AgfaPhoto DC-630 User manual

DC-630
User manual
RZ-AGFAP-06-004-UserM630-VS.indd1 1 20.09.2006 18:41:48 Uhr

- 1 -
Thank you for purchasing this DC-630 digital camera. Please read these operating instructions
carefully in order to use the product correctly. Keep the instructions in a safe place after reading
so that you can refer to them later.
Disclaimer
We assume no responsibility over and above the provisions of the Product Liability Law for damages
suffered by the user or third parties as a result of inappropriate handling of the product or its
accessories, or by their operational failure and by their use. We reserve the right to make changes to
this product and its accessories without prior notice.
Warning! Never try to open the camera or to take it apart. This will invalidate all guarantee claims.
Using Your Batteries
For best performance and prolonged battery life, we recommend the use of AA lithium or
rechargeable
Ni-MH batteries.
Extending battery life
The following functions use up a great deal of battery power and should therefore only be
used occasionally:
• Excessive use of flash
• Editing images on the camera display
• Using the camera display as a view finder
The battery life can be affected by soiling. Please clean the contacts with a clean and dry cloth
before putting the batteries in the camera.
Battery performance drops at temperatures below 5 °C (41 °F). If you use the camera at low
temperatures you should have replacement batteries to hand and ensure they do not get too cold.
Please note: you should not dispose of cold and seemingly flat batteries because these batteries
may work again at room temperature.

- 2 -
Disposal of Waste Equipment by Users in Private Households in the European Union
This symbol on the product or on its packaging indicates that this product must not be
disposed of with your other household waste. Instead, it is your responsibility to dispose of
your waste equipment by handing it over to a designated collection point for the recycling of
waste electrical and electronic equipment. The separate collection and recycling of your waste
equipment at the time of disposal will help to conserve natural resources and ensure that it is
recycled in a manner that protects human health and the environment. For more information
about where you can drop off your waste equipment for recycling, please contact your local
city office, your household waste disposal service or the shop where you purchased the
product.
Declaration of Conformity
We herewith confirm the following designated product: DC-630 has been tested and found to comply
with the requirements set up in the council directive on the approximation of the low of members
states relating to the EMC Directive 89/336/EEC, amended by 92/31/EEC & 93/68/ EEC. For the
evaluation regarding to the electromagnet compatibility, the following standards were applied
EN 55022:1998+A1:2000+A2:2003, Class B
EN 61000-3-2 edition 2:2000
EN 61000-3-3:1995+A1:2001
EN 55024:1998+A1:2001+A2:2003
IEC 61000-4-2:1995+A1:1998+A2:2001
IEC 61000-4-3:2002+A1:2002
IEC 61000-4-4:1995+A1:2001+A2:2001
IEC 61000-4-5:1995+A1:2001
IEC 61000-4-6:2004
IEC 61000-4-8:1993+A1:2001
IEC 61000-4-11:1994+A1:2001
The device is marked with CE Logo

- 3 -
FCC Compliance and Advisory
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1.) this device may not cause harmful interference, and 2.) this device must accept any interference
received, including interference that may cause unsatisfactory operation.
This equipment has been tested and found to comply with the limits for a Class B peripheral, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communication. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures.
 Reorient or relocate the receiving antenna.
 Increase the separation between the equipment and receiver.
 Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
 Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment. When shielded interface cables have been provided
with the product or when specified additional components or accessories have elsewhere been
designated to be used with the installation of the product, they must be used in order to ensure
compliance with FCC regulations.

- 4 -
Safety Information
 Before using the camera, please ensure that you read and understand the safety precautions
described
below. Always ensure that the camera is operated correctly.
 Do not aim the camera directly into the sun or other intense light sources which could damage your
eyesight.
 Do not try to open the case of the camera or attempt to modify this camera in any way. High-voltage
internal components create the risk of electric shock when exposed. Maintenance and repairs should
be carried out only by authorized service providers.
 Do not fire the flash too close to the eyes of animals or people, especially for young children. Eye
damage may result. In particular, remain at least one meter away from infants when using flash.
 Keep the camera away from water and other liquids. Do not use the camera with wet hands. Never
use the camera in the rain or snow. Moisture creates the danger of fire and electric shock.
 Keep the camera and its accessories out of the reach of children and animals to prevent accidents or
damage to the camera.
 If you notice smoke or a strange odor coming from the camera, turn the power off immediately.
Take the camera to the nearest authorized service center for repair. Never attempt to repair the
camera on your own.
 Use only the recommended power accessories. Use of power sources not expressly recommended
for this equipment may lead to overheating, distortion of the equipment, fire, electrical shock or other
hazards.

- 5 -
