Agnpro |SX-15A User manual

www.agnpro.com
PROFESSIONAL DISPLAY SOLUTIONS
FEATURES
• Looping video inputs for multiple connections
• Auto termination
• Quick signal-switching time
• Supports color and B/W picture
• NTSC/PAL/SECAM scan system compatible
• Selectable signal source
• PC compatible
• Auto-adjustment for optimal setting
• NeoV Optical Glass™
• Distinctive aluminum alloy housing for
added strength
• Kensington™ security slot
• VESA standard wall mount
SS-SX15A-V2-0706
www.agnpro.com
PROFESSIONAL DISPLAY SOLUTIONS
AGN Professional (AGNPRO)
156 Fifth Avenue Suite 434
New York, NY 10010 USA
Tel: [phone]
Fax: [phone]
[email protected]
SPECIFICATION
MULTI-SOURCE FLAT PANEL CCTV MONITORS
All specifications are subject to change without prior notice.
* X-20BV
SX-15A
SX SERIES |
FOR HIGH-END RESIDENTIAL, CORPORATE
AND RETAIL INSTALLATIONS
The NeoV Optical Filter is
a specially formulated, hardened
optical glass (6H Moh’s Rating)
that is built on top of the inter-
nal LCD panel to dramatically
enhance image quality and pro-
tect the screen from damage.
NeoV Optical Filter
About EVS Input Technology:
Enhanced Video Signal (EVS) Input monitors provide the
highest compatibility with CCTV equipment and enhanced
video clarity. Unlike many flat panel monitors designed for the PC
industry, EVS enabled monitors will not eSXerience dropped signals as
a result of video signal hunting. Dropped signals and poor composite
video quality have made most flat panel monitors (designed for the PC
industry) difficult and undesirable to use with multiplexers and digital
recorders. AGNPRO monitors are designed for video surveillance
applications and are the most compatible in the industry.
EVS
About the NeoV Optical Filter:
NeoV
OPTICAL FILTER
Panel
Input Connector
Input Signal
Output Connector
NeoV Optical Glass
Tilt
Mounting
Regulation Approval
Power
Temperature
Dimensions
Weight
Packing
Panel Type
Panel Size
Max. Resolution
Pixel Pitch
Brightness
Contrast Ratio
Viewing Angle (H/V)
Display Color
Response Time
Frequency (H/V)
Max. Pixel Clock
Life Time
Analog
Digital
BNC Security
Analog
Digital
Auto Composite System
BNC Security
Thickness
Reflection Rate
Transmission Rate
Hardness
Tilt
VESA FPMPMI
Safety & EMI
VESA
Power Source
Consumption
Operation
Net (W x H x D)
Packing (W x H x D)
Net Weight
Gross Weight
1 Pallet
20’ Container
40’ Container
TFT LCD
15” (381mm)
XGA 1024 x 768
0.297mm
400cd/m2 (Typical)
500:1 (Typical)
140°/130° (Typical)
16.7M
12ms (GTG)
H: 30kHz - 60kHz
V: 50Hz - 75Hz
80MHz
30,000hrs (Minimum)
15-Pin D-Sub
29-Pin DVI-D
BNC Connector
RGB H.V Sync
TMDS
NTSC/PAL/SECAM
BNC Connector
3.0mm (0.18”)
<1%
>96%
>6H (MOH’s Rating)
0° ~ +20°
Yes (100mm)
FCC, UL/CUL, EPA, TUV/BAURT,
CE, TCO 95, BSMI, CB, ISO 13406-2
DDC 1/2B, DPMS
100 - 240V, 50 - 60Hz
<48W (On)
<4W (Stand-by)
<2W (Off)
0°C ~ 40°C
380 x 155 x 359mm
(15.0” x 6.1” x 14.1”)
438 x 210 x 470mm
(17.2” x 8.3” x 18.5”)
4.8Kg (10.6 lbs)
7.0Kg (15.4lbs)
40 Cartons
480 Sets
1040 Sets
Available in 15”, 17”, 19” and 20"*
