AirTies AX5400 User manual
Air 4960R / Singtel / Single Pack (Printed Material Specification)
Flat dimension
Dimension after binding
Pages
Cover Printing Color
Inner Printing Color
Cover page Material
Inner pages Material
Cover Pages Coating
Inner pages Coating
Binding & Folding Process
Output lpi
Tolerance
Color Tolerance
PART NUMBER
200mm x 100mm
100mm x 100mm
12 pages
colour printing
colour printing
128g copperplate paper
128g copperplate paper
varnishing
varnishing
Booklet type folding & 2 pcs stable biding
200 Lpi
L*W:+1mm/-1mm
MP-00000xxxxx
Printing Colors
PANTONE
432C
C:60,M:60,Y:40,K:100 C:0,M:85,Y:100,K:0
BACKGROUND’S COLOR
PANTONE
871 C
Ref. PN. PN. Part Descrip�on Date Change Notes Author
Change
Point
MP-00000xxxxx 22.11.2020 Ini�al Release MBQIG, 4960R, Singtel, EN, Color, Single, R0, v0
REVISION TABLE
C:0,M:0,Y:0,K:60C:0,M:0,Y:0,K:40 C:0,M:0,Y:100,K:0 C:75,M:0,Y:100,K:0 C:73,M:13,Y:9,K:0 C:0,M:100,Y:100,K:0 C:0,M:0,Y:0,K:100
USER MANUAL
Air 4960R
AX5400
Wi-Fi 6 Router
1
2
PORTS and BUTTONS
Status LED
WPS Button
Reset Button
Power On/OFF Button
Gigabit LAN Ethernet Port
External Power Supply
Gigabit WAN Ethernet Port*
* Ethernet (Internet) cable from your Internet Service Provider or modem should be plugged into
WAN ethernet port of Air 4960R Router.
3
Please remove protective plastic cover
from the products before installation.
!
INSTALLATION
1
Connect the RJ45 Ethernet Cable to any
LAN port on the ONT or ONR and
WAN port on Air 4960R Router .
1
2
1
2
LAN WAN
WAN
4
Connect the RJ45 Ethernet Cable to any
LAN port on the ONT or ONR and
WAN port on Air 4960R Router .
Plug the power adapter first into
Air 4960R and then to a power socket,
turn on the unit.
2
3
1
3
2
LAN WAN
5
After few seconds Air 4960R LED
will be first blinking white, then
solid white. Wait until LED become
solid green, that means your device
is connected to internet and ready
to use.
up to
3 min.
3
6
Default Wi-Fi Name and Password is indicated on
the label under your Air 4960R unit.
S/N: AMPPPYYWWXXXXXX
Model: Air 4960R
MAC: XX:XX:XX:XX:XX:XX
Wi-Fi Name: XXXXXXXXXXXX
Password: XXXXXXXXXX
Wi-Fi Name: XXXXXXXXXXXX
Password: XXXXXXXXXX
4
7
•Keep devices away from:
- Potential sources of electrical interference. Equipment that may
potentially cause interference include home security systems,
microwaves and consumer electronic devices.
-Large metal surfaces and objects.
- Sources and areas of heat such as ovens and sun rooms as well as
direct sun light.
•Please make sure to remove the protective plastic covers used on the
device before first use.
•Please use the device in upright position. The openings are provided
for ventilation, do not block or cover openings.
•Your device is designed to work indoors and under room temperature
conditions only.Avoid placing the device tovery cold,very hot, very
humid or very drylocations inside yourhome.
•To change advanced settings on your device, you can access web UI
with the credentials below by typing http://masternode.local or
http://air4960-router.local/ in the address field of your browser and
press enter to display the login window:
TIPS FOR BEST PERFORMANCE:
•Username: admin
• Password: default Wi-Fi password on
the label under your device
S/N: AMPPPYYWWXXXXXX
Model: Air 4960R
MAC: XX:XX:XX:XX:XX:XX
Wi-Fi Name: XXXXXXXXXXXX
Password: XXXXXXXXXX
Wi-Fi Name: XXXXXXXXXXXX
Password: XXXXXXXXXX
8
•Operational modes:
•Maximum power consumption of networked standby mode is 4.50 W.
•This device is restricted for indoor use.
2.4 GHz: 802.11b, 802.11g, 802.11n (HT20), 802.11n (HT40),
802.11ac (VHT20), 802.11ac (VHT40), 802.11ax (HE20),
802.11ax (HE40)
5 GHz: 802.11a, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20),
802.11ac (VHT40), 802.11ac (VHT80), 802.11ac (VHT160),
802.11ax (HE20), 802.11ax (HE40), 802.11ax (HE80),
802.11ax (HE160)
PRODUCT NOTICES
•Keep devices away from:
- Potential sources of electrical interference. Equipment that may
potentially cause interference include home security systems,
microwaves and consumer electronic devices.
-Large metal surfaces and objects.
- Sources and areas of heat such as ovens and sun rooms as well as
direct sun light.
•Please make sure to remove the protective plastic covers used on the
device before first use.
•Please use the device in upright position. The openings are provided
for ventilation, do not block or cover openings.
•Your device is designed to work indoors and under room temperature
conditions only.Avoid placing the device tovery cold,very hot, very
humid or very drylocations inside yourhome.
•To change advanced settings on your device, you can access web UI
with the credentials below by typing http://masternode.local or
http://air4960-router.local/ in the address field of your browser and
press enter to display the login window:
RETURNING TO FACTORY SETTINGS
To return the device to factory settings, press
down on the reset button (in the small opening on
the back shown above) for 5 seconds and release.
A metal paperclip (with an extended tip) or strong
toothpick are typically good choices for this task.
When the reset process is triggered, the LED in
the front will “blink rapidly” and the device will
reboot to factory settings.
This product makes use of software developed by the open source community. Any such software is licensed under the specific
license terms applicable to that particular software (like GPL, LGPL etc). Detailed information on the applicable licenses and
license terms can be found on the device's user interface.
By using this product, you acknowledge that you have reviewed such license terms and that you agree to be bound by them.
Where such terms entitle you to the source code of said software, that source code will be made available at cost upon request
from AirTies.
To obtain a copy of said source code, please send your request in writing via email to [email protected] or via snail mail to:
AirTies Wireless Communications
Mithat Uluünlü Sokak No. 23 Esentepe,
P.K. 34394 Şişli ISTANBUL/Turkey
AirTies will mail to you a CD with the requested source code at the cost of CD preparation and shipping&handling. For details
LAN WAN
TROUBLESHOOTING
LED Behavior
-
Blinking
Blinking
Solid
Blinking
Solid
Blinking
Blinking
Timing
5O milliseconds OFF
5seconds ON
4 seconds OFF
4 seconds ON
1/2 Second OFF
1/2 Second ON
1/2 second OFF
1/2 second ON
Condition
Power OFF
Power ON, booting
Wireless network healthy
Weak connection to the wireless
mesh network
Unconfigured mesh device
Device configured as single
wireless access point
No Internet
Software upgrade
LED Color
OFF
White
Green
Red
Blue
Green
Red
Blue
9
Explanation
Device is turned off.
LED is steady green with a short blink
every 5 seconds.
Device is not configured and connected
to the wireless mesh network.
Device is connected to the router/
gateway with an ethernet cable and
acts as a wireless access point.
No other mesh devices are configured
in the network.
Your internet connection is down.
Device is retrieving the latest software.
Recommended Action(s)
Make sure the power button on the back is
pressed and power supply unit is connected
to the device.
No action required. If the
device
was just
powered on, please wait for at least
2 minutes for the
device
to boot up.
No action required.
Bring device closer to another device in the
wireless mesh network.
Configure the device using AirTies Vision app.
No action required, more mesh devices can
be added to the wireless mesh network if
needed.
Please check WAN ethernet cable connection
between your modem and Air 4960R Router.
If the issue persists, contact your Internet
Service Provider.
Wait for the upgrade to complete. Device
will automatically start with the latest
software.
10
MP-00000xxxxx
REV22112021
