AgfaPhoto Microflex 102 User manual

Microflex 102
User manual

Contents
Disclaimer.......................................................................6
Trademark Recognition...............................................6
Federal Communications Commission (FCC)
Compliance ....................................................................6
Declaration of Conformity ..........................................7
Disposal of Waste Equipment by Users in Private
Households in the European Union.........................8
Precautions....................................................................9
1General Introduction.............................11
1.1 System Requirements.....................................11
1.2 Features..............................................................11
1.3 Accessories.......................................................12
1.4 Camera View......................................................13
1.5 Adjusting the LCD Display.............................14
2Getting Started....................................... 15
2.1 Inserting an SD Card.......................................15
2.2 Inserting the Batteries.....................................15
2.3 Charging the Battery .......................................18
2.4 Using the Touchscreen...................................19
2.4.1 Single Touch.............................................19
2.4.2 Scroll..........................................................20
2.4.3 Rotate........................................................20
1

2.5 Buttons & Functions .......................................21
2.6 About LED Indicators......................................23
2.7 Initial Settings Before Use .............................23
2.7.1 Setting the Date and Time......................23
3LCD Display Information..................... 25
3.1 In Movie Clip Mode...........................................25
3.2 In Voice Recording Mode...............................27
3.3 In DSC Mode......................................................28
4Using the Camera.................................. 30
4.1 Recording Movie Clips....................................30
4.2 Capturing a Still Image from a Movie..........32
4.3 Capturing a Still Image in Video Mode........33
4.4 Voice Recording...............................................34
4.5 Movie Clip / Voice Clip Playback..................35
4.6 Taking / Playing Back Photos .......................37
4.6.1 Taking Photos...........................................37
4.6.2 Playing Back Photos................................38
5LCD Display Information..................... 41
5.1 Movie Clip Recording Mode...........................41
5.2 Voice Recording Mode....................................43
5.3 DSC Playback Mode ........................................44
6Menu Mode.............................................. 46
6.1 Menu Options in Movie Clip Mode...............46
2

3
6.1.1 Video Clip Resolution..............................46
6.1.2 White Balance ..........................................47
6.1.3 Effect..........................................................48
6.1.4 Metering ....................................................49
6.1.5 Backlight....................................................50
6.1.6 Night Mode................................................51
6.1.7 Motion Detection......................................52
6.1.8 EV Compensation....................................53
6.1.9 Multi Shot..................................................54
6.2 Movie Clip/Voice Playback Menus...............55
6.2.1 Delete ........................................................55
6.2.2 Protect.......................................................56
6.2.3 Infrared Night Vision................................57
6.3 Camera Mode Menu Options.........................57
6.3.1 Still Image Resolution..............................57
6.3.2 White Balance ..........................................58
6.3.3 Effect..........................................................59
6.3.4 Metering ....................................................60
6.3.5 Backlight....................................................61
6.3.6 Night Mode................................................61
6.3.7 Self-Timer..................................................62
6.3.8 Continuous Shot.......................................63
6.3.9 EV Compensation....................................64
6.4 Playback Menus................................................65
6.4.1 Delete ........................................................65
6.4.2 Protect.......................................................67

4
6.4.3 Autoplay ....................................................68
6.4.4 Rotate........................................................69
6.4.5 DPOF.........................................................70
6.5 Settings Menu ...................................................71
6.5.1 Information................................................71
6.5.2 Date / Time................................................72
6.5.3 Beep...........................................................72
6.5.4 Default.......................................................73
6.5.5 TV Standard..............................................74
6.5.6 USB............................................................75
6.5.7 Auto Power Off.........................................75
6.5.8 Frequency.................................................76
6.5.9 Language..................................................77
6.5.10 Format.......................................................78
6.5.11 File Number (Default: Series).................79
6.5.12 LCD Brightness........................................80
6.5.13 Instant Review..........................................81
6.5.14 Memory .....................................................82
6.5.15 Volume.......................................................83
6.5.16 Start-Up Logo ...........................................84
6.5.17 Face Detection.........................................85
7PC and TV Connection......................... 86
7.1 Connecting to a Computer.............................86
7.2 Connecting to a Standard TV........................86
7.3 Connecting to an HD TV.................................87

8Installing the Software......................... 88
9Editing Software.................................... 89
10 Appendix ................................................. 90
Specifications..............................................................90
Troubleshooting..........................................................92
Customer Care.............................................................94
5

6
This manual is designed to assist you in using your new AgfaPhoto
digital video camera. All information presented is as accurate as
possible but is subject to change without notice.
Disclaimer
This manual contains proprietary information protected by copyright.
All rights are reserved. No part of this manual may be reproduced by
any mechanical, electronic or other means, in any form, without prior
written permission of the manufacturer. © Copyright 2009
Trademark Recognition
Windows 98/2000/ME/XP are registered trademarks of Microsoft
Corporation in the United States and/or other countries. Windows is
an abbreviated term referring to the Microsoft Windows Operating
System. YouTube is a brand of Google, Inc. and YouTube, LLC,
Mountain View, California, US. All other companies or product names
are trademarks or registered trademarks of their respective
companies.
Federal Communications Commission
(FCC) Compliance
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or

7
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the distance between the equipment and the receiver.
• Connect the equipment to an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
Warning: A shielded-type power cord is required in order to meet
FCC emission limits and to prevent interference to radio and
television reception. Use only ashielded cable to connect I/O devices
to this equipment. Any changes or modifications not expressly
approved by the manufacturer may void your warranty and service
agreement.
Declaration of Conformity
This device complies with Part 15 of the FCC rules.
Operation is subject to the following conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including
interference that may cause undesired operation.

8
Disposal of Waste Equipment by Users in
Private Households in the European
Union
This symbol on the product or on its packaging indicates that this
product must not be disposed of with your other household waste.
Instead, it is your responsibility to dispose of your waste equipment
by handing it in to a designated collection point for the recycling of
waste electrical and electronic equipment.
The separate collection and recycling of your waste equipment at
the time of disposal will help to conserve natural resources and
ensure that it is recycled in a manner that protects human health and
the environment. For more information about where you can drop off
your waste equipment for recycling, please contact your local city
office, your household waste disposal service or the shop where you
purchased the product.

9
Precautions
General precautions
• Do not try to disassemble the product yourself, which may
damage the product or cause electric shock.
• Keep the camera away from children and animals to prevent
them from swallowing the batteries or small accessories.
• Stop using the camera if any kind of liquid or foreign object
enters it. If this happens, power off the camera and contact
your dealer for help.
• Do not operate the camera with wet hands: this may cause
electric shock.
• The camera may be damaged in a high-temperature
environment. This camera is designed for use in a temperature
range of between 0°C and 40°C (32°F and 104°F).
• Do not use or store the product in a dusty, dirty or sandy place
or in an area that is close to air-conditioning or heaters.
• It is normal that the temperature of the camera body rises if the
camera is in operation for a long period of time.
• Do not open the battery cover whilst an image is being
recorded. Doing so will not only make storage of the current
image impossible, but it may also corrupt other image data
already stored.
• Before using this camera for important occasions (such as
weddings or overseas trips), be sure to test it in order to ensure
proper operation.
