Ainol NOVO 7 Crystal User manual

Enjoy Life Enjoy AINOL
-1-www.ainol.com
Preface
Firstly thanks a lot for using Ainol digital products--NOVO 7 Crystal Quad core Tablet PC, sincerely hope you can enjoy it. This
manual will introduce the feature of this product that allows you to fully understand how to use it. For your ease to operate the
device as soon as possible, please read the instructions before using the machine so that you can properly use it!
1、It is based onAndroid 4.1 operating system that supports wireless Internet
2、It use 7.0-inch HD screen 1024*600 resolution
3、Camera: Front 0.3 Mega Pixel
4、It supports five points capacitive touch screen and button operation.
5、The CPU is: ATM7029ARM cortex A9 Family Quad core.
6. 1.0 GB DDR3 RAM and 1.0 GB ROM.
7、The picture used in the manual may be different from UI in the device, please subject to the device!

Enjoy Life Enjoy AINOL
-2-www.ainol.com
Content
Preface.............................................01
Keystroke Operation..........................04
Note.......................................06
Basic Operation.................................08
Emails............................................11
H D M e d i a P l a y e r . . . . . . . . . . . . . . . . . . . . . 1 2
Calculator.......................................12
Calendar...................................13
Setting........................................14
C l oc k...............................................16
Camera..............................................19
TF card .........................................23
Mobile storage function..............................24
USB Recharging.......................................25
FA Q. ................................................26
Product specification................................28

Enjoy Life Enjoy AINOL
-3-www.ainol.com
Accessories: If there is any change, we will advise
Novo7 Crystal Quad core

Enjoy Life Enjoy AINOL
-4-www.ainol.com
I.Main function
● 7.0 inch HD Display 1024*600 resolution；
●Support Android 4.1 operating system;
●Support APK application and installation
● Support 1080P full HD format video play;
●Support G-Sensor for screen rotation function;
● Support IR remote control operation;
● Support audio play format:MP3, WAV, (APE, FLAC,AAC, OGG need to install third-party software);
● Support TF card, capacity is 2GB--32GB;
● Support multi-format video play;
● Support JPG, BMP, PNG, GIF format picture browsing;
● Built-in microphone, can support ultra-long recording;
● Energy-saving setting, brightness freely adjustable, can set up automatic shutdown;
● Support and compatible for WIN2000, WINXP, VISTA, WIN7 system;
● Support e-book and bookmark functions;
Novo7 Crystal Quad core

Enjoy Life Enjoy AINOL
-5-www.ainol.com
● Support firmware upgrade;
● Support multi-task, can read eBook while listening to music
II、Note
This manual contains important safety measures and information to use the product correctly.
In order to avoid using improperly, please read the manual carefully before using it.
●Never use the device in extremely cold, hot, dusty and moist environment
Please avoid the device falling down, being hit strongly and suffering severe vibration.
Otherwise, it would lead to the damage or abnormal display of the TFT Screen.
The user is responsible with the damage in this circumstance.
Battery life will vary as the conditions and environment in use
Please charge the battery in time if any following conditions:
A. The system warns that the power is low
B. There is no respond when operating the keys

Enjoy Life Enjoy AINOL
-6-www.ainol.com
When the device is formatting, uploading or downloading documents do not disconnect it suddenly. Otherwise it will
probably lead to player failure. We are not responsible for any document losses incurred by damage and repair the
machine or other reasons. Please use it as the manual and copy the important data in time. If you have any questions,
please connect to the dealer. Do not disassemble the machine independently. Otherwise, you will lose the warranty that
our company is committed to. The user will be responsible for the entire problem caused by disassembling the machine
without permission.
Because the difference of calculating the capacity, the player system firmware and FLASH memory FAT partition table
should occupy a certain space. There might be some discrepancies between the memory capacity marked on the logo
and the memory capacity connected to PC, which depend on the firmware version and FLASH category used by the
tablet.
At present, there are many viruses in the computer. It is easy to damage the local documents and firmware by the virus.
Please strengthen the prevention. If it is infective which cause the failure of the tablet. Please upgrade the firmware in
the computer after you ensure that it has no virus, and then format it to solve the problem.

Enjoy Life Enjoy AINOL
-7-www.ainol.com
The product performance and functionality may be different with different version of software. We’ll not give further
notice. The company reserves the right to improve the product.
III、Basic Operation
●Power On/ OFF
Power On: In the turn-off status, press the power button for 3 seconds, the unit will enter the main interface after the boot.
(Slightly longer boot time, please be patient.)
Power Off: In the power-on status, press the power button for 3
seconds, the pop-up interface, select "Shut Down" option to
shutdown, otherwise click "cancel" option; press the power button to
close screen, press again to open screen, drag lock up
can unlock and return to the main interface.
窗口切换键

Enjoy Life Enjoy AINOL
-8-www.ainol.com
Main Screen Button operation:
: Enter the main screen
: Check the history record
: Return to main Interface from any Interface
: Return to last layer
Main Interface operation:
Clicking at any point in the center of the main interface can set he wallpaper.
Wireless Internet function: click on "Google search" in the main interface, then input the contents with the pop-up keyboard input.
After the input is complete, click to enter website.
Click the on main screen or the menu button on the device, the below interface will display:

Enjoy Life Enjoy AINOL
-9-www.ainol.com
Main Function menu operation:
Click this function button, full-featured pop-up menu, such as below:
This window shows all the features of the machine icon, click on any icon
to access the relevant function interface, click on the main interface key
to return to the main interface.
Click “windows widget” to add widget of all functions in any window

Enjoy Life Enjoy AINOL
-10-www.ainol.com
IV、Emails
Click “emails” to enter user account interface and then log in to send
and receive emails. (Require to register a google account)
V、HD Media Player
On the main screen click on "HD media player" option, you can access
the video files list interface, the point of a video can be selected into the
video player interface. Click anywhere on the screen can show or hide
the video set icon, and click to set.
Esc, return the previous interface
Previous video
Pause
Fast forward

Enjoy Life Enjoy AINOL
-11-www.ainol.com
Ⅵ、Calculator
In the main menu interface, click the "calculator" option, you can enter
the calculator display screen, click on the numbers and operators, can be
"add, subtract, multiply, divide,"
Browser
Under the main menu, click “Browser" to enter into the internet interface. The
default home page of this device is “Google”.
Click “website column”to pop up the keyboard for new website address;
Click “content column " to pop up the keyboard for new searching content.

Enjoy Life Enjoy AINOL
-12-www.ainol.com
check webpag bookmark, history record and Saved webpage
enter the interface of browser setting
pop up the keyboard for searching content
add the current webpage as bookmark
Click icon to hide the keyboard after puting in the website, click
to enter the webpage.
Please click icon or the menu button on the unit when browsing the
webpagem, the operation menu will pop up as below:
Click”refresh”to refresh the current webpage
Ⅶ、Calendar
In the main menu screen click "calendar" option, you can have access to
the calendar display, then view or set it

Enjoy Life Enjoy AINOL
-13-www.ainol.com
VIII、Setting
In the main menu click the “setting “option can enter the system menu setting
interface
1. Wireless and network
Wi-Fi: turn on/off WI-FI
Click “scan” to scan all the WIFI networks available within the range
Click” add network” to pop up Diaglog box. User can add the aimed network
to the WIFI network list after setting the network SSID and the security.
Click on any network, pass the safety test (input the wireless password), and

Enjoy Life Enjoy AINOL
-14-www.ainol.com
then click “ connect”to set this network as current online network.
Click to pop up “advanced settings interface” for advanced setting
Flow status: check the flow status
More: set air mode,VPN and mobile network
2. Device:
Sound: This can be set into the silent mode, volume, notification tone, key Sound, screen locked tone
Display: Enter this to set the screen brightness, automatically rotate screen, wallpapter,
Memory: User can tap to view the internal memory, SD card capacity, free space and relevant operations.
Battery: Click to check the batery status
Application: check all the apps in the unit which is download or in operation.
3、Personal Setting
Accounts and synchronization: Set the background data automatically synchronize
The location: Set the google location service and google searching
Security: set screen unlock pattern, password and unit Management
The language and keyboard: The system can set the language, input methods, keyboard and mouse.

Enjoy Life Enjoy AINOL
-15-www.ainol.com
Save document and reset: The user can save personal document and restore the machine to factory state.
4、System
The date and time: User can set to automatically gain the data and time from the network, and can also manually set the date /
time zone / time / format.
Auxiliary function: Click to set the Auxiliary functions
Developer choice: enter into the develop choice
About this tab: View state of the machine, electricity usage, legal information, hardware type, firmware version of MID and internal
version.
IX、Clock
In the main menu interface, click the "clock" option, enter the clock
Interface.
Click any point on the screen to adjust the brightness of the screen
Click “alarm setting” to add alarm function

Enjoy Life Enjoy AINOL
-16-www.ainol.com
X、Search
Under the main menu click the “search”into the following interface
Under the searching interface, Click to pop up setting Interface, then set searching network and apps.

Enjoy Life Enjoy AINOL
-17-www.ainol.com
XI、Audio Record
Under the state of main menu, select “Record” option, enter into
the Record interface . Click button to start record; Click
button to stop record and save it; click to display current
recording file.
XII、File Management
In the "File Manager", it list show all the files in the internal memory and SD Card. Click to enter one layer by one layer, which
list the files under the current folder.
check the files stored in the internal memory
check the files in the SD Card
check all the photos
check all videos

Enjoy Life Enjoy AINOL
-18-www.ainol.com
return to previous laye
XIII、App Installer
This device supports APK installation, uninstallation.
Click any APK in the File Management to access installation Interface. Click “installation” to start installing this APK.
Uninstallation: enter “applications interface “in the “setting “menu to uninstall the APK
XIV、Camera
In the main menu interface, click the "camera" option, you can enter the camera interface

Enjoy Life Enjoy AINOL
-19-www.ainol.com
Click it to change to video
Click it to change to photo-taking
Enter to the camera interface, click the icon , can be photographed and saved automatically. Top right of screen, click the
small icon to view the photos taken. On the right corner of the interface，click to show or hide the camera settings menu.
Click to set the exposure, photo quality, and camera.
Switch the front and back camera
Enter into the video screen, click the icon , can be video, click again to pause and automatically saved. Click the small

Enjoy Life Enjoy AINOL
-20-www.ainol.com
icon in the upper right corner, the recorded video can be played; in the video shown on the right corner of the interface click to
show or hide the video settings menu. Click to restore the default settings (as shown).
Click to set the screen effect of the video
switch the front and back camera
XV、Music Player
In the main menu interface, click the "Music Player" into the file list interface, select any music to play.
Click the icon to return to the Now Playing list.
Shuffle icon: Click to open or close the Shuffle
Click the icon to set the "repeat the current song, repeat all songs,
repeat off", etc.
Click the icon to play on last song.
Click to pause and play the current song.
Click to play the next song
