AFC 401-A017 User manual

1
WIRING DIAGRAM BY MODEL
This document describes car models to which the AFC neo (Product code:
401-A017) is applicable, and ECU terminal arrangement drawings. For the
operating method and precautions for the AFC neo, refer to the Instruction
Manual.
When installing the AFC neo, both this document and the Instruction Manual
are required.
Even if the car model and manufacturing year coincide with the contents de-
scribed in this document, this product may not be installed in certain specifica-
tion vehicles or remodeled vehicles.
The manufacturing years of applicable vehicles are as of February, 2006. For
the latest vehicles applications, Please contact your local APEXERA Office or
dealer for more information. 

2
！
！
目次

Safety Precautions
Safety messages and their meanings 3
WARNING  3
CAUTION 4
REQUEST  4
Installation
Connection  5
Connection diagram 6
ECU layout  8
Viewing ECU pin layout  9

ＴＯＹＯＴＡ      
Table of Applicable Models......................................................................... 10
ECU Terminal Arrangement Table.............................................................. 18

ＮＩＳＳＡＮ
Table of Applicable Models......................................................................... 23
ECU Terminal Arrangement Table.............................................................. 28

ＨＯＮＤＡ
Table of Applicable Models......................................................................... 31
ECU Terminal Arrangement Table.............................................................. 36

ＭＩＴＳＵＢＩＳＨＩ      
Table of Applicable Models......................................................................... 41
ECU Terminal Arrangement Table.............................................................. 43

ＭＡＺＤＡ
Table of Applicable Models......................................................................... 44
ECU Terminal Arrangement Table.............................................................. 46

ＳＵＢＡＲＵ      
Table of Applicable Models......................................................................... 48
ECU Terminal Arrangement Table.............................................................. 50

ＳＵＺＵＫＩ
Table of Applicable Models......................................................................... 52
ECU Terminal Arrangement Table.............................................................. 54

ＤＡＩＨＡＴＳＵ      
Table of Applicable Models......................................................................... 56
ECU Terminal Arrangement Table.............................................................. 57

3
Safety Precautions
Please read "Safety Precautions" carefully to operate the product with safety.
WARNING
！
This indicates the existence of potential hazard that may result in death
or serious injury of the operator or a third persons if the product is
wrongly operated in disregard of this indication.
Safety messages and their meanings
CAUTION
！
This indicates the existence of potential hazard that may result in injury to
the operator or a third persons, and that will result in only physical dam-
age if the product is wrongly operated in disregard of this indication.
REQUEST
WARNING
！
□Be sure to remove the negative terminal of the battery before
working on wiring
Do not work on wiring with the battery connected. This may cause a
fire, electric shock, or other failures. In this case, we shall disclaim all
responsibility for any damage or loss to the customer and third persons. 

□Do not use this product for any application other than applicable
vehicles or applicable goods.
We will not guarantee any operation in vehicles other than indicated in
this manual. Such an operation may cause an accident, fire or other failures.
 
□ Do not install this product in an unstable place that may interfere with driving 
This may interfere with driving, resulting in a traffic accident.

□Do not tamper, disassemble, or modify this product.
This may cause an accident, fire, electric shock, or damage.
This indicates the contents of a failure in obtaining the full performance of the
product or a product failure or faulty function item if the product is wrongly oper-
ated in disregard of this indication.
Safety Precautions

4
CAUTION
！
□Do not use an Electro-Tap
This may cause a malfunction or failure. Be sure to secure a connection
with the accessory plug and splicer.
□Insulate connections and unused harnesses
If a connection or unused harness touches your body, a fire, electric
shock, or other failures may occur.
□ Do not run a harness around hot, humid, and movable areas of a vehicle
This may cause a malfunction, fire, or other failures.
□ If you feel that the product is abnormal, stop operating it immediately
If this product gives out smoke or offensive smell, stop operating the
product immediately and notify the office that is indicated on the back
cover of this manual.
REQUEST
Regarding the installation of this product, be sure that it is installed by an
experienced professional. After the product is installed, hand this
manual, instruction manual, and warranty to the customer (user).

To remove the connector, hold it without pulling on its harness.
Also use the connector without exposing its harness to excessive forc e. 

This product may cause noise interference with radio, TV, etc.
depending on the mounting location and the routing of the signal harness. 

5
□Connecting the plug
Installation
Before installing this product, be sure to remove the negative terminal of the battery. 
Connection
□Insulating a splice
1, Peel off the coating of
the wires about 5 [mm] 2, Cover with a
sleeve 3, Fold the wires 4, Caulk securely
Caulk the coating
by these portions
Caulk the
conductors
by these
portions
Make the caulking
thrust into the wire
5, be sure to cover the connection with electrical tape
1, Remove 5 [mm]
of the wire cover
fromthe
connecting wire
2, Strip 10 [mm]
from the other
connection wire
3, Wrap the two
wires together4, Securely
fasten together
other connection wire
Make the caulking thrust
into the wire

Please move the
sleeve to the caulked
position when finished
the caulking.

6
□Vehicle with hot wire, flap, and pressure sensor
Connection diagram
Vehicle harness
Red wire: Power supply
Green wire: rpm signal
Red and white wire: Power supply
Gray wire: Throttle signal
Brown wire: Grounding
Black wire:
Grounding
Yellow wire:
Airflow and pressure signal output
White wire: Airflow and pressure signal input
Engine control
computer
(ECU)
Vehicle harness
Yellow wire: Airflow signal output
White wire:
Airflow signal input1
Blue wire: Airflow signal input2
Branching harness ※
□Vehicle with RB26DETT
Orange wire: Illumination power
Orange wire: Illumination power
CAUTION
！
To illumination power
for audio, etc.
To illumination power
for audio, etc.
splice
Plug 
Plug receptacle
Engine control
computer
(ECU)
Insulate connections and the ends of unused harnesses; otherwise
a fire electric shock or damage to electrical equipment may occur.

※to be worked on separately
Red wire: Power supply
Green wire: rpm signal
Red and white wire: Power supply
Gray wire: Throttle signal
Brown wire: Grounding
Black wire:
Grounding

7
□Vehicle with Karman turbo sensor
Connection diagram
□Vehicle with VTEC
Vehicle harness
Vehicle harness
※②Some vehicles do not have VTM signals.
To illumination power
for audio, etc.
Engine control
computer
(ECU)
Engine control
computer
(ECU)
CAUTION
！
Insulate connections and the ends of unused harnesses; otherwise
a fire electric shock or damage to electrical equipment may occur.

Brown and white wire: Karman signal output
Black and white wire: Karman signal input
Orange wire: Illumination power
To illumination power
for audio, etc.
Yellow wire:
Airflow and pressure signal output
White wire: Airflow and pressure signal input
Pink wire: VTEC signal output
Orange wire: Illumination power
Light green wire: VTM signal (※②)
Purple wire:
VTEC signal input
splice
Plug 
Plug receptacle
Red wire: Power supply
Green wire: rpm signal
Red and white wire: Power supply
Gray wire: Throttle signal
Brown wire: Grounding
Black wire:
Grounding
Red wire:
Power supply
Green wire: rpm signal
Red and white wire: Power supply
Gray wire: Throttle signal
Brown wire: Grounding
Black wire:
Grounding
※①
※①Unconnection, Insulate

8
Ａ
Ｂ Ｃ Ｄ
Ｅ Ｆ
Ｇ
Ｈ Ｉ
Ｊ
Ｋ
Ｐ
Ｌ
Ｍ
Ｎ
Ｏ
□For details on working on the ECU, see symbols in the location column of
the applicable vehicle list from page 10
ECU layout
A:Lower part of the passenger seat dash side
B:Right side of the glove box
C:Foot position of the passenger seat
D:Inner part of the glove box
E:Inner part of the center console
F:Under the driver’s seat
G:Under the passenger seat
H:Near the steering column
I
 :Left side of the meter panel
J
 :Lower part of the driver’s seat dash side
K:Left side of the center console
L
 :Engine room
M:Before the rear trunk
N:Behind after the driver’s seat
O:Behind the passenger seat
P:Upper inner part of the center console

9
The ECU pin layout shows the connectors viewed in the direction
of the arrow mark.
The orientation of the ECU depends on the vehicle with ECU pins.
Install the ECU fully checking the shape of each connector and
the number of pins.
Viewing ECU pin layout

10
ＨＷ−ＨｏｔＷｉｒｅ  ＦＬ−Ｆｌａｐ
ＰＲ−Ｐｒｅｓｓｕｒｅ  ＫＲ−Ｋａｒｍａｎ
Table of Applicable Models (TOYOTA)
Car NameCar ModelEngine
ModelManufacturing year ECU PositionTerminal DrawingSensor TypeRemarks
CELCIOR
ＵＣＦ２＃
１ＵＺ−ＦＥ
’９７.７〜‘００.７ Ｌ Ｔ１０−ｅ ＨＷ−１３ 
‘９４.１０〜‘９７.６
Ｄ Ｔ８−ａ ＨＷ−１２ 
ＵＣＦ１＃ ‘９２.9〜‘９４.９ ＫＲ 
‘８９.１０〜‘９２.８ Ｔ５−e
CROWN
ROYALＪＺＳ１７３ １ＪＺ−ＧＥ ‘９９.９〜‘０１.７ Ｌ Ｔ１０−ａ ＰＲ−１６ 
CROWN
ATHLETE
ＪＺＳ１７１ １ＪＺ−ＧＴＥ ‘９９.９〜‘０１.７ L Ｔ１０−ｂ ＨＷ−２３ 
ＪＺＳ１７３ １ＪＺ−ＧＥ Ｔ１０−ａ ＰＲ−１６ 
CROWN
MAJESTAＵＺＳ１４１ １ＵＺ−ＦＥ ‘９１.１０〜‘９５.７ Ｄ Ｔ７−ａ ＫＲ 
CROWN
ESTATE
ＪＺＳ１７１Ｗ １ＪＺ−ＧＴＥ ‘９９.９〜‘０１.７ Ｌ Ｔ１０−ｂ ＨＷ−２３ 
ＪＺＳ１７３Ｗ １ＪＺ−ＧＥ Ｔ１０−ａ ＰＲ−１６ 
CROWNＪＺＳ１４＃ ２ＪＺ−ＧＥ ‘９１.１０〜‘９５.７ Ｄ Ｔ８−ｂ ＰＲ−３ 
ARISTO
ＪＺＳ１６１ ２ＪＺ−ＧＴＥ ‘９７.８〜‘０４.１１ Ｌ Ｔ１０−ｃ ＨＷ−１３ 
ＪＺＳ１６０ ２ＪＺ−ＧＥ ‘９７.８〜‘００.６
ＪＺＳ１４７ ２ＪＺ−ＧＴＥ ‘９１.１０〜‘９７.７ Ｃ Ｔ７−ｂ ＰＲ−１ 
２ＪＺ−ＧＥ ＰＲ−３ 
ＵＺＳ１４３ ＩＵＺ−ＦＥ ‘９２.１０〜‘９７.７ Ｔ７−ａ ＫＲ 
SOARER
ＵＺＺ４０ ３ＵＺ−ＦＥ ‘０１.４〜‘０５.７ Ｌ Ｔ１１−ｂ ＨＷ−２５ 
ＪＺＺ３０ １ＪＺ−ＧＴＥ ‘９６.８〜‘０１.３
Ｃ
Ｔ８−ｃ ＨＷ−１２ 
‘９１.５〜‘９６.７ ＰＲ−１ 
ＪＺＺ３１ ２ＪＺ−ＧＥ ‘９４.１〜‘９６.７ ＰＲ−３ 
ＵＺＺ３１ １ＵＺ−ＦＥ ‘９４.１〜‘９５.４ Ｔ８−ａ
ＫＲ 
‘９１.５〜‘９３.１２ Ｔ７−ａ
ＭＺ２０ ７Ｍ−ＧＴＥ ‘８９.１〜‘９１.４
Ｄ
Ｔ５−ａ
‘８６.１〜‘８８.１２ Ｔ２−ｂ
ＧＺ２０１Ｇ−ＧＴＥ ‘８９.１〜‘９１.４ Ｔ５−ａ ＦＬ−１ 
‘８６.１〜‘８８.１２ Ｔ２−ｄ
Ｔ８−ｂ
Explanation of sensor type indication
Example PR-3
Sensor type Sensor number

11
Car NameCar ModelEngine
ModelManufacturing year ECU PositionTerminal DrawingSensor TypeRemarks
SOARERＧＺ２０１Ｇ−ＧＥ‘８９.１〜‘９１.４ ＤＴ５−ｂ ＰＲ−３ 
‘８６.１〜‘８８.１２ Ｔ２−ｃ
SUPRA
ＪＺＡ８０２ＪＺ−ＧＴＥ‘９７.８〜‘０２.８
Ｃ
Ｔ１０−ｃ ＨＷ−１３ 
‘９３.５〜‘９７.７ Ｔ７−ｂ ＰＲ−１ 
２ＪＺ−ＧＥ ＰＲ−３ 
ＪＺＡ７０ １ＪＺ−ＧＴＥ ‘９０.８〜‘９３.４
Ｄ
Ｔ６−ａ ＰＲ−１ 
ＭＡ７０ ７Ｍ−ＧＴＥ
‘８８.９〜‘９０.７ Ｔ５−ａ ＫＲ 
‘８６.２〜‘８８.８ Ｔ２−ｂ
‘８８.８ Ｔ５−ａ ＰＲ−１ Turbo A
ＧＡ７０
１Ｇ−ＧＴＥ ‘８８.９〜‘９３.４ ＦＬ−１ 
‘８６.２〜‘８８.８ Ｔ２−ｄ
１Ｇ−ＧＥ ‘８８.９〜‘９３.４ Ｔ５−ｂ ＰＲ−３ 
‘８６.２〜‘８８.８ Ｔ２−ｃ
MARK II  ＪＺＸ１１０ １ＪＺ−ＧＴＥ ‘００.１０〜
‘０４.１０ Ｌ Ｔ１０−ｂ ＨＷ−２３ 
ＪＺＸ１１５ １ＪＺ−ＧＥ Ｔ１０−ａ ＰＲ−１６ 
MARK II 
BLID
ＪＺＸ１１０Ｗ １ＪＺ−ＧＴＥ ‘０２.１〜※ L Ｔ１０−ｂ ＨＷ−２３ 
ＪＺＸ１１５Ｗ １ＪＺ−ＧＥ Ｔ１０−ａ ＰＲ−１６ 
MARK II 
QUALIS
ＭＣＶ２０Ｗ １ＭＺ−ＦＥ ‘９９.８〜‘０２.１
Ｅ
Ｔ１０−ｆ
ＨＷ−１３ 
‘９７.５〜‘９９.７
Ｔ８−ｅ
ＭＣＶ２５Ｗ
ＭＣＶ２１Ｗ ２ＭＺ−ＦＥ ‘９７.５〜‘０２.１
VEROSSAＪＺＸ１１０ １ＪＺ−ＧＴＥ ‘０１.８〜‘０４.４ Ｌ Ｔ１０−ｂ ＨＷ−２３ 
MARK II 
CRESTA
CHASER
ＪＺＸ１００
１ＪＺ−ＧＴＥ
‘９６.９〜‘０１.７
Ｅ
Ｔ８−ｃ ＨＷ−１２ MARK II 
‘96.9〜‘00.9
ＪＺＸ９０
‘９４.９〜‘９６.８ Ｔ８−ｄ ＰＲ−１ 
‘９２.１０〜‘９４.８ Ｔ８−ｂ
１ＪＺ−ＧＥ ‘９２.１０〜‘９６.８ Ｔ６−ａ
ＰＲ−３ 
ＪＺＸ９１ ２ＪＺ−ＧＥ ‘９４.９〜‘９６.８ Ｔ８−ｃ
‘９２.１０〜‘９４.８ Ｔ８−ｂ
ＪＺＸ８１ １ＪＺ−ＧＴＥ ‘９０.８〜‘９２.９
Ｄ
Ｔ６−ａ ＰＲ−１ 
１ＪＺ−ＧＥ ＰＲ−３ 
ＧＸ８１ １Ｇ−ＧＴＥ ‘８８.８〜‘９０.７ Ｔ５−ａ ＦＬ−１ 
１Ｇ−ＧＥ ‘８８.８〜‘９２.９ Ｔ５−ｂ ＰＲ−３ 

12
Car NameCar ModelEngine
ModelManufacturing year ECU PositionTerminal DrawingSensor TypeRemarks
ＭＲ２
ＳＷ２０
３Ｓ−ＧＴＥ
‘９３.１０〜‘９９.１０
Ｍ
Ｔ５−ｂ
ＰＲ−２ 
‘９１.１２〜‘９３.９ ＦＬ−２ 
‘８９.１０〜‘９１.１１ 
３Ｓ−ＧＥ
‘９７.１２〜‘９９.１０ Ｔ９−ａ ＨＷ−１３ 
‘９３.１０〜‘９７.１１ Ｔ６−ａ
ＰＲ−３

‘９１.１２〜‘９３.９ Ｔ５−ｂ 
‘８９.１０〜‘９１.１１ 
ＡＷ１１ ４Ａ−ＧＺＥ ‘８６.８〜‘８９.９ Ｔ２−ａ ＦＬ−３ 
４Ａ−ＧＥ ‘８４.６〜‘８９.９ Ｔ１−ａ ＰＲ−３ 
CELICA
ＺＺＴ２３０ １ＺＺ−ＦＥ ‘９９.９〜※ Ｌ Ｔ９−ａ ＨＷ−２４ 
ＺＺＴ２３１ ２ＺＺ−ＧＥ 
ＳＴ２０５ ３Ｓ−ＧＴＥ ‘９４.２〜‘９９.８
Ｅ
Ｔ５−ｂ ＰＲ−２ 
ＳＴ２０３
ＳＴ２０２
３Ｓ−ＧＥ ‘９３.１０〜‘９７.１１ Ｔ６−ａ
ＰＲ−３

３Ｓ−ＦＥ
‘９６.６〜‘９９.８ Ｔ４−ｅ M/T
Ｔ５−ｆ A/T
‘９５.８〜‘９６.５ Ｔ４−ａ M/T
Ｔ５−ｂ
A/T
‘９３.１０〜‘９５.７ 
ＳＴ１８５ ３Ｓ−ＧＴＥ ‘９１.９〜‘９３.９ ＦＬ−２ 
‘８９.１０〜‘９１.８ 
ＳＴ１８２ ３Ｓ−ＧＥ ‘８９.１０〜‘９３.９ ＰＲ−３ 
ＳＴ１６５ ３Ｓ−ＧＴＥ ‘８５.８〜‘８９.９ ＦＬ−２ 
ＳＴ１６２ ３Ｓ−ＧＥ 
CURREN
ＳＴ２０６ ３Ｓ−ＧＥ ‘９４.１〜‘９８.７
Ｅ
Ｔ６−ａ
ＰＲ−３

ＳＴ２０７
ＳＴ２０６ ３Ｓ−ＦＥ
‘９６.６〜‘９８.７ Ｔ４−ｅ M/T
Ｔ５−ｆ A/T
‘９５.１０〜‘９６.５
Ｔ４−ａ M/T
Ｔ６−ａ With A/T TRC
Ｔ５−ｂ Without A/T
TRC
‘９４.１〜‘９５.９ Ｔ６−ａ With TRC
Ｔ５−ｂ Without TRC
Ｔ２−ａ

13
Car NameCar ModelEngine
ModelManufactur- ing year ECU PositionTerminal DrawingSensor TypeRemarks
CARINA ED
CORONA EXIVＳＴ２０３
ＳＴ２０２
３Ｓ−ＧＥ ‘９３.１０〜‘９８.１２
Ｅ
Ｔ６−ａ
ＰＲ−３

３Ｓ−ＦＥ
‘９６.６〜‘９８.１２ Ｔ４−ｅ M/T
Ｔ５−ｆ A/T
‘９５.８〜‘９６.５
Ｔ４−ａ M/T
Ｔ６−ａ With A/T TRC
Ｔ５−ｂ Without A/T TRC
‘９３.１０〜‘９５.７ Ｔ６−ａ With TRC
Ｔ５−ｂ Without TRC
CALDINA
ＳＴ２４６Ｗ ３Ｓ−ＧＴＥ ‘０２.９〜※
Ｄ
Ｔ１２−ａ ＰＲ−２ 
ＺＺＴ２４１Ｗ １ＺＺ−ＦＥ ＨＷ−２４ 
ＳＴ２１５Ｗ ３Ｓ−ＧＴＥ
‘９７.８〜‘０２.８
Ｔ９−ａ ＰＲ−２ 
ＳＴ２１５Ｇ
ＳＴ２１０Ｇ ３Ｓ−ＦＥ Ｔ５−ｃ
ＰＲ−３

ＳＴ１９５Ｇ ３Ｓ−ＧＥ ‘９５.２〜‘９７.７ Ｔ６−ａ 
ＳＴ１９５Ｇ
ＳＴ１９１Ｇ ３Ｓ−ＦＥ
‘９６.１〜‘９７.７
Ｔ４−ｅ M/T
Ｔ５−ｄ 2WD A/T
Ｔ５−ｆ 4WD A/T
‘９４.２〜‘９５.１２
Ｔ６−ａ FF With TRC
Ｔ５−ｂ FF Without TRC
Ｔ４−ａ 4WD M/T
Ｔ５−ｂ 4WD A/T
‘９２.１１〜‘９４.１
Ｔ６−ｂ FF A/T
Ｔ４−ａ 4WD M/T
Ｔ５−ｂ 4WD A/T
ＳＴ１９０Ｇ ４Ｓ−ＦＥ ‘９２.１１〜‘９５.１２ Ｔ４−ｄ M/T
Ｔ５−ｂ A/T
CAROLLA FX
ＡＥ１０１
４Ａ−ＧＥ
‘９２.５〜‘９５.４
Ｅ
Ｔ４−ｂ ＦＬ−４ M/T
Ｔ５−ｂ A/T
４Ａ−ＦＥ Ｔ４−ｂ
ＰＲ−３
M/T
Ｔ５−ｂ A/T
ＡＥ９２ ４Ａ−ＧＥ ‘８９.５〜‘９２.４ Ｔ４−ｂ 
‘８７.５〜‘８９.４ Ｔ１−ａ 

14
Car NameCar ModelEngine
ModelManufactur- ing year ECU PositionTerminal DrawingSensor TypeRemarks
CAROLLA
SPRINTER
ＡＥ１１１ ４Ａ−ＧＥ ‘９７.４〜‘００.９
Ｅ
Ｔ５−ｂ
ＰＲ−３

４Ａ−ＦＥ ‘９５.５〜‘９７.３
Ｔ４−ｂ

ＡＥ１１０ ５Ａ−ＦＥ ‘９５.５〜‘００.９ 
ＡＥ１０１
４Ａ−ＧＥ
‘９１.６〜‘９５.４
ＦＬ−４ M/T
Ｔ５−ｂ A/T
４Ａ−ＦＥ Ｔ４−ｂ
ＰＲ−３
M/T
Ｔ５−ｂ A/T
ＡＥ９２ ４Ａ−ＧＥ ‘８９.５〜‘９１.５ Ｔ４−ｂ 
‘８７.５〜‘８９.４ Ｔ１−ａ 
LEVIN
TRUENO
ＡＥ１１１ ４Ａ−ＧＥ
‘９５.５〜‘００.９
Ｅ
Ｔ５−ｂ
ＰＲ−３

４Ａ−ＦＥ Ｔ４−ｂ 
ＡＥ１１０ ５Ａ−ＦＥ 
ＡＥ１０１
４Ａ−ＧＺＥ
‘９１.６〜‘９５.４
Ｔ５−ｂ ＰＲ−１ 
４Ａ−ＧＥ Ｔ４−ｂ ＦＬ−４ M/T
Ｔ５−ｂ A/T
４Ａ−ＦＥ Ｔ４−ｂ ＰＲ−３ M/T
Ｔ５−ｂ A/T
ＡＥ９２
４Ａ−ＧＺＥ ‘８９.５〜‘９１.５ Ｔ５−ｂ ＰＲ−１ 
‘８７.５〜‘８９.４ Ｔ２−ａ ＦＬ−３ 
４Ａ−ＧＥ ‘８９.５〜‘９１.５ Ｔ４−ｂ
ＰＲ−３

‘８７.５〜‘８９.４ Ｔ１−ａ 
ＡＥ８６ ４Ａ−ＧＥＵ ‘８３.５〜‘８７.４ Ａ Ｔ１−ｂ 
CERES
MARINO ＡＥ１０１
４Ａ−ＧＥ
‘９２.５〜‘９５.４ Ｅ
Ｔ４−ｂ ＦＬ−４ M/T
Ｔ５−ｂ A/T
４Ａ−ＦＥ Ｔ４−ｂ ＰＲ−３ M/T
Ｔ５−ｂ A/T
ALTEZZAＳＸＥ１０ ３Ｓ−ＧＥ ‘９８.１０〜‘05.7Ｌ Ｔ９−ｂ ＨＷ−１５ M/T
Ｔ１０−ｄ A/T
ALTEZZA
GITAＪＣＥ１５Ｗ
ＪＣＥ１０Ｗ ２ＪＺ−ＧＥ ‘０１.７〜※ Ｌ Ｔ１０−ｂ ＨＷ−２４ 
ＭＲ−Ｓ ＺＺＷ３０ １ＺＺ−ＦＥ ‘９９.１０〜※ Ｏ Ｔ９−ａ ＨＷ−２４ Including
Sequential M/T

15
Car NameCar ModelEngine
ModelManufacturing year ECU PositionTerminal DrawingSensor TypeRemarks
STARLET
ＥＰ９１ ４Ｅ−ＦＴＥ ‘９６.１〜‘９９.７ Ｄ
Ｔ４−ｃ ＰＲ−１ M/T
Ｔ４−ａ A/T
４Ｅ−ＦＥ ‘９６.１〜‘９７.１２ Ｔ３−ｂ ＰＲ−３ 
ＥＰ８２ ４Ｅ−ＦＴＥ
‘８９.１２〜‘９５.１２
Ｅ
Ｔ３−ａ
ＰＲ−１
M/T
‘９２.１〜‘９５.１２ Ｔ４−ｂ A/T
‘８９.１２〜‘９１.１２
４Ｅ−ＦＥ ‘８９.１２〜‘９５.１２ Ｔ３−ａ ＰＲ−３ 
ＥＰ７１ ２Ｅ−ＴＥ
２Ｅ−Ｅ ‘８６.１〜‘８９.１１ Ｔ１−ｂ ＰＲ−１ 
ＲＡＶ４
ＺＣＡ２６Ｗ
ＺＣＡ２５Ｗ １ＺＺ−ＦＥ ‘００.５〜‘０５.１０ Ｄ Ｔ９−ａ ＨＷ−２４ 
ＳＸＡ１＃Ｇ ３Ｓ−ＦＥ ‘９７.９〜‘００.４
Ｅ
Ｔ４−ｅ
ＰＲ−３
M/T
Ｔ５−ｆ A/T
ＳＸＡ１１Ｗ ３Ｓ−ＧＥ Ｔ５−ｂ 
ＳＸＡ１０Ｗ ‘９６.８〜‘００.４ 
ＳＸＡ１１Ｇ
３Ｓ−ＦＥ
‘９５.４〜‘９７.８ Ｔ４−ａ M/T
Ｔ５−ｂ A/T
ＳＸＡ１０Ｇ ‘９４.５〜‘９７.８ Ｔ４−ａ M/T
Ｔ５−ｂ A/T
VITZ
KSP90 １KR−ＦＥ ‘０５.２〜※ L Ｔ１４−ａ ＰＲ−２０ 
SCP90２SZ−FEＴ１４−ａ
ＨＷ−２４

ＮＣＰ１３１ＮＺ−ＦＥ‘０２.１２〜‘０５.１
Ｄ
Ｔ１２−ａ 
‘００.１０〜‘０２.１１ Ｔ６−ｃ 
ＮＣＰ１０
２ＮＺ−ＦＥ
‘０２.１２〜‘０５.１ Ｔ１２−ａ 
‘００.１０〜‘０２.１１ Ｔ６−ｃ 
ＮＣＰ１５ ‘０２.１２〜‘０５.１ Ｔ１２−ａ 
‘００.１０〜‘０２.１１ Ｔ６−ｃ 
FUNCARGO
ＮＣＰ２５
ＮＣＰ２１ １ＮＺ−ＦＥ
‘９９.８〜‘０５.９ Ｄ

ＮＣＰ２０ ２ＮＺ−ＦＥ 
ＮＣＰ２５
ＮＣＰ２１ １ＮＺ−ＦＥ Ｔ９−ｃ With
Steermatic
ＮＣＰ２０ ２ＮＺ−ＦＥ
Ｔ６−ｃ

16
Car NameCar ModelEngine
ModelManufactur- ing year ECU PositionTerminal DrawingSensor TypeRemarks
CAROLLA
ＺＺＥ１２＃ １ＺＺ−ＦＥ
‘０２.９〜※
Ｄ
Ｔ１２−ａ
ＨＷ−２４

ＮＺＥ１２４
ＮＺＥ１２１ １ＮＺ−ＦＥ 
ＺＺＥ１２＃ １ＺＺ−ＦＥ
‘００.８〜‘０２.８
Ｔ９−ａ 
ＮＺＥ１２４
ＮＺＥ１２１ １ＮＺ−ＦＥ Ｔ６−ｃ 
CAROLLA
FIELDER
ＺＺＥ１２３Ｇ ２ＺＺ−ＧＥ
‘０２.９〜※
Ｄ
Ｔ１０−ｆ
ＨＷ−２４

ＺＺＥ１２２Ｇ １ＺＺ−ＦＥ Ｔ９−ａ Ｍ/Ｔ
Ｔ１２ーａ
Ａ/Ｔ
ＮＺＥ１２４Ｇ
ＮＺＥ１２１Ｇ １ＮＺ−ＦＥ 
ＺＺＥ１２３Ｇ ２ＺＺ−ＧＥ
‘００.８〜‘０２.８
Ｔ１０−ｆ 
ＺＺＥ１２２Ｇ １ＺＺ−ＦＥ Ｔ９−ａ 
ＮＺＥ１２４Ｇ
ＮＺＥ１２１Ｇ １ＮＺ−ＦＥ Ｔ６−ｃ 
CAROLLA
RUNX
ALEX
ＺＺＥ１２３ ２ＺＺ−ＧＥ
‘０２.９〜※
Ｄ
Ｔ１０−ｆ
ＨＷ−２４

ＺＺＥ１２４
ＺＺＥ１２２ １ＺＺ−ＦＥ
Ｔ１２−ａ

ＮＺＥ１２４
ＮＺＥ１２１ １ＮＺ−ＦＥ 
ＺＺＥ１２３ ２ＺＺ−ＧＥ
‘０１.１〜‘０２.８
Ｔ１０−ｆ 
ＮＺＥ１２４
ＮＺＥ１２１ １ＮＺ−ＦＥ Ｔ６−ｃ 
CAROLLA
SPACIO
ＺＺＥ１２４Ｎ １ＺＺ−ＦＥ ‘０１.７〜※
Ｄ Ｔ９−ａ ＨＷ−２４

ＺＺＥ１２２Ｎ ‘０１.５〜※ 
ＮＺＥ１２１Ｎ １ＮＺ−ＦＥ Ｔ６−ｃ 
WiLL VS
ＺＺＥ１２８ ２ＺＺ−ＧＥ
‘０１.４〜‘０４.４ Ｄ
Ｔ１０−ｆ
ＨＷ−２４

ＺＺＥ１２９
ＺＺＥ１２７ １ＺＺ−ＦＥ Ｔ９−ａ 
WiLL
CYPHA
ＮＣＰ７５ １ＮＺ−ＦＥ ‘０２.１０〜‘０５.８ Ｄ Ｔ１２−ａ ＨＷ−２４ 
ＮＣＰ７０ ２ＮＺ−ＦＥ 
ALLION ＺＺＴ２４０ １ＺＺ−ＦＥ ‘０１.１２〜※ Ｂ Ｔ１２−ａ ＨＷ−２４ 
ＮＺＴ２４０ １ＮＺ−ＦＥ 
ｉｓｔＮＣＰ６１ １ＮＺ−ＦＥ ‘０２.５〜※Ｄ Ｔ１２−ａＨＷ−２４ 
ＮＣＰ６０ ２ＮＺ−ＦＥ 

17
Car NameCar ModelEngine
ModelManufactur- ing year ECU PositionTerminal DrawingSensor TypeRemarks
PLATZ
ＮＣＰ１２ １ＮＺ−ＦＥ
‘０２.８〜‘０５.１０
Ｅ
Ｔ１２−ａ
ＨＷ−２４

ＮＣＰ１６ ２ＮＺ−ＦＥ 
ＳＣＰ１１ １ＳＺ−ＦＥ 
ＮＣＰ１２ １ＮＺ−ＦＥ
‘９９.８〜‘０２.７ Ｔ６−ｃ

ＮＣＰ１６ ２ＮＺ−ＦＥ 
ＳＣＰ１１ １ＳＺ−ＦＥ 
ｂＢ
ＮＣＰ３０ ２ＮＺ−ＦＥ
‘０２.８〜‘０５.１１
Ｄ
Ｔ１2−a
ＨＷ−２４

ＮＣＰ３５
ＮＣＰ３１ １ＮＺ−ＦＥ 
ＮＣＰ３４ ‘０２.８〜‘０３.３
ＮＣＰ３０ ２ＮＺ−ＦＥ
‘００.２〜‘０２.７ Ｔ６−ｃ

ＮＣＰ３５
ＮＣＰ３１ １ＮＺ−ＦＥ 
ＮＣＰ３４ ‘０１.６〜‘０２.７ 
ＯＰＡ ＺＣＴ１＃ １ＺＺ−ＦＥ ‘００.８〜‘０２.５ Ｄ Ｔ９−ａ ＨＷ−２４ 
WINDOMＭＣＶ３０ １ＭＺ−ＦＥ ‘０１.８〜※ Ｂ Ｔ１１−ａ ＨＷ−１３ 
ESTIMA ＭＣＲ＃０Ｗ １ＭＺ−ＦＥ ‘００.１〜‘０５.１２ Ｄ Ｔ１０−ｆ ＨＷ−１５ 
ALPHARD ＭＮＨ１＃Ｗ １ＭＺ−ＦＥ ‘０２.５〜※ Ｄ Ｔ１０−ｆ ＨＷ−１５ 
VOLTZＺＺＥ１３７ ２ＺＺ−ＧＥ
‘０２.８〜‘０４.４ＤＴ１２−ａ ＨＷ−２４
ＺＺＥ１３８
ＺＺＥ１３６ １ＺＺ−ＦＥ 
ＷＩＳＨＺＮＥ１＃Ｇ １ＺＺ−ＦＥ ‘０３.１〜※ＤＴ１２−ａＨＷ−２４
SIENTAＮＣＰ８１Ｇ１ＮＺ−ＦＥ‘０３.９〜※ＢＴ１１−ｃ ＨＷ−２４
PASSOＫＧＣ１０ １ＫＲ−ＦＥ ‘０４.６〜※ＤＴ１３−ａ ＰＲ−２０Set the
number of
cylinders “1”
PORTEＮＮＰ１# １ＮＺ−ＦＥ
２ＮＺ−ＦＥ ‘０４.７〜※ＤＴ１２−ａ ＨＷ−２４

18
■ECU Terminal Arrangement Table (TOYOTA)
Ground Throttle signal IG power
rpm Pressure signal
Without throttle signal
Airflow signal
Ground
rpm  Pressure signal
IG power
rpm 
Ground Throttle signal IG power
rpm 
Ground
Throttle signal
IG power
rpm 
Ground IG power
Airflow signal
rpm 
Ground IG power
Without throttle signal
rpm Pressure signal
Ground IG power
Without throttle signal
rpm Pressure signal
Ground Throttle signal
IG power
Throttle signal
Karman signal
Pressure signal
rpm 
Ground Throttle signal IG power
pressure signal rpm 
Ground Throttle signal IG power
Airflow signal
/pressure signal

19
Turbo A pressure signal
rpm Pressure signal
Ground IG power
Without throttle signal
rpm  Pressure signal
GroundIG power
Without throttle signal
rpm Pressure signal
Ground Throttle signal IG power
rpm  Karman signal
GroundThrottle signal IG power
rpm Airflow signal
/pressure signal
Ground Throttle signal IG power 
rpm 
Ground Throttle signal IG power
rpm Pressure signal
Throttle signal IG power
Pressure signal
Ground
Karman signalrpm IG power
Throttle signal
Ground
rpm Pressure signal
Ground Throttle signal IG power
GroundPressure signal
rpm Throttle signal IG power

20
26p 16p 12p 22p
T6-cT6-b 26p 16p 12p 22p
T7-a T7-b
T8-a 34p 22p 16p 28p T8-b 34p 22p 16p 28p
T8-c 34p 22p 16p 28p T8-d 34p 22p 16p 28p
34p 22p 16p 28p
T8-e T9-a
31p 24p 28p 22p
rpm Pressure signal
Ground Throttle signal IG power
Airflow signal
rpm 
Throttle signal
Ground
Pressure signal IG power
rpm Karman signal
Throttle signal Ground IG power
rpm Pressure signal
Throttle signal Ground IG power
Airflow signal/pressure signal
Ground
rpm Throttle signal IG power
rpm 
Ground Pressure signal
Throttle signal
IG power
Airflow signalThrottle signal
Ground rpm IG power
pressure signal
Throttle signal Ground
rpm 
IG power
Ground
rpm 
Throttle signal IG power
rpm Ground
Karman signal
Throttle signal IG power
