Air King AIF10X Manual

Inline Fans
Specifications subject to change. • CFM = cubic feet per minute
Please note: The Home Ventilation Institute (HVI) does not currently have a sound test standard for remote mounted fans.
As a result sound levels (sones) are not listed. In most cases, a remote fan will be quieter than one mounted within the living area.
†Model AIF10X is not ENERGY STAR®Labeled
Inline Exhaust Fan Series
EXHAUST HVI CFM/
MODEL DESCRIPTION DUCT SIZE WATTS @ .2 WG
AIF4X Inline Exhaust Fan 4" 19 100
AIF6Y Inline Exhaust Fan 6" 71 230
AIF8X Inline Exhaust Fan 8" 122 360
AIF10X Inline Exhaust Fan†10" 240 600
Center your ventilation needs
around the power of the AIF Series
Inline Fans.
The AIF Series Inline Fans provide the driving
power of the system, giving it life. Designed for
long life and dependable performance, utilizing
an external rotor motorized impeller gives you
the knowledge that the fan will provide years
of worry-free ventilation.
The AIF Series is constructed of UL-recognized
and UV-protected thermoplastic resin and is
approved for mounting in wet locations.
Inline Fans take the noise away from the room.
Because the fan is remotely mounted, the sound
generated from the fan is minimized allowing
for a peaceful and quiet room.
ENERGY STAR®fans (models AIFX, AIF6Y, AIF8X), give you
the assurance that your room is being properly
ventilated the most efficient way.
FEATURES
•Prewired for simple and quick installation
•ENERGY STAR®models AIF4X, AIF6Y, AIF8X
•Ideal for multiple point exhaust, instead of a
single fan for each installation point
•Able to be used with a variable speed control
•UL approved for wet locations for both
residential and commercial applications and
rated for continuous duty

Inline Fan Kits
Specifications subject to change. • CFM = cubic feet per minute
Please note: The Home Ventilation Institute (HVI) does not currently have a sound test standard for remote mounted fans.
As a result sound levels (sones) are not listed. In most cases, a remote fan will be quieter than one mounted within the living area.
†Model AIK24Y is not ENERGY STAR®Labeled
Inline Exhaust Fan Kit
EXHAUST COLLAR HVI CFM/
MODEL DESCRIPTION DUCT SIZE DUCT SIZE WATTS @ .2 WG
AIK14X Fan/Intake Grill 4" 4" 19 100
AIK16X Fan/Intake Grill 6" 6" 61 190
AIK24Y Fan/2 Intake Grills 6" 4" 80 150
AIK26Y Fan/2 Intake Grills 6" 6" 71 230
Effectively solve your ventilation
needs with the simplicity of an
Inline Fan Kit.
Inline Fan Kits provide the components needed
for most installations. Add the ducting
accessories specific to your installation and
you’re ready to go.
The Inline Fan Kits include an ENERGY STAR®AIF
Series fan along with low profile and
unobtrusive inlet grills for either a single port
or dual port installation. The number of grills
included with the kit will depend on the specific
kit you choose.
DUAL INLET KIT FEATURES
•2 Low profile and unobtrusive inlet grills
•2 Collars with metal back draft damper that
includes a rubber gasket to reduce the sound
level during opening and closing
•Powerful ENERGY STAR®AIF Series fan with
mounting bracket and Y transition
SINGLE INLET KIT FEATURES
•Low profile and unobtrusive inlet grill
•Collar with metal back draft damper that
includes a rubber gasket to reduce the sound
level during opening and closing
•Powerful ENERGY STAR®AIF Series fan with
mounting bracket Models AIK14X, AIK16X
Models AIK24Y, AIK26Y

Inline Fan/Light Kits
Specifications subject to change. • CFM = cubic feet per minute
Please note: The Home Ventilation Institute (HVI) does not currently have a sound test standard for remote mounted fans.
As a result sound levels (sones) are not listed. In most cases, a remote fan will be quieter than one mounted within the living area.
†Models AIK14XL and AIK26YL are not ENERGY STAR®Labeled
Inline Exhaust Fan Kits with Light
EXHAUST HOUSING HVI CFM/
MODEL DESCRIPTION DUCT SIZE DUCT SIZE WATTS @ .2 WG
AIK14XL Fan/Intake Grill/Halogen Light†4" 4" 19 100
AIK14XF Fan/Intake Grill/Fluorescent Light 4" 4" 19 100
AIK26YL Fan/2 Intake Grills/2 Halogen Lights†6" 4" 71 230
AIK26YF Fan/2 Intake Grills/2 Fluorescent Lights 6" 4" 71 230
Effectively solve your ventilation
and lighting needs with the
simplicity of an Inline Fan/Light Kit.
Inline Fan Kits provide the components needed
for most installations. Add the ducting
accessories specific to your installation and
you’re ready to go.
The Inline Fan/Light Kits include an ENERGY STAR®
AIF Series fan along with low profile and
unobtrusive inlet grills for either a single port or
dual port installation. Choose from either a bright
Halogen light (models AIK14XL, AIK26YL) or an energy
efficient Fluorescent light (models AIK14XF, AIK26YF).
No need to search for a light bulb with the Inline
Fan/Light Kits, they are included with the unit.
Just one more convenience Air King offers.
DUAL INLET KIT FEATURES
•2 Low profile inlet grills with lights
•2 Housings with metal back draft damper
that includes a rubber gasket to reduce the
sound level during opening and closing
•Powerful ENERGY STAR®AIF Series fan with
mounting bracket and Y transition
SINGLE INLET KIT FEATURES
•Low profile inlet grill with light
•Housing with metal back draft damper that
includes a rubber gasket to reduce the sound
level during opening and closing
•Powerful ENERGY STAR®AIF Series fan with
mounting bracket
Model AIK26YF
Model AIK14XL

Intake Grills
The Air King Intake Grills allow
you to finish your system in style.
Whether you are adding to an existing system
or creating a custom one, Air King offers the
intake grill to finish it with style.
Air King provides the option to customize your
system for your specific needs with our standard
inlet grills or upgrade to a light combination
with either a bright Halogen or energy efficient
Fluorescent lamp.
All intake grills feature a metal back draft
damper that includes a rubber gasket to reduce
the sound level during opening and closing.
GRILL WITH LIGHT FEATURES
•Low profile inlet grill with light INCLUDES
either a bright Halogen (AIG46HL) or energy
efficient Fluorescent (AIG46F) lamp
•Metal housing for easy installation on or
between joists
•Wiring junction box for easy connection to
power the light fixture
GRILL FEATURES
•Low profile and unobtrusive inlet grill
•Metal collar with mounting straps make
installation quick and easy
•Sized to meet the needs of most installations
with either a 4" or 6" round metal collar that
easily accepts the ducting
Model AIG46HL
Specifications subject to change.
Intake Grills
MODEL DESCRIPTION DUCT SIZE LIGHTING
AIG46HL Intake Grill w/Halogen Lamp 4" 50 Watt
AIG46F Intake Grill w/Fluorescent Lamp 4" 14 Watt
AIG4 Intake Grill 4" N/A
AIG6 Intake Grill 6" N/A
Models AIG4, AIG6

Switches and Timers
On/Off Switches
Energize your system with a decorative switch for independent on/off
control of the fan and any other room lighting, you would like to
control separately.
Timers
Ensure proper ventilation while enjoying the freedom a timer switch
gives you. Model AKT60 gives the user the ability to set the time up to
60 minutes. Model AKDT60 offers automatic control with a delay timer
that turns the light off but allows the fan to run for a preset time before
automatically turning off.
Specialty Controls
Always know that your room is being properly ventilated with the
model DH55 dehumidistat that automatically turns the unit on or off
according to the humidity level of the room and is easily adjusted to
your personal comfort.
Specifications subject to change.
MODEL FUNCTION USES COLOR
AKS2 Double switch for On/Off Control Fan/Light or Fan/Room Light White
AKS3 Triple switch for On/Off Control Fan/Light/Room Light White
Specifications subject to change.
MODEL FUNCTION USES COLOR
AKDT60 Delay Timer Switch Fan/Light or Fan/Room Light White
AKT60 60 Minute Timer Switch Timed Fan Control White/Almond
Specifications subject to change.
MODEL FUNCTION USES COLOR
DH55 Dehumidistat Control On/Off Control according to Humidity White
Model AKS2
Model AKS3
Model AKDT60
Model AKT60
Model DH55

Accessories
Roof, Wall Caps, and Ducting
The finishing touch to any system is the wall or roof cap. Properly
exhaust the air out of the home using a roof or wall cap matched to
your system’s needs. Insulated Flexible Ducting connects all the
components and provides an extra sound barrier for the system.
Light Fixture Lamps
Give light to your room with the lamp designed specifically for your unit.
Back Draft Dampers
Prohibit outside air from coming back into the system with a back draft
damper designed to fit within the ducting.
Specifications subject to change.
MODEL DESCRIPTION CONSTRUCTION
RCB Roof Cap w/damper and bird screen for up to 4" round ducting Black ABS Plastic
RC810 Roof Cap w/spring loaded damper for up to 8" round ducting Aluminum
WC4NS Wall Cap w/damper for 4" round ducting Aluminum
AKIFD4 4" Round Insulated Flexible Ducting, 25' section Metallized Polyester
AKIFD6 6" Round Insulated Flexible Ducting, 25' section Metallized Polyester
AKIFD8 8" Round Insulated Flexible Ducting, 25' section Metallized Polyester
AKIFD10 10" Round Insulated Flexible Ducting, 25' section Metallized Polyester
Specifications subject to change.
MODEL DESCRIPTION WATTS
14WFW Fluorescent lamp UL approved for wet locations 14
50WHA Halogen lamp UL approved for wet locations 50
Specifications subject to change.
MODEL DESCRIPTION DUCT SIZE
BDD4R Inline Metal Back Draft Damper 4" Round
BDD6R Inline Metal Back Draft Damper 6" Round
BDD8R Inline Metal Back Draft Damper 8" Round
BDD10R Inline Metal Back Draft Damper 10" Round
Model RCB Model WC4NS
Model RC810
Model 14WFW
Model 50WHA
Insulated
Flexible Ducting
Back Draft Dampers

AKILC 9-06
