Rayburn Ranger
Field Service Manual
The information detailed in this guide applies to the Rayburn Ranger electric cooker, at all times the
service technician MUST apply their competencies and ensure the appliance is left safe for continued
use, should the appliance fail any test then engineering judgement must be applied as to whether
the appliance can be left operational.

Contents
Product Overview. ..................................................................................................................................3
General information ...............................................................................................................................3
Cooking zones .........................................................................................................................................4
User control panel...................................................................................................................................5
Roasting Oven and Grill.......................................................................................................................5
Baking/Simmering Oven .....................................................................................................................5
Warming Oven....................................................................................................................................5
Removal and replacement of top plate element and Induction unit.....................................................9
Removal and replacement of Induction unit........................................................................................10
Removal and replacement of side panels.............................................................................................11
Roast oven base and grill element removal,.........................................................................................13
Roast oven base element removal and replacement...........................................................................14
To gain access and remove and replace the warming oven element...................................................15
Access to the grill cooling fan. ..............................................................................................................16
Bottom left oven overheat thermostat. ...............................................................................................16
To gain access to the main terminal block, switches and thermostats................................................17
Switch and Thermostat Identification ..................................................................................................17
Removal and replacement of lid liner...................................................................................................18
Removal and replacement of lid top ....................................................................................................19
Removal and replacement of front plate. ............................................................................................21
Removal and replacement of front plate. ............................................................................................22
Essential Parts.......................................................................................................................................23
Circuit diagram. Rayburn Ranger..........................................................................................................24

Page 3of 25
Product Overview.
The brand new Rayburn Ranger, a fully-electric Rayburn cooker providing flexible, energy-efficient
cooking and stunning styling.
A cast iron hotplate that can be set to boiling or simmering mode.
Two zone Induction hob.
The cooker includes two large capacity radiant ovens plus a warming oven, which operate
independently. It also benefits from a grill,
The Rayburn Ranger vents into the room. We recommend this model is used in conjunction with a
cooker hood. The oven vent outlets are located on top of the Ranger and are designed for venting
the moisture from the ovens.
General information
Regular servicing is not required for this cooker
DO NOT ALTER or MODIFY the appliance.
The appliance warranty does not cover commercial use.
Please refer to the Rayburn Ranger cooker installation instructions for specific information
regarding appliance dimensions, clearances, electrical requirements etc.
Installation instructions and are available to view at
https://www.agaliving.com/sites/default/files/user_guides_uploaded/07-
22%20EINS%20517932%20RAYBURN%20RANGER%20100%20i%20GB_1.pdf
*Important Note*
Before carrying out work on the appliance, the power supply MUST be isolated and tested for safe
electrical isolation.
All electric 2 x 13 amp connections.
The main cooker and the induction unit assembly are electrically tested before leaving the factory.
Always inspect the cooker before any work is carried out and notify the customer of any existing
damage.

Page 4of 25
Cooking zones

Page 5of 25
User control panel.
The Ovens
Roasting Oven and Grill
The upper oven is indirectly heated by two elements, one concealed in the base of the oven and the
other is visible in the roof. These elements heat the lined cavity to provide cooking results consistent
with traditional heat storage ovens, but with the flexibility to turn the ovens off when not in use. The
appliance features three settings Roast, Grill & Bake
Baking/Simmering Oven
The lower oven is indirectly heated by two elements, one concealed in the base and the other visible
in the top of the oven. These elements heat the lined cavity oven to provide cooking results
comparable with traditional heat storage ovens, but with flexibility to turn the oven off when not in
use. The appliance features two settings bake and simmer.
Warming Oven
The Warming oven is indirectly heated by one element which is fitted underneath the oven.
The OVEN IS NOT A HOLDING OVEN and therefore is not designed to hold food at a given
temperature for long periods

Page 6of 25
Essential tools
Always protect the cooker and work area before carrying out any work on the appliance.
Inspect the cooker for any existing damage before starting work.
When undertaking maintenance work on this appliance the engineer should ensure the following
tools are available
Multi meter
Clamp meter
Insulation resistance tester
Tool kit
Torque driver with screwdriver bits
The main electrical terminal block connections on the Rayburn Ranger must be tightened by the use
of a torque screwdriver, please see below for the correct setting.
Main Terminal Block connections 2.5Nm.

Page 7of 25
Removal and replacement of major components
Before carrying out work on the appliance, the power supply MUST be isolated
and tested for safe electrical isolation.
The Rayburn Ranger utilises a wheel system which allows the appliance to be wheeled out from its
position for essential work to be carried out.
When removing the cooker from its position, the front stability feet can be raised with a 13mm
spanner to allow the cooker to be wheeled out from its position.
To gain access to the front stability feet remove the front plinth at the base of the cooker.
Some repairs will require the top plate to be lifted it is recommended to utilise two engineers for
this , the top can be propped ( as shown ) or alternatively one engineer can hold the top upright
while the other engineer carries out the work.

Page 8of 25
To gain access to the underside of the top plate.
To lift the top plate, remove 4 chrome caps covering the corner stay nuts, then remove the 4 corner
stay nuts Fig1.
The top plate can then be lifted upwards from the main chassis,
You can then view the underside of the top plate along with the fitting of the element and the
induction unit.
Fig1. Chrome caps and corner stay nuts x 4

Page 9of 25
Removal and replacement of top plate element and Induction
unit.
To remove the hob element, follow the element leads and unplug the electrical connection plug,
remove the hob element retaining bar on the underside of the element, loosen the 2 screws
securing the thermostat phial to the underside of the element and withdraw the thermostat phial
from the element, the element can then be lifted out of position
.
Replace in reverse order, always remember to refit the earth connection.
Element plug –in connection
Element retaining bar.
Thermostat phial bracket

Page 10 of 25
Removal and replacement of Induction unit.
To remove / replace the induction unit the top plate will need to be lifted and supported, disconnect
the plug –in electrical connection Fig2, then remove induction cover plate and the cable brackets
Fig3.
Fig 2 Fig 3
When the induction unit cover plate is removed this will allow access to the mounting brackets Fig 4
,remove the 4 screws and then carefully remove the springs securing the unit , then gently pull the
induction unit off the brackets Fig 5 and replace in reverse order.
Fig 4. Fig 5.

Page 11 of 25
Removal and replacement of side panels.
To remove the side panels on the Ranger, the cooker will need to be pulled out from its position,
then remove the screws securing the side panel to the back panel, then slide the back panel
backwards approx ½ inch and pull outwards.
When replacing the side panels, locate the cut-outs in the base of the side panel onto the screws in
the cooker base and then slide the side panel back into its position. Fig 6
Side panel screws.
Side panel location screws.
Fig 6

Page 12 of 25
Access to grill and left hand ovens element connections and
grill overheat thermostat.
Fig 7.
When the left hand side panel is removed, this gives access to the left hand oven element
connections as shown in Fig 7.
Always note the configuration of the connections when disconnecting the cables.
Grill element and grill overheat thermostat
connections. The grill overheat is of the auto
reset type
Top oven base
element connections
Bottom Oven top
element connections
Bottom oven base
element connections

Page 13 of 25
Roast oven base and grill element removal,
When removing the elements it is best to remove the door for better access. Lift the door off its
hinge and place in a safe position, then remove. The oven shelf guides by pulling outwards.
To remove the grill element (900watts), remove 2 screws holding the grill support bar, then remove
the 2 screws holding the grill element in position. When the screws have been removed slide the
element to the right hand side, note the configuration of the connections and remove and replace as
necessary. Replace components in reverse order.
Grill element support bar
Grill element securing screws
Grill element securing screws

Page 14 of 25
Roast oven base element removal and replacement.
When removing the roast oven base element (300 watts) it is recommended to remove the oven
door for better access and then remove the oven shelf guides. The element is positioned below the
oven base plate. Pull the base plate forward and lift on one side and pull out of the oven cavity
Fig10.
Remove the two screws securing the element to the oven cavity and then slide the element out
Fig11. Replace components in reverse order.
Fig10. Fig11.
The elements in the lower left oven (2 x300 watts) can be accessed and exchanged in a similar way
as the top left oven elements. Fig 12 & 13.
Fig 12. Lower left oven top element. Fig13.Lower oven base element.

Page 15 of 25
To gain access and remove and replace the warming oven
element.
The warming oven element (100 watts) is fixed to the bottom of the warming oven, to gain access to
the warming oven element, the side panels and the back panel will need to be removed. Then the
insulation will need to be removed, the element can then be removed from the underneath of the
oven. The new element can then be fixed into position and then route the element cables back to
their connections in the back of the control box.
Remove the insulation to gain access to warming oven element
The element is attached to the base of the oven.

Page 16 of 25
Access to the grill cooling fan.
To gain access to remove and replace the cooling fan, the Ranger will need to be pulled out from its
position and then remove the top plate, side panels and back plate. This will allow access to the four
screws holding the fan in its position. Disconnect the fan connection plug and then remove the bolt
securing the earth connection and then remove the four securing screws holding the fan in position.
Bottom left oven overheat thermostat.
To gain access to the bottom oven overheat thermostat, the side panels and back panel will need to
be removed. The thermostat is located on the back of the oven cavity and is of the manual
resettable type.
Securing screws

Page 17 of 25
To gain access to the main terminal block, switches and
thermostats.
Remove the four chrome decorative caps, then remove the 4 screws beneath the chrome caps and
then remove the 2 control knobs. Hold the glass whilst doing this and then pull down the panel
gently towards you.
When the glass panel is pulled out this will give access to the warming oven switch, take a note or a
photo of the configuration of the wiring of the switch and then remove the red and blue spade
connections that feed the neon on the switch. Then unclip the main body of the switch from the
push button that is left on the glass control panel. Remove the glass and place in a safe position.
Once the glass has been removed and placed in a safe position, remove the 2 screws securing the
switch mounting plate to the chassis. The switch mounting plate is hinged and then lower down to a
resting position. You will then see the main terminal block, switches and thermostats.

Page 18 of 25
Switch and Thermostat Identification

Page 19 of 25
Removal and replacement of lid liner.
Lift the lid and remove the rope seal, also remove all of the old sealant securing the rope in place.
When the rope is removed, slide the liner down and then lift out of position. This will also give
access to the lid insulation and the lid top cover screws.

Page 20 of 25
Removal and replacement of lid top
To remove the top of the Ranger lid, remove the 4 screws as shown below, then the lid top can be
pulled away from the frame, replace in reverse order.
Screws for removal of lid top.
