Matatakitoyo Torque Tools MTD User manual

BEFORE STARTING
TORQUE
1/4”
MTD-1405NL / MTD-1450IL
MTD-1408NL / MTD-1480IL
MTD-1405N / MTD-1450I
MTD-1408N / MTD-1480I
BodyDriver 1/4”
Main Scale
Knob
HOW TO SET TORQUE VALUE
CONTENTS
Turn LockUnlock
1 2 3
Pull to unlock and turn it to set the target torque.
Then push it back to lock.
For example, ITEM NO. MTD-1405N target torque is 3 Nm.
Red line of main scale reach 3 Nm (see A) , so as to
acquire 3 Nm.
OPERATION MANUAL
Adjustable Torque Screwdriver MTD
Models covered
A
1. Study this instruction before use.
2. This torque wrench is calibrated and tested before leaving the factory, it is certified to meet the current standard
specification and has an accuracy of C.W.±6%.
3. THIS TOOL IS A PRECISION MEASUREMENT AND DESIGNED FOR MANUAL TIGHTENING FASTENERS ONLY.
DO NOT USE IT AS A NUT BREAKER OR FOR ANY OTHER PURPOSE.
4. Do not over torquing the fastener, or it will cause tool’s damage and serious injury.
5. Do not use this tool near rotating machinery.
6. Disassemble this tool or make any adjustments will result in the loss of accuracy and invalidating the warranty.
7. Do not continuously apply force after hearing the clicking sound or feel shock.
8.
Do not use any kind of extension on the handle of the tool. This will not only damage the tool, also affect the accuracy.
9. Use special care at minimum torque setting.
10. Please wear gloves and goggles when working.
Supplied in a plastic box.Socket Manual
Torque screwdriver
Manual
WARNING

E-mail:[email protected]om
www.matatakitoyo.com Made in Taiwan
MATATAKITOYO TOOL CO., LTD.
No. 63, Ln. 493, Sec. 3, Zhongshan Rd., Tanzi Dist.,
Taichung City 42754, Taiwan
TEL : [phone]
Manufacturer
SPECIFICATION
Jun. 2023
03
L
ØD
A
1. When applying torque the screwdriver must be kept vertically to the flat use.
2. Inaccurate torque readings may occur from
applying side load.
90°
MAINTENANCE AND STORAGE
CONVERSION TABLE
Units to be
converted
1 mN.m
1 cN.m
1 N.m
1 ozf.in
1 lbf.in
1 lbf.ft
1 gf.cm
1 kgf.cm(kp.cm)
1 kgf.m(kp.m)
1
10
1000
7.062
113
1356
0.098
98.07
9807
0.1
1
100
0.706
11.3
135.6
0.01
9.807
980.7
0.001
0.01
1
0.007
0.113
1.356
0.0001
0.098
9.807
0.142
1.416
141.6
1
16
192
0.014
13.89
1389
0.009
0.088
8.851
0.0625
1
12
0.0009
0.868
86.8
0.0007
0.007
0.738
0.005
0.083
1
0.00007
0.072
7.233
10.2
102
10197
72
1152.1
13826
1
1000
100000
0.01
0.102
10.2
0.072
1.152
13.83
0.001
1
100
0.0001
0.001
0.102
0.0007
0.0115
0.138
0.00001
0.01
1
=mN.m =cN.m =N.m =ozf.in =lbf.in =lbf.ft =gf.cm =kgf.cm
(kp.cm)
=kgf.m
(kp.m)
Corresponding unit
Conversion-formula : Units to be converted × Factor=Corresponding unit
Example : Convert 5 lbf.ft into cN.m
Solution : 5 × 135.6 = 678 cN.m
C
1. Please return torque value to the lowest reading when not in use.(see C) Do not turn below the lowest reading.
2. If this tool has not been used for a period of time, it shall be preloaded several times at its maximum torque setting.
This will allow internal lubricant to recoat.
3. Clean this tool by wiping with a clean cloth after operation and storage in a dry environment.
Do not dip any type of liquid in this tool. This may damage the internal of this tool.
4. This tool should be recalibrated a period of 12 months, or 5,000 cycles, whichever occurs first.
To contact with local vendor or an authorized repair center for supporting. 12 months
5000 cycles
MTD-1405N
MTD-1405NL
MTD-1408N
MTD-1408NL
L ØD
154
235
154
235
42.5
42.5
42.5
42.5
1-5 Nm
1-5 Nm
1-8 Nm
1-8 Nm
1/4”
1/4”
1/4”
1/4”
0.5 Nm
0.5 Nm
0.5 Nm
0.5 Nm
370
430
370
430
G
A
MTD-1450I
MTD-1450IL
MTD-1480I
MTD-1480IL
L ØD
154
235
154
235
42.5
42.5
42.5
42.5
10-50 in.lb
10-50 in.lb
10-80 in.lb
10-80 in.lb
1/4”
1/4”
1/4”
1/4”
5 in.lb
5 in.lb
5 in.lb
5 in.lb
370
430
370
430
G
A
Unit : mm
Accuracy : C.W.±6%
ITEM NO. Range ITEM NO. Range
MetricSAE
Version
STOP
CLICK
