AGA marvel 4EAF Manual

Installaon
Operaon
and
Maintenance
Instrucons
Hazardous Locaon Models
4EAF Freezer
6EAR Refrigerator
6ERF Combinaon Refrigerator / Freezer

CONTENTS
Important Safety Instrucons
Warnings and safety instrucons appearing in this guide are not
meant to cover all possible condions and situaons that may
occur. Common sense, cauon, and care must be exercised when
installing, maintaining, or operang this appliance.
Recognize Safety Symbols,
Words, and Labels.
WARNING-Hazards or unsafe pracces which could result in
personal injury.
CAUTION-Hazards or unsafe pracces which could result in
personal injury or property or product damage.
NOTE
NOTE-Important informaon to make a problem free installa-
on.
1
Unpacking your refrigerator .................................................
Removing the packaging .....................................................
Warranty registraon .........................................................
Installing your refrigerator ...................................................
Select locaon ....................................................................
Installaon ..........................................................................
Cabinet clearances .............................................................
Leveling legs .......................................................................
Electrical Connecon .........................................................
Wiring .................................................................................
Sealing ...............................................................................
Handle installaon ...............................................................
Door alignment ....................................................................
Dimensions for 4EAF, 6EAR, 6ERF ........................................
Rough in opening dimensions for 4EAF, 6EAR, 6ERF ..........
Adjusng the temperature control.......................................
Defrosng instrucons .......................................................
Energy Saving Tips ................................................................
Care and Cleaning ................................................................
Trouble shoong your refrigerator ......................................
Obtaining service ...............................................................
Commercial product warranty ...........................................
2
2
2
3
3
3
3
3
3
3
3
4
4
5
5
6
6
6
7
8
9
10
is commied to building a quality product
in an environmentally friendly manner. Our processes are ghtly
controlled and closely monitored. We have achieved cerca-
ons in ISO 9001 for quality assurance and ISO 14001 for environ-
mental management from Lloyd’s Register Quality Assurance.

Remove Packaging
Your refrigerator has been packed for shipment with all parts
that could be damaged by movement securely fastened. Cut
the banding material at the boom of the carton, unfold the
carton at the boom and remove the carton from the appliance.
Remove the plasc bag, styrofoam corner posts, and any tape
holding the door closed and internal components in place. The
owners manual is shipped inside the refrigerator in a plasc bag
along with the warranty registraon card.
Important
Keep your carton packaging unl your refrigerator has been
thoroughly inspected and found to be in good condion. If there
is damage, the packaging will be needed as proof of damage
in transit. Aerwards please dispose of all items responsibly in
parcular the plasc bags which can be a suocaon hazard.
Note to Customer
This merchandise was carefully packed and thoroughly inspected
before leaving our plant. Responsibility for its safe delivery
was assumed by the retailer upon acceptance of the shipment.
Claims for loss or damage sustained in transit must be made to
the retailer.
DO NOT RETURN DAMAGED MERCHANDISE TO THE MANUFAC-
TURER - FILE THE CLAIM WITH THE RETAILER.
Help Prevent Tragedies
Child entrapment and suocaon are not problems of the past.
Junked or abandoned refrigerators are sll dangerous, even if
they sit out for “just a few days”.
If you are geng rid of your old refrigerator, please follow the
instrucons below to help prevent accidents.
Before you throw away your old refrigerator or freezer:
• Take o the doors or remove the drawers.
• Leave the shelves in place so children may not easily climb
inside.
If the unit was shipped or has been laying on its back for any
period of me allow the refrigerator to sit upright for a period of
at least 24 hours before plugging in. This will assure oil returns
to the compressor. Plugging the refrigerator in immediately may
cause damage to internal parts.
It is important you send in your warranty registraon card im-
mediately aer taking delivery of your refrigerator or you can
register online at www.agamarvel.com.
The following informaon will be required when registering your
unit.
Model Number
Serial Number
Date of Purchase
Dealer’s name and address
The model number and serial number can be found on the serial
plate which is located inside the cabinet on the le side near the
top.
Warranty Registraon
NOTE
UNPACKING YOUR REFRIGERATOR
2

These refrigerators and freezers have been engineered for in-
stuonal and industrial hazardous locaons and meet Under-
writers Laboratories specicaons for Class 1 Groups C and D.
Approved by the New York City Board of Standards and Appeals
under Calendar Number 496-80-SA.
Select Locaon
The proper locaon will ensure peak performance of your ap-
pliance. Choose a locaon where the unit will be out of direct
sunlight and away from heat sources.
The condenser is mounted on the back of the cabinet so the unit
cannot be built in. At least 1-1/2 inches (3.8cm) of clearance
from the back wall is required for proper venlaon.
Installaon
The 4.5 and 6.1 cu. . refrigerators are designed for recessed as
well as freestanding installaon.
To recess the 4.5 and 6.1 cu. . models make the opening
25-7/8” (657.4mm) wide x 35-3/4” (908.1mm) high x 27-1/2”
(698.5mm) deep with ample provision for wiring as described
in the following paragraph “Sealing” instrucons. Other service
informaon can be found on pages 7 and 8. Provisions should be
made to easily remove the unit for servicing.
Do not back the unit up to heat ducts or hot water lines.
Cabinet Clearance
Venlaon is required from the boom front secon of the unit.
Keep this area open and clear of any obstrucons.
Leveling Legs
Adjustable legs at the front and rear corners of the unit should
be set so the unit is rmly posioned on the oor and level from
side to side and front to back. Turn leveling legs clockwise to
raise unit, counterclockwise to lower it. (See Figure 1).
Electrical Connecon
Check serial plate for correct power supply. Use only electrical
power supply as specied on your appliance serial plate.
Wiring
Hazardous locaon models are not supplied with power cords or
plugs. All wiring methods must comply with the latest Naonal
Electrical Code, Arcle 501-4 for Class 1, Divisions 1 and 2.
Leveling Legs
Front Grille, keep
this
area open.
Figure 1
Front Grille
Do not obstruct the front grille. The openings within the front
grille provides air to ow into and exit from the refrigerator
condenser. For this reason it is important this area to not be ob-
structed and be kept clean. AGA MARVEL does not recommend
the use of custom made grilles as air ow may be restricted
because of inadequate openings. (See Figure 1).
Sealing
Arcle 501-5 of the Naonal Electrical Code Class 1, Division 1
requires that in Class 1 Division 1 locaons, seals shall be located
as follows:
In each conduit run entering an enclosure for switches , circuit
breakers, fuses, relays, resistors, or other apparatus which may
produce arcs, sparks, or high temperatures, seals shall be placed
as close as praccable and in no case more than 18” (45.7cm) for
such enclosures.
INSTALLING YOUR REFRIGERATOR
3
Temperature
Control access

Handle Installaon
1. Remove the handle, (2) screws, and 5/32” hex key wrench
from the bag shipped inside the cabinet.
2. Locate handle opposite the hinges and secure in place using
the (2) screws and the hex key wrench.
(See Figure 2).
Screws
Handle
Figure 2
Right hand hinged
door shown
HANDLE INSTALLATION
4
Door Alignment Procedure
The door should be parallel to the sides and top of the refrig-
erator. If alignment is necessary the door may be adjusted
by loosening the 2 screws which secure the hinge adapter
brackets to the door and adjusng the door side to side. Use
a 5/32” hex key wrench for this procedure. (See Figure 3
below).
NOTE: For door closer to work properly it is necessary to main-
tain a minimum space of 9/32” (7.1mm) between door and
cabinet ange as shown. This space can be adjusted by adjusng
the top and boom hinge adapters.
NOTE
Figure 3
Hinge adapter screws loosen
these to adjust door, on the
top and boom of the door
Top hinge pin re-
move to remove
the door.
Door must be
parallel to top
and sides of
refrigerator
9/32”
(7.1mm)
