VacPak-It SV158 User manual

11/2019
ITEM DESCRIPTION VOLTAGE WATTAGE AMPS PLUG
SV158 Sous Vide Immersion Circulator (Head Only) 120V 1800W 12.5 Amps 5-15P
SV158KIT Sous Vide Immersion Circulator Head
& 8 Gallon Water Tank 120V 1800W 12.5 Amps 5-15P
Thank you for purchasing this VACPAK-IT equipment. Before operating the equipment,
please carefully read the following operating and safety instructions.
SOUS VIDE
IMMERSION CIRCULATOR

Features ......................................1
Safety Instructions ............................2
Operating Instructions .........................3
Control Panel .................................3
Maintenance Guide ............................4
Troubleshooting...............................4
Warranty .....................................5
More from VACPAK-IT..........................6

1.
FEATURES
CONTROL
PANEL
WATER LEVEL
INDICATORS
PUMP
(INSIDE)
COOLING FAN
(INSIDE)
HEATING ELEMENT
(INSIDE)
ADJUSTABLE
CLAMP

2.
SAFETY INSTRUCTIONS
1. Use only grounded electrical outlets matching the nameplate rated voltage.
2. Have equipment installed by a qualified personnel in accordance with local
codes and ordinances.
3. Use equipment in a flat, level position.
4. DO NOT use a damaged cord or and extension cord with this equipment.
5. DO NOT plug this equipment into a power strip or multi-outlet power cord.
6. Unplug equipment and turn o before cleaning or moving.
7. DO NOT spray controls or outside of equipment with liquids or cleaning agents.
8. DO NOT clean the equipment with steel wool.
9. Keep equipment and power cord away from open flames, electric burners,
or excessive heat.
10. DO NOT operate equipment in public areas and/or around children.
11. DO NOT operate if equipment has been damaged or is malfunctioning in any way.
12. Only use this model for intended purpose.
13. DO NOT use this model to heat oil, grease, or any other liquid besides water.
14. DO NOT put your hands directly in the water.
15. The machine may still be hot to the touch right after use.
To ensure safe operation, carefully read the following statements.
These precautions should be followed at all times. Failure to follow these
precautions could result in injury to yourself and others.
To reduce risk of injury or damage to the equipment:

3.
1. Temperature Display - Shows the current water temperature.
2. Wireless Network Indicator Light (if applicable)
3. Water Heating Indicator Light
4. Water Circulating Indicator Light
5. Temp/Time Button - Press to adjust temperature or time.
6. °C/°F Button - Press to toggle between Celsius and Fahrenheit display.
7. Increase/Decrease Buttons - Press to increase/decrease temperature or time.
8. Set Temperature Display - Shows the desired water temperature.
9. Time Display - Shows remaining heating/holding time.
10. Start/Stop Button - Press to start/stop operation.
11. Power Button - Press to turn the unit on/o.
1
2
7
38
9
10
11
4
6
5
OPERATING INSTRUCTIONS
CONTROL PANEL
1. Select a container for water bath. A water container with a 6" depth is required to use
with this equipment. This unit is designed to heat and circulate up to 8 gallons of water.
2. Attach the circulator head to the container via the adjustable clamp.
Make sure the circulator head is fixed firmly to the container.
3. Fill the container with water until it reaches a level between the MAX and MIN fill lines
on the circulator head.
4. Plug the machine into a grounded electrical outlet matching the nameplate related
voltage. The LCD screen will light up once the machine is plugged in.
5. Adjust and set controls (see below).

Cleaning
Storage
This model is intended for indoor use only at commercial food service establishments.
It is designed to provide precise temperature control of water for closed loop circulation.
To extend the life of this model, please clean every 20 uses, or 100 hours of use.
1. Fill a container with a solution of water and vinegar.
2. Turn the circulator head on and let it circulate water for 20 minutes.
3. Repeat this process with a container full of clean water to rinse.
4. To clean the filter, unplug the machine and allow it to cool down.
Open the machine housing and use a soft brush to remove particles from filter.
1. Store the model in an upright position after use to prevent water from
leaking into the top portion.
2. If liquid gets into the top part of the model, turn the power o and dry
with a clean towel before use.
MAINTENANCE
4.
ISSUE REMEDY
No power
to the unit
• Ensure the machine is properly plugged into a grounded outlet.
• Check the power cord for tears, frays, or other damage.
Do not use machine if the power cord is damaged.
The unit is no
longer heating
• Ensure that the water level is between the MIN and MAX fill lines
marked on the head. If not, allow the unit to cool and add water
until the level reaches between these 2 marks.

5.
EQUIPMENT LIMITED WARRANTY
To Make a Warranty Claim:
For Warranty Inquiries contact the location where you purchased the product:
• WebstaurantStore.com: Contact [email protected]. Please have your order number ready.
• The Restaurant Store: If you purchased this unit from your local store, please contact your store directly.
• TheRestaurantStore.com: Online purchases, call 717-392-7261. Please have your order number ready.
Failure to contact the designated location prior to obtaining equipment service may void your warranty.
VacPak-It makes no other warranties, express or implied, statutory or otherwise, and HEREBY DISCLAIMS ALL
IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND OF FITNESS FOR A
PARTICULAR PURPOSE.
This Limited Warranty does not cover:
• Equipment sold or used outside the Continental United States
• Use of unfiltered water (if applicable)
• VacPak-It has the sole discretion on wearable parts not covered under warranty
• Equipment not purchased directly from an authorized dealer
• Equipment used for residential or other non-commercial purposes
• Equipment that has been altered, modified, or repaired by anyone other than an authorized service agency
• Equipment where the serial number plate has been removed or altered.
• Damage or failure due to improper installation, improper utility connection or supply, and issues resulting from
improper ventilation or airflow.
• Defects and damage due to improper maintenance, wear and tear, misuse, abuse, vandalism, or Act of God.
Any action for breach of this warranty must be commenced within 1 year of the date on which the breach occurred.
No modification of this warranty, or waiver of its terms, shall be eective unless approved in a writing signed by the
parties. The laws of the Commonwealth of Pennsylvania shall govern this warranty and the parties’ rights and duties
under it. VacPak-It shall not under any circumstances be liable for incidental or consequential damages of any kind,
including but not limited to loss of profits.
VacPak-It warrants its equipment to be free from defects in material and workmanship for a period of 1 year. This is the sole
and exclusive warranty made by VacPak-It covering your VacPak-It brand equipment. A claim under this warranty must be
made within 1 year from the date of purchase of the equipment. Only the equipment’s original purchaser may make a claim
under this warranty. VacPak-It reserves the right to approve or deny the repair or replacement of any part or repair request.
The warranty is not transferable. VacPak-It Equipment installed in/on a food truck or trailer will be limited to a period of 30
days from the original date of purchase.
