SERVICE and
TRAINING MANUAL
AIRXCEL, INC. - SUBURBAN DIVISION
Information published in this manual is subject to change without notice.
MODELS:
This manual covers
multiple models.
FOR RECREATIONAL
VEHICLE USE ONLY
COOKING APPLIANCES
2 & 3 BURNER DROP-IN COOKTOPS,
SLIDE-IN COOKTOPS, 17” & 22” RANGES
17” & 22” RANGES W/ BUILT-IN GLASS COVER
205613
05-31-2019
2 BURNER DROP-IN
COOKTOP 3 BURNER DROP-IN COOKTOP
LEFT FRONT RIGHT
SLIDE-IN COOKTOP
22” RANGE
17” RANGE
RANGE W/ BUILT-IN
GLASS COVER
Technical service information in electronic, digital, video, audio or hard copy format is provided byAirxcel, Suburban Division, Technical
Services Department to be used only by professional, qualied service technicians.
This information is provided to you, as a professional service technician, only. You are not authorized to share or duplicate this
information. You may not reproduce or transmit, in whole or in part, any of this information in any form or by any means (electronic,
mechanical, photocopying, recording, or otherwise) without prior written permission of Suburban Manufacturing.

2
TABLE OF CONTENTS
PAGE
Introduction............................................................................................................3
Model Variations, Descriptions and Serial Number Location.................................4
Range and Cooktop Model Numbers....................................................................5
Slide-In Cooktop Model Numbers..........................................................................7
Drop-In Cooktop Model Numbers..........................................................................8
INSTALLATION INSTRUCTIONS
Slide-In Cooktops and Ranges ....................................................................9
Drop-In Cooktops.......................................................................................10
Cooking Appliance Terminology ..........................................................................17
Manifold Identication Information.......................................................................18
Burner Identication Information..........................................................................19
Burner BTU Output Information...........................................................................19
TROUBLE SHOOTING GUIDE
Ranges.......................................................................................................20
Slide-In and Drop-In Cooktops...................................................................21
Operating Instructions .........................................................................................22
Range Door Removal Instructions.......................................................................22
Warranty Information...........................................................................................23

3
COOKING APPLIANCE INTRODUCTION
This Service and Training Manual provided by the Suburban
Products Factory Service Department is intended to be used
by qualied service technicians only as a valuable tool in
terms of product identication, troubleshooting and diagnosis
of service issues, and as an outline of information concerning
proper procedures for ling warranty service claims.
Included in this manual are product and component
identication descriptions, sequence of operation information,
maintenance and service recommendations. In addition to
the information available in this manual, other resources
for servicing Suburban RV appliances include our website -
www.AIRXCEL.com, our Factory Service Department Hotline at
423-775-2131 EXT 7102, and our Customer Service Department
at 423-775-2131 EXT 7101.
Having an understanding of the appliance sequence of
operation and a thorough comprehension of how the
individual components function is of the utmost importance
to ensure proper troubleshooting and diagnosis. Another
point of emphasis is the adherence to proper installation
which includes variables such as gas pressure, along with
constant measurable factors such as the compliance to the
physical installation tolerances and clearances. This manual
is designed to assist service technicians in making the correct
diagnosis e󰀩ciently.
Proper maintenance and service of an appliance is of the
utmost importance. Failure to keep the appliance clean and
well maintained is a signicant contributing factor in component
breakdown and premature failure of the appliance.

4
MODEL VARIATIONS
1. These units are certied by Underwriters Laboratories (UL or CSA) for the U.S.A. and Canada.
2. To determine your exact model, use the chart shown below:
SUBURBAN RV RANGE/COOKTOP MODEL NUMBER POSITIONS
1 2 3 4 5 6 7 8 9 10
BRAND TYPE BURNER
TYPE THERMOSTAT BURNERS OVEN MODELS
TOP
COLOR
(PORCELAIN)
DOOR
COLOR
(PAINTED)IGNITION OPTIONS
S=Suburban R=Range
C=Cooktop
(Slide-In)
N=Conventional
S=Sealed
A=Mercury
Free 2=2-Burner
3=3-Burner
S=17” Oven
L=22” Oven
B=Black
S=Stainless
P=Porcelain
Stainless
B=Black
S=Stainless
G=Black
Glass
X=Stainless
w/Black
Glass
V=Open
Window
Glass
U=Black w/
Brush Nickel
Handle
M=Match
E=Piezo
S=Spark
Z=Deluxe
Cooking Grate
Y=Extended
Manifold
C=Cover
YC=Extended
Manld/Cover
YZ=Extended
Manifold/
Deluxe Grate
ZC=Deluxe
Grate/Cover
YCZ=Extended
Manifold/
Deluxe Grate/
Cover
SUBURBAN RV DROP-IN
MODEL NUMBER POSITIONS
BRAND TYPE BURNER
TYPE BURNERS
S=Suburban D=Drop-In N=Conventional
S=Sealed
2=2-Burner
3=3-Burner
3. The complete model, serial number and stock number are located on the UL or CSA label located under the top,
as shown in Figure 3. This information will be needed when servicing the appliance or ordering parts. Record the
information and retain for future reference. Replacement parts can be ordered through your local dealer or Suburban
Service Center. To obtain information on locating a local service agency, call AIRXCEL, INC. - Suburban Division
Customer Service Department, 423-775-2131, EXT 7101 or Fax: [phone].
4. These units are designed certied for use with LP/Propane gas only. Do not attempt
to convert to natural gas.
5. Gas supply pressure for checking of the regulator setting shall be at least 1” W.C.
above the suggested manifold pressure.
Minimum Gas Supply Pressure - 11” W.C.
Maximum Gas Supply Pressure - 14” W.C.
NOTE: Our service technicians are available to assist you in making repairs or parts
replacements from 8:00 am to 5:00 pm, Monday through Friday (except holidays), by
calling423-775-2131,Extension7102. Oure-mailaddressisSMCSales@suburbanmfg.
com or
visit our website at www.AIRXCEL.com.
UL OR CSA LABEL
UL OU CSA LABEL
SUBURBAN SERIAL NUMBER INFORMATION
All Suburban Serial Numbers manufactured after January 1990, will be nine digits. The rst two (2)
digits signify the year of manufacture. The next set of digits, indicate the week of the year and the
remaining digits are serial numbers.
EXAMPLE SERIAL NUMBER DESCRIPTION
Sample Serial Number:
07 25 03340
Serial Number for that Week
Week of the Year
Year of Manufacture

5
RANGE AND COOKTOP MODEL NUMBERS
17” AND 22” CONVENTIONAL BURNER MERCURY FREE CONTROL RANGES
Model
Number Burners Oven Height Top Porcelain Door Top Ignition
SRNA3SBBE 3 17” Black Black Piezo
SRNA3SBBM 3 17” Black Black Match
SRNA3SBGE 3 17” Black Black w/
Glass Piezo
SRNA3SBGM 3 17” Black Black w/
Glass Match
SRNA3SPSS 3 17” Stainless 1Stainless Spark 2
SRNA3LBBE 3 22” Black Black Piezo
SRNA3LBBM 3 22” Black Black Match
SRNA3LBGE 3 22” Black Black w/
Glass Piezo
SRNA3LBGM 3 22” Black Black w/
Glass Match
SRNA3LPSS 3 22” Stainless 1Stainless Spark 2
17” AND 22” SEALED BURNER MERCURY FREE CONTROL RANGES
Model
Number Burners Oven Height Top Porcelain Door Top Ignition
SRSA3SBBE 3 17” Black Black Piezo
SRSA3SBBM 3 17” Black Black Match
SRSA3SBGE 3 17” Black Black w/
Glass Piezo
SRSA3SBSE 3 17” Black Stainless Piezo
SRSA3SPSS 3 17” Stainless 1Stainless Spark 2
SRSA3LBBE 3 22” Black Black Piezo
SRSA3LBBM 3 22” Black Black Match
SRSA3LBGE 3 22” Black Black w/
Glass Piezo
SRSA3LBSE 3 22” Black Stainless Piezo
SRSA3LPSS 3 22” Stainless 1Stainless Spark 2
1 Porcelain with appearance of stainless steel
2 Spark igniter requires 1 AAA battery (included)

6
RANGE AND COOKTOP MODEL NUMBERS
17” AND 22” CONTEMPORARY CONVENTIONAL BURNER RANGES
Model
Number Burners Oven Height Top Porcelain Door Top Ignition
SRNA3SBVEZ 3 17” Black OPEN
GLASS Piezo
SRNA3LBVEZ 3 22” Black OPEN
GLASS Piezo
SRNA3SBUEZ 3 17” Black Black with Nickel
Handle Piezo
SRNA3LBUEZ 3 22” Black Black with Nickel
Handle Piezo
17” AND 22” CONTEMPORARY SEALED BURNER RANGES
Model
Number Burners Oven Height Top Porcelain Door Top Ignition
SRSA3SBVEZ 3 17” Black OPEN
GLASS Piezo
SRSA3LBVEZ 3 22” Black OPEN
GLASS Piezo
17” AND 22” BUILT-IN GLASS COVER RANGES
Model
Number Burners Oven Height Top Porcelain Door Top Ignition
SRNA3SBVSYZC 3 17” Black OPEN
GLASS Spark
SRNA3LBVSYZC 3 22” Black OPEN
GLASS Spark
GLASS DOOR
STEEL DOOR
GLASS DOOR
BUILT-IN GLASS COVER

7
SLIDE-IN COOKTOP MODEL NUMBERS
SLIDE-IN COOKTOPS -CONVENTIONAL BURNERS
Model
Number Burners DESCRIPTION Ignition
SCN3BM 3 Slide-in, Black Match
SCN3BE 3 Slide-in, Black Piezo
SCNA3PS 3 Slide-in, Stainless1Spark 2
SLIDE-IN COOKTOPS -SEALED BURNERS
Model
Number Burners DESCRIPTION Ignition
SCS3BM 3 Slide-in, Black Match
SCS3BE 3 Slide-in, Black Piezo
SCSA3PS 3 Slide-in, Stainless1 Spark 2
SLIDE-IN AND RANGE BI-FOLD COVERS
FLUSH MOUNT GLASS COVER
Part Number DESCRIPTION
2814A Bi-Fold Cover, Black (NOT SHOWN)
2815A Bi-Fold Cover, White (NOT SHOWN)
2985A FLUSH MOUNT GLASS COVER
3085A FLUSH MOUNT GLASS COVER WITH HANDLE
3088A FLUSH MOUNT GLASS COVER (BUILT-IN GLASS COVER
UNITS)
1 Porcelain with appearance of stainless steel
2 Spark igniter requires 1 AAA battery (included)
LEFT FRONT RIGHT
LEFT FRONT RIGHT

8
DROP-IN COOKTOP MODEL NUMBERS
DROP-IN COOKTOPS
Model
Number Burners DESCRIPTION
SDN2 2 RV Drop-In Cook Top (Burner Box Only)
SDN2SS 2 RV Drop-In Cook Top with Stainless Top
SDN2BK 2 RV Drop-In Cook Top with Black Top
SDN2WH 2 RV Drop-In Cook Top with White Top
SDN2-SS 2 SDN2 Stainless Steel (Top Only)
SDN2-BK 2 SDN2 Black (Top Only)
SDN2-WH 2 SDN2 White (Top Only)
SDN3 3 RV Drop-In Cook Top (Burner Box Only)
SDN3SS 3 RV Drop-In Cook Top with Stainless Top
SND3BK 3 RV Drop-In Cook Top with Black Top
SDN3WH 3 RV Drop-In Cook Top with White Top
SDN3-SS 3 SDN2 Stainless Steel (Top Only)
SDN3-BK 3 SDN2 Black (Top Only)
SDN3-WH 3 SDN2 White (Top Only)
SDS2 2 RV Drop-In Cooktop with Stainless Top and Black
Glass Cover (Flush Mounted)
DROP-IN COVERS
DESCRIPTION
2968AST SDN2 Cover, Stainless Steel
2968ABK SND2 Cover, Black
2968AWH SDN2 Cover, White
2697AST SDN2 Cover, Stainless Steel (With Side Shields)
2967ABK SND2 Cover, Black (With Side Shields)
2967AWH SDN2 Cover, White (With Side Shields)
2948AST SDN3 Cover, Stainless Steel
2948ABK SND3 Cover, Black
2948AWH SDN3 Cover, White
2947AST SDN3 Cover, Stainless Steel (With Side Shields)
2947ABK SND3 Cover, Black (With Side Shields)
2947AWH SDN3 Cover, White (With Side Shields)
FLUSH MOUNT GLASS COVER
2983A Flush Mount Glass Cover, 2 Burner
2990A Flush Mount Glass Cover, 3 Burner

9
INSTALLATION
INSTRUCTIONS
SCN(S) and SRN(S)A
WARNING! Installation of this appliance must be made in accordance with the
written instructions provided in this manual. No agent, representative or employee
of Suburban or other person has the authority to change, modify or waive any
provision of the instructions contained in this manual.
1. In the U.S.A., the installation must conform with state or other codes or in the
absence of such codes, refer to the latest edition of:
a. Standard for Recreational Vehicles NFPA 1192
b. National Fuel Gas Code ANSI Z223.1/NFPA 54
In Canada, the installation must be in accordance with:
a. Standard CAN/CSA Z-240.4.2-08, Installation Requirements for Propane
Appliances and Equipment in Recreational Vehicles.
b. Any applicable local codes and regulations
2. Minimum clearances from combustible walls above and below counter: (See
Figure 1A)
MODELS
Below
Counter
Center of Burner Head(s) to adjacent
vertical combustible material above the
cooking surface burners.
Sides, Rear
and Bottom Right Sidewall
Left
Sidewall Backwall
SCN3/SCNA3
SCS3/SCSA3 0” 6” 6” 9”
SRNA3
SRSA3 0” 6” 6” 9”
3. Cut-out dimensions illustrated in Figure 2 are as follows:
MODELS DIMENSIONS
A B C D E
SRNA3S
SRSA3S 18 5/8” 16” 2” 20 5/8” 7/8”
SRNA3L
SRSA3L 18 5/8” 21 3/4” 2” 20 5/8” 7/8”
SCN3/SCNA3
SCS3/SCSA3 18 5/8” 3 5/8” 2” 20 5/8” 7/8”
The minimum vertical distance to combustible material above the range cooking top
is 24 inches, provided the overhead construction does not extend 13 inches from the
rear wall.
NOTE: UL and cUL certied with a minimum top clearance of 19 1/2” to overhead
combustible construction when installed with a range hood spaced a minimum of 1/4”
from the construction.
4. Ensure the cabinets are properly constructed. The cabinets must be squared with
respect to the counter top and the cabinet face. For proper operation of these
units, the cabinet must be level and the bottom of the range must be supported.
5. After the cabinet has been prepared per the dimensions given and the gas
connection is in place, remove main top and position the unit in the cabinet
opening.
NOTE: Be sure all opening in the cabinetry around the gas lines are sealed at the time
of installation.
WARNING! It is imperative that the cabinet in which the unit is placed be separated
from other appliances so that the combustion air supply to the top burners can not
be a󰀨ected in any way by any forced-air heating appliance or its return air system or
by any source of positive or negative air pressure, such as, but not limited to, power
vents, fans, etc. A negative air pressure created by another forced air moving
appliance may draw the ame down around the top burners and into the main top
resulting in damage to the burners and cooktop, as well as possible personal injury
and/or damage to vehicle. A positive draft could cause the burner ame to lift-o󰀨
the burner and go out resulting in an uncontrolled escape of gas. Whenever the gas
fumes reach an open ame or another ignition source, an explosion and/or re will
occur resulting in property damage, personal injury and/or loss of life.
6. Fasten unit in place with wood screws through holes provided in side anges of
burner box and front frame bottom tabs with a minimum of six screws.
7. Be sure burner knobs are in “o󰀨” position. Secure gas connection and turn on
gas supply. Check all connections for leaks using soapy-water solution or a non-
corrosive leak detection solution. Do not use a soapy-water solution containing
ammonia.
CAUTION: Gas supply tubing within the connes of the appliance connection
shall be rigid or semi-rigid metallic tubing.
WARNING! Never check for leaks with an open ame or any ignition source for this purpose.
NOTE: The appliance must be disconnected from the gas supply piping system during
any pressure testing of that system at test pressure in excess of 1/2 PSIG.
8. Replace main top.
9. Your unit is now ready for operation. Before operating, read the safety information
and operating instructions contained in the installation manual.
Figure 2
Figure 1A
9.000
BACK WALL
SIDE WALL
6.000
C
LOF BURNER
OF BURNER
C
L
MOUNTING SURFACE (COUNTERTOP)
SURFACE DE MONTAGE (PLAN DE TRAVAIL)
MUR LATERAL
MUR ARRIERE
DU BRULEUR
DU BRULEUR
1 3/4" 2 1/8"
D
B
D
C
E
A
GAS SERVICE PIPE OPENING
MIN. DIM. TO EITHER SIDE WALL
MIN. DIM. TO BACK WALL
MOUNTING HOLES
DÉGAGEMENT DE SÈCURITÈ - MUR LATÈRAL (2 COTÈS)
TROU POUR CANALISATION DE GAZ
DÉGAGEMENT DE SÉCURITÉ - MURARRIÈRE
TROUS DE MONTAGE

10
17” AND 22” RANGES WITH BUILT-IN
GLASS COVER INSTALLATION
WARNING: Installation of this appliance must be made in accordance with the written
instructions provided in this manual. No agent, representative or employee of Suburban or
other person has the authority to change, modify or waive any provision of the instructions
contained in this manual.
1. In the U.S.A., the installation must conform with state or other codes or in the absence
of such codes, refer to the latest edition of:
a. Standard for Recreational Vehicles NFPA 1192
b. National Fuel Gas Code ANSI Z223.1/NFPA 54
In Canada, the installation must be in accordance with:
a. Standard CAN/CSA Z-240.4.2-08, Installation Requirements for Propane Appliances
and Equipment in Recreational Vehicles.
b. Any applicable local codes and regulations
2. Minimum clearances from combustible walls above and below counter: (See Figure 1A)
Models
Below
Counter Center of Burner Head(s) to adjacent vertical combus- tible material above the cooking surface burners.
Sides, Rear
and Bottom Right Side- wall
Left Side-
wall Backwall
SCNA3
SCSA3 0” 6” 6” 9”
SRNA3
SRSA3 0” 6” 6” 9”
3. Cut-out dimensions illustrated in Figure 2 are as follows:
Models Dimensions
A B C D E
SRNA3S
SRSA3S 20 3/8” 18 1/4” 2 1/2” 22 3/4” 7/16”
SRNA3L
SRSA3L 20 3/8” 24” 2 1/2” 22 3/4” 7/16”
SCNA3
SCSA3 20 3/8” 5 7/8” 2 1/2” 22 3/4” 7/16”
The minimum vertical distance to combustible material above the range cooking top is 24
inches, provided the overhead construction does not extend 13 inches from the rear wall.
NOTE: UL and cUL certied with a minimum top clearance of 19 1/2” to overhead
combustible construction when installed with a range hood spaced a minimum of 1/4” from
the construction.
4. Ensure the cabinets are properly constructed. The cabinets must be squared with
respect to the counter top and the cabinet face. For proper operation of these units, the
cabinet must be level and the bottom of the range should be supported.
5. After the cabinet has been prepared per the dimensions given and the gas connection
is in place, position the unit in the cabinet opening.
WARNING: It is imperative that the cabinet in which the unit is placed be separated from
other appliances so that the combustion air supply to the top burners can not be a󰀨ected
in any way by any forced-air heating appliance or its return air system or by any source
of positive or negative air pressure, such as, but not limited to, power vents, fans, etc. A
negative air pressure created by another forced air moving appliance may draw the ame
down around the top burners and into the main top resulting in damage to the burners
and cooktop, as well as possible personal injury and/or damage to vehicle. A positive draft
could cause the burner ame to lift-o󰀨 the burner and go out resulting in an uncontrolled
escape of gas. Whenever the gas fumes reach an open ame or another ignition source,
an explosion and/or re will occur resulting in property damage, personal injury and/or
loss of life.
6. Fasten unit in place with provided fasteners through four holes provided in side of glass
cover. Secure front frame bottom tabs with two appropriate fasteners. SEE FIGURE 2.
7. Be sure burner knobs are in “o󰀨” position. Remove the main top. Secure 3/8” are gas
connection and turn on gas supply. Check all connections for leaks using a pressure
drop test; or a soapy-water solution; or a non-corrosive leak detection solution. Do not
use a soapy-water solution containing ammonia.
CAUTION: Gas supply tubing within the connes of the appliance connection shall be
rigid or semi-rigid metallic tubing.
WARNING: Never check for leaks with an open ame or any ignition source for this
purpose.
NOTE: The appliance must be disconnected from the gas supply piping system during any
pressure testing of that system at test pressure in excess of 1/2 PSIG.
The appliance must be isolated from the gas supply piping during any pressure testing of the
gas supply piping system at test pressure equal to, or less than, 1/2 PSIG.
8. Install rubber trim pieces onto the side edges of main top. Pieces are located in a plastic
bag stapled to this manual. Place two pieces on each side of main top, one front and
one rear. The “U” shaped trim piece will slip over the vertical edge of the main top side.
See Figure 4.
9. Replace main top.
10. Your unit is now ready for operation. Before operating, read the safety information and
operating instructions contained in the manual.

11
9.000
BACK WALL
SIDE WALL
6.000
C
LOF BURNER
OF BURNER
C
L
MOUNTING SURFACE (COUNTER TOP)
SURFACE DE MONTAGE (PLAN DE TRAVAIL)
MUR LATERAL
MUR ARRIERE
DU BRULEUR
DU BRULEUR
2 13/16"
4 3/8"
D
B
D
C
E
GAS SERVICE PIPE OPENING
MIN. DIM. TO EITHER SIDE WALL
MIN. DIM. TO BACK WALL
MOUNTING HOLES
A
DEGAGEMENT DE SECURITE - MUR LATERAL (2 COTES)
TROU POUR CANALISATION DE GAZ
DEGAGEMENT DE SECURITE - MURARRIERE
TROUS DE MONTAGE

12
INSTALLATION
INSTRUCTIONS
SDN2 • SDN3
WARNING! Installation of this appliance must be made in accordance with the
written instructions provided in this manual. No agent, representative or employee
of Suburban or other person has the authority to change, modify or waive any
provision of the instructions contained in this manual.
1. In the U.S.A., the installation must conform with state or other codes or in the
absence of such codes, refer to the latest edition of:
a. Standard for Recreational Vehicles NFPA 1192.
b. National Fuel Gas Code ANSI Z223.1/NFPA 54
In Canada, the installation must be in accordance with:
a. Standard CAN/CSA 240.4.2-08, Installation Requirements for Propane
Appliances and Equipment in Recreational Vehicles.
b. Any applicable local codes and regulations
2. Minimum clearances from combustible walls above and below counter:
MODELS
Below Counter
Center of Burner Head(s) to adjacent vertical
combustible material above the cooking
surface burners.
Sides, Rear
and Bottom Right
Sidewall
Left
Sidewall Backwall
SDN2 0” 5 7/8” 5 7/8” 8”
SDN3 0” 5 5/8” 6” 8”
3. Cut-out dimensions illustrated in Figure 2 are as follows:
MODEL DIMENSIONS
A B C* D* E
SDN2 16 3/8” 11 5/8” 2 3/16” 3/4” min. 18”
SDN3 18 15/16” 16 1/8” 2 1/16” 2 3/8” min. 21”
*Minimum acceptable spacing between adjacent models is 3 inches.
WARNING! Installation of cook top cannot be such that the user is required to reach over any
of the burners to reach the knobs.
4. Before placing drop-in cook top into cabinet, determine which one of the three
knockout openings in the burner box (left side, right side or rear) will be used for
routing of the gas supply tubing to the pressure regulator. After making selection,
knockout the 1 inch plug. Place drop-in cook top into the prepared opening and
secure to cabinet with four (4) wood screws. (Not provided)
NOTE: For models with a manifold extension, place the drop-in cook top into
the prepared opening and secure to the cabinet with four (4) wood screws. (Not
provided)
5. Route gas line through opening in burner box and connect the gas line to the 3/8”
are tting inside the burner box. Place nylon bushing over gas line and insert
bushing into opening in burner box.
NOTE: For models with a manifold extension, connect the gas line to the 3/8”
are tting just outside the burner box. Be sure to hold the tting on the
extension with a wrench when tightening the are nut. Failure to hold tting
secure could result in a gas leak due to tting being damaged.
CAUTION: Gas supply tubing within the connes of the appliance burner box
shall be rigid or semirigid metallic tubing.
6. Be sure all openings in the cabinets around the gas line are sealed at time of
installation.
CAUTION: It is imperative that the cabinet in which the cook top is placed be separated from
other appliances so that the combustion air supply to the top burners can not be a󰀨ected in any
way by any forced-air heating appliance or its return air system or by any other source of positive
or negative air pressure. A negative air pressure created by another forced air appliance may
draw the ame down around the top burners and into the cook top resulting in damage to the
burners and cook top, as well as possible personal injury and/or damage to vehicle. A positive
draft could cause the burner ame to lift-o󰀨 the burner and go out resulting in an uncontrolled
escape of gas. Whenever the gas fumes reach an open ame or another ignition source, an
explosion and/or re will occur resulting in property damage, personal injury and/or loss of life.
7. Be sure burner knobs are in “o󰀨” position. Turn on gas supply. Check all
connections for leaks.
WARNING! Never check for leaks with an open ame. Apply a soap and water solution to all
joints to see if bubbles are formed.
NOTE: The appliance must be disconnected from the gas supply piping system during
any pressure testing of that system at test pressure in excess of 1/2 PSIG.
8. Remove the top and the grate(s) from their packing - Install the grate(s) on the top.
9. Position the top over the burners and secure in place with two (2) thumb screws
and two (2) nylon washers provided.
10. Your Suburban Drop-in Cooktop is now ready for operation. Before operating,
read the safety information and operating instructions contained in the installation
manual.
11. If installation of this product is in a portable counter top, the following additional
guidelines must be followed:
a. Portable counter top is provided by installer and must be able to support a
minimum weight of 20 lbs.
b. OEM must provide a label placed on the counter top that clearly states the
maximum weight that can be added to the portable counter top after installation.
(This should take into account the weight of the cooking unit - 20 lbs).
FOR EXAMPLE: Mounting bracket used is rated for 100 lbs. OEM should weigh
fabricated counter top. Subtract weight of counter top (i.e. 20 lbs) and weight of
cooking unit (20 lbs.) from 100 lbs. The weight label should say no more than 60 lbs.
can be put on the counter top.
c. The surface material for the counter top must be rated for a minimum of 200°F
continuous operation temperature with the maximum weight applied.
d. Minimum clearances from combustible walls above and below the counter top
must be adhered to during operation.
e. The OEM must provide a warning label placed on the counter top that requires
the unit to be cooled a minimum of 30 minutes after use before storing.
f. During storage, a clearance of 1” must be maintained from the top surface of
the unit.
g. NOTE: The gas must be turned “OFF” and disconnected when stored.
A
4" 3 1/8"
18" E
MIN.
C
MINIMUM DISTANCE TO COMBUSTIBLE SURFACES
DIRECTLYABOVE COOK-TOP 24"
*D
WALL
*C-SEE UL LABEL
*
13" MAXIMUM OVERHEAD
CABINET DEPTH
B
REAR
FRONT

13
SDS2 INSTALLATION
INSTRUCTIONS
WARNING
Installation of this appliance must be made in accordance
with the written instructions provided in this manual. No
agent, representative or employee of Suburban or other
person has the authority to change, modify or waive any
provision of the instructions contained in this manual.
1. In the U.S.A., the installation must conform with state or other codes or in the
absence of such codes, refer to the latest edition of :
a. Standard for Recreational Vehicles NFPA 1192.
b. National Fuel Gas Code ANSI Z223.1/NFPA 54
2. In Canada, the installation must be in accordance with:
a. Standard CAN/CSA Z240.4.2-08, Installation Requirements for Propane
Appliances and Equipment in Recreational Vehicles.
b. Any applicable local codes and regulations.
Not suitable for use with a hose assembly.
Not for installation or operation with aftermarket lids or covers.
3. Minimum clearances from combustible walls above and below counter:
MODELS Below Counter Bottom
(From Gas Connection)
Center of Burner Head(s) to adjacent vertical
combustible material above the cooking surface
burners.
Sides, Rear, and Bottom Right Sidewall Left Sidewall Backwall
SDS2 0" 4 3/4" 6 3/4" 6 3/4"
4. Cut-out dimensions illustrated in Figure 2 are as follows:
MODEL
DIMENSIONS
A B C* D*
SDS2 18-3/8" 14-1/16" 4" 2-1/4"
*Minimum acceptable spacing between adjacent models is 3".
NOTE: The maximum depth of cabinets installed above cooking
appliances is 13 inches. WARNING
Installation of cooktop cannot be such that the user is required
to reach over any of the burners to reach the knobs.
5. Prepare the countertop cutout per the dimensions above and in Figure 1a.
6. Access to install the gas line will be dependent upon type of enclosure and
clearances. For low clearance bottom installations, it may be necessary to drill a
hole in the bottom to route the gas line. See gures 1B for gas connection location.
7. Secure the cooktop to the countertop by tightening clamp screws located under
rubber bumpers (See Figure 4). DO NOT OVERTIGHTEN.
a. If the countertop thickness range is between 0.827” - 0.984”, the plastic
spacer piece provided should NOT be used in conjunction with the clamping
mechanism (Refer to Figure 4A).
b. If the countertop thickness range is between 0.629” - 0.827”, the plastic spacer
piece provided SHOULD be used in conjunction with the clamping mechanism
(Refer to Figure 4B).
8. Route gas line and connect the 3/8" male ared tting.
NOTE: Be sure to hold the tting at the end of the manifold with a wrench when
tightening the gas connection. Failure to hold tting secure could result in a gas
leak due to tting being damaged.
CAUTION
It is imperative that the cabinet in which the cook top is placed be
separatedfromotherappliancessothatthecombustionairsupply
to the top burners can not be a󰀨ected in any way by any forced-air
heatingapplianceoritsreturnairsystemorbyanyothersourceof
positive or negative air pressure.Anegative air pressure created
by another forced air appliance may draw the ame down around
the top burners and into the cook top resulting in damage to the
burners and cook top, as well as possible personal injury and/or
damage to vehicle. A positive draft could cause the burner ame
to lift-o󰀨 the burner and go out resulting in an uncontrolled escape
of gas. Whenever the gas fumes reach an open ame or another
ignition source, an explosion and/or re will occur resulting in
property damage, personal injury and/or loss of life.
9. Be sure all openings in the cabinets around the gas line are sealed at time of
installation.
10. Be sure burner knobs are in “OFF” position. Turn on gas supply. Check all
connections for leaks according to the manufacturer's instructions. Ensure that
the gas connection point is accessible with the appliance installed.
WARNING
Never check for leaks with an open ame. Apply a soap and
water solution to all joints to see if bubbles are formed.
NOTE: The appliance and its individual shuto󰀨 must be disconnected from the gas
supply piping system during any pressure testing of that system at test pressures in
excess of ½ PSIG.
11. If installation of this product is in a portable counter top, the following additional
guidelines must be followed:
a. Portable counter top is provided by installer and must be able to support a
minimum weight of 20 lbs.
b. OEM must provide a label placed on the counter top that clearly states the
maximum weight that can be added to the portable counter top after installation.
(This should take into account the weight of the cooking unit - 20 lbs.).
FOR EXAMPLE: Mounting bracket used is rated for 100 lbs. OEM should
weigh fabricated counter top. Subtract weight of counter top (i.e. 20 lbs.) and
weight of cooking unit (20 lbs.) from 100 lbs. The weight label should say no
more than 60 lbs can be put on the counter top.
c. The surface material for the counter top must be rated for a minimum of 200°F
continuous operation temperature with the maximum weight applied.
d. Minimum clearances from combustible walls above and below the counter top
must be adhered to during operation.
e. The OEM must provide a warning label placed on the counter top that requires
the unit to be cooled a minimum of 30 minutes after use before storing.
f. During storage, a clearance of 1" must be maintained from the top surface of
the unit.
g. NOTE: The gas must be turned "OFF" and disconnected when stored.
12. Appliance commissioning - installer to check for correct burner test point pressure
with at least 50% of cooktop burners operating, and any other appliance in
operation. Verify proper ignition of all burners.
13. Check all connections for gas leaks with soap and water. DO NOT use a naked
ame for detecting leaks. Ignite all burners both individually and concurrently to
ensure correct operation of gas valves, burners and ignition. Turn gas valves to
low ame position and observe stability of the ame for each burner individually
and concurrently. When satised with the appliance, please instruct the user on
the correct method of operation. In case the appliance fails to operate correctly
after all checks have been carried out, refer to the authorized service provider in
your area.
14. Your Suburban Drop-in Cook top is now ready for operation. Before operating,
read the safety information and operating instructions contained in this manual.
RECOMMENDED PAN SIZE
MINIMUM MAXIMUM
6.25" 8.75"
15. To prevent damage to the cook top, top burners, or top grate, never operate a top
burner without a pan in place. The top burners should not be operated on high for
an extended period of time.
Use the high ame setting to begin, then reduce the ame to a lower setting to continue
cooking. Never use cookware which extends beyond one inch of the grate, or rests
over two operating top burners. This will cause excessive heat build-up which results
in damage to the grate, top burner, and cook top.

14
OPERATING INSTRUCTIONS
WARNING
The glass lid on the Suburban SDS2 Cooktop is NOT a
cooking surface. The top cover must be open when main
burner is in operation. See the warning label on the glass
lid: COVER MUST BE IN THE FULL OPEN POSITION
WHEN ANY TOP BURNER IS IN OPERATION. AFTER
USE OF TOP BURNER(S), LET TOP BURNER GRATE
COOL BEFORE REPLACING TOP COVER.
1. Know which knob controls which burner. Always be sure the correct burner is
turned on.
SYMBOL DESCRIPTION
LITE / HIGH FLAME
LOW FLAME
IGNITION SWITCH
2. Push the electronic ignition button down.
3. Depress knob and turn counter-clockwise to “High Flame” position.
a. Verify su󰀩cient gas supply before attempting to light the burner. Air in the gas
line will signicantly delay burner ignition. The burner may light unexpectedly
as the air in the line clears and is replaced by Propane gas. This unexpected
ignition could burn you. Air in the gas lines may occur after the vehicle gas
bottle and/or tank is relled, during and after servicing other appliances on
same gas line, etc.
b. Do not attempt to light more than one burner at a time.
CAUTION
Hand held ignitors may be used but be sure they are the
type designed for lighting open ame burners.
9.764
[248]
9.764
[248]
9.173
[233] 9.173 [233]
7.047 [179]
7.047 [179]
R1.181
[R30]
R1.181
[R30]
R1.181
[R30]
R1.181
[R30]
R2.756
[R70] 18.346
[466]
R2.756
[R70]
14.094 [358]
135° 135°
SDS2
3. If any burner should extinguish after initial lighting or due to accidental blow-out,
turn gas o󰀨 by turning control knob clockwise to “OFF”, wait ve (5) minutes
before attempting to relight the burner. Failure to follow these instructions could
result in a re or explosion. If the burner should go out while cooking, or if there is
an odor of gas, turn control knob(s) clockwise to “OFF”. Wait ve (5) minutes
for gas odor to disappear. If gas odor is still present - Do not relight burners. See
“What To Do If You Smell Gas” on the front cover of this manual.
4. To turn burner(s) “OFF”, turn the appropriate control knob clockwise to “OFF”.
WARNING
Be sure all control knobs are turned “OFF” when you are
not cooking. Someone could be burned or a re could start
if a burner is accidently left on or unattended even if only
momentarily.
MAKING ELECTRICAL CONNECTION
LOW VOLTAGE 12 VOLTS D.C.
A. Applicable to the following model: 3032AST
B. Refer to Figure 4 for location of screw-type terminal.
C. Electrical connections must be made in accordance with local codes and
regulations. In the absence of local codes and regulations, refer to the latest
edition of the National Electrical Code ANSI/NFPA 70.
D. Make the 12 Volt D.C. electrical connection following the wiring diagram illustrated
in Figure 4. CAUTION
This appliance must be connected to a 12V power supply. The
circuit must be tted with a safety fuse not higher than 3 amps.
When Wiring the appliance, respect correct polarity.
WARNING
It is of utmost imporance to never connect this appliance to a higher
voltage

15
SMALL
FLAME
BURNER
WILL NOT
IGNITE
NO
SPARK
BURNER
WILL NOT
STAY LIT POSSIBLE CAUSE
XXXXX XXXXX Empty Gas Supply
XXXXX XXXXX Dead Battery
XXXXX Insu󰀩cient Gas Pressure
Electrode 1
Electrode 2
(-)
(+)
Ignition Module
(+) (-)
Ignition Switch
R
Bk
Bk
Y/G
Y/G
BkW
AA Battery
SDS2 SERVICE INSTRUCTIONS
WARNING
Installation and service must be performed by a qualied installer, service agency or the
gas supplier.
WARNING
Before beginning any service of cooktop, the gas supply to the appliance must be in the
OFF position.
DO NOT MODIFY THIS APPLIANCE.
BURNERS, ORIFICES, THERMOCOUPLES,
AND ELECTRODES
1. Remove grates by pulling up from main top of cooktop.
2. Remove gas tubing with an 8 mm wrench. Take care to
not bend or kink gas tubing.
3. Unscrew thumb screws from orice holder.
4. Lift burner head free of cooktop.
5. Gently pull orice holder free of cooktop.
6. Remove gasket from orice holder.
7. Loosen nut retaining thermocouple using an 8 mm
wrench. Pull thermocouple quick connector free from
appropriate gas valve.
8. Pull wire free from ignition module.
9. Spread bottom of electrode retaining spring and pull free
from electrode.
10. Feed electrode wire through slot in orice holder.
11. Unscrew orice using a 7 mm socket.
12. Replacement is reverse of above procedure.
VALVE AND MANIFOLD ASSEMBLY
1. Ensure the gas supply to the cooktop is in the OFF
position.
2. Disconnect the gas supply line to the cooktop.
3. Remove gas tubing from each valve with an 8 mm
wrench. Take care to not bend or kink gas tubing.
4. Pull thermocouple quick connectors free from gas
valves.
5. Remove control knobs by gently pulling away from valve
stem.
6. Remove valve retaining nuts using a 16 mm socket.
7. Pull the manifold assembly free of the cooktop.
8. Replacement is reverse of above procedure.
BATTERY REPLACEMENT
1. Remove the battery from the battery holder located
under rear of cooktop.
2. Insert new AA size battery into battery holder. Observe
correct polarity of battery.

16
2.388 [61]
3.448 [88]
COUNTER TOP SURFACE
GAS CONNECTION
14.531 [369]
4.455 [113]
18.813 [478]
GAS CONNECTION
BATTERY HOLDER
12VDC 12VDC TERMINAL CONNECTION
Electrode 2
(-)
(+)
Ignition Module
(+)
(-)
Ignition Switch
R
Bk
Bk
Y/G
Y/G
Touch-Safe
Terminal Block
Bk
12 VDC IN
(FIELD WIRING)
(FACTORY WIRING)
Electrode 1
Bk

17
COOKING APPLIANCE TERMINOLOGY
TERMINOLOGY DEFINITION
CSA ..................................................................Canadian StandardsAssociation – International
UL......................................................................Underwriters Laboratories
CUL ...................................................................Underwriters Laboratories Canada
PILOT THERMOCOUPLE ................................A bimetal probe which generates a small electrical
current when heat is applied to it
OVEN PILOT ....................................................The oven pilot burner that continually heats the
thermocouple and furnishes the ignition source
for the main oven burner.
BLOCK WITH MAIN BURNER ORIFICE ..........A precision drilled component that meters gas
ow to the main burner.
MANIFOLD .......................................................A pressurized tube or pipe that provides gas to
the top and oven burner valves.
OVEN THERMOSTAT ......................................The control that regulates the temperature of the
oven at the preferred cooking temperature and
supplies gas for both the pilot burner and oven
burner.
PIEZO IGNITER................................................An electromechanical device that can be used to
ignite the top burners.
SPARK IGNITER ..............................................A battery operated device that can be used to
ignite the top burner and oven pilot. (Requires 1
AAA battery)
REGULATOR ...................................................A valve that reduces the high propane tank
pressure to the appropriate operating pressure
that will serve the appliance.
THERMAL BULB ..............................................The bulb located in the oven attached to the
thermostat containing thermal uid and forces the
thermostat to open and close based on the set
cooking temperature.
YELLOW TIPPING ...........................................A burner ame with yellow tips caused by
inaccurate gas/air mixture, incorrect placement or
restriction of orice and venturi tube.

18
MANIFOLD IDENTIFICATION
Sabaf (Round) Manifold with plug-in thermocouple
• Original mercury free system (Ranges with an A in the model number). Used exclusively in all Suburban
mercury free ranges from 2004 through 2006.
• Used concurrently with the square manifold system (BSI) from late 2006 through early 2009.
• Since early 2009 the Sabaf manifold was used on some sealed burner and all glass top models.
• Individual components available separately
BSI (Square) Manifold
• First used in late 2006
• Used concurrently along with Sabaf manifolds on all conventional and sealed burner model ranges from late
2006 through mid 2009
• Used exclusively on all conventional burner model ranges (N in the model number) from mid 2009 through
mid 2011
• Used concurrently with Copreci manifold (round manifold with screw in style thermocouple) on all
conventional burner model ranges from mid 2011 to present date
• Used currently with sealed burner models
• All components only available as an assembly
Copreci Manifold (Round) Manifold With screw in thermocouple
• Initial release in mid 2011
• Used concurrently with BSI on all conventional burner model ranges from January 2012 to present
• All components only available as an assembly

19
In 2013, Suburban began a transition on stove top burners. All ranges
currently have the low prole conventional burners (SI version).
The burners shown above must be replaced with respective burner. They
are not backwards compatible. Review the Suburban parts manual or
contact Customer Service at 423.775.2131 EXT 7101.
If a replacement is required for BSI/Mueller style burner, you will need to
order KIT# 521119 and replace all three burners.
BURNER BTU OUTPUT INFORMATION
RANGE-TOP BURNER
Left and Right Rear 6500 BTU
Center (High Output) 9000 BTU
SLIDE-IN
Left and Right Rear 6500 BTU
Center (High Output) 9000 BTU
DROP-IN COOKTOP
SDN 2 6500 BTU
SDN 3
Left Front & Rear 5200 BTU
Right 6500 BTU
Oven Burner 7100 BTU
SUBURBAN TOP BURNER IDENTIFICATION
INFORMATION
BSI MUELLER SI - CURRENT

20
TROUBLE SHOOTING GUIDE FOR SUBURBAN RANGES
- OVEN -
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
PILOT WON’T LIGHT A. Insu󰀩cient Gas Supply A. Inspect Gas Supply
B. Insu󰀩cient Gas Pressure B. Check for gas leaks and correct gas pressure (11
W.C. - 14 W. C.
C. Restriction in pilot orice or tubing C. Inspect and clean pilot orice, inspect tubing for
kinks or leaks around ttings.
PILOT WON’T STAY LIT WHEN KNOB
RELEASED A. Defective Thermocouple
A. Inspect thermocouple connection, Inspect for
proper ame impingement at thermocouple tip.
Inspect mV output from thermocouple when heated
(18 mV on screw in thermocouple) (4 mV. on plug in
thermocouple)
B. Pilot plunger inside gas control not fully engaged
with magnet when knob is depressed
B. Inspect that knob is not coming in contact with
range front when knob is depressed. This could keep
pilot plunger inside gas valve from coming in contact
with the electromagnet in valve. Inspect that plunger
on valve is engaging when knob is depressed.
C. Defective magnet in control thermostat C. Replace control valve/manifold assembly
D. Micro-switch not engaged (plug in thermocouple
models only) D. Inspect micro-switch, adjust as required.
MAIN BURNER WON’T LIGHT A. No gas owing to main burner
A. Inspect burner orice for obstruction. Inspect
gas pressure to main burner, replace oven control if
defective. Ensure pilot is lit.
MAIN BURNER FLUTTERS WHEN LIT A. Air Shutter incorrectly set A. Adjust air shutter on burner
B. Low gas pressure/restriction in orice B. Inspect gas pressure and orice. Adjust as
required
PILOT GOES OUT (STARTS POPPING) DURING
BAKING CYCLE A. Pilot burner defective A. Replace pilot burner
B. Gas control thermostat defective B. Inspect gas pressure from gas control to pilot
burner, replace gas control if found defective
C. Pilot tubing restricted C. Inspect pilot tubing for kinks or leaks at
connections
POOR BAKING RESULTS
- Food too light or too dark
- Food cooks unevenly A. Oven not preheated A. Preheat oven a minimum of 10 minutes
B. Poor oven air circulation B. Inspect to ensure that oven vent is not blocked or
that oven is too full for proper air circulation
C. Oven temperature sensing bulb not installed
correctly C. Inspect that bulb is installed into clip located at the top of cooking compartment
D. Thermostat out of calibration D. Have range inspected by qualied service technician. Replace thermostat manifold assembly
if found to be defective.
