Aimco SPC-P2325Q User manual

MODEL NO.: SPC-P2325Q
SPC-P2625Q
SPC-P2925Q
SPC-P21225Q
18V Cordless Precision Clutch
Shut Off Pistol Screwdriver

2

3
(A) 1/4" Hex with quick change chuck.
(B) Covered Torque Adjustment.
(C) LED indicator provides simple process information to the operator.
The signal is visible from any angle.
(D) LED light for workpiece illumination.
(E) Tool Trigger with repeat protection feature to avoid double hits on an
already seated fastener.
(F) Easy Press button for simple Forward/Reverse selection.
(G) Ergonomic handle design provides optimal balance.
(H) Easily attached sliding battery connection.
( I ) Lightweight Li-Ion battery pack delivers long tool operating times
(A)
(B) (C)
(D)
(E) (F)
(G)
(H)
(I)

4
Work Area Safety
●Keep your work area clean
and well lit. Cluttered benches
and dark areas invite accidents.
●Do not operate power tools in
explosive atmospheres, such as
in the presence of flammable
liquids, gases, or dust. Power
tools create sparks which may
ignite the dust or fumes.
●Keep bystanders, children,
and visitors away while oper-
ating a power tool. Distrac-
tions can cause you to lose con-
trol.
Personal Safety
●Stay alert, watch what you are
doing and use common sense
when operating a power tool. Do
not use tool while tired or under
the influence of drugs, alcohol,
or medication. A moment of in-
attention while operating power
tools may result in serious person-
al injury.
●Dress properly. Do not wear
loose clothing or jewelry. Con-
tain long hair. Keep your hair,
clothing, and gloves away from
moving parts. Loose clothes,
jewelry, or long hair can be caught
in moving parts.
●Do not overreach. Keep proper
footing and balance at all
times. Proper footing and bal-
ance enables better control on
the tool in unexpected situations.
General Safety Rules ●Use safety equipment. Always
wear eye protection. Dust
mask, non-skid safety shoes,
hard hat, or hearing protection
must be used for appropriate
conditions.
Tool Use and Care
●Use clamps or other practical
ways to secure and support
the work piece to a stable plat-
form. Holding the work piece
by hand or against your body is
unstable and may lead to loss of
control.
●Do not force tools. Use the
correct tool for your applica-
tion. The correct tool will do
the job better and safer at the
rate for which it is designed.
●Do not use tool if switch does
not turn it on or off. Any tool
that cannot be controlled with the
switch is dangerous and must be
repaired.
●Store idle tools out of reach of
children and other untrained
persons. Tools are dangerous
in the hands of untrained users.
●Check for misalignment or
binding of moving parts,
breakage of parts, and any
other condition that may affect
the tool operation. If damaged,
have the tool serviced before
using. Many accidents are
caused by poorly maintained
tools.
●Use only Signature Series rec-
ommended accessories for
your model tool. Accessories
WARNING! READ ALL INSTRUCTIONS. Always observe the safety
regulations applicable in your country to reduce the risk of fire, electric shock,
and personal injury. Understand the following safety instructions before
attempting to operate this product. Always wear eye protection when working
with power tools. Keep these instructions in a safe place.
SAVE THESE INSTRUCTIONS

5
that may be suitable for one tool,
may become hazardous when
used on another tool.
Service
●Tool service must be per-
formed only by qualified repair
personnel. Service or mainte-
nance performed by unqualified
personnel could result in a risk of
injury.
●When servicing an AIMCO Sig-
nature Series Precision Clutch
tool it is important to use
AIMCO Signature Series parts
and all work should be under-
taken by a qualified AIMCO
Signature Series Authorized
Technician. Use of unauthor-
ized parts or work performed by
a non-authorized technician will
void warranty and may create a
risk of damage to the tool, risk of
electric shock, or injury to a user.
Battery Charger
●Caution: To reduce risk of injury,
charge only the authorized batter-
ies. Other types of batteries may
burst, causing personal injury and
damage.
●
●Do not allow anything to cover or
clog the charger vents.
●Do not expose charger to rain,
snow, or wet conditions.
●To reduce the risk of damage to
electric plug and cord, pull by
plug rather than cord when dis-
connecting charger.
●Use of an attachment not recom-
mended or sold by the manufac-
turer may result in a risk of fire,
electric shock, or injury to per-
sons.
Additional Safety Rules
●Make sure cord for charger is
located so that it will not be
stepped on, tripped on, tripped
over, or otherwise subjected to
damage or stress.
●Do not abuse the power cord. Nev-
er use the cord to carry the charger.
Keep cord away from heat, oil, wa-
ter, sharp edges, or moving parts.
Replace damaged cords immedi-
ately.
●Do not operate charger if it has
been damaged in any way. Take it
to a qualified service center for re-
pair.
●To reduce risk of electric shock,
unplug charger from outlet before
attempting any maintenance or
cleaning. Turning off controls will
not reduce this risk.
●Do not disassemble charger or bat-
tery cartridge. Take it to a qualified
service center when repair is re-
quired. Incorrect reassembly may
result in a risk of electric shock or
fire.
Battery Pack
●Do not charge battery pack when
temperature is below 0°C (32°F)
or above 40°C (104°F).
●Do not attempt to use a step-
down transformer, an engine gen-
erator, or DC power receptacle.
●Do not short the battery pack: Do
not touch the terminals with any
conductive material. Avoid storing
battery cartridge in a container
with other metal objects such as
nails, coins, paper clips, etc.
●Do not expose battery cartridge
to water or rain. A battery short
can cause large current flow,
overheating, possible burns, and
even a breakdown.
●Do not store the machine and
battery pack in locations where
the temperature may reach or
exceed 50°C (122°F).

6
●Do not incinerate the battery
pack even if it is severely dam-
aged or completely worn out.
The battery pack can explode in
a fire.
●Be careful not to drop, shake, or
strike the battery.
●Do not charge inside a box or
container of any kind. The bat-
tery must be placed in a well-
ventilated area during charging.
●Do not dispose of battery packs
into household waste, fire, or
water. Battery packs should be
collected, recycled, or disposed
of in an environmentally-friendly
manner. Call authorized warran-
ty centers for locations to dis-
pose of damaged or inoperable
batteries.
The Signature Series Precision
Clutch industrial shut off screwdriver
is designed for nut tightening/
loosening and screw driving/
loosening. It is not appropriate to
use for wood/mild steel drilling.
Please refer to Figure 1 on this
page to familiarize yourself with the
major components of this tool be-
fore use.
1. Power Switch
Depressing the power switch will
energize the LED light (2) in front
and the tool starts to rotate. When
released, power to the motor ceas-
es and the tool stops working im-
mediately. The LED light will re-
main on for 5 seconds, then shut
off.
2. LED Light
3. Forward/Reverse Button
The tool is always in forward
operation unless the Forward/
Reverse button is pressed.
When the button is pressed, the
Functional Description
blue LED shows and the tool will
be in reverse operation. To
switch the tool back to forward
operation, simply press the but-
ton again. The blue LED shuts
off and the tool is back in for-
ward operation.
4. Quick Change Holder
This driver accepts only 1/4” hex
bits. Be sure the bit is fully en-
gaged by the chuck before oper-
ating tool. Otherwise, the bit may
detach and cause property dam-
age or personal injury.
5. Li-Ion Battery
This battery provides electrical
power to the motor. Please
charge it according to the charg-
ing instruction listed in this man-
ual.
6. Torque Adjustment Cover
Open the torque adjustment cap.
Use the supplied torque adjust-
ment tool to either tighten or loos-
en the spring until the desired
torque is reached. CW increases
torque output, CCW decreases
torque output. Page 8 describes
this in detail.
WARNING: Use the tool to either
tighten or loosen nuts and screws
ONLY in stipulated torque and volt-
age ranges.
46
3
2
1
5
Figure 1

7
This product has been carefully
inspected prior to leaving the facto-
ry. It should provide you with years
of satisfying service under normal
operating conditions. Do not, how-
ever, force the tool to perform out-
side its design parameters. Such
usage will void the warranty.
1. Slide battery into the bottom of
the housing handle until a click
sound occurs. Do not force bat-
tery: It should slide easily into
place with nominal force. Any
difficulty doing so indicates in-
correct alignment.
2. Tool speed is preset to the max-
imum range of the tool. With an
SPC-2PGM External Program-
ming Module (optional accesso-
ry), tool speeds may be reset to
a lower speed within the range
of the tool.
3. Select a proper size drive bit and
insert it into the quick change
holder. Pull forward on the quick
change holder while inserting the
drive bit and release when bit is
seated correctly. Verify secure
seating prior to operation of the
tool.
4. Depress the trigger to engage
the LED light and start the tool.
5. When the pre-set torque is
reached, the tool’s precision
clutch will shut off the tool auto-
matically.
Operations
WARNING! Read the in-
struction manual before op-
erating the tool. Always wear
safety glasses or face
shields when operating this
product. Failure to do so can
result in injury.
Check for damage to tool, parts, or
accessories that may have oc-
curred during transport. Take time
to thoroughly read and understand
this manual prior to operation.
This tool kit contains:
1 - 18V Cordless Shut-Off
Precision Clutch Screwdriver
1 - 18V Li-Ion Battery Pack
1 - Torque Adjustment Tool
1 - Instruction Manual
1. To connect battery, line up the
tracks and attach the battery
pack. Slide toward the battery
pack until it locks into position
with a click.
2. To remove the battery pack,
press the red button on the top of
the battery pack and release the
battery
Assembly
2. RELEASE
1. PRESS
SLIDE

8
Steps for Torque Adjustment
NOTE: Remove the battery pack
before adjusting the torque to avoid
injury.
1. Lift the torque adjustment cover.
Use the torque adjust tool and
insert it in to the quick change
holder and turn until the adjust
hole appears below the cover.
2. Use the torque adjust tool to
turn clockwise to increase
torque and turn counterclock-
wise to decrease torque.
6. Prior to using on an application,
it is advised to verify the output
torque of the tool as set. Check
the torque on an Auditor™ Digi-
tal Tester (or comparable sys-
tem).
7. Delivered torque to the applica-
tion may vary due to the type of
joint the tool is tightening. Good
practice is to perform periodic
audits of the application. Audi-
tor™ Torque Wrenches of
Rotary Transducers are ideal-
ly suited to make these checks.
Forward/Reverse Rotation
Switch Operation
To prevent damage, do not press
Forward/Reverse button until the
tool comes to a complete stop.
Forward Rotation Operation
The tool is in forward operation if
the blue light is not on.
Reverse Rotation Operation
By long pressing on the F/R switch,
users are able to choose the mode
of Reverse operation, either auto-
matic or manual.
Mode 1: Automatic – Tool re-
turns to Forward operation
automatically after reverse
operation.
Mode 2: Manual – Tool needs to
be adjusted manually to return to
Forward operation after reverse
operation.
Adjust Hole
Cover
Decrease Torque
Press
Increase Torque

9
LED INDICATION
Status of the Tool Action to be Taken
LED lights RED, YELLOW and
GREEN together for one second.
A long beep for one second.
The motor is
switched on. None required
LED lights RED for one second.
A long beep for one second.
The preset torque
is not reached
(NOK).
The application
should be reworked.
The screw has
been refastened
after already tight-
Double Hit (NOK).
The application
should be reworked.
LED lights GREEN.
The preset torque
is reached and the
tightening is OK.
None required
LED Blinks YELLOW five times.
Five short beeps.
Battery power is
low.
Recharge battery or
replace with fully
charged battery.
LED lights YELLOW for five seconds.
A long beep for five second.
Battery power is
too low for tool
operation and tool
will not run.
Recharge battery or
replace with fully
charged battery.
LED lights BLUE.
The tool is set to
run in reverse
operation.
None required.
LED lights RED twice.
Tool temperature is
too hot. Warning to
protect tool from
damage.
Remove battery and
allow tool to cool.
LED lights RED three times. The motor has a
failure.
Send tool in for
service.
LED lights RED four times. Internal connector
wire has failed.
Send tool in for
service.

10
Li-ion Battery Pack
NOTE: Your battery pack is not
fully charged at the time of pur-
chase. Be sure to charge battery
before first use.
●Batteries should be charged in
ambient temperatures between 0°
C (32°F) and 40°C (104°F).
Charging outside this range will
result in either less than full
charge or damage to the battery
pack.
●Allow the charger to cool when
charging more than two battery
packs consecutively.
●Do not insert finger/body parts
or foreign objects into contact
area of charger.
1. Place charger in a relatively
cool and well-ventilated area.
2. Plug charger into the AC outlet.
CAUTION: Ensure that the pow-
er source to be utilized con-
forms to the power requirement
specified on the charger name-
plate.
3. Turn the battery upside-down
and slide the battery into
charger while keeping the align-
ment marks line up. Slide the
forward in the direction of the
arrow. Do not force battery: It
should slide easily into place
with nominal force. Any difficulty
doing so indicates incorrect
alignment.
4. If the power lamp (RED) does
not light immediately or goes
out soon after the charger is
plugged in, consult a Signature
Series authorized dealer.
5. During charging, the charging
lamp (GREEN) will start flash-
ing. When charging is complet-
ed, an internal electronic switch
will automatically be triggered
to prevent overcharging.
- Charging will not start if the
battery pack is warm. For ex-
ample, immediately after high
duty cycle operation. The YEL-
LOW standby lamp will flash
until the battery temperature
drops to where safe charging is
possible.
6. If the temperature of the battery
pack is 0oC (320F) or less,
charging will take longer to fully
charge the battery pack than
standard charging time. At this
low temperature, even when
the battery is fully charged, it
will have approximately 50% of
the power of a fully charged
battery at normal operation
temperatures.
7. Once the battery is fully
charged, the GREEN lamp will
light to indicate the charger has
entered into a trickle charge
mode.
CHARGING THE BATTERY PACK

11
Red Light
Charger is plugged into the AC outlet. Ready to charge.
Yellow Flashing Light
(1) When the temperature of the battery is too low (<0oC
(<32oF)), it is in a trickle charge mode until the temperature
of the battery goes up to over 0oC(<32oF). The lamp will
change from the Yellow Flashing to Green Flashing auto-
matically and start to charge. (If after 70 minutes, the lamp
changes from yellow flashing to yellow lit, consult an au-
thorized dealer.)
(2) When the temperature of the battery is too high (>40oC
(104oF)), it is in a trickle charge mode until the temperature
of the battery drops to under 40oC(104oF). The lamp will
change from the Yellow Flashing to Green Flashing auto-
matically and start to charge. (If after 70 minutes, the lamp
changes from yellow flashing to yellow lit, consult an au-
thorized dealer.)
(3) When the voltage of the battery is too low (below 14.4 volt-
age), it is in a trickle charge mode until the voltage of the
battery reaches to the standard value. The lamp will change
from the Yellow Flashing to Green Flashing automatically
and start to charge. (If after 20 minutes, the lamp changes
from yellow flashing to yellow lit, consult an authorized
dealer.)
Yellow Light
The battery and the charger are not connected. If the yellow lit
still on after trying re-attach the battery, consult an authorized
dealer.
Green Flashing Light
Now start charging Light
Green Flashing Light
Battery is approximately 50% charged.
Green Flashing Light
Battery is approximately 80% charged.
Green Light
Charging is complete. (Fully charged.)
LAMP INDICATIONS

12
MODEL
SPC-P2325Q SPC-P2625Q
Voltage 18 VDC 18 VDC
Drive Size 6.35 mm Hex. (1/4”) 6.35 mm Hex. (1/4”)
Torque Range 0.8 ~ 3 Nm (7 ~ 27 in-lb) 1~6 Nm (9 ~ 53 in-lb)
Free Speed 500 ~ 1,550 rpm 300 ~ 1000 rpm
Weight W/O Battery 0.95 kg (2.1 lb) 0.95 kg (2.1 lb)
Vibration (m/s2)2.5 2.5
Sound level (dB(A)) <75 <75
Battery Type Li-Ion 2.0Ah Li-Ion 2.0Ah
Charge Time Approx. 45 min Approx. 45 min
MODEL
SPC-P2925Q SPC-P21225Q
Voltage 18 VDC 18 VDC
Drive Size 6.35 mm Hex. (1/4”) 6.35 mm Hex. (1/4”)
Torque Range 1.5 ~ 9 Nm (13 ~ 80 in-lb) 2~12 Nm(18 ~ 106 in-lb)
Free Speed 300 ~ 800 rpm 250 ~ 600 rpm
Weight w/o Battery 0.95 kg (2.1 lb) 0.95 kg (2.1 lb)
Vibration (m/s2)2.5 2.5
Sound level (dB(A)) <75 <75
Battery Type Li-Ion 2.0Ah Li-Ion 2.0Ah
Charge Time Approx. 45 min Approx. 45 min
SPECIFICATIONS

13
NOISE AND VIBRATION LEVEL DECLARATION (Max. value) EN 60745-2-2
Models: SPC-P2325Q, SPC-P2625Q
Sound pressure level (no load) LpA: 65.5 dBA Uncertainty K: 1.5 dB
Sound power level (no load) LwA: 76.5 dBA Uncertainty K: 1.5 dB
Vibration total value (no load) ahd: 0.4 m/s2 Uncertainty K: 1.5 m/s2
Models: SPC-P2925Q, SPC-P21225Q
Sound pressure level (no load) LpA: 69.1 dBA Uncertainty K: 1.5 dB
Sound power level (no load) LwA: 80.1 dBA Uncertainty K: 1.5 dB
Vibration total value (no load) ahd: 0.5 m/s2 Uncertainty K: 1.5 m/s2
The declared vibration total value has been measured in accordance with a standard test
method and may be used for comparing one tool with another. The declared vibration total
value may also be used in a preliminary assessment of exposure.
WARNING:
− The vibration emission during actual use of the power tool can differ from the declared
total value depending on the ways in which the tool is used; and
− Need to identify safety measures to protect the operator that are based on an
estimation of exposure in the actual conditions of use (taking account of all parts of the
operating cycle such as the times when the tool is switched off and when it is running
idle in addition to the trigger time).
CLUTCH UNITS
For Models: SPC-P2325Q SPC-P2625Q SPC-P2925Q SPC-
Index
No Description Q'ty Index No Description Q'ty Index No Description Q'ty
aClutch
Assembly 1eSpring 1iBall Bearing 1
bSteel Ball 3fAdjust Washer 1jSnap Ring 1
cWasher 1gAdjust Nut 1
dWasher 1hSnap Ring 1
Specific Part Numbers may be obtained by review of the correct Signature Series
tool breakdown. Consult your Signature Series dealer for details.

14
For Model: SPC-P2325Q
GEAR BOX UNITS
Specific Part Numbers may be obtained by review of the correct Signature Series
tool breakdown. Consult your Signature Series dealer for details.
Index
No Description Q’ty Index No Description Q’ty
aInverted Retaining Ring 1eGear Plate Assembly 1
bWasher 2Gear Box Assembly 1
f
cPlanet Gear 6(1) O-ring 1
dGear Cage Assembly 1
For Model: SPC-P2625Q
Index
No Description Q’ty Index No Description Q’ty
aInverted Retaining Ring 1eGear Plate Assembly 1
bWasher 2Gear Box Assembly 1
f
cPlanet Gear 6(1) O-ring 1
dGear Cage Assembly 1

15
For Model: SPC-P2925Q
GEAR BOX UNITS
Specific Part Numbers may be obtained by review of the correct Signature Series
tool breakdown. Consult your Signature Series dealer for details.
Index
No Description Q’ty Index No Description Q’ty
aInverted Retaining Ring 1ePlanet Gear 3
bWasher 2fGear Plate Assembly 1
cPlanet Gear 3gGear Box Assembly 1
dGear Cage Assembly 1(1) O-ring 1
For Model: SPC-P21225Q
Index
No Description Q’ty Index No Description Q’ty
aInverted Retaining Ring 1eGear Plate Assembly 1
bWasher 2Gear Box Assembly 1
f
cPlanet Gear 6(1) O-ring 1
dGear Cage Assembly 1

16
Specific Part Numbers may be obtained by review of the correct Signature Series
tool breakdown. Consult your Signature Series dealer for details.
HOUSING AND MOTOR
For Model: SPC-P2325Q
Index
No Description Q'ty Index No Description Q'ty
aUpper Housing 1mAnvil Collar 1
bLower Housing 1nSensor Assembly 1
cCover 1oF/R Valve (1 set x 2 pcs) 1
dBrushless Motor w/driver 1pSpring 1
eRing 1qPC Board 1
fO-Ring (Ø16 x Ø1.5) 1rConnector Wire 1
gMotor Holder 1sTrigger Assembly 1
hScrew (M4 x 6L) 2tSpring 1
iSteel Ball 2uLock Nut 1
jQuick Change Holder 1vCover 1
kSpring 1wScrew (Ø3 x 14L) 7
lHold Spacer 1xWasher 1

17
HOUSING AND MOTOR
Specific Part Numbers may be obtained by review of the correct Signature Series
tool breakdown. Consult your Signature Series dealer for details.
For Models: SPC-P2625Q SPC-P2925Q
Index
No Description Q'ty Index No Description Q'ty
aUpper Housing 1mAnvil Collar 1
bLower Housing 1nSensor Assembly 1
cCover 1oF/R Valve (1 set x 2 pcs) 1
dBrushless Motor w/driver 1pSpring 1
eRing 1qPC Board 1
fO-Ring (Ø16 x Ø1.5) 1rConnector Wire 1
gMotor Holder 1sTrigger Assembly 1
hScrew (M4 x 6L) 2tSpring 1
iSteel Ball 2uLock Nut 1
jQuick Change Holder 1vCover 1
kSpring 1wScrew (Ø3 x 14L) 7
lHold Spacer 1xWasher 1

18
HOUSING AND MOTOR
Specific Part Numbers may be obtained by review of the correct Signature Series
tool breakdown. Consult your Signature Series dealer for details.
For Model: SPC-P21225Q
Index
No Description Q'ty Index No Description Q'ty
aUpper Housing 1mAnvil Collar 1
bLower Housing 1nSensor Assembly 1
cCover 1oF/R Valve (1 set x 2 pcs) 1
dBrushless Motor w/driver 1pSpring 1
eRing 1qPC Board 1
fO-Ring (Ø16 x Ø1.5) 1rConnector Wire 1
gMotor Holder 1sTrigger Assembly 1
hScrew (M4 x 6L) 2tSpring 1
iSteel Ball 2uLock Nut 1
jQuick Change Holder 1vCover 1
kSpring 1wScrew (Ø3 x 14L) 7
lHold Spacer 1xWasher 1

19
NOTES
_______________________________________________________
_______________________________________________________
_______________________________________________________
_______________________________________________________
_______________________________________________________
_______________________________________________________
_______________________________________________________
_______________________________________________________
_______________________________________________________
_______________________________________________________
_______________________________________________________
_______________________________________________________
_______________________________________________________
_______________________________________________________
_______________________________________________________
_______________________________________________________

20
LIT-MAN254 Rev. 06/15
Printed in USA ©2015 AIMCO
