airPointe ID-R400 User manual

USER MANUAL
Contents
PREFACE
Trademarks
FCC Compliance
Copyright Statement
ID-R400
Introduction
Features
Hardware
LED Indicators
Data Connections
Antennas
Environmental Limits
CUSTOMER SUPPORT
air ointe Customer Support

USER MANUAL
PREFACE
Trademarks
air ointe of New Hampshire and the air ointe of New Hampshire logo are trademarks of
air ointe of new Hampshire. All other product names are copyright and registered
trademarks or trade names of their respective owners.
Information in this document is provided solely to enable system and software
implementers to use the air ointe of New Hampshire system. There are no express or
implied copyright licenses granted hereunder to design or fabricate any integrated
circuits or integrated circuits based on the information in this document.
air ointe of New Hampshire reserves the right to make changes without further notice
to any products herein. air ointe of new Hampshire makes no warranty, representation
or guarantee regarding the suitability of its products for any particular purpose, nor
does air ointe of New Hampshire assume any liability arising out of the application or
use of any product, and specifically disclaims any and all liability, including without
limitation consequential or incidental damages.
The user of this system is cautioned that any changes or modifications to this system,
not expressly approved by air ointe of New Hampshire. could void the warranty.
FCC COMPLIANCE
Changes or modifications not expressly approved by air ointe of New Hampshire could
void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to art 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in
a commercial environment. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.

USER MANUAL
“WARNING!
FCC Radiation Exposure Statement:
This equipment complies with FCC’s RF radiation exposure limits set forth for an
uncontrolled environment under the following conditions:
1. This equipment should be installed and operated such that a minimum separation
distance of 20cm is maintained between the radiator (antenna) & user’s/nearby
person’s body at all times
2. This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.”

USER MANUAL
PREFACE
COPYRIGHT STATEMENT
Copyright © 2007 air ointe of New Hampshire. All Rights Reserved.
This document, as well as the hardware and firmware described therein, are furnished
under license and may only be used or copied in accordance with the terms of such
license. The information in these pages are furnished for informational use only, are
subject to change without notice, and should not be construed as a commitment by
air ointe of New Hampshire, air ointe of New Hampshire assumes no responsibility or
liability for any errors or inaccuracies that may appear in these pages.
Every effort has been made to supply complete and accurate information. However,
air ointe of New Hampshire assumes no responsibility for its use, or for any
infringements of patents or other rights of third parties, which would result.
air ointe of New Hampshire
35E Industrial Way
Suite 101
Rochester, NH 03867

USER MANUAL
ID-R400
INTRODUCTION
air ointe delivers software and hardware solutions that enable healthcare organizations
to streamline operations, improve quality-of-care, reduce costs and generate additional
revenue.
air ointe develops an innovative next generation Intelligent Real-Time Location System
(i-RTLS) which can gather data on high-value assets within an organization, including
medical equipment, clinical staff, patients and visitors. An active RF tag is placed on an
item or person that requires monitoring.
Information, or data, is intelligently and automatically collected from each active tag by
air ointe’s ID-R400 router. This data is transcribed to identify the asset type, the exact
location, movement timestamp and other desired device attributes. This allows specific
items to be easily located anywhere within the air ointe network, as well as their
proximity relationship to each other.
FEATURES
- Embedded LAN - 10/100 full duplex Ethernet LAN and WAN ports
- Redundant power supply capable
- Inte rated 802.11 a/b/ - capable of 108Mb/s in homo eneous networks
- Embedded lon ran e RFID a ile transceiver
- Support for all ISM frequency bands
- Fault tolerant traffic controls and fault resilient power mana ement
- Auto wireless network calibration and self-confi uration
- Embedded DSP for stron encryption and firewall security
- Type II compact FLASH slot
- Embedded XML WebServer Appliance Services
- Intelli ent data flow mana ement & data capture for fault resilient

USER MANUAL
ID-R400
HARDWARE
The tags are incased in a 3 3/16” x 2 5/16” x 5/16 (8cm x 5.8cm x .8cm) UL rated ABS
Cellcore plastic housing and contain the internal components of a RF transmitter and
battery source.
LED Ind cators
There are 8 LEDs on the front of the ID-R400. As you look at the front of the device
starting on the left the LEDs represent as follows:
- ower- LED signifies that the device has power applied through an external power
supply. Remains constantly lit when power applied
-DIAG (Diagnostic) - LED signifies that the processer is properly functioning. Should
blink on and off at the frequency of one second.
-RFID- LED signifies RF activity is being sensed by the router, should be constantly
toggling if RF is present
-WAN- LED signifies that the router has a connection to the Wide Area Network.
Should blink if connection is present.
-LAN (status on the Local Area Connection) – LED signifies that the router has Local
Area Network activity. Should blink if connection is present.
-WiFi- (Option) LED signifies that WiFi card is installed. LED will remain constant if
card is installed.
-NA – Non-Applicable with this model

USER MANUAL
-CF- (Option) LED signifies that a compact flash card has been inserted into compact
flash slot. LED will remain constant if compact flash card is present.
ID-R400
Data Connect ons
There are three inputs as you look at the top of the device. As the router lay on its back
(the flat side) the inputs are as follows:
-LAN ort- This RJ-45 jack is for the option of setting up a sub network using the router
as a gateway.
-WAN ort – This RJ-45 jack is used to connect the device to the Wide Area Network and
is oE capable.
-External Wall ower Supply – a supplied 120 volt power source can be used as an
alternate to oE.
Antennas
There are two fixed non adjustable omni directional RF antennas that will point to the
ground when router is properly fixed to the wall.
ENVIRONMENTAL LIMITS
Humidity: 0%-95% non-condensing

USER MANUAL
Temperatures: 0° C to 70°C
If device is exposed to temperatures or humidity levels outside of the
parameters above, it may cause the device to not function properly.
CUSTOMER SUPPORT
AIRPOINTE CUSTOMER SUPPORT
air ointe gives the ability to intended parties to contact air ointe directly if any
problems should arise.
-Customer Support
Via hone: 603.994.2200
Via Email: supp[email protected]
Via the Web: www.airpointe.com/support
