its front.
3. Put the appliance back into an
upright position. Remove the power
supply cable and the drain hose from
the hose holders.
WARNING!
It is possible to see
water flowing from the
drain hose. This is
because the washing
machine has been
tested at the factory.
4. Remove the three bolts by using the
key supplied with the appliance. Pull
out the plastic spacers.
We recommend that you
keep the packaging and
the transit bolts for any
transport of the appliance.
5. Put the plastic caps, that you find in
the user manual bag, in the holes.
5.2 Positioning and levelling
1. Install the appliance on a flat hard
floor.
Make sure that carpets do
not stop the air circulation
below the appliance.
Make sure that the appliance
does not touch the wall or
other units.
2. Loosen or tighten the feet to adjust
the level.
WARNING!
Do not put cardboard, wood
or equivalent materials
below the appliance feet to
adjust the level.
x4
The appliance must be level and stable.
A correct adjustment of the
appliance level prevents the
vibration, noise and the
movement of the appliance
when in operation.
ENGLISH 9

When the appliance is
installed on a plinth or a
tumble dryer is stacked on
the washing machine, use
the accessories described in
chapter 'Accessories'. Read
carefully the instructions
supplied with the appliance
and with the accessory.
5.3 The inlet hose
1. Connect the water inlet hose to the
back of the appliance.
2. Position it toward left or right
depending on the position of the
water tap.
20º20º
45º45º
Make sure that the inlet hose
is not in vertical position.
3. If necessary, loose the ring nut to set
it in the correct position.
4. Connect the water inlet hose to the
cold water tap with 3/4" thread.
WARNING!
The inlet water shall not
exceed 25 °C.
CAUTION!
Make sure that there are no
leaks from the couplings.
Do not use an extension
hose if the inlet hose is too
short. Contact the service
centre for the replacement of
the inlet hose.
5.4 Water-stop device
The inlet hose has a water stop device.
This device prevents water leaks in the
hose because of its natural ageing.
The red sector in the window «A» shows
this fault.
A
If this occurs, close the water tap and
contact the authorized service centre to
replace the hose.
5.5 Water drainage
The drain hose should be positioned at a
height of not less than 60 cm and not
more than 100 cm from the floor.
www.aeg.com10

You can extend the drain
hose to maximum 400 cm.
Contact the authorized
service centre for the other
drain hose and the
extension.
It is possible to connect the drain hose in
different ways:
1. Make a U shape with the drain hose
and put it around the plastic hose
guide.
2. On the edge of a sink - Fasten the
guide to the water tap or to the wall.
Make sure that the plastic
guide cannot move when the
appliance drains.
Make sure that the drain
hose end is not immersed in
the water. There may be a
return of dirty water into the
appliance.
3. To a stand pipe with vent-hole -
Insert the drain hose directly into a
drain pipe. Refer to the illustration.
The end of the drain hose
must always be ventilated ,
i.e. the inner diameter of the
drain pipe (min. 38 mm -
min. 1.5") must be larger
than the external diameter of
the drain hose.
4. If the end of the drain hose looks like
this (see the picture), you can push it
directly into the stand pipe.
5. Without the plastic hose guide, to
a sink spigot - Put the drain hose in
the spigot and tighten it with a clamp.
Refer to the illustration.
Make sure that the drain
hose makes a loop to
prevent particles going into
the appliance from the sink.
6. Position the hose directly to a built-
in drain pipe in the room wall and
tighten it with a clamp.
ENGLISH 11

5.6 Electrical connection
At the end of installation you can connect
the mains plug to the mains socket.
The rating plate on the inner edge of the
appliance door and the 'Technical Data'
chapter indicate the necessary electrical
ratings. Make sure that they are
compatible with the mains power supply.
Check that your domestic electrical
installation can take the maximum load
required, also taking into account any
other appliances in use.
Connect the appliance to an earthed
socket.
The power supply cable must be easily
accessible after installing the appliance.
For any electrical work required to install
this appliance, contact our Authorised
Service Centre.
The manufacturer does not accept any
responsibility for damage or injury
through failure to comply with the above
safety precaution.
6. ACCESSORIES
6.1 Available in
www.aeg.com/shop or from
authorised dealer
Read carefully the instructions supplied
with the accessory.
Only appropriate
accessories approved by
AEG ensure the safety
standards of the appliance. If
unapproved parts are used,
any claims will be
invalidated.
6.2 Stacking kit
The tumble dryer can be stacked on the
top of the washing machine only by
using the correct stacking kit.
WARNING!
Do not put the tumble dryer
under the washing machine.
Verify the compatible
stacking kit by checking the
depth of your appliances.
www.aeg.com12

7. CONTROL PANEL
7.1 Control panel description
23
6
12 11 10 8
1
4
5
7
9
1Programme dial
2Display
3Tijd besparen touch button
4Startuitstel touch button
5Extra skipping touch button
• Alleen spoelen option
• Centrifugeren/Pompen option
6Start/Pauze touch button
7Vlekken/Voorwas skipping touch
button
8Plus Steam touch button
9Extra spoelen touch button
10 Centrifug. reduction touch button
11 Temperatuur touch button
12 Aan/Uit push button
7.2 Display
Door locked indicator.
Washing phase indicator. It flashes during prewash and wash phase.
ENGLISH 13

Rinsing phase indicator. It flashes during rinse phase.
Spinning and draining phase indicator. It flashes during spin and drain
phase.
Anti-crease phase indicator.
Read the paragraph Plus Steam for more details.
Steam phase indicator.
The digital indicator can show:
• Programme duration (e. g. ).
• Delay time (e. g. or ).
• Cycle end ( ).
• Warning code ( ).
• Indication of total operating hours of the appliance. Refer to the 'Op‐
erating hours counter' section in the 'Settings' paragraph for more
details.
The indicator flashes during the laundry load estimation.
Maximum laundry indicator. It flashes when the laundry load exceeds
the maximum declared load of the selected programme.
Time saving indicator.
Delay start indicator.
Drum clean indicator. Refer to the 'Cleaning the drum' section in the
'Care and cleaning' paragraph for more details.
The Temperature area:
Temperature indicator
Cold water indicator
Extra silent indicator.
Rinse hold indicator.
The spin area:
Spin speed indicator
No Spin indicator. Spin phase is off.
Pre-wash indicator.
Stain indicator.
Child safety lock indicator.
www.aeg.com14

8. DIAL AND BUTTONS
8.1 Aan/Uit
Pressing this button for a few seconds
allows to activate or deactivate the
appliance. Two different tunes sound
while switching the appliance on or off.
As the Stand-by function automatically
deactivates the appliance to decrease
the energy consumption in a few cases,
you may need to activate the appliance
again.
For more details, refer to Stand-by
paragraph in Daily Use chapter.
8.2 Introduction
The options/functions are
not selectable with all
washing programmes.
Check the compatibility
between options/functions
and washing programmes in
the "Programme Chart". An
option/function can exclude
another one, in this case the
appliance doesn't allow you
to set the incompatible
options/functions together.
Make sure the screen and
touch buttons are always
clean and dry.
8.3 Temperatuur
When you select a washing programme,
the appliance automatically proposes a
default temperature.
Touch this button repeatedly until the
desired temperature value appears on
the display.
When the display shows the indicators
and , the appliance does not heat
the water.
8.4 Centrifug.
When you set a programme, the
appliance automatically sets the default
spin speed.
Touch repeatedly this button to:
•Decrease the spin speed.
The display shows only
the spin speeds available
for the set programme.
•Activate the Rinse Hold option.
The final spin is not performed. The
water of the last rinse is not drained
out to prevent the fabrics from
creasing. The washing programme
ends with water in the drum.
The display shows the indicator .
The door stays locked and the drum
turns regularly to reduce creasing.
You must drain the water to unlock
the door.
If you touch the Start/Pauze button,
the appliance performs the spinning
phase and drains the water.
The appliance empties
the water out
automatically after 18
hours approximately.
•Activate the Extra Silent option.
The intermediate and the final
spinning phases are suppressed and
the programme ends with water in the
drum. This helps to reduce creasing.
The display shows the indicator .
The door stays locked. The drum
turns regularly to reduce creasing.
You must drain the water to unlock
the door.
As the programme is very quiet, it is
suitable for use at night time when
cheaper electricity tariffs are
available. In some programmes the
rinses are performed with more water.
If you touch the Start/Pauze button,
the appliance performs the only
draining phase.
The appliance empties
the water out
automatically after 18
hours approximately.
8.5 Vlekken/Voorwas
Press this button repeatedly to activate
one of the two options.
The relevant indicator goes on in the
display.
ENGLISH 15

•Vlekken
Select this option to add an anti-stain
phase to a programme in order to
treat heavily soiled or stained laundry
with stain remover.
Pour the stain remover into
compartment . The stain remover
will be added in the appropriate phase
of the washing programme.
This option is not
available with a
temperature lower than
40 °C.
•Voorwas
Use this option to add a pre-wash
phase at 30 °C before the washing
phase.
This option is recommended for
heavily soiled laundry, especially if
containing sand, dust , mud and other
solid particles.
The options can increase the
programme duration.
8.6 Extra
With this button you can select one of the
following options:
•Skipping wash phase - Alleen
spoelen option
The appliance performs only the
rinsing phase, the spinning and the
draining phases of the selected
programme. When this option is set
the washing phase is not performed.
•Centrifugeren/Pompen option
The appliance performs only final
spinning or only draining phase of
selected programme. By selecting No
Spin option via Centrifug.
button only Drain cycle can be
configured.
The corresponding indicator above the
touch button illuminates.
8.7 Extra spoelen
With this option you can add a few rinses
according to the selected washing
programme.
Use this option for people with allergies
to detergent residues and with sensitive
skin.
This option increases the
programme duration.
The related indicator comes on.
8.8 Plus Steam
This option adds a steam phase followed
by a short anti-crease phase at the end
of the washing programme. The steam
phase reduces fabric creasing and
facilitates the fabric ironing.
The drum performs smooth movements
for about 30 minutes. The duration of the
steam phase changes accordingly to the
selection. When Plus Steam option is set
the programme ends up with an
anticrease phase during which the drum
is occasionally rotated to prevent
wrinkling. The display shows the
indicator is steady on and the
indicator starts flashing. Start/Pauze
button is lit as well. At the end of the
anticrease phase the drum definitely
stops, the indicator goes off, the door
unlocks. User at any moment can
terminate the anticrease phase by:
• pressing the Aan/Uit button for a few
seconds to activate or deactivate the
appliance;
• turning the selector knob to another
position.
A small laundry load helps to
reach better results.
8.9 Tijd besparen
With this option you can decrease the
programme duration.
• If your laundry is normally or lightly
soiled, it may be advisable to shorten
the washing programme. Touch this
button once to decrease the duration.
• In case of smaller load, touch this
button twice to set an extra quick
programme.
The display shows the indicator .
www.aeg.com16

This option can also be used
to shorten the Plus Steam
programme duration.
8.10 Startuitstel
With this option you can delay the start of
a programme in a more convenient time.
Touch the button repeatedly to set the
required delay. The time increases by
steps of 30 minutes up to 90' and from 2
hours up to 20 h.
After touching the Start/Pauze button,
the display shows the indicator and
the selected delay time and the
appliance begins the countdown.
8.11 Start/Pauze
Touch the Start/Pauze button to start,
pause the appliance or interrupt a
running programme.
9. PROGRAMMES
9.1 Programme Chart
Washing programmes
Programme Programme description
MixLoad 69min Cotton and mixed synthetic fabrics. Ideal to wash your daily load in
a short time, for a better clothes care and good cleaning already at
30°C.
Eco 40-60 Low energy cycle for cottons. Decreases temperature and extends
time to reach good washing results.
Katoen White and coloured cotton fabrics. Ideal for normal and heavy soil.
Synthetica Synthetic items or mixed fabric items. Normal soil.
Fijne was Delicate fabrics such as acrylics, viscose and mixed fabrics requir‐
ing gentler washing. Normal soil.
Wol Machine washable wool, hand washable wool and other fabrics with
«hand washing» care symbol1).
20 min. - 3 kg Cotton and synthetic items lightly soiled or worn only once.
Stoom Cotton, synthetic and mixed items. Special steam cycle without
washing that can be used to prepare your dried laundry for ironing
or refreshing garments worn once. This programme reduces crea‐
ses, odours and relaxes the fibres. Do not use any detergent.
When the programme is completed, quickly remove the laundry
from the drum2). If necessary, remove stains by washing or using lo‐
calized stain removal. Steam programmes do not perform any hy‐
gienic cycle. Do not set a Steam programme with these types of
items:
• Items that are not suitable for tumble drying.
• Items with label "Dry clean only".
ENGLISH 17

Programme Programme description
Hygiëne White cotton items. This high-performance wash programme com‐
bined with steam vapour, removes more than 99,99% of bacteria
and viruses3) keeping the temperature above 60°C throughout the
washing phase; with an additional action on the fibers thanks to a
vapour phase, an enhanced rinsing phase ensures a proper remov‐
al of detergent and micro-organism residues. This programme en‐
sures also a proper reduction of pollens/allergenic items.
Machine clean Maintenance cycle with hot water to clean and freshen the drum and
to remove residue that may cause odour. Before running this cycle,
remove all items from the drum. In the washing phase compartment
of the detergent dispenser, put the flap of the compartment in up‐
ward position. Pour a cup of chlorine bleach or a washing machine
cleaner in the washing phase compartment of the detergent dis‐
penser. DO NOT use both together4).
1) During this cycle the drum rotates slowly to ensure a gentle wash. It can seem that the drum doesn't
rotate or doesn't rotate properly, but this is normal for this programme.
2) If you set a Steam programme with dried laundry, at the end of the cycle the laundry can be humid.
Line dry the items for about 10 minutes. This programme does not remove particularly intense odour.
3) Tested for Staphylococcus aureus, Enterococcus faecium, Candida albicans, Pseudomonas aerugino‐
sa and MS2 Bacteriophage in external test performed by Swissatest Testmaterialien AG in 2021 (Test
Report No. 202120117).
4) After the drum cleaning, run a further rinse cycle with empty drum and no detergent to remove any
residue of bleach.
Programme temperature, maximum spin speed and maximum load
Programme
Default tempera‐
ture
Temperature
range
Reference spin
speed
Spin speed range
Maximum load
MixLoad 69min 30 °C
60 °C - 30 °C
1600 rpm
1600 rpm - 400 rpm 5 kg
Eco 40-60 40 °C 1) 1600 rpm
1600 rpm - 400 rpm 8 kg
Katoen 40 °C
95 °C - Cold
1600 rpm
1600 rpm - 400 rpm 8 kg
Synthetica 40 °C
60 °C - Cold
1200 rpm
1200 rpm - 400 rpm 3 kg
Fijne was 30 °C
40 °C - Cold
1200 rpm
1200 rpm - 400 rpm 2 kg
Wol 40 °C
40 °C - Cold
1200 rpm
1200 rpm - 400 rpm 1,5 kg
www.aeg.com18

Programme
Default tempera‐
ture
Temperature
range
Reference spin
speed
Spin speed range
Maximum load
20 min. - 3 kg 30 °C
40 °C - 30 °C
1200 rpm
1200 rpm - 400 rpm 3 kg
Stoom - - 1 kg
Hygiëne 60 °C 1600 rpm
1600 rpm - 400 rpm 8 kg
Machine clean 60 °C 1200 rpm
1200 rpm - 400 rpm -
1) According to Commission Regulation EU 2019/2023, this programme at 40 °C is able to clean normal‐
ly soiled cotton laundry declared to be washable at 40 °C or 60 °C, together in the same cycle.
For the reached temperature in the laundry, the programme duration and other data,
please refer to 'Consumption Values' chapter.
The most efficient programmes in terms of energy consumption are generally those that
perform at lower temperatures and longer duration.
Programme options compatibility
OPTIONS
PROGRAMME
MixLoad 69min
Eco 40-60
Katoen
Synthetica
Fijne was
Wol
20 min. - 3 kg
Stoom
Hygiëne
Machine clean
Centrifug. ■ ■ ■ ■ ■ ■ ■ ■ ■
■ ■ ■ ■ ■ ■ ■
■ ■ ■
Vlekken 1) ■ ■ ■
Voorwas ■ ■ ■
Alleen spoelen ■ ■ ■ ■ ■ ■ ■
Centrifugeren/
Pompen ■ ■ ■ ■ ■ ■ ■
Extra spoelen ■ ■ ■ ■ ■
Plus Steam 1) ■ ■ ■
ENGLISH 19

OPTIONS
PROGRAMME
MixLoad 69min
Eco 40-60
Katoen
Synthetica
Fijne was
Wol
20 min. - 3 kg
Stoom
Hygiëne
Machine clean
Tijd besparen 2) ■ ■ ■ ■
Startuitstel ■ ■ ■ ■ ■ ■ ■ ■ ■ ■
1) This option is not available with temperature lower than 40 °C.
2) If you set the shortest duration, we recommend that you decrease the load size. It is possible to fully
load the appliance, however the washing results can be less satisfactory.
Suitable detergents for washing programmes
Programme Universal
powder1)
Liquid Uni‐
versal
Liquid for
coloureds
Delicates
woollens Special
MixLoad 69min -- ▲ ▲ -- --
Eco 40-60 ▲ ▲ ▲ -- --
Katoen ▲ ▲ ▲ -- --
Synthetica ▲ ▲ ▲ -- --
Fijne was -- -- -- ▲ ▲
Wol -- -- -- ▲ ▲
20 min. - 3 kg -- ▲ ▲ -- --
Hygiëne ▲ ▲ -- -- ▲
1) At temperature higher than 60 °C the use of powder detergent is recommended.
▲ = Recommended
-- = Not recommended
9.2 Stoom programme
with AEG Steam Fragrance
Available in www.aeg.com/shop .
Steam programmes can be used for
reducing wrinkles and odours of
garments that just need to be refreshed,
avoiding washing. Steam programme
doesn't remove particularly intense
odour.
The fabric fibres are relaxed and
afterwards ironing becomes effortless.
When the programme is completed,
quickly remove the laundry from the
drum. Steam programme does not
perform any hygienic cycle. Do not set a
steam programme with the following type
of items:
• Items that are not suitable for tumble
drying.
• Items with label "Dry clean only".
www.aeg.com20
