MODEL 50027-10
150 PSI BOOSTER PUMP KIT
10 NOZZLE NYLON TUBE SYSTEM
Installation Instructions

Outlet
Inlet
The Aero Mist 150 PSI Pump takes ordinary home water pressure which is normally
about 50-70 PSI for most homes and “boosts” it up to 150 PSI. The higher water pres-
sure created by the pump enhances mist cooling and heat absorpon in two ways.
First, it produces a higher ow of water through the nozzle. More water being ex-
pelled from the nozzle means more cooling. Second, it creates a smaller ner mist
droplet which allows the droplet to evaporate more quickly. Beer evaporaon
means beer cooling.
There are many applicaons for 150 PSI Booster Pump Kit by Aero Mist. Applicaons
include, Pao Cooling for Homes and Restaurants, Greenhouses, Humidicaon, Dust
control, Odor control and many more.
Cauon, Warning and Safety Instrucons:
1. Outdoor use ONLY! Not for use indoors
2. Install pump in a suitable place to prevent property damage in the event a leak
should occur.
3. Turn water o and disconnect power to the unit when not in use for extended
periods of me.
4. Plug pump into 110 volt GFCI protected outlet.
5. Do not place pump in or in damp or wet environments.
6. Feed system with potable cold water supply only. Do not connect pump to hot
water supply.
7. Do not expose pump to freezing temperatures. When winterizing disconnect
pump from power and water supply and store in a dry safe place. Make sure all
water is drained from the system to prevent damage in the event of a freeze.
Operaon Overview
Item ID Item Descripon Qty.
50027 Misng Pump 150 PSI 120 Volt 1.
52014 Misng Nozzle 10/24 x .014 10
52505 Calcium Inhibitor Filter 1
52345 1/4"x3/8" Plasc Male Adapter 1
26102 Hose Adapter 3/4" x 3/8" 1
52340 1/4" Plasc Nozzle Union 10
56425-75 1/4" Nylon Tubing 75Ft Roll LP 1
52329 1/4" Push Lock End Plug 1
65186 Mini Tube Cuer 1
56374 Coated Clamp 1/4" 15
52602 Screw 15
52603 Plasc Anchor 15
LIST OF ALL ENCLOSED PARTS
1. Mount pump on wall in an outdoor locaon that is not in a not a damp or wet
environment.
2. Verify 110 Volt power supply is GFIC protected.
3. Verify water feed to pump locaon is potable cold water supply only.
4. Connect cold water feed to pump inlet and connect nylon tubing to pump outlet.
5. Proper installaon of the mist line requires mounng the nylon tubing around the
boom outside edge of the fascia, header or beam of the pao structure.
Properly installed mist lines create a curtain of mist around the open air sides of
the pao which cools the air as it enters the pao. Nozzles should be placed two
feet apart and should spray out into the open air. Do not install nozzles where
the spray may hit the pao, structure or surrounding objects as water damage
can occur. You will want to keep nozzles 12” to 18” inches away from columns,
structures and windows.
6. This system uses quick connect style ngs. Simply, cut the tubing at the desired
point and push and twist the ng on to the end of the tubing. Check to see the
ng is secure by gently pulling on the nylon tubing to make sure it is secure.
7. To release the tubing from the ng you can us your hands or place a wrench
over the tubing where it goes into the ng and press the collar of the ng
back against the body of the ng a pull the tubing free.
8. Before installing the nozzles in the system ush system by turning the pump on
and run water through the system without nozzles to expel any debris that may
have entered into the line during installaon.
9. While the system is ushing, begin installing the nozzles. Hand ghten nozzles.
Start by installing the nozzles in the ngs closest to the pump rst and work
your way back to the end of the mist line. Note: you will need the turn the pump
o when you get to the last 2-3 nozzles.
INSTALLATION INSTRUCTIONS
