Aime T500 User manual

User Guide

AIME WORKSTATIONS

T500 | T502 | T504

02/11

AIME T500 Workstation

Arti cial Intelligence

Machines

Contents

1. Device Description & Scope of Delivery 03

2. Important Safety Instructions 04

3. Technical Speci cation 05

4. Components & Cooling System 06

5. Connectivity 07

6. Cleaning & Care 08

7. AIME ML Container Manager 09

8. Compliance & Services 10

9. Warranty 11

AIME UG limited liability). Other brands may be trademarks of their respective owners.

This product was individually made to customer speciﬁcations. The ocially stated prices are

subject to change without notice. If you have any questions about the price, please contact

your AIME customer manager.

AIME is not responsible for incorrect images or printing errors.

03/11

AIME T500 Workstation

Arti cial Intelligence

Machines

1. Device Description & Scope of Delivery

Device Description

The AIME T500 workstation series is designed for

deep learning development and has been optimized

for maximum performance with regard to low

volume development and the lowest possible energy

consumption without compromising on durability and

reliability.

All installed components were selected for their

energy eciency, durability, compatibility and high

performance. They are perfectly balanced with each

other so that there are no performance bottlenecks.

With the sophisticated cooling system of the AIME

T500 series, the CPU and all built-in GPUs are cooled

highly eectively. High thermal conduction blocks

and the far higher cooling capabilities of liquid

compared to air keeps the operation temperature of

all components well below 60°C.

The secured low operation temperature reduces

stressful overheating for GPU and CPU silicons and

allows that all components keep operating at their

highest performance levels even under full load in

24/7 scenarios.

The large radiators in the front and on top of the

system are cooled by high durability noise reduced

fans with a guaranteed operation of more than 10

years MTBF. This setup keeps the system cooler,

more performant, durable and far less noisy than a

collection of many small fans for each component.

The AIME T500 enables you to train deep learning

models at up to four times the speed of a single GPU,

without throttling the computing power due to heat.

This means AI supercomputing performance with

over 400 trillion tensor FLOPS, which is equivalent to

the performance of hundreds of conventional

servers.

AIME workstations are delivered with a pre-installed

Linux operating system and are preconﬁgured with

the latest drivers and frameworks such as

Tensorﬂow, Keras, PyTorch and Mxnet.

The pre-installed AIME ML Container Manager oers

a comprehensive software stack, allowing

developers to comfortably set up AI projects and

navigate between frameworks and projects. The

libraries and GPU drivers required for the respective

deep learning framework are loaded in

preconﬁgured Docker containers and can be

conﬁgured and started with simple commands. The

most common frameworks - i.a. TensorFlow, Keras,

PyTorch and Mxnet - are pre-installed and ready to

use.

The AIME ML Container Manager makes life easier

for developers, so they don't have to worry about

problems installing the framework versions.

AIME customers log in immediately after unpacking

and start development right away with their

preferred deep learning framework.

Scope of Delivery

1x AIME Workstation T500 | T502 | T504

1x power cable for power supply 2x for T504)

IEC connector on protective contact)

1x WLAN antenna

1x quick start guide with individual access data

1x technical speciﬁcations

04/11

AIME T500 Workstation

Arti cial Intelligence

Machines

2. Important Safety Instructions

CAUTION - RISK OF ELECTRIC SHOCK!

WATCH OUT! When using the workstation, the basic

safety rules must always be followed to avoid

injuries, overvoltage, re and electric shock:

1. Follow the manufacturer's instructions and safety

instructions during installation. Failure to do so can

damage the device and cause serious injury or death.

2. The device operates on high voltage. Never open

the device and do not try to repair it. Above all, never

open the power supply - not even when it is switched

o - there is a risk to life and can lead to injuries,

overvoltage, ﬁre and electric shock!

3. This product is only intended for indoor use.

4. Do not use the device near water or at high

temperatures or in environments with high humidity.

5. Do not use the device during thunderstorms. In the

event of a thunderstorm, pull the power plug from

the power supply to protect it from damage caused

by lightning and overvoltage and to protect people.

6. Do not place the device near heat sources such as

fan heaters, heaters, stoves or other devices that

generate heat.

7. Do not insert any objects into the open areas of the

ventilation or fan grilles of the device.

8. The device needs adequate ventilation. Make sure

there is a distance of at least 10 cm on both sides,

front and back. Do not place any objects on the top,

the fans must remain free.

9. Do not modify any cables or connectors included

with this device.

10. Only use power cords that are compatible with

the device's power supply model. When using other

cables, the contacts may not be compatible, which

can seriously damage your device.

11. Modiﬁcations inside the device are only to be

carried out by a specialist. Before starting such work,

switch o the device and pull out the main power

plug. ESD protective measures must be observed

during all work.

12. Failure to observe the manufacturer's

instructions or one of these safety instructions, as

well as opening the device or removing, severing or

damaging one of the guarantee seals leads to the

immediate loss of all warranty and guarantee claims.

13. This device has been developed in such a way

that all speciﬁed EN classiﬁcations are only met if it

is used within a completely closed metal housing.

14. Make sure that your data is backed up regularly

to prevent data loss due to faulty data carriers,

memory modules and other hardware and software

errors or malware. In the event of a defect, the data

can then quickly be restored.

*: Notes on ESD protection

Electronic components are very sensitive to electrostatic

discharge. Therefore, never touch chips and contacts on circuit

boards directly, but only on the outer edges of the circuit board

without touching contacts or components. Ensure electrical

grounding on the housing or on metallic objects, e.g. radiators.

The following applies in particular to the T504:

The T504 is supplied with two power adapters due

to its increased power requirements.

It is important to keep in mind to only operate the

device when both power adapters are plugged in

and turned on.

CAUTION: To prevent damage to the device both

power adapters have to be connected to the power

grid via the IEC cables before turning the device

on. Also both power adapters should be turned on

at the back of the device. Only then the workstation

should be started by touching the switch on the

front panel!

05/11

AIME T500 Workstation

Arti cial Intelligence

Machines

3.Technical Speci cation

PERFORMANCE

CPU Options

T500 | T504:

Threadripper 3960X 24 cores, 4.5 GHz)

Threadripper 3970X 32 cores, 4.5 GHz)

Threadripper 3990X 64 cores, 4.3 GHz)

T502:

AMD Ryzen 5 3600XT 6 cores, 4.5 GHz)

AMD Ryzen 5 5600X 6 cores, 4.6 GHz)

AMD Ryzen 7 3800XT 8 cores, 4.5 GHz)

AMD Ryzen 7 5800X 8 cores, 4.7 GHz)

AMD Ryzen 9 3900XT 12 cores, 4.7 GHz)

AMD Ryzen 9 5900X 12 cores, 4.8 GHz)

RAM

64 to 256 GB, ECC optional

GPU Options

T500:

2 bis 3 NVIDIA RTX 3090 24 GB

2 bis 3 NVIDIA RTX A6000 48 GB

T502:

2x NVIDIA RTX 3080 10 GB

2x NVIDIA RTX 3090 24 GB

T504:

4 NVIDIA RTX 3090 24 GB

Cooling

CPU liquid cooled

Low-noise radiator fan > 100000h MTBF

Main Memory

up to 2 X 4TB NVMe SSD, conﬁgurable:

QLC: 1500 MB/s read, 1000 MB/s write

TLC: 3500 MB/s read, 1750 MB/s, write

MLC: 3500 MB/s read, 2700 MB/s write

Chipset

AMD TRX40

Power Supply

1600 or 1200 watts of power depending on the

number of GPUs installed), T504 is equipped with

two power supplies. Please note the instructions on

page 4 for handling and switching on sequence.

80 PLUS Titanium or Platinum certiﬁed 96% Eciency):

92% at 20% utilization

94% at 20% utilization

90% at 80% utilization

Noise Level

Idle < 30dBA, Full Load < 50dBA

T504: Idle < 35dBA, Full Load < 60 dBA

DESIGN

Type

Mid Tower Workstation

Dimensions (WxHxD)

270 x 465 x 476 mm

Weight

T500 | T502: approx. 26 kg

T504: approx. 30 kg

SOFTWARE

Preinstalled

Linux OS Ubuntu)

AIME ML Container Manager, Docker,

AI-Frameworks TensorFlow, Keras, PyTorch, Mxnet)

CONNECTIVITY

Front

2x USB 3.1 Gen 1 ports

1x HD-Audio In

1x HD-Audio Out Stereo)

1x USB Type-C™ port mit USB 3.1 Gen 1

Back

GPU outputs depending on conﬁguration

HDMI 2.0b, USB Type-C)

2x USB 3.2 Gen1 Ports USB32G1_1_2)

2x USB 3.2 Gen1 Ports USB32G1_3_4)

2x USB 3.2 Gen2 Type-A Ports USB32G2_1_2)**

1x USB 3.2 Gen2x2 Type-C Port

PS/2 Mouse/Keyboard Port

2 x MMCX antenna connectors 2T2R)

1 x optical S/PDIF Out

5 x audio jacks Center/Subwoofer Speaker Out, Rear

Speaker Out, Line In, Line Out, Mic In)

Network

AQUANTIA® 10G LAN, Realtek 2.5G LAN

Intel® Wi-Fi 6 802.11ax 2.4Gbps) + BT 5.0

Bluetooth 5.0 + High speed class II, MU-MIMO

Electricity

T500 | T502: 1x 230V IEC connector

T504: 2x 230V IEC connector

ENVIRONMENTAL CONDITIONS

Ambient Temperature

In operation: 9°C - 37°C

Out of operation: 1°C - 60°C

Ambient Humidity

rel. Air humidity without condensation

In operation: 20 - 80%

Out of operation: 20 - 85%

06/11

AIME T500 Workstation

Arti cial Intelligence

Machines

4. Components & Cooling System

Fans (blowing out)

Cooling block with

fans (blowing out)

Fan

(sucking in)

SSD’s

RAM

CPU

Pump

(liquid cooling)

GPU’s

Liquid Cooling

(CPU)

Air Cooling

(System, GPU)

Air Cooling

(GPU)

07/11

AIME T500 Workstation

Arti cial Intelligence

Machines

5. Connectivity

Back

BIOS Flashback Button

2x USB 3.2 Gen1 Ports USB32G1_1_2)

PS/2 Mouse/Keyboard Port

Antenna Ports

Clear CMOS Button

Optical SPDIF Out Port

Audio Out: Rear Speaker Black)

Audio Out: Central / Bass Orange)

Audio In: Microphone Pink)

Audio Out: Front Speaker Lime)*

Audio Line In Light Blue)

2x USB 3.2 Gen1 Ports USB32G1_3_4)

2.5G LAN RJ-45 Port Dragon RTL8125AG)

USB 3.2 Gen2 Type-A Ports USB32G2_1_2)**

10G LAN RJ-45 Port AQUANTIA® AQC107)

USB 3.2 Gen2x2 Type-C Port

* If you use a 2-channel speaker, please connect the speaker’s

plug into „Front Speaker Jack“.

** ACPI wake-up function is not supported on USB32G2_1_2 ports

GPU outputs, depending on the individual conﬁguration

Display Port, HDMI, USB Type-C)

Network

AQUANTIA® 10G LAN, Realtek 2.5G LAN

Intel® Wi-Fi 6 802.11ax 2.4Gbps) + BT 5.0

Bluetooth 5.0 + High speed class II, MU-MIMO

Front

On / o switch

2x USB 3.1 Gen 1 ports

1x HD-Audio In

1x HD-Audio Out Stereo)

1x USB Type-C™ port mit USB 3.1 Gen 1

1

2

3

4

6

5

a

b

c

d

e

6

10

7

3

8

9

10

12

11

13

15

14

16

9

a

b

c

d

e

Activity LED

Speed LED

11

12

14

16

15

13

08/11

AIME T500 Workstation

Arti cial Intelligence

Machines

6. Cleaning & Care

Filter Cleaning

The ﬁlter on the bottom of the AIME T500 Workstation is removable and can be

cleaned with a vacuum cleaner. It is attached magnetically and easy to remove.

09/11

AIME T400 Workstation

Arti cial Intelligence

Machines

7. AIME ML Container Manager

AIME ML Container Manager

AIME has developed a container management

system that helps to easily install, run, execute and

manage Docker containers for the most common

deep learning frameworks.

Features

• Setup and run a speciﬁc version of Tensorﬂow,

Pytorch or Mxnet with one simple command

• Run dierent versions of machine learning

frameworks and required libraries in parallel

• Manage required libraries CUDA, CUDNN, CUBLAS,

etc.) in containers, without compromising the host

installation

• Clear separation of user code and framework

installation, test your code with a dierent

framework version in minutes

• Multi Session: Open and run many shell session on

a single container simultaneously

• Multi User: Separate container space for each user

• Multi GPU: Allocate GPUs per user, container or

session

• Runs with the same performance as a bare metal

installation

• Repository of all major deep learning framework

versions as containers

Available Frameworks

• Tensorﬂow

• Mxnet

• Pytorch

Available Versions

Tensorﬂow: 2.3, 1.15.4,

Mxnet: 2.0, 1.9, 1.8

Pytorch: 1.7

For more information, visit the AIME GitHub website:

https://github.com/aime-team/aime-ml-containers

10/11

AIME T500 Workstation

Arti cial Intelligence

Machines

8. Compliance & Services

SECURITY & TEST SEALS, STANDARDS

EU Directives

2011/65 / EU restriction of the use of certain

hazardous substances in electrical and electronic

equipment)

2012/19 / EU old electrical and electronic

equipment)

2014/35 / EU ready-to-use electrical equipment for

use within certain voltage limits)

2014 / 30 / EU electromagnetic compatibility)

2009/125 / EG environmentally friendly design of

computers and computer servers)

Harmonizing Standards (Power Supply)

EN 55032, Class B, EN 55024, EN 60950-1, EN 61000-

3-2, Class A/D, EN 61000-3-3, EN 61000-4-2, EN

61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-

4-6, EN 61000-4-8, EN 61000-4-11, RoHS DIRECTIVE

2011/65/), WEEE Directive 2012/19/EU)

ENVIRONMENTAL CERTIFICATIONS

80 PLUS Power Supply

The 80 Plus certiﬁcation stipulates an eciency of

80% or more. Such a power supply saves at least

33% electricity compared to conventional power

supplies.

RECOMMENDED SERVICES

Warranty Extensions*

With its ﬁxed term and ﬁxed costs, this service

enables you to plan your IT expenses more precisely.

Protect your investment and reduce the total cost

over its useful life.

Premium Support* **

You get direct contact to a qualiﬁed and experienced

AIME technician with comprehensive hardware and

software support. Your support inquiries are directly

and professionally looked after at short notice and

from start to ﬁnish.

*: Up to 5 years total term

**: May not be available in all regions.

AIME UG haftungsbeschränkt)

Bordeauxstr. 7

13127 Berlin

Germany

Tel: +49 30 459 54 380

[email protected]

http://www.aime.info

11/11

AIME T500 Workstation

Arti cial Intelligence

Machines

9.Warranty

AIME'S LIMITED WARRANTY

AIME UG haftungsbeschränkt) - hereinafter referred to as

AIME - guarantees the buyer of this device that it is free

from defects in material and workmanship for 12 months

from the date of purchase. Unless prohibited by applicable

law, this guarantee is limited to the original purchaser and

is not transferable. This warranty gives you speciﬁc legal

rights. Depending on the applicable legislation, you may

have additional rights. In general, this guarantee means for

you that the function of the device as described in the data

sheet and/or in the product documentation when used in

the intended environment is guaranteed for the life of the

product or for as long as stated on the data sheet.

Appeal

The total liability of AIME and your exclusive claim for

violations of the guarantee are at AIME's sole discretion:

1) repair or replacement of the hardware or

2) the refund of the purchase price, provided the hardware

is returned with the original invoice or a valid copy) to the

original place of purchase or to another location speciﬁed

by AIME. You may be required to pay shipping and handling

fees, customs fees, taxes, or other fees, unless prohibited

by applicable law.

AIME may, at its sole discretion, use new or used/revised,

functional parts to repair or replace the hardware. The

repaired or replaced hardware warranty is valid for the

remainder of the original warranty period, or for thirty 30)

days, whichever is longer, or for an additional period

required by applicable law.

Outdated or no longer manufactured system components

A system component that is out of date or no longer

manufactured will be replaced by the same product if

possible. If AIME is unable to replace an outdated or

discontinued product with the same product, AIME will

replace it with a product that has a similar function.

Exceptions

This guarantee does not apply to problems or damage that

arise in particular from the following causes:

1. Wear caused by normal use

2. Modiﬁcation, misuse, accident, dismantling, incorrect

use or unauthorized repair

3. Removal of the rating plate or any manipulation of test

labels or guarantee seals

4. Improper use, including use not in accordance with the

supplied instructions for use

5. Connection to an unsuitable voltage source

6. Any other cause that is not related to a material or

manufacturing defect of the product.

The transport, storage and operation of the workstation

should only be carried out under the environmental

conditions speciﬁed overleaf, to protect against damage

and errors.

Limitation of Liability

AIME IS NOT LIABLE FOR SPECIAL AND INDIRECT

DAMAGES OR CONSEQUENTIAL DAMAGES, IN PARTICULAR

NOT FOR LOST PROFITS AND REVENUES, DIRECT OR

INDIRECT DATA LOSSES OR ECONOMIC LOSSES FROM THE

IDENTIFICANTLY, OR IN THE LOST, LOST, IMPROPRIATE WAY

KNOWLEDGE HAS BEEN SET

Legislation in some countries prohibits the exclusion or

limitation of special and indirect and consequential

damages, so this limitation and exclusion may not apply to

the legislation that applies to you.

Duration of the Floating Guarantees

UNLESS THAT IS PROHIBITED BY APPLICABLE LAW, ANY

IMPLIED WARRANTY OR REPRESENTATION IS LIMITED TO

THE MERCHANTABILITY OR FITNESS OF THIS APPLIANCE

FOR A PARTICULAR PURPOSE, LIMITED TO THE DURATION

OF THE APPLICABLE LIMIT.

Laws in some countries do not allow limitations on how

long an implied warranty lasts, so this limitation may not

apply to the legislation that applies to you.

National Legal Rights

Consumers may have legal rights under current legislation

that regulates the sale of consumer goods. Such rights are

not aected by the guarantees in this limited guarantee.

Registration of a Warranty Claim

We recommend that you contact our technical support

team or read the technical support section on our website

prior to submitting a warranty claim. You may be able to

easily ﬁx your problem yourself this way. You can ﬁnd the

contact details for our customer service on the Internet at

http://www.aime.info/imprint. You will receive a goods-

return-number by email via the contact address

[email protected].

Web: http://www.aime.info,

Email: [email protected],

Phone: +49 30 459 54 380

Adress: AIME UG haftungsbeschränkt),

Bordeauxstr. 7,

13127 Berlin, Germany

AIME T500 Workstation

Arti cial Intelligence

Machines

Notes

_______________________________________________________________________________________________________________

AIME UG haftungsbeschränkt)

Bordeauxstr. 7

13127 Berlin

Germany

http://www.aime.info

AIME T500 User manual

Popular Desktop manuals by other brands
