JVC KD-R201 User manual

ENGLISHFRANÇAIS
CD RECEIVER
RÉCEPTEUR CD
KD-R201
For installation and connections, refer to the separate manual.
Pour l’installation et les raccordements, se référer au manuel séparé.
INSTRUCTIONS
MANUEL D’INSTRUCTIONS
GET0583-003A
[EX]
For canceling the display demonstration, see page 5.
Pour annuler la démonstration des affichages, référez-vous à la page 5.
Cover_KD-R201_003A_4.indd 1Cover_KD-R201_003A_4.indd 1 6/27/08 9:47:39 AM6/27/08 9:47:39 AM

2
ENGLISH
Warning:
If you need to operate the unit while driving, be
sure to look around carefully or you may be involved
in a traffic accident.
How to reset your unit
• Your preset adjustments will also be erased.
How to forcibly eject a disc
• Be careful not to drop the disc when it ejects.
• If this does not work, reset your unit.
Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best
possible performance from the unit.
IMPORTANT FOR ASER PRODUCTS
. CLASS LASER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicing to
qualified service personnel.
3. CAUTION: Visible and/or invisible class M laser radiation when open. Do not view directly with optical
instruments.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUTSIDE THE UNIT.
Information for Users on Disposal of Old
Equipment and Batteries
[European Union only]
These symbols indicate that the product and the
battery with this symbol should not be disposed as
general household waste at its end-of-life.
If you wish to dispose of this product and the
battery, please do so in accordance with applicable
national legislation or other rules in your country
and municipality.
By disposing of this product correctly, you will help
to conserve natural resources and will help prevent
potential negative effects on the environment and
human health.
Notice:
The sign Pb below the symbol for batteries indicates
that this battery contains lead.
Products
Battery
EN02-05_KD-R201_003A_4.indd 2EN02-05_KD-R201_003A_4.indd 2 26/6/08 11:23:31 AM26/6/08 11:23:31 AM

ENGLISH
3
How to use the M MODE button
If you press M MODE, the unit goes into functions mode,
then the number buttons and 5 / ∞ buttons will work
as different function buttons.
Ex. When number button 2 works as
MO (monaural) button.
To use these buttons for their original functions
again after pressing M MODE, wait for 5 seconds
without pressing any of these buttons until the
functions mode is cleared, or press M MODE again.
Detaching the control panel
Attaching the control panel
Caution on volume setting:
Discs produce very little noise compared with other
sources. Lower the volume before playing a disc
to avoid damaging the speakers by the sudden
increase of the output level.
CONTENTS
Control panel ..................................
Getting started ................................ 5
Basic operations ................................................... 5
Radio operations ............................. 6
FM Radio Data System operations ..... 7
Searching for your favorite FM Radio Data System
programme .......................................................... 7
Disc operations ................................ 9
Playing a disc in the unit ..................................... 9
Sound adjustments .......................... 11
General settings — PSM .................. 12
Other external component
operations .................................... 15
Maintenance ................................... 15
More about this unit ........................ 16
Troubleshooting .............................. 18
Specifications .................................. 19
For safety...
• Do not raise the volume level too much, as this will
block outside sounds, making driving dangerous.
• Stop the car before performing any complicated
operations.
Temperature inside the car...
If you have parked the car for a long time in hot or cold
weather, wait until the temperature in the car becomes
normal before operating the unit.
EN02-05_KD-R201_003A_3.indd 3EN02-05_KD-R201_003A_3.indd 3 20/6/08 9:58:05 AM20/6/08 9:58:05 AM

4
ENGLISH
o RPT (repeat) button
; RND (random) button
a AUX (auxiliary) input jack
s Disc information indicator
d D SC indicator
f Playback mode / item indicators—RND (random),
(disc), RPT (repeat)
g Radio Data System indicators—AF, REG, TP, PTY
h Tuner reception indicators—MO (monaural),
ST (stereo)
j LOUD (loudness) indicator
k EQ (equalizer) indicator
l Tr (track) indicator
/ Source display / Track number / Volume level
indicator / Time countdown indicator
z Main display
x Sound mode (c-EQ: custom equalizer) indicators—
JAZZ, ROCK, H P HOP, CLASS C, POPS, USER
Parts identification
Display window
Control panel
1 0 (eject) button
2 4 / ¢ buttons
3 Loading slot
4 (standby/attenuator) button
5 BAND button
6 Display window
7 T/P (traffic programme/programme type) button
8 D SP (display) button
9 5(up)/∞(down) buttons
p (control panel release) button
q SRC (source) button
w Control dial
e SEL (select) button
r M MODE button
t EQ (equalizer) button
y MO (monaural) button
u SSM (Strong-station Sequential Memory) button
Number buttons
EN02-05_KD-R201_003A_4.indd 4EN02-05_KD-R201_003A_4.indd 4 23/6/08 2:21:20 PM23/6/08 2:21:20 PM

ENGLISH
5
Basic settings
• See also “General settings — PSM” on
pages 12 – 14.
1
2
1Canceling the display demonstrations
Select “DEMO,” then “DEMO OFF.”
2Setting the clock
Select “CLOCK H” (hour), then adjust the hour.
Select “CLOCK M” (minute), then adjust the
minute.
Select “24H/12H,” then “24H” (hour) or
“12H” (hour).
3Finish the procedure.
To check the current clock time while the
power is turned off
Clock time is shown on the
display for about 5 seconds. See
also page 13.
Getting started
Basic operations
~Turn on the power.
Ÿ
* You cannot select “CD” as the playback source if
there is no disc in the unit.
!For FM/AM tuner
⁄Adjust the volume.
@Adjust the sound as you want. (See
pages 11 and 12.)
To drop the volume in a
moment (ATT)
To restore the sound, press the
button again.
To turn off the power
Volume level appears.
EN02-05_KD-R201_003A_f.indd 5EN02-05_KD-R201_003A_f.indd 5 28/7/08 3:30:26 PM28/7/08 3:30:26 PM

6
ENGLISH
When an FM stereo broadcast is hard to
receive
Reception improves, but the stereo effect will be lost.
To restore the stereo effect, repeat the same
procedure. “MONO OFF” appears and the MO indicator
goes off.
Storing stations in memory
You can preset six stations for each band.
FM station automatic presetting—
SSM (Strong-station Sequential
Memory)
1Select the FM band (FM1 – FM3) you want to
store into.
2
3
“SSM” flashes, then disappears when automatic
presetting is over.
Local FM stations with the strongest signals are
searched and stored automatically in the FM band.
Radio operations
~
Ÿ
!Start searching for a station.
When a station is received, searching stops.
To stop searching, press the same button
again.
To tune in to a station manually
In step !above...
1
2Select a desired station frequency.
Lights up when receiving an FM stereo
broadcast with sufficient signal strength.
Lights up when monaural mode is activated.
EN06-13_KD-R201_003A_f.indd 6EN06-13_KD-R201_003A_f.indd 6 28/7/08 3:28:46 PM28/7/08 3:28:46 PM

7
ENGLISH
Manual presetting
E .: Storing the FM station of 92.5 MHz into preset
number 4 of the FM1 band.
1
2
3
Listening to a preset station
1
2 Select the preset station (1 – 6 you want.
To check the current clock time while
listening to an FM (non-Radio Data System
or AM station
• For FM Radio Data System stations, see page 9.
FM Radio Data System
operations
What you can do with Radio Data System
Radio Data System allows FM stations to send an
additional signal along with their regular programme
signals.
By receiving the Radio Data System data, this unit can
do the following:
• Programme Type (PTY) Search (see the following)
• TA (Traffic Announcement) and PTY Standby
Receptions (see pages 8, 9, 13 and 14)
• Tracing the same programme automatically
—Network-Tracking Reception (see page 9)
• Programme Search (see pages 9 and 14)
Searching for your favorite
FM Radio Data System
programme
You can tune in to a station broadcasting your favorite
programme by searching for a PTY code.
• To store your favorite programme types, see page 8.
~ The last selected PTY
code appears.
Ÿ Select one of your favorite programme
types.
or
Select one of the PTY codes (see
page 9 .
Preset number flashes for a while.
Frequency Ô Clock
Continued on the next page
EN06-13_KD-R201_003A_2.indd 7EN06-13_KD-R201_003A_2.indd 7 6/17/08 4:48:01 PM6/17/08 4:48:01 PM

8
ENGLISH
! Start searching for your favorite
programme.
If there is a station broadcasting a programme
of the same PTY code as you have selected, that
station is tuned in.
Storing your favorite programme
types
You can store si favorite programme types.
Preset programme types in the number buttons
(1 to 6 :
1 Select a PTY code (see pages 7 and 8 .
2 Select the preset number (1 – 6 you want to
store into.
3 Repeat steps 1 and 2 to store other PTY codes
into other preset numbers.
4 Finish the procedure.
E .: When “ROCK M” is selected
Using the standby receptions
TA Standby Reception
TA Standby Reception allows the unit to switch
temporarily to Traffic Announcement (TA) from any
source other than AM.
The volume changes to the preset TA volume level if the
current level is lower than the preset level (see
page 14).
To activate TA Standby Reception
The TP (Traffic Programme)
indicator either lights up or
flashes.
• If the TP indicator lights up, TA Standby Reception is
activated.
• If the TP indicator flashes, TA Standby Reception is
not yet activated. (This occurs when you are listening
to an FM station without the Radio Data System
signals required for TA Standby Reception.)
To activate TA Standby Reception, tune in to another
station providing these signals. The TP indicator will
stop flashing and remain lit.
To deactivate the TA Standby Reception
The TP indicator goes off.
PTY Standby Reception
PTY Standby Reception allows the unit to switch
temporarily to your favorite PTY programme from any
source other than AM.
To activate and select your favorite PTY code for
PTY Standby Reception, see page 13.
The PTY indicator either lights up or flashes.
• If the PTY indicator lights up, PTY Standby Reception
is activated.
• If the PTY indicator flashes, PTY Standby Reception is
not yet activated.
To activate PTY Standby Reception, tune in to
another station providing these signals. The PTY
indicator will stop flashing and remain lit.
EN06-13_KD-R201_003A_2.indd 8EN06-13_KD-R201_003A_2.indd 8 6/17/08 4:48:02 PM6/17/08 4:48:02 PM

9
ENGLISH
To check the current clock time while
listening to an FM Radio Data System station
PTY codes
NEWS, AFFAIRS, INFO, SPORT, EDUCATE, DRAMA, CULTURE,
SCIENCE, VARIED, POP M (music), ROCK M (music), EASY
M (music), LIGHT M (music), CLASSICS, OTHER M (music),
WEATHER, FINANCE, CHILDREN, SOCIAL, RELIGION, PHONE
IN, TRAVEL, LEISURE, JAZZ, COUNTRY, NATION M (music),
OLDIES, FOLK M (music), DOCUMENT
Disc operations
Playing a disc in the unit
~ Turn on the power.
Ÿ
All tracks will be played repeatedly until you
change the source or eject the disc.
To deactivate the PTY Standby Reception, select
“OFF” for the PTY code (see page 13). The PTY indicator
goes off.
Tracing the same programme—
Network-Tracking Reception
When driving in an area where FM reception is not
sufficient enough, this unit automatically tunes in to
another FM Radio Data System station of the same
network, possibly broadcasting the same programme
with stronger signals (see the illustration below).
When shipped from the factory, Network-Tracking
Reception is activated.
To change the Network-Tracking Reception
setting, see “AF-REG” on page 13.
Programme A broadcasting on different frequency areas
(01 – 05)
Automatic station selection—
Programme Search
Usually when you press the number buttons, the preset
station is tuned in.
If the signals from the FM Radio Data System preset
station are not sufficient for good reception, this
unit, using the AF data, tunes in to another frequency
broadcasting the same programme as the original
preset station is broadcasting.
• The unit takes some time to tune in to another
station using programme search.
• See also page 14.
Station name (PS = Station
Frequency = Programme
type (PTY = Clock = (back to
the beginning)
Continued on the next page
EN06-13_KD-R201_003A_2.indd 9EN06-13_KD-R201_003A_2.indd 9 6/17/08 4:48:03 PM6/17/08 4:48:03 PM

10
ENGLISH
To stop play and eject
the disc
• Press SRC to listen to
another playback source.
To fast-forward or reverse
the track
To go to the next or
previous track
To locate a particular track directly
To select a number from 01 – 06:
To select a number from 07 – 12:
Other main functions
Skipping tracks quickly during play
E .: To select track 32 while playing a track whose
number is a single digit (1 to 9)
1
2
Each time you press the button, you can skip 10
tracks.
• After the last track, the first track will be selected
and vice versa.
3
Prohibiting disc ejection
You can lock a disc in the loading slot.
To cancel the prohibition, repeat the same
procedure.
Changing the display information
The elapsed playing time with the current
track number = Clock with the current
track number = Disc title/performer * =
Track title * [ ] = (back to the beginning)
[ ] : Corresponding indicator lights up on the display.
* If the current disc is an audio CD, “NO NAME” appears.
EN06-13_KD-R201_003A_2.indd 10EN06-13_KD-R201_003A_2.indd 10 6/17/08 4:48:04 PM6/17/08 4:48:04 PM

11
ENGLISH
Selecting the playback modes
You can use only one of the following playback modes
at a time.
1
2 Select your desired playback mode.
7 Repeat play
Mode Plays repeatedly
TRK RPT : The current track. [ ]
RPT OFF : Cancels.
7 Random play
Mode Plays at random
ALL RND : All tracks of the current disc.
[ ]
RND OFF : Cancels.
[ ] : Corresponding indicator lights up on the
display.
Sound adjustments
You can select a preset sound mode suitable to the
music genre (c-EQ: custom equalizer).
1
2
Indication (For
BAS
(bass)
TRE
(treble)
LOUD
(loudness)
USER
(Flat sound) 00 00 OFF
ROCK
(Rock or disco music) +03 +01 ON
CLASSIC
(Classical music) +01 –02 OFF
POPS
(Light music) +04 +01 OFF
HIP HOP
(Funk or rap music) +02 00 ON
JAZZ
(Jazz music) +02 +03 OFF
Preset values
Continued on the next page
EN06-13_KD-R201_003A_2.indd 11EN06-13_KD-R201_003A_2.indd 11 6/17/08 4:48:05 PM6/17/08 4:48:05 PM

12
ENGLISH
Adjusting the sound
You can adjust the sound characteristics to your
preference.
1
2
Indication, [Range]
BAS*1 (bass), [–06 to +06]
Adjust the bass.
TRE*1 (treble), [–06 to +06]
Adjust the treble.
FAD*2 (fader), [R06 to F06]
Adjust the front and rear speaker balance.
BAL (balance), [L06 to R06]
Adjust the left and right speaker balance.
LOUD*1 (loudness), [LOUD ON or LOUD OFF]
Boost low and high frequencies to produce a
well-balanced sound at a low volume level.
VOL (volume), [00 to 50 or 00 to 30]*3
Adjust the volume.
*1 When you ad ust the bass, treble, or loudness, the
ad ustment you have made is stored for the currently
selected sound mode (c-EQ) including “USER.”
*2 If you are using a two-speaker system, set the fader
level to “00.”
*3 Depending on the amplifier gain control setting. (See
page 14 for details.)
You can change PSM (Preferred Setting Mode) items
listed on pages 13 and 14.
1
2 Select a PSM item.
3 Adjust the PSM item selected.
4 Repeat steps 2 and 3 to adjust other PSM
items if necessary.
5 Finish the procedure.
General settings — PSM
EN06-13_KD-R201_003A_2.indd 12EN06-13_KD-R201_003A_2.indd 12 6/17/08 4:48:06 PM6/17/08 4:48:06 PM

13
ENGLISH
Indications Item
( : Initial)
Selectable settings, [reference page]
DEMO
Display demonstration
• DEMO ON
• DEMO OFF
: Display demonstration will be activated automatically if no
operation is done for about 20 seconds, [5].
: Cancels.
CLK DISP *1
Clock display
• ON
• OFF
: Clock time is shown on the display at all times when the power is
turned off.
: Cancels; pressing DISP will show the clock time for about
5 seconds when the power is turned off, [5].
CLOCK H
Hour adjustment
0 – 23 (1 – 12) [Initial: 0 (0:00)], [5].
CLOCK M
Minute adjustment
00 – 59 [Initial: 00 (0:00)], [5].
24H/12H
Time display mode
• 24H
• 12H
: See also page 5 for setting.
CLK ADJ *2
Clock adjustment
• AUTO
• OFF
: The built-in clock is automatically adjusted using the CT (clock
time) data in the Radio Data System signal.
: Cancels.
AF-REG *2
Alternative frequency/
regionalization
reception
• AF
• AF REG
• OFF
: When the currently received signals become weak, the unit
switches to another station (the programme may differ from the
one currently received), [9, 16].
• The AF indicator lights up.
: When the currently received signals become weak, the unit
switches to another station broadcasting the same programme.
• The AF and REG indicators light up.
: Cancels.
PTY-STBY *2
PTY standby
OFF, PTY codes Activates PTY Standby Reception with one of the PTY codes, [9].
*1 If the power supply is not interrupted by turning off the ignition key of your car, it is recommended that you select
“OFF” to save the car’s battery.
*2 Only for FM Radio Data System stations.
Continued on the next page
EN06-13_KD-R201_003A_2.indd 13EN06-13_KD-R201_003A_2.indd 13 6/17/08 4:48:06 PM6/17/08 4:48:06 PM

14
ENGLISH
Indications Item
( : Initial)
Selectable settings, [reference page]
TA VOL *2
Traffic
announcement
volume
VOL 00
– VOL 50
(or VOL 00
– VOL 0)*3
[Initial: VOL 15]
P-SEARCH *2
Programme search
• ON
• OFF
: Activates Programme earch, [9].
: Cancels.
DIMMER
Dimmer
• ON
• OFF
: Dims the display and button illumination.
: Cancels.
TEL
Telephone muting
• MUTING 1/
MUTING 2
• OFF
: elect either one which mutes the sounds while using a cellular
phone.
: Cancels.
SCROLL *4
croll
• ONCE
• AUTO
• OFF
: crolls the displayed information once.
: Repeats scrolling (at 5-second intervals).
: Cancels.
• Pressing DI P for more than one second can scroll the display
regardless of the setting.
AUX ADJ
Auxiliary input level
adjustment
A.ADJ 00
— A.ADJ 05
: Adjust the auxiliary input level to avoid the sudden increase of the
output level when changing the source from external component
connected to the AUX input jack on the control panel.
AMP GAIN
Amplifier gain control
• LOW PWR
• HIGH PWR
: VOL 00 – VOL 30 ( elect this if the maximum power of the speaker
is less than 50 W to prevent damaging the speaker.)
: VOL 00 – VOL 50
IF BAND
Intermediate
frequency band
• AUTO
• WIDE
: Increases the tuner selectivity to reduce interference noise between
close stations. ( tereo effect may be lost.)
: ubject to the interference noise from adjacent stations, but sound
quality will not be degraded and the stereo effect will remain.
*2 Only for FM Radio Data System stations.
*3 Depends on the amplifier gain control.
*4 Some characters or symbols will not be shown correctly (or will be blanked) on the display.
EN14-19_KD-R201_003A_2.indd 14EN14-19_KD-R201_003A_2.indd 14 6/17/08 4:51:37 PM6/17/08 4:51:37 PM

ENGLISH
15
Other external component
operations
You can connect an external component to the AUX
(auxiliary) input jack on the control panel.
~
Ÿ Turn on the connected component and
start playing the source.
! Adjust the volume.
⁄ Adjust the sound as you want.
(See pages 11 and 12.)
To check the clock time while listening to an
external component
Portable audio player,
etc. tereo mini plug
(not supplied)
AUX IN Ô Clock
Maintenance
How to clean the connectors
Frequent detachment will deteriorate the connectors.
To minimize this possibility, periodically wipe the
connectors with a cotton swab or cloth moistened with
alcohol, being careful not to damage the connectors.
Moisture condensation
Moisture may condense on the lens inside the unit in
the following cases:
• After starting the heater in the car.
• If it becomes very humid inside the car.
hould this occur, the unit may malfunction. In this
case, eject the disc and leave the unit turned on for a
few hours until the moisture has evaporated.
How to handle discs
When removing a disc from its
case, press down the center holder
of the case and lift the disc out,
holding it by the edges.
• Always hold the disc by the edges. Do not touch its
recording surface.
When storing a disc in its case, gently insert the
disc around the center holder (with the printed surface
facing up).
• Make sure to store discs in cases after use.
Center holder
Connectors
Contin ed on the next page
EN14-19_KD-R201_003A_2.indd 15EN14-19_KD-R201_003A_2.indd 15 6/17/08 4:51:41 PM6/17/08 4:51:41 PM

16
ENGLISH
To keep discs clean
A dirty disc may not play correctly.
If a disc does become dirty, wipe it with
a soft cloth in a straight line from center
to edge.
• Do not use any solvents (for example, conventional
record cleaner, spray, thinner, benzine, etc.) to clean
discs.
To play new discs
New discs may have some rough spots
around the inner and outer edges. If
such a disc is used, this unit may reject
the disc.
To remove these rough spots, rub the edges with a
pencil or ball-point pen, etc.
ingle CD (8 cm disc) Warped disc
ticker and sticker residue tick-on label
Unusual shape C-thru Disc (semi-
transparent disc)
Transparent or semi-
transparent parts on its
recording area
Do not use the following discs:
More about this unit
Basic operations
Turning on the power
• By pressing RC on the unit, you can also turn on the
power. If the source is ready, playback also starts.
Turning off the power
• If you turn off the power while listening to a disc,
disc play will start from where it had been stopped
previously next time you turn on the power.
Tuner operations
Storing stations in memory
• During M search...
– All previously stored stations are erased and the
stations are stored anew.
– Received stations are preset in No. 1 (lowest
frequency) to No. 6 (highest frequency).
– When M is over, the station stored in No. 1 will
be automatically tuned in.
• When storing a station manually, the previously
preset station is erased when a new station is stored
in the same preset number.
FM Radio Data System operations
• Network-Tracking Reception requires two types
of Radio Data ystem signals—PI (Programme
Identification) and AF (Alternative Frequency)
to work correctly. Without receiving these data
correctly, Network-Tracking Reception will not
operate correctly.
• If a Traffic Announcement is received by TA tandby
Reception, the volume level automatically changes to
the preset level (TA VOL) if the current level is lower
than the preset level.
• When Alternative Frequency Reception is activated
(with AF selected), Network-Tracking Reception is
also activated automatically. On the other hand,
Network-Tracking Reception cannot be deactivated
without deactivating Alternative Frequency
Reception. ( ee page 13.)
EN14-19_KD-R201_003A_2.indd 16EN14-19_KD-R201_003A_2.indd 16 6/17/08 4:51:42 PM6/17/08 4:51:42 PM

ENGLISH
17
Disc operations
Caution for DualDisc playback
• The Non-DVD side of a “DualDisc” does not comply
with the “Compact Disc Digital Audio” standard.
Therefore the use of Non-DVD side of a DualDisc on
this product may not be recommended.
General
• This unit has been designed to reproduce CDs/
CD Texts and CD-Rs (Recordable)/CD-RWs
(Rewritable) in audio CD (CD-DA) formats.
Playing a CD-R or CD-RW
• Use only “finalized” CD-Rs or CD-RWs.
• This unit can play back multi-session discs; however
unclosed sessions will be skipped while playing.
• Some CD-Rs or CD-RWs may not be played back on
this unit because of their disc characteristics or for
the following reasons:
– Discs are dirty or scratched.
– Moisture condensation has occurred on the lens
inside the unit.
– The pickup lens inside the unit is dirty.
– The files on the CD-R/CD-RW are written using the
“Packet Write” method.
– There are improper recording conditions (missing
data etc.) or media conditions (stained scratched
warped etc.).
• CD-RWs may require a longer readout time since the
reflectance of CD-RWs is lower than that of regular
CDs.
• Do not use the following CD-Rs or CD-RWs:
– Discs with stickers labels or protective seal stuck
to the surface.
– Discs on which labels can be directly printed by an
ink jet printer.
Using these discs under high temperature or high
humidity may cause malfunctions or damage to the
unit.
Changing the source
• If you change the source playback also stops
(without ejecting the disc).
Next time you select “CD” for the playback source
disc play starts from where it has been stopped
previously.
Ejecting a disc
• If the ejected disc is not removed within 15 seconds
it is automatically inserted into the loading slot again
to protect it from dust.
• After ejecting a disc “NO DISC” appears and you
cannot operate some of the buttons. Insert another
disc or press SRC to select another playback source.
General settings—PS
• If you change the “AMP GAIN” setting from
“HIGH PWR” to “LOW PWR” while the volume level
is set higher than “VOL 30 ” the unit automatically
changes the volume level to “VOL 30.”
EN14-19_KD-R201_003A_3.indd 17EN14-19_KD-R201_003A_3.indd 17 19/6/08 4:33:11 PM19/6/08 4:33:11 PM

18
ENGLISH
Symptoms Remedies/Causes
General
• ound cannot be heard from the speakers. • Adjust the volume to the optimum level.
• Check the cords and connections.
• The unit does not work at all. Reset the unit (see page 2).
FM/AM
• M automatic presetting does not work. tore stations manually.
• tatic noise while listening to the radio. Connect the aerial firmly.
Disc playback
• Disc cannot be played back. Insert the disc correctly.
• CD-R/CD-RW cannot be played back.
• Tracks on the CD-R/CD-RW cannot be skipped.
• Insert a finalized CD-R/CD-RW.
• Finalize the CD-R/CD-RW with the component which you
used for recording.
• Disc can be neither played back nor ejected. • Unlock the disc (see page 10).
• Eject the disc forcibly (see page 2).
• Disc sound is sometimes interrupted. • top playback while driving on rough roads.
• Change the disc.
• Check the cords and connections.
• “NO DI C” appears on the display.
• “PLEA E” and “EJECT” appear alternately on
the display.
Insert a playable disc into the loading slot.
Troubleshooting
What appears to be trouble is not always serious. Check the following points before calling a service center.
EN14-19_KD-R201_003A_2.indd 18EN14-19_KD-R201_003A_2.indd 18 6/17/08 4:51:45 PM6/17/08 4:51:45 PM

ENGLISH
19
Specifications
AUDIO AMPLIFIER SECTION
Maximum Power Output:
Front/Rear: 50 W per channel
Continuous Power Output (RM ):
Front/Rear: 19 W per channel into 4 Ω,
40 Hz to 20 000 Hz at no more
than 0.8% total harmonic
distortion.
Load Impedance: 4 Ω (4 Ω to 8 Ω allowance)
Tone Control Range:
Bass: ±12 dB at 100 Hz
Treble: ±12 dB at 10 kHz
Frequency Response: 40 Hz to 20 000 Hz
ignal-to-Noise Ratio: 70 dB
Line-Out Level/
Impedance:
2.5 V/20 kΩ load (full scale)
Output Impedance: 1 kΩ
Other Terminal: AUX (auxiliary) input jack
TUNER SECTION
Frequency Range:
FM: 87.5 MHz to 108.0 MHz
AM: MW: 522 kHz to 1 620 kHz
LW: 144 kHz to 279 kHz
FM Tuner
Usable ensitivity: 11.3 dBf (1.0 μV/75 Ω)
50 dB Quieting
ensitivity:
16.3 dBf (1.8 μV/75 Ω)
Alternate Channel
electivity (400 kHz):
65 dB
Frequency Response: 40 Hz to 15 000 Hz
tereo eparation: 30 dB
MW Tuner
ensitivity/ electivity: 20 μV/35 dB
LW Tuner
ensitivity: 50 μV
CD PLAYER SECTION
Type: Compact disc player
ignal Detection
ystem:
Non-contact optical pickup
(semiconductor laser)
Number of Channels: 2 channels (stereo)
Frequency Response: 5 Hz to 20 000 Hz
Dynamic Range: 93 dB
ignal-to-Noise Ratio: 98 dB
Wow and Flutter: Less than measurable limit
GENERAL
Power Requirement:
Operating Voltage: DC 14.4 V
(11 V to 16 V allowance)
Grounding ystem: Negative ground
Allowable Operating
Temperature:
0°C to +40°C
Dimensions (W × H × D): (approx.)
Installation ize: 182 mm × 52 mm × 160 mm
Panel ize: 188 mm × 58 mm × 13 mm
Mass: 1.3 kg (excluding accessories)
Design and specifications are s bject to change witho t
notice.
EN14-19_KD-R201_003A_2.indd 19EN14-19_KD-R201_003A_2.indd 19 6/17/08 4:51:46 PM6/17/08 4:51:46 PM

2
FRANÇAIS
Avertissement:
Si vous souhaitez opérer l’appareil pendant que
vous conduisez, assurez-vous de bien regarder
autour de vous afin de ne pas causer un accident de
la circulation.
Comment réinitialiser votre appareil
• Vos ajustements préréglés sont aussi effacés.
Comment forcer l’éjection d’un
disque
• Faites attention de ne pas faire tomber le disque quand
il est éjecté.
• Si cela ne fonctionne pas, essayez de réinitialiser
l’autoradio.
Merci pour avoir acheté un produit JVC.
Veuillez lire attentivement toutes les instructions avant d’utiliser l’appareil afin de bien comprendre son
fonctionnement et d’obtenir les meilleures performances possibles.
IMPORTANT POUR PRODUITS LASER
1. PRODUIT LASER CLASSE 1
2. ATTENTION: N’ouvrez pas le couvercle supérieur. Il n’y a aucune pièce réparable par l’utilisateur à l’intérieur de
l’appareil; confiez toute réparation à un personnel qualifié.
3. ATTENTION: Rayonnement laser visible et/ou invisible de classe 1 M une fois ouvert. Ne pas regarder
directement avec des instruments optiques.
4. REPRODUCTION DE L’ÉTIQUETTE: ÉTIQUETTE DE PRÉCAUTION PLACÉE À L’EXTÉRIEUR DE L’APPAREIL.
Informations relatives à l’élimination des
appareils et des piles usagés, à l’intention des
utilisateurs
[Union européenne seulement]
Ces symboles signifient que le produit et les piles
ne doivent pas être éliminés en tant que déchet
ménager à la fin de son cycle de vie.
Si vous souhaitez éliminer ce produit et les piles,
faites-le conformément à la législation nationale
ou autres règles en vigueur dans votre pays et votre
municipalité.
En éliminant correctement ce produit, vous
contribuez à la conservation des ressources
naturelles et à la prévention des éventuels effets
négatifs sur l’environnement et la santé humaine.
Notification:
La marque Pb en dessous du symbole des piles
indique que cette pile contient du plomb.
Produits
Pile
FR_KD-R201[EX]f.indb 2FR_KD-R201[EX]f.indb 2 7/24/08 12:17:48 PM7/24/08 12:17:48 PM
