Agromehanika AGP 300 PRO User manual

Rev.02/2019
TRACTOR MOUNTED MIST BLOWERS
AGP 300 PRO
AGP 400 PRO
AGP 500 PRO
AGP 600 PRO
INSTRUCTIONS FOR USE
AGROMEHANIKA reserves the right to design modifications or product changes, without any liabilities to inform
the customer before and after each change.

INSTRUCTIONS FOR USE
AGP 300 –600 PRO
Rev.02/2019
ACKNOWLEDGEMENT
We thank you for the trust, given when choosing our spraying device AGROMEHANIKA for
chemical protection of plants. Reliability and performance of the device depends on your care for
the device. Before connecting the spraying device to a tractor carefully read the instructions for
use and heed to them, while operating the machine. Instructions contain essential information on
effective and safe use and long life of the machine.

INSTRUCTIONS FOR USE
AGP 300 –600 PRO
Rev.02/2019
INDEX
1GENERAL....................................................................................................7
2HEALTHY-SAFETY WARNINGS AND MEASURES..........................8
2.1 Safety signs.................................................................................................... 8
2.2 Maintenance of safety signs .......................................................................... 8
2.3 Readiness for danger..................................................................................... 8
2.4 Removing unauthorized persons ................................................................... 9
2.5 Safety in handling with chemical products.................................................... 9
2.6 Labels for danger, according to danger level............................................. 10
2.7 Danger of mechanical injuries.................................................................... 11
2.8 Dangers, caused by liquids under high pressure........................................ 11
2.9 Working place of operator .......................................................................... 12
2.10 Personal protection ..................................................................................... 12
2.11 Protection of respiratory system ................................................................. 12
2.12 Skin protection............................................................................................. 13
2.13 Maintaining protection equipment.............................................................. 14
2.14 Safe operation.............................................................................................. 14
2.15 Safe maintenance......................................................................................... 15
2.16 Road transport............................................................................................. 15
2.17 Procedures in accidents with chemicals .................................................... 16
2.18 Regulations regarding machine use............................................................ 16
3DRIVE - CARDAN SHAFT (NOT INCLUDED)...................................17
3.1 Operator's safety ......................................................................................... 17
3.2 Connection of cardan shaft ........................................................................ 17
4SAFETY SIGNS ON MACHINE AND INSTRUCTIONS FOR USE19
5DESCRIPTION..........................................................................................21
5.1 Machine transportation............................................................................... 21
5.2 Sprayer component parts............................................................................. 23
5.3 Machine identification................................................................................. 25
5.3.1 Machine identification plate....................................................................... 25
5.3.1 Pump identification plate........................................................................... 25
6MIST BLOWER CONECTION TO TRACTOR...................................26
7DETAILED DESCRIPTION WITH OPERATING INSTRUCTIONS27
7.1 Reservoir...................................................................................................... 27
7.2 Reservoir lid ................................................................................................ 27
7.3 Reservoir for rinsing ................................................................................... 28
7.4 Reservoir for washing hands....................................................................... 28

INSTRUCTIONS FOR USE
AGP 300 –600 PRO
Rev.02/2019
7.5 Mixing nozzle............................................................................................... 28
7.6 Suction filter ................................................................................................ 29
7.6.1 Cleaning filter insert................................................................................... 29
7.7 Nozzle for cleaning interior of main reservoir............................................ 29
7.8 Strainer and packaging cleaner .................................................................. 30
7.9 Blower.......................................................................................................... 30
7.9.1 General description of the blower.............................................................. 31
7.9.2 Blower components.................................................................................... 31
7.9.3 Fan.............................................................................................................. 32
7.9.4 Distribution cube and adjustable nozzle holders........................................ 32
7.9.5 Multiplier gearbox...................................................................................... 33
7.9.6 Nozzle holders............................................................................................ 33
7.10 Blower maintenance.................................................................................... 34
8FUNCTION SCHEMA..............................................................................35
8.1 Description of valve adjustments for spraying or cleaning ........................ 37
8.1.1 Spraying..................................................................................................... 37
8.1.2 Complete cleaning...................................................................................... 38
8.1.3 Partial cleaning........................................................................................... 38
9ADDITIONAL EQUIPMENT..................................................................39
9.1 External cleaning kit ................................................................................... 39
9.2 Packaging and strainer cleaner under the lid............................................. 39
9.3 Suction basket.............................................................................................. 40
9.4 Nozzle holder for spraying tall crops.......................................................... 41
10 PRESSURE REGULATOR......................................................................42
10.1 The PR8 pressure regulator ........................................................................ 42
10.1.1 Manual pressure regulator (PR8F/2EC)..................................................... 42
10.1.2 Remote pressure regulator (PR8ECF/2EC) ............................................... 42
10.2 The PR9 pressure regulator ........................................................................ 43
10.3 Regulator markings..................................................................................... 44
10.3.1 Standard models......................................................................................... 44
10.4 Main components of the pressure regulator ............................................... 44
10.4.1 Control panel.............................................................................................. 44
10.4.2 Manual control valve ................................................................................. 45
10.4.3 The PR8 electric motor operated control valve ......................................... 45
10.4.4 The PR9 electric motor operated control valve ......................................... 46
10.4.5 Pressure filter ............................................................................................. 46
10.4.6 Diverter valves........................................................................................... 47
10.5 Adjusting the regulator for operation ......................................................... 47
10.5.1 Manual pressure regulator (PR8F/2EC)..................................................... 47
10.5.2 Remote pressure regulator (PR8ECF/2EC) ............................................... 48

INSTRUCTIONS FOR USE
AGP 300 –600 PRO
Rev.02/2019
10.6 Pressure regulator maintenance ................................................................. 48
11 PUMPS........................................................................................................50
11.1 Control before use....................................................................................... 50
11.2 Use............................................................................................................... 50
11.3 After use....................................................................................................... 51
11.4 Technical data ............................................................................................. 51
11.5 Pump maintenance ...................................................................................... 52
11.5.1 Oil change.................................................................................................. 52
11.5.2 The APS 121 pump.................................................................................... 52
11.5.3 Pump inspection intervals.......................................................................... 53
12 CLEANING THE MACHINE.................................................................54
13 MAINTANCE AND STORAGE AFTER SEASON ..............................56
13.1 Hoses ........................................................................................................... 56
13.2 Surface protection ....................................................................................... 56
13.3 Reservoir...................................................................................................... 56
13.4 Pressure regulator....................................................................................... 56
13.5 Pump............................................................................................................ 56
13.6 Multiplier gearbox....................................................................................... 56
13.7 Drive/cardan shaft....................................................................................... 56
13.7.1 Bolts........................................................................................................... 57
1270....................................................................................................................57
13.9 HOSE JUNCTIONS..................................................................................... 57
13.10 OTHER PARTS ......................................................................................... 58
14 POSSIBLE ERRORS ................................................................................60
15 TECHNICAL DATA.................................................................................61
15.1 CHARACTERIZATION ............................................................................... 62
15.2 SPRAYER DISPOSAL ................................................................................. 62
15.3 MATERIALS AND RECYCLING................................................................. 62
16 COMBINATIONAL MATRIX ................................................................63
17 GENERAL INSTRUCTIONS FOR SPRAYING..................................64
17.1 Connection for checking the pump flow rate measurement........................ 64
17.2 Nozzle flow rate measurement check........................................................... 64
18 TYPES OF NOZZLE INSERTS..............................................................65
18.1 Tables .......................................................................................................... 65
18.1.1 Table 1: Active driving time (min/ha) ....................................................... 65
18.1.2 Table 2: Required aggregate flow rate (l/min)........................................... 66
18.1.3 Table 3: Flow rates of LECHLER-TR ceramic nozzle inserts (l/min)...... 67

INSTRUCTIONS FOR USE
AGP 300 –600 PRO
Rev.02/2019
18.2 Different calculations.................................................................................. 67
18.3 Recommendations........................................................................................ 68
19 NOTES........................................................................................................69

INSTRUCTIONS FOR USE
AGP 300 –600 PRO
Rev.02/2019
6
EC DECLARATION OF CONFORMITY
MANUFACTURER:
AGROMEHANIKA, proizvodnja in trgovina Kranj, d. d.
Hrastje 52a, KRANJ, SLOVENIJA
declares that the product:
MIST BLOWER AGP 300 PRO
MIST BLOWER AGP 400 PRO
MIST BLOWER AGP 500 PRO
MIST BLOWER AGP 600 PRO
is manufactured in accordance with:
1. Directive on Machinery 2006/42/EC;
2. Directive 2009/127/EC amending the Directive 2006/42/EC, as regards machinery for
pesticide application;
3. Rules on the requirements for the correct operation of equipment for the application of
plant protection products, and on the conditions and method for inspections of such
equipment (Official Gazette of the Republic of Slovenia, No. 101/2013)
The following harmonized European standards on safety were applied:
SIST EN ISO 4254-1:2013 - Agricultural machinery –Safety –Part 1: General requirements
SIST EN ISO 4254-6:2010 - Agricultural machinery –Safety –Part 6: Sprayers and devices
for distributing liquid fertilizers (ISO 4254-6:2009);
SIST EN ISO 4254-6:2010/ AC:2011 - Correction AC:2011 to standard SIST EN ISO 4254-
6:2010;
SIST EN ISO 12100:2011 - Machine safety –General principles of planning –Risk assessment
and risk reduction (ISO 12100:2010);
SIST EN ISO 13857:2008 - Machine safety –Safe distances, preventing reach of dangerous
areas with upper or lower limbs.
Kranj, 12. 1. 2019
Head of production:
(resp. for. tech. documentation)
Matjaž Kuhar
Manager:
Jan Šinkovec

INSTRUCTIONS FOR USE
AGP 300 –600 PRO
Rev.02/2019
7
1GENERAL
Spraying device is designed and constructed for applying chemical products in water-based
solution, which are normally used for chemical protection of crops, on field crops. Construction
design enables access to all vital elements of the sprayer and easy handling. Robust construction,
quality component parts and a great deal of additional equipment enable the user to work reliably
and use spraying agents and energy optimally. Never use the spraying equipment for pumping or
spraying: this spraying equipment was designed and built for the application of water-soluble
chemicals on crops, which are normally used for the chemical protection of agricultural crops.
Spraying device is not to be used for pumping or spraying of:
•water-based solutions with greater specific weight and viscosity than water;
•chemical solutions, whose compatibility with elements, built on the spraying device, is not
reliable;
•drinking water;
•sea water and other saline solutions;
•water, with temperature exceeding 40 °C or lower than 5 °C;
•any kind of varnish or patina;
•quick acting diluters;
•oils and greases;
•liquids, containing granulates or floating hard particles.

INSTRUCTIONS FOR USE
AGP 300 –600 PRO
Rev.02/2019
8
2HEALTHY-SAFETY WARNINGS AND MEASURES
2.1 Safety signs
Sign on the left is a warning safety sign and is normally located on the
machine with other signs.
Respect instructions for safe work and act accordingly in extreme
situations.
2.2 Maintenance of safety signs
Carefully read instructions, regarding safety regulations, described in
instructions for use of your machine. Ensure that the signs are clearly
visible on the machine. After repairing the machine and changing
component parts, make sure that the machine includes all required safety
signs. Safety signs are available from authorized dealers. Learn the
operation of your machine and proper handling and control units.
Ensure that your machine is in good technical condition. Each unauthorized change to the machine
can diminish its function, as well as safe operation, and can shorten its life span.
2.3 Readiness for danger
Be prepared for sudden fire.
Make sure that a first aid kit and a fire extinguisher are
always at hand, when working.
Make sure that you have phone numbers of your doctor,
emergency, clinic, hospital and fire service written in a
visible location.
WARNING: Do not allow unauthorized persons to use the machine!

INSTRUCTIONS FOR USE
AGP 300 –600 PRO
Rev.02/2019
9
2.4 Removing unauthorized persons
Every unauthorized person, riding on the machine, can
have an accident (a fall from the machine or an injury by
the machine). Person, riding on the machine, can affect
the driver, who is controlling the machine, and can
change the machine's barycentre. Person on the machine
obstructs overview of the driver and can contribute to
unreliable working conditions on the machine. Do not
allow unauthorized persons to gain access to themachine
2.5 Safety in handling with chemical products
Handle chemical products extremely carefully, to avoid potential injuries and dangers to health, as
well as to the environment:
•Be very careful, when handling chemical products. Ensure that you do not have direct
contact with chemical products. Handle chemical products as you would poisons.
•Choose chemical products, which are least dangerous to your health, most effective and easy
soluble.
•Always read instructions for use, given on the chemical products. Regard regulations, safety
measures and use instructions.
•When working, use respiratory protection, such as gas mask, helmet with fresh air.
•When preparing chemical products, wear appropriate clothing. When working, use
protection mask, gloves, boots and protection clothing. Be careful with your protection
equipment. Do not use "worn-out" protection.
•Make sure that your protection equipment and clothing is in good condition. Dirty gas mask
can cause skin irritation. Change the filter regularly!
•Choose "safer" chemical products. When choosing chemical products, use products that are
less irritant to the skin and do not cause dust.
WARNING: Driving unauthorized persons on the machine is prohibited!
