Air King DRLC702 User manual

SPECIFICATIONS
EXHAUST FANS
DRLC
70 CFM/4.0 SONES @ 0.10" WG. -HVI CERTIFIED
120 Volts, 1.6 amps, 60 hz.
•Grill
DRLC702 - Nickel Finish: 131/2" diameter.
DRLC703 - White Finish: 131/2" diameter.
DRLC709 - Bright Brass Finish: 131/2" diameter.
• Light Lens
Ribbed frosted glass light lens.
• Light Housing
Heavy gauge cold rolled steel c/w baked enamel finish; locks
in place on the grill via two integral tabs.
• Blower Wheel
One piece polymeric wheel, 41/2" diameter, 1" wide, with 10 fins.
• Motor
Single coil plug-in, two pole motor, life time lubrication, thermally
protected. Rated 120 volts, 60 hz., 1.6 amps.
• Fan Housing
23 ga. Galvanized metal housing, dimensions 8" x 67/8" x 51/2",
double metal thickness mounting tabs.
• Duct Collar
Plastic collar for 4" duct connection, comes complete with built
in non-metallic back draft damper for quiet operation.
• Lighting
Single 100 watt maximum light capacity (bulb not included).
CUL/HVI
Canada: 110 Glidden Road
Brampton, Ontario L6T 2J3
Tel: [phone]
Fax: [phone]
U.S.: 820 Lincoln Drive
West Chester, Pennsylvania 19380-4466
Tel: [phone] • 877-304-3785
Fax: [phone]
New 4-05Specifications subject to change without notice.
• Unit Mounting
Rated Type IC for ceilings insulated to R-40. Designed to mount
in ceilings with at least 6" of clearance. The unit will mounts
directly to the joist with a rough in opening of 83/16" x 71/16". The
housing will mount through drywall thickness up to 3/4".
• Ventilating Area
For bathrooms up to 70 sq. ft. for other rooms up to 85 sq. ft.
• Single Pack Shipping Info
Box Dim: 111/2" x 131/4" x 91/2"
DRLC702 - UPC: 0-8316227421-2
DRLC703 - UPC: 0-8316227411-3
DRLC709 - UPC: 0-8316227431-1
CUS
Air-King exhaust fans are tested by the Air Movement and Control Association (AMCA) in accordance with HVI test standard 916, (Air Flow Test Standard) and HVI test standard
915 (Procedure For Loudness Rating Of Residential Fan Products). The Performance results are certified and verified by the Home Ventilating Institute (HVI).
HVI PERFORMANCE
Static Pressure (inches of w.g.) 0 0.05 0.1 0.15 0.2 0.25 0.3 0.35 0.4
CFM 77 74 71 68 65 61 57 52 45
RPM 2300 2400 2450 2500 2550 2600 2650 2710 2840
WATTS 65 66 65 64 64 63 61 60 58
PROJECT
LOCATION
CONTRACTOR
ARCHITECT
ENGINEER
SUBMITTED BY DATE
FAN MODEL CFM IN RPM WATTS AMPS SONES QTY OPTIONAL EQUIPMENT
NUMBER NUMBER W.C. & REMARKS
Acceptable for use over tub or shower when
installed in a GFCI protected branch circuit.
