Airmar SmartFlex SmartBoat ASM-C-T1-1 User manual


SmartBoat
®
Module
Patent http://www.airmar.com/patent.html
User Manual
NMEA 2000® Certified
D-20189-rev.3 102079-rev.3 04/12/22

1 
2
Copyright © 2022 Airmar Technology Corp. All rights reserved.
All rights reserved. Except as expressly provided herein, no part of this manual may be reproduced,
copied, transmitted, disseminated, downloaded, or stored in any storage medium, for any
purpose without prior written consent of Airmar. Airmar hereby grants permission to download a
single copy of this manual and of any revision of this manual onto a hard drive or other electronic
storage medium to be viewed and to print one copy of this manual or any revision hereto,
provided that such electronic or printed copy of this manual or revision must contain the complete
text of this copyright notice and provided further that any unauthorized commercial distribution
of this manual or any revision hereto is strictly prohibited. Information in this manual is subject to
change without notice. Airmar reserves the right to change or improve its products and to make
changes in the content without obligation to notify any person or organization of such changes.
Visit the Airmar website at www.airmar.com for current updates and supplemental information
concerning the use and operation of this and other Airmar products.

1 
3
1 Contents
2 Introduction..........................................................................................................................6
3 Specifications.......................................................................................................................7
3.1 General specifications.................................................................................................7
3.2 Monitored parameters ................................................................................................8
3.2.1 Voltage measurement .........................................................................................8
3.2.2 Thermistor temperature sensor ............................................................................8
3.2.3 Current-loop sensor...............................................................................................9
3.2.4 Thermocouple temperature sensor ..................................................................10
3.2.5 Resistive sender ...................................................................................................10
3.2.6 Switch detector...................................................................................................11
3.2.7 Run detector........................................................................................................11
3.2.8 Relay control........................................................................................................12
3.3 SmartBoat module supported devices....................................................................13
3.4 Common and advanced features ..........................................................................14
4 Physical Interfaces.............................................................................................................15
4.1 Network and device connectors .............................................................................15
4.2 User interface..............................................................................................................16
4.2.1 LED indicators ......................................................................................................16
4.2.2 Reset switch .........................................................................................................17
4.3 Primary NMEA 2000 bus .............................................................................................18
4.4 DB-9 connector ..........................................................................................................18
4.4.1 Pinout and accessory connector......................................................................18
4.4.2 Secondary NMEA 2000 / SAE J1939 bus / digital sensor interface ................19
4.4.3 NMEA 0183 serial interface ................................................................................19
4.5 USB 2.0 ports ................................................................................................................20
4.6 Ethernet port ...............................................................................................................20
4.7 Installation ...................................................................................................................21
4.8 Connecting devices ..................................................................................................22
5 Configuring Your SmartBoat Module ..............................................................................24
5.1 Connecting through the Wi-Fi access point ...........................................................24

1 
4
5.2 Configuration steps ....................................................................................................25
5.2.1 Security settings ...................................................................................................26
5.2.2 Configure devices...............................................................................................29
5.2.3 Set up NMEA network connections ..................................................................36
5.2.4 Wi-Fi/Ethernet connections and servers ...........................................................38
6 SmartBoat Module Operation .........................................................................................43
6.1 Status screen...............................................................................................................43
6.2 Viewing connected devices ....................................................................................45
6.3 Viewing NMEA 2000 network information ...............................................................46
7 NMEA 2000 Network Bridging and Filtering.....................................................................52
7.1 Bridging operations ....................................................................................................54
7.2 Using SmartFlex filter...................................................................................................55
7.3 SmartFlex filter example.............................................................................................56
8 Alerting (advanced SmartBoat module only) ...............................................................60
8.1 Alert variables .............................................................................................................60
8.1.1 PGN value variables ...........................................................................................61
8.1.2 Calculated variables ..........................................................................................63
8.1.3 Timer variables.....................................................................................................65
8.1.4 Event-counter variables .....................................................................................66
8.2 Alert actions ................................................................................................................67
8.3 NMEA 2000 bus alerts.................................................................................................69
9 NMEA 0183 Support (advanced SmartBoat module only)...........................................72
9.1 Talker and listener support ........................................................................................73
9.2 NMEA 0183 conversions.............................................................................................74
9.3 Viewing NMEA 0183 sentences ................................................................................78
10 Engine Gateway (advanced SmartBoat module only)................................................79
10.1 SAE J1939 Interface configuration ...........................................................................80
10.2 SAE J1708/J1587 Interface configuration ................................................................83
10.3 Viewing engine/transmission data...........................................................................84
11 SmartFlex Digital Sensors (advanced SmartBoat modules only)..................................87
11.1 Diesel fuel-flow meters...............................................................................................87
11.1.1 Fuel-flow configuration.......................................................................................87
11.1.2 Viewing fuel flow sensor information ................................................................89

1 
5
11.1.3 Viewing digital sensor status ..............................................................................90
12 Wi-Fi/Ethernet Connectivity..............................................................................................92
12.1 Configuring the Wi-Fi/Ethernet network...................................................................93
12.2 Extending the NMEA 2000 bus ..................................................................................95
13 Administrative Features.....................................................................................................96
13.1 Change username and password ...........................................................................97
13.2 Change module nickname ......................................................................................99
13.3 Manage licensed features........................................................................................99
13.4 Updating the SmartBoat module firmware ...........................................................100
13.5 Adding or updating Feature Packages.................................................................102
13.6 System log .................................................................................................................102
13.7 System functions.......................................................................................................102
14 Appendix A: NMEA 2000 PGNs ......................................................................................104
14.1 Table of generated PGNs .......................................................................................104
14.2 Proprietary PGN definitions .....................................................................................106
15 Appendix B: NMEA 0183 Gateway Conversions..........................................................108
15.1 NMEA 0183 sentence to NMEA 2000 PGN conversions .......................................108
15.2 NMEA 2000 PGN to NMEA 0183 sentence conversions .......................................109
16 Appendix C: PGN Identifying Fields ..............................................................................110
17 Appendix D: Mounting Template ..................................................................................111
18 Appendix E: Warranty .....................................................................................................112

1 
6
2 Introduction
Airmar’s SmartFlex
™
system products support multiple network standards and are highly
configurable for a wide range of applications. They share a common set of features
including built-in wireless networking support and browser-based configuration and
management.
SmartBoat
®
modules are certified for use with NMEA 2000
®
networks and designed
specifically for marine applications.
Basic models provide programmable device interfaces for parameters including
voltage, current loop sensors, resistive senders, thermistor, and thermocouple
temperature sensors, run detection, switch detection, flow metering, and relay control.
Advanced models add support for multi-network bridging and management including
multiple NMEA 2000 networks, NMEA 0183
support, and SAE J1939 engine interface
features. Unique alerting features provide customizable messages and task automation
capabilities.
All SmartBoat modules are designed to operate in harsh marine environments and are
rated for water ingress to IP66 (water jet) and IP67 (submersion).

1 
7
3 Specifications
3.1 General specifications
PARAMETER VALUE COMMENT
Operating Voltage 9 to 16 VDC NMEA 2000 interface
Input Current 475 mA (maximum) From NMEA 2000 interface
Load Equivalence Number 10 NMEA 2000: 1 LEN = 50 mA
Measured at a supply voltage of 9 V
Isolation 1,500 VDC: power input
2,500 V
rms : signals
Reverse Voltage Protection Yes Indefinitely
Load Dump Protection Yes
Over-current Protection Yes 2A Auto-resettable electronic fuse
Size
221 mm x 145 mm x 61 mm
(8.7” x 5.7” x 2.4”) Including mounting flanges
Weight 675 gm (1.5 lb.) Maximum for all models
IEC 60945 Classification Exposed
Water Ingress Rating IP66 (water jet)
IEC 60529
Operating Temperature -25°C to +55°C
(-13°F to +130°F)
Storage Temperature -40°C to +70°C
(-40°F to +158°F)
Electromagnetic Emission
Conducted/Radiated
emission per IEC/EN 61000-
2/3
Electromagnetic Immunity
Conducted/Radiated,
supply, and ESD per IEC
61000-4
Flammability Rating
UL94V-0 Printed circuit board
UL94-5VA Enclosure
Compass Interference None EN 60945:2002
Certifications
NMEA 2000 standard v1.200, Level A
Maritime navigation and
radio communication
equipment & systems
IEC 61162-3
IEC 60945
Manufacturing ANSI/IPC-A-610C class 2
RoHS/REACH Compliance Yes

1 
8
3.2 Monitored parameters
Accuracy parameters are exclusive of sensor/transducer accuracy.
3.2.1 Voltage measurement
CHARACTERISTIC VALUE COMMENT
Range 0 to 75 VDC
Accuracy +/- 100 mV
Resolution 0.0031 V
Input Resistance > 15 KΩ
Configuration Inputs Damping period None to 25 seconds
0.1 second steps
MEASURED PARAMETER AVAILABLE NMEA 2000 PGN
DC Voltage 127751, 130840
Fluid Level 127505
3.2.2 Thermistor temperature sensor
CHARACTERISTIC VALUE COMMENT
Range -40°C to +125°C Dependent on thermistor used
Accuracy +/- 2%
Resolution 0.0076°C
Configuration Inputs Thermistor parameters
Dropdown selection for standard
devices. You may also specify a
custom thermistor by providing the
R25 value (1 to 100 KΩ) and one of
the following:
 Thermistor beta
 Three resistance-
temperature curve points
 Steinhart-Hart coefficients
Minimum temperature
Maximum temperature
Damping period
None to 25 seconds
0.10 second steps
MEASURED PARAMETER AVAILABLE NMEA 2000 PGN
Temperature 130310, 130311, 130312, 130316

1 
9
3.2.3 Current-loop sensor
CHARACTERISTIC VALUE COMMENT
Range 4 to 20 mA Allowable range 0 to 22 mA
Accuracy +/- 1% full scale
Resolution 0.0013 mA
Excitation Voltage 12 to 14 VDC Type II only
Configuration Inputs Type
Type II (2-wire)
Type III (3-wire)
Type IV (4-wire)
Minimum value 4 mA value
Maximum value 20 mA value
Damping period
None to 25 seconds
0.1 second steps
MEASURED PARAMETER AVAILABLE NMEA 2000 PGN
Temperature 130310, 130311, 130312, 130316
Pressure 130310, 130311, 130314
Humidity 130311, 130313, 130840
Fluid Level 127505
Flow Rate 065286
Linear Velocity 130840
Rotation Rate 130840
Acceleration 130840
Angular Velocity 130840
Angular Acceleration 130840
Angle 130840
Force 130840
Decibels 130840
Resistance 130840
Distance 130840
DC Voltage 127751, 130840
DC Current 130840

1 
10
3.2.4 Thermocouple temperature sensor
CHARACTERISTIC VALUE COMMENT
Range -100°C to +1275°C Dependent on thermocouple
used
Accuracy +/- 2%
Resolution 0.0778°C
Configuration Inputs Type of thermocouple J, K, T, E
Minimum temperature
Maximum temperature
Damping period
None to 25 seconds
0.1 second steps
MEASURED PARAMETER AVAILABLE NMEA 2000 PGN
Temperature 130310, 130311, 130312, 130316
3.2.5 Resistive sender
CHARACTERISTIC VALUE COMMENT
Range 10 to 300 Ω
US: 30 to 240 Ω
Europe: 10 to 180 Ω
Custom: 10 to 300 Ω
Accuracy +/- 1% full scale
Resolution 0.0183 Ω
Configuration Inputs Sensor standard US, European, or custom
Sensor type e.g. rudder angle
Minimum resistance: R
min
In Ohms
Maximum resistance: R
max
In Ohms
Sensor value at R
min
e.g. R
min
= minimum angle
Sensor value at R
max
e.g. R
max
= maximum angle
Damping period
None to 25 seconds
0.1 second steps
MEASURED PARAMETER AVAILABLE NMEA 2000 PGN
Fluid Level 127505
Rudder Angle 127245

1 
11
3.2.6 Switch detector
CHARACTERISTIC VALUE COMMENT
Configurations
Unsupervised (no EOL
resistor)
One EOL resistor
Two EOL resistor
EOL = End of Line
Fault Detection
Supervised:
One EOL resistor: open line
Two EOL resistor:
open or shorted line
Configuration Inputs Number of EOL resistors 0, 1, or 2
EOL resistor value
Note: If 2 EOL resistors, they
must be the same value
Dropdown menu selection:
25 KΩ, 20 KΩ, 15 KΩ, 10 KΩ,
8 KΩ, 2 KΩ, 1 KΩ, 680 Ω
Invert value
Select “ON” state as closed or
open.
MEASURED PARAMETER AVAILABLE NMEA 2000 PGN
Binary Switch 127501
3.2.7 Run detector
CHARACTERISTIC VALUE COMMENT
“OFF” Voltage (switch open) 9 to 240 VAC RMS
9 to 240 VDC Terminals connected across
switch
“ON” Voltage (switch closed) < 3 V: AC or DC
“ON” Voltage (switch closed) 9 to 240 VAC RMS
9 to 240 VDC Terminals connected across
load
“OFF” Voltage (switch open) Not applicable
Configuration Inputs Connection mode Across switch or load
MEASURED PARAMETER AVAILABLE NMEA 2000 PGN
Binary Switch 127501

1 
12
3.2.8 Relay control
CHARACTERISTIC VALUE COMMENT
Maximum Switching Current 10 A resistive
5 A inductive
DC Only
(Use external relay for AC)
DC Switching Voltage 32 VDC maximum
Contact Resistance 100 mΩmaximum
Configuration Inputs None
MEASURED PARAMETER AVAILABLE NMEA 2000 PGN
Binary Switch 127501

1 
13
3.3 SmartBoat module supported devices
The following table outlines the device types supported by each model.
ASM MODEL
ASM-XXX-T1 ASM-XXX-T2
FEATURE/FUNCTION
PROGRAMMABLE SENSOR INPUTS (Total)
Thermistor (NTC)
(1)
8 4
Current Loop (2, 3, or 4-wire interface)
(1)
8
Resistive Senders (US or European)
(1)
8
Binary Switch (0, 1, or 2 EOL resistors)
(1)
8 4
Voltage (0 to 75 VDC)
(1)
4
(1)
Maximum inputs are shared in a module
FIXED SENSOR INPUT/OUTPUT
Thermocouples (J, K, T, E)
(2)
2
Relays (10 A resistive, 5 A inductive)
(2)
4
Run Detector (9 to 240 VDC/VAC rms)
(2)
4
(2)
Dedicated: all can be used at the same time

1 
14
3.4 Common and advanced features
SMARTBOAT MODULE
FUNCTION
ALL MODELS ADVANCED
MODELS
MULTI-NETWORK FEATURE/FUNCTION
NMEA 2000 BRIDGING
NMEA 2000 primary/secondary bridging 
NMEA 2000 traffic bridging over Wi-Fi 
NMEA 2000 traffic bridging over Ethernet 
SmartFlex Network View provides a complete picture of NMEA 2000
traffic at device/PGN level 
SmartFlex Filter provides “whitelist” and “blacklist” filtering by bus,
device, or PGN 
SmartFlex Alert provides customized alerting and task automation 
NMEA 2000 LOGGING
Network traffic logging and download 
Supports USB memory for nearly unlimited log storage 
NMEA 2000 WI-FI/ETHERNET
Unlimited client connections in multiple formats 
Network advertising and automatic connection 
NMEA 0183 SUPPORT
Duplex operation 
Listener interface with NMEA 0183 to NMEA 2000 conversion gateway 
Talker interface with NMEA 2000 to NMEA 0183 conversion gateway 
Simple “click to set” conversion selection and control 
Smart conversion gateway reduces redundant and incomplete
messages 
Wi-Fi/Ethernet gateway with unlimited client connections and talker
multiplexing 
SAE J1939 ENGINE GATEWAY
SAE J1939 bus monitoring with automatic or manual configuration 
Two Engine status monitor with DTC reporting and DTC reset 
Support for separate engine/transmission ECU addressing 
SAE J1939 to NMEA 2000 conversion 
Simple “click to set” conversion selection and control 
View and clear engine DTC alerts 
Detect and display SAE J1939 PGNs present on the NMEA 2000 bus 
SAE J1708/J1587 ENGINE GATEWAY 
SAE J1587 to NMEA 2000 conversion 
Simple “click to set” conversion selection and control 
WI-FI/ETHERNET NETWORK INFRASTRUCTURE
Wi-Fi router with DHCP support 
Wi-Fi/Ethernet bridge function 
Wi-Fi access point functions 

1 
15
4 Physical Interfaces
4.1 Network and device connectors
Figure 4-1 Pluggable terminal blocks for device connections
Figure 4-2 USB and Ethernet connectors
Figure 4-3 NMEA 2000 and DB-9 connectors

1 
16
4.2 User interface
4.2.1 LED indicators
There are four LED indicators on the top of each SmartBoat module.
 Power: This orange LED lights to indicate that the module is receiving power
through the primary NMEA 2000 bus connection. In normal operation, it will
remain on. This LED will flash during configuration, diagnostic testing, and during
a low-level firmware update.
 Status:This green LED lights to indicate that the module is operating normally.
When first starting, this LED will flash as diagnostics are performed and the
initialization process is underway. The web configuration interface will be
available when it remains on.
 NMEA 2000: This blue LED will flash when there is NMEA 2000 PGN traffic on either
the primary or secondary physical NMEA buses. A fully configured module will
begin processing NMEA 2000 PGN traffic as soon as possible after power-on.
 Network: This yellow LED will flash when there is web server Wi-Fi or Ethernet traffic
received or sent by the module.
Figure 4-2 Label with LED indicators

1 
17
4.2.2 Reset switch
If you forget the password for a SmartBoat module or there is an issue with the Wi-Fi
network configuration that prevents access to the configuration web server, you may
need to reset the configuration of the module. This switch may also be used after a
firmware update to return to the previous firmware version.
On the end of the module enclosure opposite the primary NMEA 2000 bus connector
(above the ethernet connector on an advanced SmartBoat module) is a recessed
switch. It may be used to reset the module. This recessed switch is covered by a small
adhesive label to prevent water ingress.
Figure 4-3 Reset switch location
To reset the system, remove the adhesive label cover. Gently activate the reset switch
by inserting a paper clip or similar implement.
 Reset configuration: Press and hold the reset switch. After approximately 5
seconds, the LEDs will begin to flash. Release the reset switch and the
configuration will be reset to the factory default.
 Restore firmware: Continue to hold the reset switch for an additional 5 seconds
after the LEDs begin flashing. The system will revert to the previous firmware
version. This is only applicable after a firmware update has been performed.
The reset switch is recessed and not visible through the opening. Always press
gently.
Replace the adhesive label after performing the reset to prevent water
ingress.

1 
18
4.3 Primary NMEA 2000 bus
Each SmartBoat module is attached to the NMEA 2000 bus through a standard drop
cable. This cable must also provide the power to operate the module. Each module
has a bus termination resistor that may be enabled through the user interface. The
interface to the primary NMEA 2000 bus. It is fully isolated according to the NMEA 2000
standard.
4.4 DB-9 connector
Each advanced SmartBoat module has an industry-standard DB-9 connector for access
to a second CAN bus and NMEA 0183 RS-422 serial data. The CAN bus may be
configured as a secondary physical NMEA 2000 bus, an SAE J1939 bus, or used with a
SmartFlex digital sensor.
4.4.1 Pinout and accessory connector
The pinout of this connector is shown below.
PIN FUNCTION SIGNAL NAME
1 RS-422 RXD+
2 RS-422 RS-422 shield
3 NMEA 2000 CAN +12 V
4 RS-422 TXD-
5 NMEA 2000 CAN ground
6 RS-422 TXD+
7 NMEA 2000 CAN H
8 RS-422 RXD-
9 NMEA 2000 CAN L
Figure 4-4 DB-9 connector pinout
An optional accessory cable is available: Airmar part-number ACC-YCBL-ASM-01. This
cable provides a standard NMEA 2000 connector for attaching the module to a
secondary physical bus, plus wires for NMEA 0183 talker and listener functions. It is
strongly recommended that only an Airmar cable be used to prevent damage to the
SmartBoat module.

1 
19
Figure 4-5 DB-9 adapter cable: Airmar part-number ACC-YCBL-ASM-01
4.4.2 Secondary NMEA 2000 / SAE J1939 bus / digital sensor interface
Using the DB-9 adapter cable, a SmartBoat module may be attached to a second
NMEA 2000 bus through a standard drop cable. This cable must also provide the power
(LEN 1) to operate the bus interface. An advanced SmartBoat module has a 120 Ωbus
termination resistor for a second NMEA 2000 bus that may be enabled through the user
interface. The interface to the secondary NMEA 2000 bus is fully isolated.
This same interface may be configured for other devices that use the Controller Area
Network (CAN) bus interface for the physical layer. This includes J1939 engine gateway
functions and SmartFlex digital sensors.
4.4.3 NMEA 0183 serial interface
The serial interface follows the TIA/EIA-422 technical standard originated by the
Electronic Industries Alliance that specifies electrical characteristics of a digital signaling
circuit. It provides independent listener (RXD+, RXD-) and talker (TXD+, TXD-) functions
according to the NMEA 0183 standard.

1 
20
4.5 USB 2.0 ports
There are two USB 2.0 ports. In the current software release, these ports may be used for
a USB storage drive for extended NMEA 2000 bus logging functions only.
4.6 Ethernet port
A standard RJ-45 Ethernet port allows connection to a wired Ethernet network. Network
speeds of 10, 100, or 1000 Mbps are supported.
