Air King AK864L User manual

SPECIFICATIONS
EXHAUST FAN WITH LIGHT
AK864L
100 CFM/3.5 SONES @ 0.10" WG. -HVI CERTIFIED
120 Volts, 1.9 amps, 60 hz.
•Grill
White, round polymeric grill secured in place with torsion springs;
easily removed if necessary, dimensions - 133/4" dia.
• Light Lens
Moonstone glass lens, secured in position using 5 philip’s head
screws.
• Light Housing
Heavy gauge cold rolled steel c/w powder coat finish; locks in
place on the housing using a wing nut.
• Blower Wheel
One piece polymeric wheel, 51/8" diameter, 23/8" wide, with 48 fins.
• Motor
Heavy duty, permanently split capacitor, plug-in, 4 pole motor,
life time lubrication, suitable for continuous operation. Rated 120
volts, 60 hz., 0.80 amps.
• Fan Housing
23 ga. painted steel housing, dimensions 8" x 8" x 73/4", double
metal thickness mounting tabs.
• Duct Collar
Plastic collar for 4" duct connection, comes complete with built
in non-metallic back draft damper for quiet operation.
• Lamping Information
100 watt maximum, type A19, Medium base bulb
CUL/HVI
Canada: 110 Glidden Road
Brampton, Ontario L6T 2J3
Tel: [phone]
Fax: [phone]
U.S.: 820 Lincoln Drive
West Chester, Pennsylvania 19380-4466
Tel: [phone] • 877-304-3785
Fax: [phone]
Updated 6-06Specifications subject to change without notice.
• Unit Mounting
Rated Type IC for ceilings insulated to R-40. Designed to mount
in ceilings with at least 8" of clearance. The unit has two
mounting options 1. directly to the joist using mounting tabs. 2.
centered between joists (with 16" centers) using hanging
brackets. The housing will mount through drywall thickness up
to 3/4", with a rough-in opening of 123/4" diameter.
• Ventilating Area
For bathrooms up to 100 sq. ft. for other rooms up to 125 sq. ft.
• Single Pack Shipping Info
Box Dim Box Dim: 15" x 15" x 10"
Shipping Weight: 11 lbs.
CUS
PROJECT
LOCATION
CONTRACTOR
ARCHITECT
ENGINEER
SUBMITTED BY DATE
FAN MODEL CFM IN RPM WATTS AMPS SONES QTY OPTIONAL EQUIPMENT
NUMBER NUMBER W.G. & REMARKS
Acceptable for use over tub or shower when
installed in a GFCI protected branch circuit.
PERFORMANCE
HVI Sones Fan Speed Power
Static Pressure (inches of w.g.) @ .1 SP RPM Watts
0 0.05 0.1 0.15 0.2 0.25 0.3 0.35
Air Flow - CFM 110 105 100 99 95 90 82 78 3.5 2250 170
73/4"
4"
8"
8"
133/4"
