Aime T400 User manual

User Guide

AIME T400 - WORKSTATION

02/12

AIME T400 Workstation

Artiﬁ ial Intelligen e

Ma hines

Contents

1. Devi e Des ription & S ope of Delivery 03

2. Important Safety Instru tions 04

3. Te hni al Spe iﬁ ation 05

4. Components & Cooling System 06

5. Conne tivity 07

6. Cleaning & Care 08

7. Liquid Cooling 09

8. AIME ML Container Manager 10

9. Complian e & Servi es 11

10. Warranty 12

AIME U (limited liability). Other brands may be trademarks of their respective owners.

This product was individually made to customer speciﬁcations. The ocially stated prices are

subject to change without notice. If you have any questions about the price, please contact

your AIME customer manager.

AIME is not responsible for incorrect images or printing errors.

03/12

AIME T400 Workstation

Artiﬁ ial Intelligen e

Ma hines

1. Devi e Des ription & S ope of Delivery

Devi e Des ription

The AIME T400 is a workstation that is designed for

deep learning development and has been optimized

for maximum performance with regard to low

volume development and the lowest possible energy

consumption without compromising on durability and

reliability.

All installed components were selected for their

energy eciency, durability, compatibility and high

performance. They are perfectly balanced with each

other so that there are no performance bottlenecks.

The elobareted cooling system of the AIME T400

covers the CPU and all PUs with a stream of liquid

cooling. High thermal conduction blocks and the far

higher cooling capabilities of liquid compared to air

keeps the operation temperature of all components

well below 60°C.

The secured low operation temperature reduces

stressful overheating for PU and CPU silicons and

allows that all components keep operating at their

highest performance levels even under full load in

24/7 scenarios.

The large radiators in the front and on top of the

system are cooled by high durability noise reduced

fans with a guaranteed operation of more than 10

years MTBF. This setup keeps the system cooler,

more performant, durable and far less noisy than an

collection of many small fans for each component.

The AIME T400 enables you to train deep learning

models at up to four times the speed of a single PU,

without throttling the computing power due to heat.

This means AI supercomputing performance with

over 400 trillion tensor FLOPS, which is equivalent to

the performance of hundreds of conventional

servers.

AIME workstations are delivered with a pre-installed

Linux operating system and are preconﬁgured with

the latest drivers and frameworks such as

Tensorﬂow, Keras, PyTorch and Mxnet.

The pre-installed AIME ML Container Manager oers

a comprehensive software stack, with which

developers can comfortably set up AI projects and

navigate between frameworks and projects. The

libraries and PU drivers required for the respective

deep learning framework are loaded in

preconﬁgured Docker containers and can be

conﬁgured and started with simple commands. The

most common frameworks - i.a. TensorFlow, Keras,

PyTorch and Mxnet - are pre-installed and ready to

use.

The AIME ML Container Manager makes life easier

for developers, so they don't have to worry about

problems installing the framework versions.

AIME customers log in immediately after unpacking

and start development right away with their

preferred deep learning framework.

S ope of Delivery

1x AIME Workstation T400

1x power cable for power supply

(IEC connector on protective contact)

1x WLAN antenna

1x quick start guide with individual access data

1x technical speciﬁcations

04/12

AIME T400 Workstation

Artiﬁ ial Intelligen e

Ma hines

2. Important Safety Instru tions

CAUTION - RISK OF ELECTRIC SHOCK!

WATCH OUT! When using the workstation, the basi

safety rules must always be followed to avoid

injuries, overvoltage, ﬁre and ele tri sho k:

1. Follow the manufacturer's instructions and safety

instructions during installation. Failure to do so can

damage the device and cause serious injury or death.

2. The device operateson high voltage. Never open

the device and do not try to repair it. Above all, never

open the power supply - not even when it is switched

o - there is a risk to life and can lead to injuries,

overvoltage, ﬁre and electric shock!

3. This product is only intended for indoor use.

4. Do not use the device near water or at high

temperatures or in environments with high humidity.

5. Do not use the device during thunderstorms. In the

event of a thunderstorm, pull the power plug from

the power supply to protect it from damage caused

by lightning and overvoltage and to protect people.

6. Do not place the device near heat sources such as

fan heaters, heaters, stoves or other devices that

generate heat.

7. Do not insert any objects into the open areas of the

ventilation or fan grilles of the device.

8. The device needs adequate ventilation. Make sure

there is a distance of at least 10 cm on both sides,

front and back. Do not place any objects on the top,

the fans must remain free.

9. Do not modify any cables or connectors included

with this device.

10. Only use power cords that are compatible with

the device's power supply model. When using other

cables, the contacts may not be compatible, which

can seriously damage your device.

11. Modiﬁcations inside the device are only to be

carried out by a specialist. Before starting such work,

switch o the device and pull out the main power

plug. ESD protective measures must be observed

during all work.

12. Failure to observe the manufacturer's

instructions or one of these safety instructions, as

well as opening the device or removing, severing or

damaging one of the guarantee seals leads to the

immediate loss of all warranty and guarantee claims.

13. This device has been developed in such a way

that all speciﬁed EN classiﬁcations are only met if it

is used within a completely closed metal housing.

14. Make sure that your data is backed up regularly

to prevent data loss due to faulty data carriers,

memory modules and other hardware and software

errors or malware. In the event of a defect, the data

can then quickly be restored.

*: Notes on ESD prote tion

Electronic components are very sensitive to electrostatic

discharge. Therefore, never touch chips and contacts on circuit

boards directly, but only on the outer edges of the circuit board

without touching contacts or components. Ensure electrical

grounding on the housing or on metallic objects, e.g. radiators.

05/12

AIME T400 Workstation

Artiﬁ ial Intelligen e

Ma hines

3. Te hni al Spe iﬁ ation

PERFORMANCE

CPU ( onﬁgurable)

Threadripper 1920X (12 cores, 4 Hz)

Threadripper 1950X (16 cores, 4 Hz)

Threadripper 2920X (12 cores, 4.3 Hz)

Threadripper 2950X (16 cores, 4.3 Hz)

Threadripper 2970X (24 cores, 4.2 Hz)

Threadripper 2990X (32 cores, 4.2 Hz)

RAM

64 or 128 B, ECC optional

GPU

2 to 4 NVIDIA RTX 2080 TI

Cooling

CPU and PU liquid cooled

Low-noise radiator fan > 100000h MTBF

Main Memory

up to 2 X 2TB NVMe SSD, conﬁgurable:

QLC: 1500 MB/s read, 1000 MB/s write

TLC: 3500 MB/s read, 1750 MB/s, write

MLC: 3500 MB/s read, 2700 MB/s write

Chipset

AMD X399

Power Supply

1600 or 1200 watts of power (depending on the

number of PUs installed),

80 PLUS Titanium or Platinum certiﬁed (96% Eciency):

92% at 20% utilization

94% at 20% utilization

90% at 80% utilization

Noise Level

Idle < 30dBA, Full Load < 40dBA

DESIGN

Type

Mid Tower Workstation

Dimensions (WxHxD)

233 x 465 x 538 mm

Weight

approx. 23 kg

SOFTWARE

Preinstalled

Linux OS (Ubuntu)

AIME ML Container Manager, Docker,

AI-Frameworks (TensorFlow, Keras, PyTorch, Mxnet)

CONNECTIVITY

Front

1 x USB Type-C™ port with USB 3.1 en 1

2 x USB 3.1 en 1 ports

Ba k

PU outputs depending on conﬁguration

(HDMI 2.0b, USB Type-C)

1 x USB Type-C™ USB 3.1 en 2

1 x USB 3.1 en 2 Type-A

8 x USB 3.1 en 1

1 x PS/2 keyboard/mouse port

1 x RJ-45 port

2 x MMCX antenna connectors (2T2R)

1 x optical S/PDIF Out

5 x audio jacks (Center/Subwoofer Speaker Out, Rear

Speaker Out, Line In, Line Out, Mic In)

Network

2 x 1000 MBit LAN

Intel® Wi-Fi 802.11, 2.4/5 Hz Dual-Band

BLUETOOTH 4.2, 4.1, BLE, 4.0, 3.0, 2.1+EDR

Ele tri ity

1x 230V IEC connector

ENVIRONMENTAL CONDITIONS

Ambient Temperature

In operation: 9°C - 37°C

Out of operation: 1°C - 60°C (liquid cooling)

Ambient Humidity

rel. Air humidity without condensation

In operation: 20 - 80%

Out of operation: 20 - 85%

06/12

AIME T400 Workstation

Artiﬁ ial Intelligen e

Ma hines

4. Components & Cooling System

Cooling blo ks with

fans (blowing out)

Fan

(su king in)

Flux Capa itor

(surge tank)

Pump

(liquid ooling)

Power Adapter SSD’s

RAM

CPU

GPU’s

Liquid Cooling

(System)

Air Cooling

(System)

Air Cooling

(Power Adapter)

07/12

AIME T400 Workstation

Artiﬁ ial Intelligen e

Ma hines

5. Conne tivity

Ba k

1x PS/2 keyboard/mouse port

2x USB 3.1 en 1 port mit DAC--UP

1x USB 3.1 en 1 port (white) with Q-Flash Plus for BIOS Upgrade

5x USB 3.1 en 1 ports (Standard)

1x USB Type-C™ port, with USB 3.1 en 2 Support

1x USB 3.1 en 2 Type-A port (red)

2x RJ-45 ports (Netzwerk, 1000 MBit LAN)

2x MMCX antenna connectors (2T2R)

1x optical S/PDIF Out connector

5x audio jacks (Rear, Center/Subwoofer Speaker Out,

Mic In, Speaker/Line Out, Line In)

PU outputs, depending on the individual conﬁguration

(Display Port, HDMI, USB Type-C)

Network

2x 1000 MBit LAN

Intel® Wi-Fi 802.11, 2.4/5 Hz Dual-Band

BLUETOOTH 4.2, 4.1, BLE, 4.0, 3.0, 2.1+EDR

Front

1x HD-Audio Out

1x HD-Audio In

1x USB Type-C™ port with USB 3.1 en 1

On / o switch

Reset switch

2x USB 3.1 en 1 ports

1

2

3

4

5

a

b

c

d

e

f

5

6

7

8

9

8

10

9Speed LED

Activity LED

a b c d e f

08/12

AIME T400 Workstation

Artiﬁ ial Intelligen e

Ma hines

6. Cleaning & Care

Filter Cleaning

The ﬁlters on the front and top of the AIME T400 Workstation are removable and

can be cleaned with a vacuum cleaner.

09/12

AIME T400 Workstation

Artiﬁ ial Intelligen e

Ma hines

7. Liquid Cooling

Che k Liquid Level

The liquid cooling of the AIME T400 is designed for problem-free operation of

7-10 years. If the PU temperature rises to such an extent that individual PUs

cause self-throttling or if a gurgling noise can be heard continuously, please

contact AIME customer support.

If you have an AIME T400 as "White lass" edition, you can visually check the liquid

level yourself. If the ﬁll level is below 50%, the tank should be ﬁlled with coolant. To

do this, please contact AIME customer support for recommended and compatible

coolant and instructions for ﬁlling the expansion tank.

Cloudiness of the coolant over time is normal and does not impair its function.

After transporting the AIME T400 Workstation, there may initially be some noise

("gurgling") when the device is put into operation - if the device was on its side

during transport or "upside down". If these noises persist for a long time, it can be

assumed that there is too little liquid in the cooling circuit. Then please contact

AIME customer support.

AIME Customer-Support: [email protected]

10/12

AIME T400 Workstation

Artiﬁ ial Intelligen e

Ma hines

8. AIME ML Container Manager

AIME ML Container Manager

AIME has developed a container management

system that helps to easily install, run, execute and

manage Docker containers for the most common

deep learning frameworks.

Features

• Setup and run a speciﬁc version of Tensorﬂow,

Pytorch or Mxnet with one simple command

• Run dierent versions of machine learning

frameworks and required libraries in parallel

• Manage required libraries (CUDA, CUDNN, CUBLAS,

etc.) in containers, without compromising the host

installation

• Clear separation of user code and framework

installation, test your code with a dierent

framework version in minutes

• Multi Session: Open and run many shell session on

a single container simultaneously

• Multi User: Separate container space for each user

• Multi PU: Allocate PUs per user, container or

session

• Runs with the same performance as a bare metal

installation

• Repository of all major deep learning framework

versions as containers

Available Frameworks

• Tensorﬂow

• Mxnet

• Pytorch

Available Versions

Tensorﬂow: 2.0.0, 1.15.0, 1.15, 1.14.0, 1.13.2

Mxnet: 1.5.0, 1.4.1, 1.3.1

Pytorch: 1.3.0, 1.2.0, 1.1.0

For more information, visit the AIME itHub website:

https://github. om/aime-team/aime-ml- ontainers

11/12

AIME T400 Workstation

Artiﬁ ial Intelligen e

Ma hines

9. Complian e & Servi es

SECURITY & TEST SEALS, STANDARDS

EU Dire tives

2011/65 / EU (restriction of the use of certain

hazardous substances in electrical and electronic

equipment)

2012/19 / EU (old electrical and electronic

equipment)

2014/35 / EU (ready-to-use electrical equipment for

use within certain voltage limits)

2014 / 30 / EU (electromagnetic compatibility)

2009/125 / E (environmentally friendly design of

computers and computer servers)

Harmonizing Standards (Power Supply)

EN 55032, Class B, EN 55024, EN 60950-1, EN 61000-

3-2, Class A/D, EN 61000-3-3, EN 61000-4-2, EN

61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-

4-6, EN 61000-4-8, EN 61000-4-11, RoHS (DIRECTIVE

2011/65/), WEEE (Directive 2012/19/EU)

ENVIRONMENTAL CERTIFICATIONS

80 PLUS Power Supply

The 80 Plus certiﬁcation stipulates an eciency of

80% or more. Such a power supply saves at least

33% electricity compared to conventional power

supplies.

RECOMMENDED SERVICES

Warranty Extensions*

With its ﬁxed term and ﬁxed costs, this service

enables you to plan your IT expenses more precisely.

Protect your investment and reduce the total cost

over its useful life.

Premium Support* **

You get direct contact to a qualiﬁed and experienced

AIME technician with comprehensive hardware and

software support. Your support inquiries are directly

and professionally looked after at short notice and

from start to ﬁnish.

*: Up to 5 years total term

**: May not be available in all regions.

AIME U (haftungsbeschränkt)

Bordeauxstr. 7

13127 Berlin

ermany

Tel: +49 30 917 49 821

[email protected]

http://www.aime.info

12/12

AIME T400 Workstation

Artiﬁ ial Intelligen e

Ma hines

10.Warranty

AIME'S LIMITED WARRANTY

AIME U (haftungsbeschränkt) - hereinafter referred to as

AIME - guarantees the buyer of this device that it is free

from defects in material and workmanship for 12 months

from the date of purchase. Unless prohibited by applicable

law, this guarantee is limited to the original purchaser and

is not transferable. This warranty gives you speciﬁc legal

rights. Depending on the applicable legislation, you may

have additional rights. In general, this guarantee means for

you that the function of the device as described in the data

sheet and/or in the product documentation when used in

the intended environment is guaranteed for the life of the

product or for as long as stated on the data sheet.

Appeal

The total liability of AIME and your exclusive claim for

violations of the guarantee are at AIME's sole discretion:

1) repair or replacement of the hardware or

2) the refund of the purchase price, provided the hardware

is returned with the original invoice (or a valid copy) to the

original place of purchase or to another location speciﬁed

by AIME. You may be required to pay shipping and handling

fees, customs fees, taxes, or other fees, unless prohibited

by applicable law.

AIME may, at its sole discretion, use new or used/revised,

functional parts to repair or replace the hardware. The

repaired or replaced hardware warranty is valid for the

remainder of the original warranty period, or for thirty (30)

days, whichever is longer, or for an additional period

required by applicable law.

Outdated or no longer manufa tured system omponents

A system component that is out of date or no longer

manufactured will be replaced by the same product if

possible. If AIME is unable to replace an outdated or

discontinued product with the same product, AIME will

replace it with a product that has a similar function and

Ex eptions

This guarantee does not apply to problems or damage that

arise in particular from the following causes:

1. Wear caused by normal use

2. Modiﬁcation, misuse, accident, dismantling, incorrect

use or unauthorized repair

3. Removal of the rating plate or any manipulation of test

labels or guarantee seals

4. Improper use, including use not in accordance with the

supplied instructions for use

5. Connection to an unsuitable voltage source

6. Any other cause that is not related to a material or

manufacturing defect of the product.

The transport, storage and operation of the workstation

should only be carried out under the environmental

conditions speciﬁed overleaf, to protect against damage

and errors.

Limitation of Liability

AIME IS NOT LIABLE FOR SPECIAL AND INDIRECT

DAMA ES OR CONSEQUENTIAL DAMA ES, IN PARTICULAR

NOT FOR LOST PROFITS AND REVENUES, DIRECT OR

INDIRECT DATA LOSSES OR ECONOMIC LOSSES FROM THE

IDENTIFICANTLY, OR IN THE LOST, LOST, IMPROPRIATE WAY

KNOWLED E HAS BEEN SET

Legislation in some countries prohibits the exclusion or

limitation of special and indirect and consequential

damages, so this limitation and exclusion may not apply to

the legislation that applies to you.

Duration of the Floating Guarantees

UNLESS THAT IS PROHIBITED BY APPLICABLE LAW, ANY

IMPLIED WARRANTY OR REPRESENTATION IS LIMITED TO

THE MERCHANTABILITY OR FITNESS OF THIS APPLIANCE

FOR A PARTICULAR PURPOSE, LIMITED TO THE DURATION

OF THE APPLICABLE LIMIT.

Laws in some countries do not allow limitations on how

long an implied warranty lasts, so this limitation may not

apply to the legislation that applies to you.

National Legal Rights

Consumers may have legal rights under current legislation

that regulates the sale of consumer goods. Such rights are

not aected by the guarantees in this limited guarantee.

Registration of a Warranty Claim

We recommend that you contact our technical support

team or read the technical support section on our website

prior to submitting a warranty claim. You may be able to

easily ﬁx your problem yourself this way. You can ﬁnd the

contact details for our customer service on the Internet at

http://www.aime.info/imprint. You will receive a goods-

return-number by email via the contact address

[email protected].

Web: http://www.aime.info,

Email: [email protected],

Phone: +49 30 917 49 821

Adress: AIME U (haftungsbeschränkt),

Bordeauxstr. 7,

13127 Berlin, ermany

AIME T400 Workstation

Artiﬁ ial Intelligen e

Ma hines

Notes

_______________________________________________________________________________________________________________

AIME U (haftungsbeschränkt)

Bordeauxstr. 7

13127 Berlin

ermany

http://www.aime.info

AIME T400 User manual

Popular Desktop manuals by other brands
