HPE FlexNetwork MSR Router Series
Comware 7 Network Management and Monitoring
Command Reference
Part number: 5998-8765
Software version: CMW710-E0407
Document version: 6W100-20160526

© Copyright 2016 Hewlett Packard Enterprise Development LP
The information contained herein is subject to change without notice. The only warranties for Hewlett Packard
Enterprise products and services are set forth in the express warranty statements accompanying such
products and services. Nothing herein should be construed as constituting an additional warranty. Hewlett
Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.
Confidential computer software. Valid license from Hewlett Packard Enterprise required for possession, use, or
copying. Consistent with FAR 12.211 and 12.212, Commercial Computer Software, Computer Software
Documentation, and Technical Data for Commercial Items are licensed to the U.S. Government under vendor’s
standard commercial license.
Links to third-party websites take you outside the Hewlett Packard Enterprise website. Hewlett Packard
Enterprise has no control over and is not responsible for information outside the Hewlett Packard Enterprise
website.
Acknowledgments
Intel®, Itanium®, Pentium®, Intel Inside®, and the Intel Inside logo are trademarks of Intel Corporation in the
United States and other countries.
Microsoft® and Windows® are trademarks of the Microsoft group of companies.
Adobe® andAcrobat® are trademarks ofAdobe Systems Incorporated.
Java and Oracle are registered trademarks of Oracle and/or its affiliates.
UNIX® is a registered trademark of The Open Group.

i
Contents
Ping, tracert, and system debugging commands·····································1
debugging··························································································································1
display debugging ···············································································································2
ping··································································································································2
ping ipv6····························································································································6
tracert·······························································································································8
tracert ipv6·······················································································································11
NQA commands ············································································14
NQA client commands ··············································································································14
advantage-factor···············································································································14
codec-type·······················································································································14
data-fill····························································································································15
data-size ·························································································································16
description·······················································································································18
destination ip····················································································································18
destination ipv6·················································································································19
destination port·················································································································20
display nqa history·············································································································20
display nqa reaction counters·······························································································22
display nqa result ··············································································································24
display nqa statistics··········································································································31
filename ··························································································································40
frequency ························································································································41
history-record enable ·········································································································42
history-record keep-time ·····································································································42
history-record number ········································································································43
init-ttl ······························································································································44
lsr-path····························································································································45
max-failure·······················································································································45
mode······························································································································46
next-hop ip·······················································································································47
next-hop ipv6····················································································································47
no-fragment enable············································································································48
nqa·································································································································49
nqa agent enable ··············································································································49
nqa schedule····················································································································50
operation (FTP operation view) ····························································································51

ii
operation (HTTP operation view) ··························································································52
out interface·····················································································································53
password·························································································································54
probe count······················································································································55
probe packet-interval··········································································································56
probe packet-number·········································································································57
probe packet-timeout ·········································································································58
probe timeout ···················································································································59
raw-request······················································································································60
reaction checked-element { jitter-ds | jitter-sd }·········································································60
reaction checked-element { owd-ds | owd-sd }·········································································62
reaction checked-element icpif ·····························································································63
reaction checked-element mos·····························································································64
reaction checked-element packet-loss ···················································································66
reaction checked-element probe-duration···············································································67
reaction checked-element probe-fail (for trap)··········································································69
reaction checked-element probe-fail (for trigger) ······································································70
reaction checked-element rtt································································································71
reaction trap·····················································································································73
rresolve-target ··················································································································74
route-option bypass-route ···································································································75
source interface ················································································································75
source ip ·························································································································76
source ipv6 ······················································································································77
source port·······················································································································78
statistics hold-time·············································································································79
statistics interval················································································································80
statistics max-group···········································································································80
target-only ·······················································································································81
tos··································································································································82
ttl ···································································································································82
type································································································································83
url ··································································································································84
username ························································································································85
version····························································································································86
vpn-instance·····················································································································86
NQA server commands·············································································································87
display nqa server ·············································································································87
nqa server enable··············································································································88
nqa server tcp-connect·······································································································89
nqa server udp-echo··········································································································90

iii
NTP commands·············································································92
display ntp-service ipv6 sessions··························································································92
display ntp-service sessions ································································································97
display ntp-service status·································································································· 101
display ntp-service trace ··································································································· 103
ntp-service acl ················································································································ 104
ntp-service authentication enable························································································ 106
ntp-service authentication-keyid ························································································· 106
ntp-service broadcast-client······························································································· 107
ntp-service broadcast-server······························································································ 108
ntp-service dscp·············································································································· 109
ntp-service enable··········································································································· 110
ntp-service inboundenable ································································································ 110
ntp-service ipv6 acl·········································································································· 111
ntp-service ipv6 dscp ······································································································· 112
ntp-service ipv6 inbound enable ························································································· 113
ntp-service ipv6 multicast-client·························································································· 114
ntp-service ipv6 multicast-server························································································· 115
ntp-service ipv6 source····································································································· 116
ntp-service ipv6 unicast-peer ····························································································· 117
ntp-service ipv6 unicast-server··························································································· 118
ntp-service max-dynamic-sessions······················································································ 120
ntp-service multicast-client ································································································ 121
ntp-service multicast-server······························································································· 121
ntp-service refclock-master································································································ 123
ntp-service reliable authentication-keyid··············································································· 124
ntp-service source··········································································································· 125
ntp-service unicast-peer···································································································· 126
ntp-service unicast-server ································································································· 127
SNTP commands········································································· 129
display sntp ipv6 sessions································································································· 129
display sntp sessions ······································································································· 130
sntp authentication enable································································································· 130
sntp authentication-keyid ·································································································· 131
sntp enable···················································································································· 132
sntp ipv6 unicast-server···································································································· 133
sntp reliable authentication-keyid························································································ 134
sntp unicast-server ·········································································································· 135

iv
PoE commands ··········································································· 137
apply poe-profile ············································································································· 137
apply poe-profile interface································································································· 138
display poe device··········································································································· 139
display poe interface········································································································ 141
display poe interface power ······························································································· 143
display poe power-usage ·································································································· 144
display poe pse··············································································································· 147
display poe pse interface ·································································································· 149
display poe pse interface power ························································································· 151
display poe-power ··········································································································· 152
display poe-profile ··········································································································· 156
display poe-profile interface······························································································· 157
poe disconnect ··············································································································· 158
poe enable····················································································································· 159
poe enable pse··············································································································· 160
poe legacy enable ··········································································································· 160
poe max-power··············································································································· 161
poe max-power (system view)···························································································· 162
poe pd-description··········································································································· 162
poe pd-policy priority········································································································ 163
poe priority····················································································································· 164
poe priority (system view)·································································································· 165
poe pse-policy priority ······································································································ 166
poe update····················································································································· 166
poe-profile ····················································································································· 167
poe utilization-threshold···································································································· 168
SNMP commands ········································································ 170
display snmp-agent community ·························································································· 170
display snmp-agent context ······························································································· 172
display snmp-agent group································································································· 172
display snmp-agent local-engineid ······················································································ 174
display snmp-agent mib-node ···························································································· 174
display snmp-agent mib-view····························································································· 180
display snmp-agent remote ······························································································· 182
display snmp-agent statistics ····························································································· 183
display snmp-agent sys-info ······························································································ 185
display snmp-agent trap queue ·························································································· 186
display snmp-agent trap-list······························································································· 186
display snmp-agent usm-user ···························································································· 187
enable snmp trap updown ································································································· 189

v
snmp-agent···················································································································· 190
snmp-agent calculate-password ························································································· 191
snmp-agent community ···································································································· 192
snmp-agent community-map······························································································ 195
snmp-agent context ········································································································· 196
snmp-agent group ··········································································································· 197
snmp-agent local-engineid ································································································ 199
snmp-agent log··············································································································· 200
snmp-agent mib-view······································································································· 201
snmp-agent packet max-size ····························································································· 202
snmp-agent port·············································································································· 203
snmp-agent remote·········································································································· 204
snmp-agent { inform | trap } source······················································································ 205
snmp-agent sys-info contact ······························································································ 206
snmp-agent sys-info location ····························································································· 207
snmp-agent sys-info version ······························································································ 207
snmp-agent target-host····································································································· 208
snmp-agent trap enable···································································································· 211
snmp-agent trap if-mib link extended ··················································································· 212
snmp-agent trap life········································································································· 213
snmp-agent trap log········································································································· 213
snmp-agent trap queue-size ······························································································ 214
snmp-agent usm-user { v1 | v2c }························································································ 215
snmp-agent usm-user v3 ·································································································· 217
snmp-agent usm-user v3 user-role······················································································ 222
RMON commands········································································ 224
display rmon alarm ·········································································································· 224
display rmon event ·········································································································· 225
display rmon eventlog ······································································································ 227
display rmon history········································································································· 228
display rmon prialarm······································································································· 231
display rmon statistics ······································································································ 233
rmon alarm ···················································································································· 235
rmon event····················································································································· 237
rmon history··················································································································· 239
rmon prialarm················································································································· 240
rmon statistics ················································································································ 242
Event MIB commands ··································································· 244
action···························································································································· 244
comparison···················································································································· 245
context (action-set view) ··································································································· 246

vi
context (trigger view)········································································································ 247
delta falling ···················································································································· 247
delta rising····················································································································· 248
description (event view) ···································································································· 249
description (trigger view)··································································································· 250
display snmp mib event ···································································································· 251
display snmp mib event event···························································································· 252
display snmp mib event object list······················································································· 254
display snmp mib event summary ······················································································· 255
display snmp mib event trigger··························································································· 256
event enable ·················································································································· 259
event owner (trigger-Boolean view)····················································································· 260
event owner (trigger-existence view)···················································································· 260
falling···························································································································· 261
frequency ······················································································································ 262
object list (action-notification view) ······················································································ 263
object list (trigger view)····································································································· 264
object list (trigger-Boolean view)························································································· 265
object list (trigger-existence view) ······················································································· 266
object list (trigger-threshold view)························································································ 266
oid (action-notification view)······························································································· 267
oid (action-set view)········································································································· 268
oid (trigger view) ············································································································· 269
rising ···························································································································· 269
sample·························································································································· 270
snmp mib event ·············································································································· 271
snmp mib event object list································································································· 272
snmp mib event sample instance maximum ·········································································· 273
snmp mib event sample minimum······················································································· 274
snmp mib event trigger ····································································································· 275
snmp-agent trap enable event-mib······················································································ 276
startup (trigger-existence view)··························································································· 276
startup (trigger-threshold view)··························································································· 277
startup enable················································································································· 278
test······························································································································· 279
trigger enable ················································································································· 280
type······························································································································ 281
value (action-set view)······································································································ 282
value (trigger-Boolean view) ······························································································ 282
wildcard context (action-set view)························································································ 283
wildcard context (trigger view)···························································································· 284
wildcard oid (action-set view) ····························································································· 285
wildcard oid (trigger view)·································································································· 286

vii
NETCONF commands ·································································· 287
netconf log····················································································································· 287
netconf soap http acl········································································································ 288
netconf soap http enable··································································································· 289
netconf soap https acl ······································································································ 290
netconf soap https enable ································································································· 290
netconf ssh server enable ································································································· 291
netconf ssh server port····································································································· 292
xml······························································································································· 292
CWMP commands ······································································· 294
cwmp···························································································································· 294
cwmp acs default password······························································································· 294
cwmp acs default url ········································································································ 295
cwmp acs default username ······························································································ 296
cwmp acs password········································································································· 297
cwmp acs url·················································································································· 298
cwmp acs username········································································································ 299
cwmp cpe connect interface ······························································································ 299
cwmp cpe connect retry···································································································· 300
cwmp cpe inform interval ·································································································· 301
cwmp cpe inform interval enable························································································· 302
cwmp cpe inform time ······································································································ 302
cwmp cpe password ········································································································ 303
cwmp cpe provision-code·································································································· 304
cwmp cpe stun enable······································································································ 305
cwmp cpe username········································································································ 306
cwmp cpe wait timeout ····································································································· 307
cwmp enable·················································································································· 307
display cwmp configuration································································································ 308
display cwmp status········································································································· 309
ssl client-policy ··············································································································· 311
EAA commands··········································································· 312
action reboot ·················································································································· 313
action switchover············································································································· 315
action syslog ·················································································································· 316
commit·························································································································· 317
display rtm environment···································································································· 318
display rtm policy············································································································· 318
event cli························································································································· 320

viii
event hotplug·················································································································· 321
event interface················································································································ 323
event process················································································································· 326
event snmp oid ··············································································································· 327
event snmp-notification····································································································· 329
event syslog··················································································································· 330
rtm cli-policy··················································································································· 331
rtm environment·············································································································· 332
rtm scheduler suspend ····································································································· 334
rtm tcl-policy··················································································································· 334
running-time··················································································································· 335
user-role························································································································ 336
Process monitoring and maintenance commands································ 338
display exception context·································································································· 338
display exception filepath ·································································································· 343
display kernel deadloop···································································································· 344
display kernel deadloop configuration ·················································································· 348
display kernel exception···································································································· 349
display kernel reboot········································································································ 353
display kernel starvation ··································································································· 356
display kernel starvation configuration·················································································· 359
display process··············································································································· 361
display process cpu ········································································································· 364
display process log·········································································································· 366
display process memory ··································································································· 367
display process memory heap···························································································· 369
display process memory heap address ················································································ 371
display process memory heap size······················································································ 372
exception filepath ············································································································ 374
monitor kernel deadloop enable·························································································· 375
monitor kernel deadloop exclude-thread··············································································· 376
monitor kernel deadloop time····························································································· 378
monitor kernel starvation enable························································································· 379
monitor kernel starvation exclude-thread ·············································································· 380
monitor kernel starvation time ···························································································· 382
monitor process ·············································································································· 383
monitor thread ················································································································ 388
process core ·················································································································· 392
reset exception context····································································································· 394
reset kernel deadloop······································································································· 395
reset kernel exception ······································································································ 395
reset kernel reboot··········································································································· 396

ix
reset kernel starvation······································································································ 397
third-part-process start ····································································································· 398
third-part-process stop······································································································ 399
Sampler commands······································································ 401
display sampler··············································································································· 401
sampler························································································································· 402
Port mirroring commands······························································· 404
display mirroring-group····································································································· 404
mirroring-group··············································································································· 405
mirroring-group mirroring-port (interface view) ······································································· 406
mirroring-group mirroring-port (system view) ········································································· 407
mirroring-group monitor-port (interface view)········································································· 408
mirroring-group monitor-port (system view)··········································································· 408
Flow mirroring commands······························································ 410
mirror-to ························································································································ 410
NetStream configuration commands················································· 411
display ip netstream cache ································································································ 411
display ip netstream export································································································ 418
display ip netstream template····························································································· 419
enable··························································································································· 422
ip netstream··················································································································· 423
ip netstream filter············································································································· 423
ip netstream sampler········································································································ 424
ip netstream aggregation ·································································································· 425
ip netstream export host ··································································································· 427
ip netstream export rate···································································································· 428
ip netstream export source································································································ 429
ip netstream export v9-template refresh-rate packet································································ 430
ip netstream export v9-template refresh-rate time··································································· 431
ip netstream export version ······························································································· 432
ip netstream max-entry····································································································· 433
ip netstream mpls············································································································ 434
ip netstream timeout active································································································ 435
ip netstream timeout inactive ····························································································· 435
reset ip netstream statistics ······························································································· 436
IPv6 NetStream commands···························································· 437
display ipv6 netstream cache····························································································· 437

x
display ipv6 netstream export····························································································· 442
display ipv6 netstream template ························································································· 443
enable··························································································································· 447
ipv6 netstream················································································································ 448
ipv6 netstream filter ········································································································· 448
ipv6 netstream sampler ···································································································· 449
ipv6 netstream aggregation ······························································································· 450
ipv6 netstream export host ································································································ 452
ipv6 netstream export rate································································································· 453
ipv6 netstream export source····························································································· 454
ipv6 netstream export v9-template refresh-rate packet ···························································· 455
ipv6 netstream export v9-template refresh-rate time································································ 456
ipv6 netstream export version 9·························································································· 456
ipv6 netstream max-entry·································································································· 457
ipv6 netstream timeout active····························································································· 458
ipv6 netstream timeout inactive ·························································································· 459
reset ipv6 netstream statistics ···························································································· 460
sFlow commands········································································· 461
display sflow··················································································································· 461
sflow agent ···················································································································· 462
sflow collector················································································································· 463
sflow counter interval ······································································································· 464
sflow counter collector······································································································ 465
sflow flow collector··········································································································· 466
sflow flow max-header······································································································ 466
sflow sampling-mode ······································································································· 467
sflow sampling-rate·········································································································· 468
sflow source··················································································································· 468
Information center commands························································· 470
diagnostic-logfile save······································································································ 470
display diagnostic-logfile summary······················································································ 471
display info-center ··········································································································· 471
display logbuffer·············································································································· 472
display logbuffer summary································································································· 475
display logfile summary ···································································································· 476
display security-logfile summary ························································································· 477
enable log updown ·········································································································· 478
info-center diagnostic-logfile directory·················································································· 479
info-center diagnostic-logfile enable····················································································· 479
info-center diagnostic-logfile frequency ················································································ 480
info-center diagnostic-logfile quota······················································································ 481

xi
info-center enable············································································································ 481
info-center format············································································································ 482
info-center logbuffer········································································································· 482
info-center logbuffer size··································································································· 483
info-center logfile directory ································································································ 484
info-center logfile enable··································································································· 485
info-center logfile frequency······························································································· 485
info-center logfile overwrite-protection·················································································· 486
info-center logfile size-quota ······························································································ 487
info-center logging suppress duplicates················································································ 487
info-center loghost··········································································································· 489
info-center loghost source ································································································· 490
info-center security-logfile alarm-threshold············································································ 491
info-center security-logfile directory ····················································································· 491
info-center security-logfile enable························································································ 492
info-center security-logfile frequency···················································································· 493
info-center security-logfile size-quota··················································································· 494
info-center source············································································································ 494
info-center synchronous···································································································· 496
info-center syslog min-age ································································································ 497
info-center syslog trap buffersize ························································································ 498
info-center timestamp······································································································· 499
info-center timestamp loghost ···························································································· 500
info-center trace-logfile quota····························································································· 500
logfile save····················································································································· 501
reset logbuffer ················································································································ 502
security-logfile save ········································································································· 502
snmp-agent trap enable syslog··························································································· 503
terminal debugging·········································································································· 504
terminal logging level ······································································································· 505
terminal monitor·············································································································· 506
Flow log commands······································································ 507
display userlog export ······································································································ 507
reset userlog flow export··································································································· 508
userlog flow export host···································································································· 508
userlog flow export load-balancing ······················································································ 509
userlog flow export source-ip ····························································································· 510
userlog flow export timestamp localtime··············································································· 511
userlog flow export version································································································ 511
userlog flow syslog ·········································································································· 512

xii
Packet capture commands····························································· 514
display packet-capture status····························································································· 514
packet-capture (on wired devices)······················································································· 515
packet-capture local interface (on wired devices/fat APs)························································· 518
packet-capture read (on wired devices)················································································ 520
packet-capture remote interface (on wired devices/fat APs)······················································ 521
packet-capture stop ········································································································· 521
Document conventions and icons ···················································· 523
Conventions ························································································································· 523
Network topology icons ··········································································································· 524
Support and other resources ·························································· 525
Accessing Hewlett Packard Enterprise Support ············································································ 525
Accessing updates················································································································· 525
Websites ······················································································································· 526
Customer self repair········································································································· 526
Remote support ·············································································································· 526
Documentation feedback ·································································································· 527
Index························································································· 528

1
Ping, tracert, and system debugging
commands
debugging
Use debugging to enable debugging for a module.
Use undo debugging to disable debugging for a module.
Syntax
debugging module-name [ option ]
undo debugging module-name [ option ]
Default
Debugging is disabled for all modules.
Views
User view
Predefined user roles
network-admin
Parameters
module-name: Specifies a module by its name, such as arp or device. For a list of supported
modules, use the debugging ? command.
option: Specifies the debugging option for a module. Available options vary by module. To display the
debugging options supported by a module, use the debugging module-name ?command.
Usage guidelines
Output from debugging commands is memory intensive. To guarantee system performance, enable
debugging only for modules that are in an exceptional condition.
The system sends the debugging command output as debug messages to the device information
center. The information center then sends the messages to appropriate destinations based on the
log output configuration. For more information about configuring debug message output, see
Network Management and Monitoring Configuration Guide.
Examples
# Enable debugging for the device management module.
<Sysname> debugging dev
Related commands
display debugging

2
display debugging
Use display debugging to display the enabled debugging features for a module or for all modules.
Syntax
display debugging [module-name ]
Views
Any view
Predefined user roles
network-admin
network-operator
Parameters
module-name: Specifies a module by its name. For a list of supported modules, use the display
debugging ? command. If you do not specify a module name, this command displays the enabled
debugging features for all modules.
Examples
# Display all enabled debugging features.
<Sysname> display debugging
DEV debugging switch is on
Related commands
debugging
ping
Use ping to test the reachability of the destination IP address and display ping statistics.
Syntax
ping [ ip ] [ -a source-ip | -c count | -f | -h ttl | -i interface-type interface-number | -m interval | -n | -p
pad | -q | -r | -s packet-size | -t timeout | -tos tos | -v | { -topology topo-name | -vpn-instance
vpn-instance-name } ] * host
Views
Any view
Predefined user roles
network-admin
Parameters
ip: Distinguishes between a destination host name and the ping command keywords if the name of
the destination host is i, ip, ipv, or ipv6. For example, you must use the command in the form of ping
ip ip instead of ping ip if the destination host name is ip.

3
-a source-ip: Specifies an IP address of the device as the source IP address of ICMP echo requests.
If this option is not specified, the source IP address of ICMPecho requests is the primary IPaddress
of the outbound interface.
-c count: Specifies the number of ICMP echo requests that are sent to the destination. The value
range is 1 to 4294967295, and the default is 5.
-f: Sets the "do-not-fragment" bit in the IP header.
-h ttl: Specifies the TTL value of ICMP echo requests. The value range is 1 to 255, and the default is
255.
-i interface-type interface-number: Specifies the source interface for ICMP echo requests. If you do
not specify this option, the system uses the primary IP address of the matching route's egress
interface as the source interface for ICMP echo requests.
-m interval: Specifies the interval (in milliseconds) to send ICMPecho requests. The value range is 1
to 65535, and the default is 200.
-n: Disables domain name resolution for the host argument. If the host argument represents the host
name of the destination, and if this keyword is not specified, the device translates host into an
address.
-p pad: Specifies the value of the pad field in an ICMP echo request, in hexadecimal format, 1 to 8
bits. The pad argument is in the range of 0 to ffffffff. If the specified value is less than 8 bits, 0s are
added in front of the value to extend it to 8 bits. For example, if pad is configured as 0x2f, then the
packets are padded with 0x0000002f to make the total length of thepacket meet the requirements of
the device. By default, the padded value starts from 0x01 up to 0xff, where another round starts
again if necessary, such as 0x010203…feff01….
-q: Displays only the summary statistics. If this keyword is not specified, the system displays all the
ping statistics.
-r: Records the addresses of the hops (up to 9) the ICMP echo requests passed. If this keyword is
not specified, the addresses of the hops that the ICMP echo requests passed are not recorded.
-s packet-size: Specifies the length (in bytes) of ICMP echo requests (excluding the IP packet
header and the ICMP packet header). The value range is 20 to 8100, and the default is 56.
-t timeout: Specifies the timeout time (in milliseconds) of an ICMP echo reply. The value range is 0 to
65535, and the default is 2000. If the source does not receive an ICMPecho reply within the timeout,
it considers the ICMP echo reply timed out.
-tos tos: Specifies the ToS value of ICMP echo requests. The value range is 0 to 255, and the default
is 0.
-v: Displays non-ICMP echo reply packets. If this keyword is not specified, the system does not
display non-ICMP echo reply packets.
-topology topo-name: Specifies the topology to which the destination belongs, where topo-name is
a case-sensitive string of 1 to 31 characters. If the destination is on the public network, do not specify
this option.

4
-vpn-instance vpn-instance-name: Specifies the MPLS L3VPN instance to which the destination
belongs, where the vpn-instance-name argument is a case-sensitive string of 1 to 31 characters. If
the destination is on the public network, do not specify this option.
host: Specifies the IP address or host name of the destination. The host name is a case-insensitive
string of 1 to 253 characters. It can contain letters, digits, and special characters such as hyphen (-),
underscore (_), and dot (.).
Usage guidelines
To ping a device identified by its host name, configure the DNS settings on the device first. If the DNS
settings are not configured, the ping operation fails.
To abort the ping operation during the execution of the command, press Ctrl+C.
Examples
# Test whether the device with an IP address of 1.1.2.2 is reachable.
<Sysname> ping 1.1.2.2
Ping 1.1.2.2 (1.1.2.2): 56 data bytes, press CTRL_C to break
56 bytes from 1.1.2.2: icmp_seq=0 ttl=254 time=2.137 ms
56 bytes from 1.1.2.2: icmp_seq=1 ttl=254 time=2.051 ms
56 bytes from 1.1.2.2: icmp_seq=2 ttl=254 time=1.996 ms
56 bytes from 1.1.2.2: icmp_seq=3 ttl=254 time=1.963 ms
56 bytes from 1.1.2.2: icmp_seq=4 ttl=254 time=1.991 ms
--- Ping statistics for 1.1.2.2 ---
5 packet(s) transmitted, 5 packet(s) received, 0.0% packet loss
round-trip min/avg/max/std-dev = 1.963/2.028/2.137/0.062 ms
# Test whether the device with an IP address of 1.1.2.2 in VPN 1 is reachable.
<Sysname> ping -vpn-instance vpn1 1.1.2.2
Ping 1.1.2.2 (1.1.2.2): 56 data bytes, press CTRL_C to break
56 bytes from 1.1.2.2: icmp_seq=0 ttl=254 time=2.137 ms
56 bytes from 1.1.2.2: icmp_seq=1 ttl=254 time=2.051 ms
56 bytes from 1.1.2.2: icmp_seq=2 ttl=254 time=1.996 ms
56 bytes from 1.1.2.2: icmp_seq=3 ttl=254 time=1.963 ms
56 bytes from 1.1.2.2: icmp_seq=4 ttl=254 time=1.991 ms
--- Ping statistics for 1.1.2.2 in VPN instance vpn1 ---
5 packet(s) transmitted, 5 packet(s) received, 0.0% packet loss
round-trip min/avg/max/std-dev = 1.963/2.028/2.137/0.062 ms
# Test whether the device with an IP address of 1.1.2.2 is reachable. Only results are displayed.
<Sysname> ping -q 1.1.2.2
Ping 1.1.2.2 (1.1.2.2): 56 data bytes, press CTRL_C to break
--- Ping statistics for 1.1.2.2 ---
5 packet(s) transmitted, 5 packet(s) received, 0.0% packet loss
round-trip min/avg/max/std-dev = 1.962/2.196/2.665/0.244 ms

5
# Test whether the device with an IP address of 1.1.2.2 is reachable. The IP addresses of the hops
that the ICMP packets passed in the path are displayed.
<Sysname> ping -r 1.1.2.2
Ping 1.1.2.2 (1.1.2.2): 56 data bytes, press CTRL_C to break
56 bytes from 1.1.2.2: icmp_seq=0 ttl=254 time=4.685 ms
RR: 1.1.2.1
1.1.2.2
1.1.1.2
1.1.1.1
56 bytes from 1.1.2.2: icmp_seq=1 ttl=254 time=4.834 ms (same route)
56 bytes from 1.1.2.2: icmp_seq=2 ttl=254 time=4.770 ms (same route)
56 bytes from 1.1.2.2: icmp_seq=3 ttl=254 time=4.812 ms (same route)
56 bytes from 1.1.2.2: icmp_seq=4 ttl=254 time=4.704 ms (same route)
--- Ping statistics for 1.1.2.2 ---
5 packet(s) transmitted, 5 packet(s) received, 0.0% packet loss
round-trip min/avg/max/std-dev = 4.685/4.761/4.834/0.058 ms
The output shows that:
•The destination is reachable.
•The route is 1.1.1.1 <-> {1.1.1.2; 1.1.2.1} <-> 1.1.2.2.
Table 1 Command output
Field Description
Ping 1.1.2.2 (1.1.2.2): 56 data
bytes, press CTRL_C to break
Test whether the device with IP address 1.1.2.2 is reachable. There
are 56 bytes in each ICMP echo request. Press Ctrl+C to abort the
ping operation.
56 bytes from 1.1.2.2: icmp_seq=0
ttl=254 time=4.685 ms
Received ICMP echo replies from the device whose IP address is
1.1.2.2. If no echo reply is received within the timeout period, no
information is displayed.
•bytes—Number of bytes in the ICMP echo reply.
•icmp_seq—Packet sequence, used to determine whether a
segment is lost, disordered or repeated.
•ttl—TTL value in the ICMP echo reply.
•time—Response time.
RR: Routers through which the ICMP echo request passed. They are displayed in inversed order, which means the router with a smaller
distance to the destination is displayed first.
--- Ping statistics for 1.1.2.2 --- Statistics on data received and sent in the ping operation.
--- Ping statistics for 1.1.2.2 in VPN
instance vpn1 --- Ping statistics for a device in a VPN instance.
5 packet(s) transmitted Number of ICMP echo requests sent.
5 packet(s) received Number of ICMP echo replies received.
0.0% packet loss Percentage of unacknowledged packets to the total packets sent.
round-trip min/avg/max/std-dev =
4.685/4.761/4.834/0.058 ms Minimum/average/maximum/standard deviation response time, in milliseconds.

6
ping ipv6
Use ping ipv6 to test the reachability of the destination IPv6 address and display IPv6 ping statistics.
Syntax
ping ipv6 [ -a source-ipv6 | -c count | -i interface-type interface-number | -m interval |-q | -s
packet-size | -t timeout |-tc traffic-class|-v |-vpn-instance vpn-instance-name ] * host
Views
Any view
Predefined user roles
network-admin
Parameters
-a source-ipv6: Specifies an IPv6 address of the device as the source IP address of ICMP echo
requests. If this option is not specified, the source IPv6 address of ICMP echo requests is the IPv6
address of the outbound interface. See RFC 3484 for information about the address selection rule.
-c count: Specifies the number of ICMPv6 echo requests that are sent to the destination. The value
range is 1 to 4294967295, and the default is 5.
-i interface-type interface-number: Specifies the source interface for ICMPv6 echo requests. This
option must be specified when the destination address is a multicast address or a link local address.
If you do not specify this option, the system uses the primary IP address of the matching route's
egress interface as the source interface for ICMPv6 echo requests.
-m interval: Specifies the interval (in milliseconds) to send an ICMPv6 echo reply. The value range is
1 to 65535, and the default is 1000.
-q: Displays only the summary statistics. If you do not specify this keyword, the system displays all
the ping statistics.
-s packet-size: Specifies the length (in bytes) of ICMPv6 echo requests (excluding the IPv6 packet
header and the ICMPv6 packet header). The value range is 20 to 8100, and the default is 56.
-t timeout: Specifies the timeout time (in milliseconds) of an ICMPv6 echo reply. The value range is 0
to 65535, and the default is 2000.
-tc traffic-class: Specifies the traffic class value in an ICMPv6 packet. The value range is 0 to 255
and the default is 0.
-v: Displays detailed information (including the dst field and the idx field) about ICMPv6 echo replies.
If this keyword is not specified, the system only displays brief information (not including the dst field
and the idx field) about ICMPv6 echo replies.
-vpn-instance vpn-instance-name: Specifies the MPLS L3VPN instance to which the destination
belongs, where the vpn-instance-name argument is a case-sensitive string of 1 to 31 characters. If
the destination is on the public network, do not specify this option.
