User Guide
System DECT 30
System Phone

About this User Guide
This user manual is intended for the telephone system with the firmware installed at the time of
shipment. As the DECT30 Cordless System Phone is controlled from the telephone system certain
features described in this manual may no longer apply if the system firmware is changed.
This manual contains user instructions for the DECT 30 Cordless System Phone and a brief
reference regarding the system features. A detailed description of features relating to the telephone
system can be found in the user guide of the telephone system.
The AGFEO DECT 30 Cordless System Phone is designed for the connection / registration to an
AGFEO DECT-Module or AGFEO DECT-SO-Base.
AGFEO GmbH & Co. KG will not accept any liability whatsoever for any damages which may be
caused by improper use of the DECT 30 Cordless System Phone.
User Instruction

System DECT 30
3
User Instruction .................................................................................................................................... 2
About this User Guide ........................................................................................................................... 2
This Pack Contains: .............................................................................................................................. 4
Charging the Battery Pack .................................................................................................................... 4
DECT 30 Handset ................................................................................................................................... 5
Buttons of the DECT 30 Cordless Phone .............................................................................................. 6
DECT 30 Display ..................................................................................................................................... 7
Status Display ........................................................................................................................................ 7
Display of Features Set .......................................................................................................................... 7
Switch Handset ON / OFF .................................................................................................................... 8
Keypad Lock ........................................................................................................................................... 8
Ringer Switch ........................................................................................................................................ 8
Telephone Settings ................................................................................................................................ 9
Register DECT 30 to Base Unit ............................................................................................................ 10
DECT Delete Registration .................................................................................................................... 11
Delete Registration in Telephone System ........................................................................................... 11
Delete Registration in DECT 30 Handset ............................................................................................. 11
Function Buttons- Overview of freely programmable Function Buttons .......................................... 12
Function Button Assignment .............................................................................................................. 14
Store / Change a Function .................................................................................................................. 14
Making Calls ........................................................................................................................................ 14
Exchange Line Seizure „Direct“......................................................................................................... 14
Exchange Line Seizure with „9“......................................................................................................... 15
Call Log ................................................................................................................................................ 15
Store an Entry ...................................................................................................................................... 16
Calling Stored Number (or Delete) ...................................................................................................... 16
Phone Book of the DECT 30 ................................................................................................................ 16
Cleaning the DECT 30 ......................................................................................................................... 17
Accessories /Range ............................................................................................................................. 17
Rechargeable Battery .......................................................................................................................... 17
Battery Replacement ........................................................................................................................... 17
Changing the Battery .......................................................................................................................... 18
Declaration of Conformity ................................................................................................................... 19
Table of Contents

System DECT 30
4
ThisPack Contains:
Charging the Battery Pack
1 System DECT 30 Cordless Handset
1 Rechargeable Battery Pack
1 Charging Cradle with Plug In Power Supply
1 User Manual
NOTE: The supplied battery has not been charged.
To charge the battery insert the handset in the charging cradle of the DECT 30. The charging status
will be shown in the display of the phone. However, the display may remain without any indication
for a few minutes if the battery will be charged for the first time. The handset will sound a beep
once the battery has been fully charged.
- NOTE: The first initial charge should be carried out for at least 16 hours - regardless of the
charging status display.
- After the initial charge you may return the handset into the charging cradle after each call. The
charging of the battery is electronically controlled to guarantee an optimal and gentle charging
process.
- The battery may get warm during charging.
An even longer battery life can be achieved if you discharge the battery completely every so often. To
discharge the battery, leave the handset switched on until this will switch off by itself.

System DECT 30
5
DECT 30 Handset
AGFEO
ABC DEF
JKL
GHI MNO
PQRS TUV WXYZ
Volume Control
Earpiece
LED Indicator
Browse
Last Number Redial
Stop
Programming
Illuminated Display
Browse
Phone Book
Confirmation
Call Log / Set Features
2nd Level
Recall
Delete
Initiate or End Call
Keypad Lock
Headset Connection Microphone
Ringer Off
Mute (not used)
Keypad / Characters
programmable Buttons
CLR
DECT 30
<>
OK
ALT
R
23
1
5
46
789
0

System DECT 30
6
Buttons of the DECT 30 Cordless Phone
1...0
N L
I J
H
A
K
D
B
A B
G
Keypad - to dial or enter data
Arrow Buttons - To browse through the
display
OK - To confirm entry
Alt - To initiate a function within the
telephone system. To go to 2nd keypad
level. To use the freely programmable
function buttons. To switch to Phone
Book.
Recall - Enquiry or Brookers Call.
Answer or End a Call. Quit a function.
Phone Book -Access DECT 30 Phone
Book.
ALT Phone Book - Access phone book of
telephone system. (Central Dialling)
Messages - Currently without function.
ALT Mail - To access Call Log,
Answering Machine and to check
active features in the telephone
system.
Last Number Redial - To use LNR of
the DECT 30 handset.
ALT Last Number Redial - use LNR of
the telephone system.
Programming - To program functions
of the DECT 30 handset.
ALT Programming - To program
functions of the telephone system.
Key - Used to lock keypad.
without function
Bell - Switch off tone ringer. Incoming
calls will be signalled by vibration or
visual in display.
Clear - Delete an entry.
A G
P
A P
Q
A Q
Q M
O
Q E
A C

System DECT 30
7
BRI ISDN trunk line. One line (one B-Channel) is in use. The x will be flashing on an incoming
call.
BRI ISDN trunk line. Both channels of the line are in use.
ISDN Extension line. One line (one B-Channel) is in use.
ISDN Extension line. Both channels of the line are in use.
Both B-channels of the ISDN – line are available. (Extension or BRI trunk line)
Extension, Static: Extension is busy, Flashing: Extension is ringing.
x
X
i
I
-
12
DECT 30 Display
Status Display
Display of Features Set
Call Waiting ON
Do Not Disturb (DND) ON
Diversion / ISDN-Diversion ON.
Call Forwarding / Alternative Extension ON
Night Service
Appointment Reminder ON.
Wake Up Call ON
CallLog
Answering Machine (AGFEO A-Module 30 only)
Sensorenabled
K
R
U
E
N
T
W
L
A
S
To access ALT-Display press ALT button once.
DECT 30 is off hook and has a radio connection to the system
Browse trough menu
DECT 30 is within reach of base station
Status Indication of S0 Connection
Extension Status
ALT-Display
Indicates the features enabled
active WRL

System DECT 30
8
Switch Handset ON / OFF
Switch to ON:
Press the call button for 1 second
Switch OFF:
Press the OK button for 3 seconds
The DECT 30 will switch ON after the battery is
connected and the handset is inserted into the
chargingcradle.
KeypadLock
Enable the keypad lock by pressing the SET Button
follwed by the STAR * button.
Disable the keypad lock by pressing the SET But-
ton follwed by the STAR * button.
Pressing any buttons will have no functions when
the keypad is locked.
To answer a call press the „call button“, the
keypad lock is automatically disabled during a call.
D O
H O
Q N
Q N
1 sec.
1 sec.
Ringer Switch
To switch the ringer off press the SET Button
followed by the #-Button.
To switch the ringer back to on press the SET
Button followed by the #-Button.
Q L
Q L

System DECT 30
9
TelephoneSettings
Press the „Set“ button longer to change the settings of the DECT 30 Cordless System Phone:
Note, two different user profiles can be set in the menu PROFILE SET UP.
Each of the profiles will have the following settings available:
- Tone Ringer: Will set the various ring tones.
- Ringer Volume: 5 Volume settings are available.
- Keypad Click: Here you can set if a click should be heard on pressing a button on the keypad.
- Vibrator: To switch the vibration alarm on or off.
- Auto Answer: Will answer an incoming call automatically. This feature is useful if a headset is
worn by the user and each call wants to be answered without pressing a button.
- Charging Cradle: Will set if a call should be answered if the ringing DECT 30 is lifted out of the
chargingcradle.
- Handset Volume: Here the volume can be set in 5 steps.
- Range: Will set if a warning tone should sound once the handset is out of range of the DECT base
station.
- Illumination: Background illumination of the Display area can be set here.
- Keypad Lock: Will set if the keypad lock should activate automatically after 1 minute.
The menu LOGIN offers following selection:
- 10 DECT Base Stations to be stored and selected,
- to register your DECT 30 to another Base Station,
- to delete Base Stations from your DECT 30 handset.
Telephone Settings
Press the „Set“ button.
Select using the arrow buttons the Menu „Profi-
le“. Confirm the selection with „OK“.
Select by using the arrow buttons the profile to
which the changes should apply. Confirm the
selection with „OK“.
You now can select the above described settings.
The required section is selected by pressing
„OK“, use the arrow buttons to change the
setting.
By pressing „Ok“ the required setting will be
stored.
To leave this programming menu press briefly the
„Set“ button.
Q
IJH
IJH
IJ
H
IJ
H
Q
9

System DECT 30
10
Register DECT 30 to Base Unit
The DECT 30 handset can be registered to a
maximum of 10 Base Units.
Should you only have one base unit, then you may
ignore this point and all other relating infor-
mation regarding the selection of a base unit.
Should you have more than one base unit in use
with your telephone system, then you select the
base unit to which you want to register the DECT
30 handset to. The base unit can be allocated by
use of the Identnumber. (Sticker on module or
indication in display)
First switch your DECT Base to registration mode
as described in the user manual of your DECT
SO-Base or DECT Module.
Press the „Set“ button on the DECT 30.
Using the arrow buttons select the menu LOGIN
and confirm with „OK“.
With the arrow buttons go to the menu
„SUBSCRIPTION CREATE“ and confirm with
„OK“. The DECT 30 will now search for a base
unit which is in registration mode.
Once a base is found, then this will be shown in
the display area. You may select the required base
with the arrow buttons should more than one
base be in registration mode. Confirm selection
by pressing „OK“
Use the arrow buttons select the required
location. Enter the system PIN if so required
(default is 2580) and confirm with OK.
The DECT 30 is now registered to the base unit.
Q
IJ
H
IJ
H
H
H

System DECT 30
11
DECT Delete Registration
11
A registration may be deleted at any time. For this the registration will have to be deleted in the
telephone system first and then in the DECT 30 handset.
Delete Registration in Telephone System
Enter programming mode.
Enter system PIN after „9“, if this has been
enabled.
Use the arrow buttons to display the DECT
handset which you want to deregister from the
base unit. Confirm by pressing „OK“.
The DECT phone is now deregisterd from the
base.
AQ9L z713
IJ
H
( )
enter System PIN if applicable
Delete Registration in DECT 30 Handset
Q
IJ
H
IJ
H
IJ
H
H
On the DECT 30 press the button „Set“.
Using the arrow buttons go to the menu LOGIN
and confirm with „OK“.
Continue with the arrow buttons and select
„SUBSCRIPTION REMOVE“ and confirm with
„OK“.
Select the base unit which you would like to
delete from the DECT 30 and confirm by pressing
„OK“.
Confirm the final request with „OK“.
The base unit is now deleted from the DECT 30.

System DECT 30
12
FunctionButtons-Overviewoffreely
programmableFunctionButtons
To switch the answering machine of the System Phone ST 30 / ST 40 on or off. This
will only function from another telephone if the notification to this phone has been
enabled. (Info to Systels)
Interrogation of answering machine.
To record memos or a two way telephone conversation.
Reject current call. The caller will hear busy tone. (depending on programming,
not applicable for analogue trunk)
Enable / Disable Call Waiting / Call Waiting Tone
To set the Call Filter
To display the Call Log.
Will switch off the Tone Ringer
Following function can be programmed to a button:
- DND from Extension
- DND from Incoming Calls
- DND Incoming and Extension Calls
Switch the Telephone System into Night Service
Special function buttons may be programmed:
- Enable Night Service for each trunk line independently
- Enable Night Service for all trunk lines
Enable call to be forwarded to an alternative extension.
Special function buttons may be programmed:
- Forward to be set for each trunk line independently,
- Forward to be set for all trunk lines
Will return busy tone to caller if the line is already in use.
Special function buttons may be programmed:
- Busy on Busy set for each call distribution table,
- Busy on Busy set for all call distribution tables
Select LCR Carrier for a specific call
This enables for extensions to be checked in or out. This function will start or stop
capture of call charges and trunk line seizure.
Delete setting
Pageing to other System Phones. Special function button may be programmed:
- Pageing to set extensions only.
Displays Call Charges
A specific MSN number can be sent for an outgoing call. This could be used for
billing purposes. A function button may be programmed as either fixed - or
selectable number.
Malicious calls can be traced via the ISDN telephone exchange.
Overdialling of a stored DTMF sequence (1 ... 0, *, # ), may be used for the remote
interrogation of an answering machine.
Dialling a number from a telephone for another extension.
Log in / out a group and associated features.
To pick up incoming calls.
A special function button is programmable: - Pick up extension - and incoming
calls from specific extensions.
Answering
Machine on/off
TAM info
TAM Memo
Reject
Call Waiting
Call Filter
Call Log
Do not Disturb
(DND)
Night Service
Forward to
Alternative Extn.
Busy on Busy
Call by Call
Check in/out
Clear (clr)
Pageing
(to Extensions)
Units
External
Call Trace
Remote Access
Remote Dial
Group
Call Pick Up

System DECT 30
13
Function Buttons- Overview of freely
programmable Function Buttons
Withhold
Internal
ISDN-Hold
Conference
Speaker Vol.
LCR
Line Button
Brokers Call
Account Code
Cleaning
Relays
Reserve
Enquiry Call
Sensor
SMS Info
Write SMS
Mute
Phone Book
Phone Lock
Appointment
Timer
Ringer off
Door
Door Opener
Transfer
Diversion from
(Follow me)
Diversion to
Call List
Wake Up Call
Call Deflection
Memory
Button
- Public
- Private
To withhold own number being forwarded to the number called. (Feature must be
supported by network provider)
To Dial Extensions. Function Button can be assigned to call specific Extensions (DSS)
To Hold an external call in the Telephone Exchange (only available on PTMP ISDN lines)
To set up a Conference Call with Internal and or External calls.
To adjust Speaker Volume for Handsfree or On Hook use.
To set or cancel Least Cost Routing (LCR) on your System Phone.
To access line directly by pressing the line button and to display line status
To talk to one internal and one external call at a time without connecting them.
An account code may be allocated to a call. This may be done with a set account code on a
function button or with a general function, ie enter account code after function button is
pressed.
In connection with the check in / check out button. This can be used to indicate to the front
desk that a room has been cleaned and is ready for occupation.
To activate Relays.
To reserve a line should all lines be engaged at the time. (Ring Back when free).
To establish or set up an Enquiry Call
Set or disable sensors.
Will list all saved SMS messages.
Write a new SMS message.
Mute microphone on telephone.
To select a stored telephone number within the telephone system.
To lock System Phone, Emergency / Direct Call enabled.
To set or delete a preset appointment time
Will switch timer on or off (timed functions controlled via the telephone systems, such like
class of service, diversions, relays) Special function button may be assigned: - Timer 1.....9,0
Switch off tone ringer of telephone.
Will establish a connection to the door phone (TFE).
Will activate the door opener.
To transfer and connect an external call to an external call.
To divert all calls from another phone to the current phone used.
To divert all calls to another extension- or external number.
Displays the last calls incoming and outgoing, depending on system setup. Numbers can be
transferred to the phone book by just pressing the phone book button.
To set or cancel a Wake Up Call
Will divert an incoming call during the ringing phase. There will be no change to the ringing
tone when diverted. The caller will not be aware that the call was forwarded.
To Call a preset Telephone Number
- A number is stored in the Telephone System Memory
- A number is only stored in your telephone

System DECT 30
14
Function Button Assignment
The assignment of function buttons can be tailor made to your own application. You are able to
define which function will be available on each button. Each of the 10 buttons can have a function
stored which can be recalled by pressing Az0-9. If a function button has been recalled in error,
then entering again „Alt and number“will recall a new function. In default all programmable
function buttons are stored with „Phone Book“.
Store / Change a Function
Enter programming mode.
Select function button which is going to be
changed.
Browse through the available functions by
using the arrow buttons.
Confirm selection.
Select another button to be changed or end
programming mode.
AQ31
Az
z
IJ
H
Q
MakingCalls:
Exchange Line Seizure „Direct“
Calling an Extension:
Dial hash followed by the required extension
number.
Press the Call Button
Making an Outside Call:
Dial the required telephone number
Press the Call Button
Pick Up an Incoming Call
Another phone rings. Press the Call Button
followed by „OK“.
You picked up the ringing call.
Pick Up Call from Answering Machine
Press Call Button,
Press button „Pick Up“. Only possible if the
button „Pick Up“is programmed for the
extension number of the answering machine.
Lz
D
z
D
D
H
D
Az

System DECT 30
15
Exchange Line Seizure with „9“
Calling an Extension:
Dial the required extension number.
Press the Call Button
Making an Outside Call:
Dial 9 followed by the required telephone number
Press the Call Button
Pick Up an Incoming Call
Another phone rings. Press the Call Button
followed by „OK“.
You picked up the ringing call.
Pick Up Call from Answering Machine
Press Call Button,
Press button „Pick Up“. Only possible if the
button „Pick Up“is programmed for the
extension number of the answering machine.
z
D
0z
D
D
H
D
Az
Call Log
Display Call Log:
Press the „Ok“button
Dialling from the Call Log:
Select the required phone number by using the
arrow buttons,
then press the Call Button.
Store a Phone Number from the Call Log into
the Phone Book of the Telephone System:
Select the require phone number which you want
to store in the phone book of the telephone
system by using the arrow buttons. Then press
the phone book button and follow the instruction
in the user manual of your telephone system
„Phone Book / Storing a Number“.
H
IJ
D
IJ
B
15

System DECT 30
16
Phone Book of the DECT 30
The DECT 30 has a phone book with up to 80 entries. Each entry can store of up to 24 characters for
name and 24 digits for a telephone number.
A telephone number is shown in the display
Press Phone Book Button
Confirm selection
Enter name and confirm entry
Open Phone Book
Enter first character
Browse for required entry by using the arrow
buttons
Press Call Button
orDelete
Store an Entry
Calling Stored Number (or Delete)
B
H
zH
B
z
IJ
D
H

System DECT 30
17
Cleaning the DECT 30
- Only wipe the cordless phone with a slightly damp cloth or dry anti static cloth.
- Please ensure that no moisture is allowed to enter the unit.
Accessories / Range
Accessories (Available via our dealer network )
The following items are available via our dealer network: replacement batteries, head sets of various
manufacturers, charging cradle, DECT 30 repeater to extend the range, leather cases and belt clips.
Range
The maximum range between DECT 30 handset and DECT module or DECT S0-Base can be up to
300 metres. However, the range will be reduced by obstacles between base and handset such as
walls and furniture. As a general rule the range within a building will be approx. 50 metres.
StandbyTime TalkTime
max. 120 hours max. 12 hours
- Please only use original AGFEO DECT 30 rechargeable batteries.
- DO NOT use any other charging device as the rechargeable batteries could be damaged.
Please dispose of old batteries responsibly.
Battery Replacement
Rechargeable Battery

System DECT 30
18
ChangingtheBattery
To open the battery compartment, press the cover with your thumb toward the headset connection
and then lift this upwards. To refit the cover follow the previous instruction in reversed order.
Approved rechargeable batteries:
Only the enclosed battery is approved for use with this handset. Do not use any other battery.

System DECT 30
19
DeclarationofConformity

Ident no. 1101609
Subject to change without notice. No liability
can be accepted for errors contained in this
document.
Printed in Germany
0071
AGFEO GmbH & Co. KG
Gaswerkstr.8
D-33647 Bielefeld
Internet: http://www.agfeo.com
The crossed out wheeled bin on the product means that this belongs to the group of
Electro- and electronic apparatus.
In this context you are directed by the European regulation to dispose of used apparatus
- at the point of buying an item of equal proportion / value
- at the local available collection point for disposal
With this you will participate in the reuse of material and valorisation of disused electric-
and electronic apparatus, which otherwise could be a health hazard and be negative to the
environment.
