AGA Glide-out Operating manual

Legacy
Glide-out™ Broiler Kit
ArtNo.000-0003 Slide out grill pan
Installation and Use Guide
U109500 - 02

2

3
Contents
Installing your Glide-out™ Broiler Page 4
Using the Glide-out™ Broiler Page 8
Cleaning your Range Page 9
Troubleshooting Page 10
General Safety Instructions Page 10

4
Installing your Glide-out™ Broiler
Your new Glide-out™ Broiler kit consists of:-
Two sliding side rails. A grill pan support frame with handle. And a new broiler pan and grid.
Fitting the parts
1 If you look closely at the
two telescopic sliding
side rails in the kit you
will see that they are
dierent – one ts on
the left hand side and
the other on the right
hand side.
2 This is the left hand side
slide rail.
"sh hook" shaped part
3 Open the broiler compartment door and
remove the old broiler pan.
Look in the broiler chamber. At the back is
the rear shelf and at each side is a thick wire
side support.
rear shelf
wire side supports
4 Pull the left hand side slide rail fully open and hold it with the ‘sh hook’ shaped part pointing
upwards.

5
5 Place the side slide rail in the broiler chamber with
the hook at the back behind the front lip of the rear
shelf.
6 Lift it up and hook it onto the wire side
support.
7 Rotate the side rail so that it now hangs down from the side support.
8 At the front lift the side slide rail and hold it so
that the front clip is just in front of and above
the front part of the side support wire.
9 Move the side slide rail back and push the front
clip down.
The front part of the clip should be in front and
the long tongue should go down behind the
support wire.
The side slide rail should now be securely held hanging down from the side support wire, hooked on
at the back and clipped on at the front. It should slide smoothly in and out. Push it back out of the way
for the moment.

6
10 Repeat the procedure at the right hand side of the broiler chamber to x the other side slide rail in
place.

7
11 The broiler should never be used with the
broiler door closed. There is a warning label
about this in the kit.
Find it and x it to the inside face of the grill
door, so that anyone using the grill can see the
label.
Separate the label from the backing paper and
stick it in place.
12 Find the broiler pan support frame.
It should be this way up with the back and
front parts standing up above the sides.
13 Pull both side sliders forward.
Make sure that they are both pull forward the
same amount. This is important because the
frame will not t properly otherwise.
Notice that there are two clips at each side.
14 Clip the support frame to the sliders with the
handle at the front. There are two clips at each
side - they may be a little sti. Press the frame
down into place.
ArtNo.331-0003 Grill frame out, no pan
15 There is a second warning label stuck to the
inside of the broiler pan.
Before using the new broiler pan, wash it in
soapy water and remove the label.
Dry the broiler pan and place it on the support
frame.
Make sure that the wide rim at the front.
ArtNo.000-0003 Slide out grill pan

8
Your Glide-out™ Broiler is now fully
assembled but before using it for the rst
time, make sure that all packing materials
have been removed and then to dispel
manufacturing odours, turn on the grill and
run for 30 minutes with the broiler pan in
position, pushed fully back, and the broiler
door open.
Make sure the room is well ventilated to
the outside air, by opening windows or
turning on a range hood for example. We
recommend that people with respiratory or
allergy problems should vacate the area for
this brief period.
Please dispose of your old broiler pan and
broiler pan grid responsibly.
Using the Glide-out™ Broiler
Caution: Accessible parts may be
hot when the broiler is in use. Young
children should be kept away.
Using the broiler
Open the broiler door and pull the broiler pan
carriage forward using the handle.
ArtNo.000-0003 Slide out grill pan
The Broiler pan gets very hot when the broiler
is on. Don't touch the pan or broiler pan grid
unless you are sure it is cool.
After placing your food on the broiler grid, slide the
broiler carriage into the broiler chamber. Make sure
it is pushed right in.
Never close the broiler door when the
broiler is on.
The new broiler grid has been designed to adjust
for the slightly raised broiler pan position. It can be
turned over to give two cooking positions.
ArtNo.331-0002 Grill pan high/low position
Don’t leave the broiler on for more than a few
moments, without the broiler pan underneath
it.
For best results, especially with toast, preheat
the grill with the broiler pan in the cooking
position for two minutes before use.
Before you remove any of the broiler parts
for cleaning make sure that they are cool or
use oven gloves.
The broiler grid can be removed and the food
placed on it while you are waiting for the
broiler to preheat.
When you pull the broiler pan forward is the
wide rim at the front? It's important that the
wider part is at the front.
ArtNo.331-0006 Grill pan plan
Please note
Although it is possible to use the old broiler
pan, with the handle, on your new Glide-out™
Broiler we do not recommend this.
It is not possible to store the old broiler pan
in the bottom of the broiler chamber without
unclipping the broiler frame from the slide rails
every time. It is not a good idea to unclip the
frame more than necessary.

9
Cleaning your Range
Essential information
Before thorough cleaning isolate the electricity
supply. Remember to switch on the electricity
supply and reset the clock before using the
range.
Never use paint solvents, washing soda,
caustic cleaners, biological powders,
bleach, chlorine based bleach cleaners,
coarse abrasives or salt. Don’t mix dierent
cleaning products - they may react together
with hazardous results.
Do not use a steam cleaner on your range.
All parts of the range can be cleaned with hot
soapy water - but take care that no surplus
water seeps into the appliance.
Glide-out™ Broiler
Before you remove any of the broiler parts
for cleaning make sure that they are cool.
The broiler pan and grid should be washed in
hot soapy water. After cooking meats or any
foods that soil, leave to soak for a few minutes
in the sink immediately after use. Stubborn
particles may be removed from the grid by
using a nylon brush. Alternatively the broiler
pan can be washed in a dish washer.
To remove the broiler pan support frame, pull
the broiler pan forward.
ArtNo.331-0001Grill pan pulled forwards
Lift the broiler pan clear of the support frame.
The support frame is held to the side rails by
two clips on each side.
ArtNo.331-0003 Grill frame out, no pan
For each side, support the side rail with one
hand and with the other hand lift the frame up
and out of the side clips.
ArtNo.331-0004 Removing the grill frame
For safety, push the side rails back into the
broiler chamber.
The side rails can be removed to make cleaning
the broiler chamber easer. Lift the front of the
side rail and unclip it from the side support.
Turn the rail and unhook it at the back.
Slides can be wiped clean with soft cloth and
mild detergent.
Do not use any abrasive substance.
DO NOT put the side runners in a dishwasher
When you have nished replace the parts as
shown in the installation instruction at the
front of the book.

10
Troubleshooting
Broiler not cooking properly
Are you using the pan and trivet supplied
with the range? Is the pan being used on the
runners, not the oor of the compartment? Is
the broiler pan pushed fully back to stop?
ArtNo.331-0006 Grill pan plan
When you pull the
broiler pan forward
is the wide rim at the
front? It's important
that the wider part is
at the front.
The knobs get hot when I use the grill, can I avoid
this?
Yes, this is caused by heat rising from the
broiler, and heating them up. Make sure that
the broiler pan is pushed right back to the‘back
stop’ when cooking.
General Safety Instructions
Never close the broiler door when the grill is
on.
This appliance is designed for domestic
cooking only. Use for any other purpose could
invalidate any warranty or liability claim.
Ensure that the kitchen is well ventilated:
keep natural ventilation holes open or install
a mechanical ventilation device, (mechanical
extractor hood).
Prolonged intensive use of the appliance
may call for additional ventilation, for
example opening a window, or more eective
ventilation, for example increasing the level of
mechanical ventilation where present.
All parts of the range become hot with use and
will retain heat even after you have stopped
cooking.
Take care when touching range, to minimize
the possibility of burns, always be certain that
the controls are in the OFF position and that it
is cool before attempting to clean the range.
Use dry oven gloves when applicable - using
damp gloves might result in steam burns when
you touch a hot surface. Never operate the
range with wet hands.
Do not use a towel or other bulky cloth in place
of a glove. They might catch re if they touch a
hot surface.
Clean with caution. If a wet sponge or cloth is
used to wipe spills on a hot surface, be careful
to avoid steam burns. Some cleansers can
produce noxious fumes if applied to a hot
surface.

11
Babies, toddlers and young children should not
be allowed near the range at any time. They
should never be allowed to sit or stand on any
part of the appliance. Teach them not to play
with controls or any other part of the range.
Never store anything of interest to children in
cabinets above a range -children climbing on
the range to reach them could be seriously
injured.
In the interests of hygiene and safety the range
should be kept clean at all times as a build up
in fats and other food stu could result in a re.
Always keep combustible wall coverings or
curtains etc. a safe distance away from your
range.
Do not spray aerosols in the vicinity of the
range while it is in on.
Do not store or use combustible materials,
or ammable liquids in the vicinity of this
appliance.
Do not use water on grease res. Never pick up
a aming broiler pan. Turn the controls o. If
available use a multipurpose dry chemical or
foam-type re extinguisher.
Never wear loose-tting or hanging clothes
while using the appliance. Be careful when
reaching for items stored in cabinets over the
hotplate. Flammable material could be ignited
if brought in contact with a hot surface unit
and may cause severe burns.
Do not use the top of the ue (the slot along
the back of the range) for warming plates,
dishes, drying tea towels or softening butter.
Take care that no water seeps into the
appliance
Do not allow anyone to climb, stand or hang on
any part of the range.
Do not use aluminium foil to cover shelves,
linings or the oven roof.
The range is designed for cooking foods only
and must not be used for any other purpose.
The oven should NOT be used for heating the
kitchen, not only does this waste fuel but the
control knobs may become overheated.
When the broiler is not in use ensure that the
control knob is in the o position.

AGA Marvel
1260 E. VanDeinse St.
Greenville, MI 48838
Business [phone]
Fax: [phone]
Toll Free Telephone [phone]
www.agamarvel.com
